Downloaded from hlayiso.com GRADE 10 LIFE SCIENCES JUNE EXAM MEMO QUESTION 1 1.1 1.1.1 1.1.2 1.1.3 1.1.4 1.1.5 1.1.6 1.1.7 1.1.8 1.1.9 1.1.10 C B D C B A B A C D [10] 1.2 1 D 2 H 3 E 4 G 5 M 6 I 7 F 8 B 9 L 10 A [10] 1.3.1 Interphase  (1) 1.3.2 Mitosis (1) 1.3.3 A (1) 1.3.4 DNA must replicate so that each daughter cell receives the same DNA as the parent cell and as each other    (2) 1.3.5 D - metaphase (2) 1.3.6 Cytokinesis  (2) [8] 1.4.1 A – Cell wall  B – Channel protein  (2) 1.4.2 Cellulose  (1) 1.4.3 Active transport  movement of ions from a low concentration to a high concentration against the diffusion gradient () which requires energy through a channel protein due to them being too large  (4) [7] 1.5.1 Fatty acids 1.5.2 Sclereids 1.5.3 phospholipids  1.5.4 Endoplasmic reticulum 1.5.5 Ribosomes  [5] QUESTION 2

Downloaded from hlayiso.com 2.1.1 Compound light microscope  (1) 2.1.2 Only use the fine adjustment knob when focussing / do not use the course adjustment knob when focussing. (1) 2.1.3 B - Rotating/revolving nose piece  (2) 2.1.4 - Easier to handle - not as expensive - view living specimens - view in colour  (1) 2.1.5 Guard cell  (1) 2.1.6 Chloroplasts  (1) 2.1.7 - Allows for gaseous exchange, taking in of CO2 which is a requirement for photosynthesis - Allows for transpiration which draws water up from the roots which is a requirement for photosynthesis (4) 2.1.8 XY = 4 cm 5 µm = 1 cm 4  Actualsize   5  20 µm  (3) 1 2.1.9 Drop cover slip at a 450 angle to avoid air bubbles  (1) [15] 2.2.1 Cancerous cells are shed into the bloodstream and lymphatic vessels which helps the spread of cancer to other parts of the body. (1) 2.2.2 Activin B and ALK7  (1 mark for both) (1) 2.2.3 Carbon, Hydrogen, Oxygen, Nitrogen (all or nothing) (1) 2.2.4 Advantage - share enough biological and chemical similarities to be able to see how the cancer would react in our bodies - do not have to do tests on humans  Disadvantage - Animal cruelty - Not human and so may react differently in a human’s body  (Any sensible answer) (2) [5]

Downloaded from hlayiso.com 2.3.1 The process of producing an organism that is genetically identical to the parent organism. (2) 2.3.2 No, the clones will not be exposed to exactly the same environmental conditions / amount of food, exercise as Missy was growing up so they may look slightly differently. (2) 2.3.3 Any body cell is acceptable (no egg/sperm)  (1) 2.3.4 - novelty - cover the cost of the labs, scientists and equipment required for cloning (any sensible answer)  (1) [6] 2.4.1 Cell membrane (1) 2.4.2 Y to X  (1) 2.4.3 It is semi / selectively / differentially permeable.  (1) [3] [30] QUESTION 3 3.1.1 The relative effectiveness in photosynthesis will be the lowest in the green/yellow wavelength (500 – 600 nm) OR The relative effectiveness in photosynthesis will be the highest in violet/blue light (420 – 450 nm) Statement  Both variables (2) 3.1.2 Optimum conditions would be a temperature of 30 0 C and 440 nm wavelength (2) 3.1.3 Heading Size and accuracy Drawing rules 4 correct labels (7) [11] 3.2.1 To investigate whether carbon dioxide is needed for photosynthesis. (2) 3.2.2 To remove CO2 in the part of the experiment that acts as the control. (1) 3.2.3 To destarch the plant, to ensure that starch is absent from the leaf at the beginning of an experiment, so that if any starch is formed, then photosynthesis must have taken place. (2) [5] 3.3.1 A – Mitochondria B – Rough endoplasmic reticulum  (2) 3.3.2 As water moves into the vacuole it swells causing the cytoplasm to push against the cell wall making the cell turgid.  (2) [4]

Downloaded from hlayiso.com QUESTION 4 4.1.1 D  (1) 4.1.2 - Many chloroplasts in each cell for maximum photosynthesis - Closely packed to fit more photosynthetic cells in the tissue - Upright so each cell has direct exposure to sunlight (Must give structure and reason) (2) 4.1.3 - Large, empty lumen for uninterrupted water transportation  - walls thickened with lignin for support.  (1) 4.1.4 Phloem – sieve tube - companion cell (3) 4.1.5 W – many stomata / location of the spongy mesophyll (2) 4.1.6 Cuticle- waxy, waterproof layer on the epidermis (1) [10] 4.2.1 a) W – the walls are evenly thickened with lignin all around the cell (2) b) Z - thin cellulose walls of even thickness (2) c) X – thickened in the corners (unevenly thickened) with cellulose (2) [6] 4.3.1 4 and 6 (1) 4.3.2 Apical meristem (1) 4.3.3 - large, prominent nucleus - thin cell walls - no large vacuoles - no intercellular spaces - dense cytoplasm  (1) 4.3.4 Tips of shoots OR tips of lateral branches  (1) [4] [20] Powered by TCPDF (www.tcpdf.org)
