Module 1: Safety and health in the workshop
TEACHING SAFETY MEASURES
Safety is important in the workshop in order to save time, energy and even
lives.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
GOOD HOUSEKEEPING
Good housekeeping means there is a place for everything, and that
everything is in its place. Good housekeeping is the basis for safe working
conditions.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
ACCIDENTS
An accident can be defined as an unforeseen and uncontrolled event caused
by dangerous actions and dangerous conditions.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
HYGIENE AND SAFETY IN THE WORKSHOP
It is important to ensure that workers work under healthy conditions and the
responsibility for a hygienic workplace lies with employers and employees
alike.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
SAFE HANDLING OF COMPRESSORS
The compressor is driven by an electric motor, therefore all precautions
related to electricity must be taken at all times. The compressor and the
compressed air cylinder form a unit and should be housed in a separate
room.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
SAFE HANDLING OF HYDRAULIC PRESSES AND APPARATUS
The platform on which the workpiece is resting must be rigid, level and at
right angles to the cylinder of the press. To prevent damage to soft material,
the prescribed equipment and supports must be applied.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
HOISTS, JACKS AND TRESTLES
A hoist designed to support the motor vehicle under an axle or other parts of
the chassis should be placed so that the vehicle is raised evenly. Supports of
different lengths are available for this purpose. Before the hoist is operated,
care should be taken to support the mass of the motor vehicle evenly over
the hoist.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
CARE, STORAGE AND SAFE HANDLING OF CUSTOMERS’ VEHICLES
Make sure you return every vehicle you have worked on in a better
mechanical condition and cleaner than when it came into the shop. When
you repair a vehicle, always do the best job you can – a satisfied customer
will bring his or her vehicle to you again.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 1: Safety and health in the workshop (continued)
TOWING A VEHICLE
It is often necessary for you to collect a stationary or damaged vehicle to
bring it to your workshop. All equipment required for towing must be in good
working condition – equipment showing any faults or deficiencies must not
be used.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 2: Workshop measuring tools
TOOLS IN THE MODERN WORKSHOP
Modern workshops increasingly need electronic measuring and diagnostic
equipment to deal with vehicles with many electronic and computerised
systems.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 2: Workshop measuring tools (continued)
BASIC HAND TOOLS
The most common tools are:
• Spanners; • Hacksaws;
• Pliers; • Files;
• Screwdrivers; • Chisels; and
• Hammers; • Centre and prick punches.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 2: Workshop measuring tools (continued)
SPECIAL WORKSHOP TOOLS AND EQUIPMENT
Apart from the large variety of general hand tools, the competent motor
mechanic also requires various special tools, instruments and equipment for
dealing with particular tasks related to motor vehicles. This includes the
torque wrench, brake spring pliers, battery pliers, piston ring compressor,
piston ring spreader, valve spring lifter, vale grinder, and screw cutters.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 2: Workshop measuring tools (continued)
GENERAL TOOLS USED IN A WORKSHOP
This includes but is not limited to:
• Trestles;
• Hydraulic jack;
• Battery charger;
• Manual and electrical hydraulic presses;
• Motor car creeper and tool stand; and
• Ball joint puller.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 2: Workshop measuring tools (continued)
MEASURING AND MARKING INSTRUMENTS
The modern motor car is a precision-made mechanism with extremely fine
tolerances. Even simple measuring tasks and settings such as valve
clearances and backlash must be done with a great deal of precision.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components
THE CYLINDER BLOCK
The cylinder block is the main engine assembly that houses the crankshaft,
the pistons and their connecting rods and is made to accommodate the
forces generated by combustion.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
WATER JACKET
These cylinder blocks are cast with intricate passages, called water jackets,
through which the coolant is circulated by a pump.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
THE CYCLINDER HEAD
The cylinder head serves as a “lid” for the cylinders. When the air-petrol
mixture is compressed in the cylinders and ignited, the resulting pressure is
contained by the cylinder head to force down the pistons.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
THE CRANKSHAFT
The crankshaft is the main moving part of the engine. It is fitted into the
cylinder block (or crankcase) and supported by a range of bearings.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
THE PISTON
The piston and its valves form an air pump that creates a partial vacuum in
the cylinder during the intake (down) stroke. The piston is a hollow cylinder,
open at the bottom. The closed is called the piston crown and forms part of
the combustion chamber.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
PISTON RINGS
There are two types of piston rings: compression and oil control rings. Their
number and arrangement vary from engine to engine, but generally all
compression rings are fitted above the gudgeon pin while oil control rings are
fitted below it.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
THE CAMSHAFT
The main function of the camshaft is to convert the rotary movement of the
crankshaft into the reciprocating movement of the valves and to open the
valves at their pre-determined intervals.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
TIMING (CAMSHAFT) GEARS, CHAINS AND BELTS
Camshafts are commonly driven by one of three arrangements from the front
of the crankshaft – a gear train, chain or a toothed rubber belt. Camshafts
run at half engine speed so the drive has to be stepped down from the
crankshaft by having twice the number of teeth on the crankshaft gear, pulley
or sprocket than on the camshaft.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
VALVE LIFTERS
Valve lifters are used in pushrod (overhead-valve) engines and are designed
to follow the shape of the pear-shaped cam on the camshaft and use this lift
to push down and open a valve.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
PUSHRODS
The pushrod has the simple function of transmitting the reciprocating
movement of the valve lifter to the rocker that opens a valve.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
ROCKERS
The rocker transmits the reciprocating movement of the pushrod to the valve
stem.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
VALVES AND SPRINGS
Four-stroke engines use valve springs to close their valves and to keep them
closed for better sealing to prevent loss of pressure. The valve spring is kept
onto the valve by means of a valve spring retainer and two halfmoon cotters.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
EXHAUST AND INLET MANIFOLDS
The intake manifolds convey the fuel-air mixture from the carburettor or fuel
injection system to the cylinders and help to promote vaporisation of the air-
petrol mixture before admitting it to the cylinders.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
GASKETS AND SEALS
Gaskets are used in assemblies such as gearboxes that are bolted together.
A gasket or seal for an assembly that is not subject to heat can be a simple
thick paper or cork pattern.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
CYLINDER HEAD
Revolving shafts on the inside of an engine that end outside, such as the
crankshaft or wheel bearings, must be sealed against oil loss and dust, and
have seals made of a metal cover with a spring-loaded neoprene rubber ring
that fits tightly around the shaft.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
CARBURETTOR
Carburettors supply the internal combustion engine with an air-fuel mixture
that varies in ratio to suit a range of conditions.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
IGNITION COIL
The ignition coil transforms the 12 volt DC current from the battery to the
high voltage (between 16 000 volts and 22 000 volts) required to create a
timed spark across the spark plug gap that ignites the fuel-air mixture in the
cylinder.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
SPARK PLUGS
Spark plugs are screwed into the combustion chambers of petrol engines
and provide the spark that ignites the mixture towards the end of the
compression stroke.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
DISTRIBUTOR
The distributor collects the high voltage sparks from the coil and conveys it to
the different spark plugs in the correct order and at the right instant during
the ignition cycle.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
STARTER MOTOR
The starter is an electric motor that engages temporarily with the ring gear
around the clutch plate to make the crankshaft rotate fast enough to start the
engine
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
ALTERNATOR
Modern cars use AC alternators instead of the older DC generators to
provide electrical power for charging the car battery.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
BEARINGS AND BUSHES
A modern internal combustion engine uses a variety of plain and ball or roller
bearings as well as bushes to support all the moving parts and reduce play
and friction.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
PISTON RINGS
Bushes are plain one-piece bearings that tend to be longer than plain
bearings. They are made from brass or phosphor bronze, which is porous
and can be impregnated with oil to reduce friction, and are used around
gudgeon pins, for valve guides and in gearboxes.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
FLYWHEEL
Because the internal combustion engine delivers its power in spurts once
every two or four revolutions, it needs a flywheel that can store some of the
energy generated during a power stroke to keep the engine moving during
the other stroke or strokes.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
FUEL PUMPS
The fuel pump is used to supply fuel from the petrol tank to the carburettor or
fuel injector at a pre-set pressure at all engine speeds.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
WATER PUMP
The water pump is mounted at the front of the engine between the engine
block and the radiator, and keeps the coolant circulating from the engine
block and cylinder head and back.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
MATERIALS USED IN MOTOR VEHICLES
The modern motor vehicle uses a wide variety of materials, some known for
thousands of years like iron and copper, some dating from the space age like
plastics and titanium. Iron and steel make up the bulk of the materials used
in motor vehicles because the base metal iron is cheap, tough, easy to
process and turn into a variety of alloys or heat treat for special applications.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 3: Engine components (continued)
PROPERTIES OF MATERIALS
• Tenacity;
• Elasticity;
• Malleability;
• Ductility;
• Plasticity;
• Toughness; and
• Hardness. Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains
THE SINGLE PLATE CLUTCH
Because internal combustion engines deliver most of their torque at higher
revolutions, they need clutches that can be made to slip until the vehicle can
move off. In manual transmissions the clutch must be let out smoothly and
gradually feed in torque until the vehicle is moving fast enough to let the
clutch out completely.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
THE CLUTCH ASSEMBLY
The clutch assembly consists of a series of flat, smooth surfaces that can be
locked together by friction when the clutch pedal is let out. These friction
surfaces are the outside face of the flywheel, the double-sided pressure plate
and finally the clutch plate that is operated by a foot pedal.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
PRESSURE PLATES
There are two types of friction clutches in use: the helical spring-type
pressure plate and the diaphragm spring type.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
THE CLUTCH PLATE
The ideal clutch plate must perform the following functions:
• It must create a firm link between the engine and the gearbox without
slipping;
• Be able to be completely released quickly and easily take up the drive
smoothly without sticking or jerking; and
• Be able to dissipate all the heat created by friction without damage, even
under heavy loads.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
CLUTCH RELEASE MECHANISMS
The linkages between the clutch pedal and the clutch assembly may be
mechanical or hydraulic and some bigger models may have power
assistance. Mechanical linkages must include some form of adjustment to
compensate for wear and maintain the correct free play between the release
bearing and the pressure plate fingers.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
THE CLUTCH RELEASE BEARING
Two types of bearings are used to apply pressure to the pressure plate
fingers and disengage the clutch: the graphite (or carbon) ring and the ball-
bearing types.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
CLUTCH PEDAL FREE PLAY
Clutch free play should be set according to the manufacturer’s instructions –
normally 20 mm movement at the clutch pedal before resistance is felt will be
sufficient.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 4: Drive trains (continued)
CLUTCH PROBLEMS
Modern clutches are robust and give years of use under normal conditions.
When problems do occur they usually take the following forms:
• Slipping clutch;
• Dragging clutch;
• Grabbing clutch; and
• Shuddering clutch.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines
TYPES OF ENGINES
The four-stroke engine is used in the following:
• Motorcars and motorbikes;
• Boats;
• Trucks;
• Lifting equipment;
• Water pumps; and
• Generators. Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE FOUR-STROKE PETROL ENGINE
The engine comprises a cylinder block in which a cylinder is
bored to accommodate the piston and piston rings. A
crankshaft is mounted on one side of the cylinder block,
which is enclosed in an oil pan/ sump. The included space is
called the crankcase. The oil pan contains a specified
quantity of engine lubricating oil. The piston is connected to
the crankshaft by a connecting rod and
Downloaded froma gudgeon pin.
hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE THREE-PORT TWO-STROKE PETROL ENGINE
Two-stroke engines are widely used by motorcycles, lawn mowers and
motorboats.
The construction of this engine is similar to that of the four-stroke petrol
engine. However, the three-port two-stroke engine does not have valves.
Instead there are the intake port, the exhaust port and the transfer port, all of
which are closed and opened by the moving piston.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
ADVANTAGES OF PETROL INJECTION IN COMPARISON TO
CARBURETTORS
• The air fuel mixture may be measured exactly at all engine speeds.
• Ignition knock is improbable.
• Air pollution is reduced.
• More than 100% volumetric efficiency is possible.
• Higher CR’s may be used because of better mixture control.
• Icing of inlet manifold cannot occur
Downloaded as only
from air passes through.
hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
COMPRESSION IGNITION ENGINES (DIESEL ENGINES)
Compression ignition engines operate as a result of fuel burning in the
cylinder and are dependent on the amount of heat generated by the burning
fuel. This heat energy is then converted into useful work.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE FOUR-STROKE C.I. ENGINE
The engine consists mainly of the following components:
• Cylinder; • Main bearings;
• Piston; • Crankshaft timing gear;
• Connecting rod; • Camshaft; and
• A hinge action; • Valve mechanism.
• Crankshaft;
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE TWO-STROKE C.I. ENGINE
There are two basic types of engines:
1. Engines with ports in the bottom end of the cylinder which are used to
scavenge exhaust gases and admit the fresh air charge. (Port-type)
2. Engines where the intake port is in the bottom end of the cylinder and the
exhaust port is in the cylinder head. The closing and opening of the
exhaust port in this case is controlled by poppet valves. (Uniflow-type)
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE PORT-TYPE TWO-STROKE ENGINE
The cylinder is designed with ports at the side of the cylinder, more or less at
the end of the stroke of the piston. The intake ports are designed so that the
fresh air charge is directed in a spiral movement towards the cylinder head.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE ‘UNIFLOW’-TYPE TWO-STROKE ENGINE
The cylinder is designed with intake ports only, which are cut around the
whole bottom end of the cylinder. When the piston is at b.t.c., the ports are
exposed. The cylinder head is equipped with two exhaust ports which are
controlled by poppet valves.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE OPPOSED-PISTON TWO-STROKE DIESEL ENGINE
The two-stroke diesel engine is also used to power large machines and ship
engines. It can be seen as two diesel engines with their cylinder heads
removed, bolted together head to head. The combustion chamber is formed
by the space between the two pistons where the injector is mounted as well.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 5: Heat engines (continued)
THE ROTARY ENGINE
The rotary engine consists of the following main components:
• An oval rotor casing with ports, a water jacket and flat end casings;
• A triangular rotor with curved sides and flat ends;
• An eccentric crankshaft;
• An annular gear inside the rotor that engages with fixed gear on one end
casing; and
• Inlet and exhaust ports and sparkfrom
Downloaded plugs inhlayiso.com
the casing.
www.futuremanagers.com
Module 6: Mounting an engine
POSITIONING AND MOUNTING AND ENGINE
Probably the most common arrangement for passenger vehicles used today
is the front-engine, front-wheel drive (FWD) transverse engine type.
When it comes to commercial vehicles, the front-engine, rear-wheel drive
(RWD) is the rule, while every sports car worthy of the name has a mid-
engine driving the rear wheels, or even all-wheel drive.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 6: Mounting an engine (continued)
MOUNTING AN ENGINE
• Four-point system: The engine is attached to the frame at four different
points. This system is mainly used for heavy vehicles and tractors.
• Three-point system: The engine is attached to the frame at three different
points. This system is used in passenger cars and light motor vehicles.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 6: Mounting an engine (continued)
FRAMES
A clear distinction should be drawn between the A-frame and chassis of a
vehicle as these two concepts are very often interpreted incorrectly. The
chassis of a vehicle includes the front and rear wheel suspension, the
steering system, brake system, engine, gearbox, the drive system and the
frame. The bodywork is excluded.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 6: Mounting an engine (continued)
BEAMS
In order to make the framework of a vehicle as light as possible, various
hollow beam profiles are used for manufacturing these frames. They are
designed to resist bending and flexing. O-beams are often used as cross
members in ladder frames.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems
LUBRICATION
When gases condense after cooling, they become all the types of petroleum
fuels and lubricants as we know them.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
LUBRICANTS
After distillation, the lubricating oil stock contains a number of undesirable
non-lubricating compounds such as gum, tar and wax.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
ENGINE LUBRICATING SYSTEMS
Moving components in an engine are protected by the engine oil, which
prevents metal-to-metal contact by placing a very thin film of oil between
moving surfaces. Supplying enough of the right oil to an engine is important
because without lubrication, moving parts will overheat, seize and fail.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
OIL CONTROL METHODS
There are several basic oil control devices:
• Oil seals and retainers;
• Oil restrictors;
• Gaskets or packing;
• Oil throwers; and
• Oil turbines.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
OIL PRESSURE IN AN ENGINE
In the modern engine it is not only necessary to get the oil between bearing
surfaces, but also to keep it there under pressure so that an oil cushion is
maintained between the surfaces. Oil is necessary to cool friction bearings
by a constant supply of cooler oil. The oil is drawn from the sump by the oil
pump and fed under pressure to the parts.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
ABNORMAL OIL CONSUMPTION
Oil can be lost out of the engine in three ways, namely:
• Burning in the combustion chamber;
• Leaking out pst gaskets and seals in liquid form; and
• Leaking through the breather pipe as a vapour.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
CRANKCASE VENTILATION
The function of crankcase ventilation is to remove harmful evaporates that
contaminate the oil from the crankcase.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
OIL COOLERS
It is necessary to fit oil coolers on some vehicles to prevent harmful rises in
oil temperature during heavy engine running conditions. The oil is circulated
by a pump and passes through the cooler, where heat is extracted on the
heat exchanger principle.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
OIL FILTERS
The function of the oil filter is to trap as much as possible of the larger solid
impurities in circulation with the lubricating oil; the oil filter does not actually
clean the oil.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 7: Lubrication systems (continued)
OIL PUMPS
The oil pump draws oil from the sump and supplies it under considerable
pressure to the different engine components, especially plain bearings such
as the mains big-end and camshaft bearings.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems
TEMPERATURE CONTROL
The internal combustion engine is a heat engine that produces a large
amount of heat while it works, so much that it will destroy itself unless this
heat is absorbed – the function of the cooling system is to remove as much
of this heat from an engine as possible, and fast enough, to keep its
temperature within safe limits and avoid permanent damage.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
DIRECT WATER COOLING
Water cooling without air as a cooling medium is used in marine and water-
pump engines. A positive water pump circulates water from an external
source, which may be a river or the sea, through the water jackets of the
engine and directly back to the source, so the water is not re-circulated.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
DIRECT AIR COOLING (AIR-COOLED)
Large volumes of air must be brought into direct contact with the hot surfaces
of an engine and then removed as quickly and efficiently as possible to keep
it cool. This direct air cooling, or simply air cooling, is well known from its use
in motor cycles and petrol lawn mowers, for instance.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
INDIRECT AIR COOLING (WATER COOLED)
These engines need a complicated system of water jackets cast into the
cylinder block and cylinder head, a water pump, a radiator and its hoses, a
fan and a thermostat, and some way of heating the vehicle’s interior from the
engine coolant.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
RADIATORS
The radiator is the component that exchanges heat between water and air.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
WATER PUMPS
• The positive pump consists of a housing of aluminium alloy or cast iron
containing a centrifugal impeller mounted on a set of bearings.
• The impeller pump acts on the same principle as the positive pump except
that the impeller is inserted directly in the water jacket, while the housing
carrying the shaft bearings with their water seal and the by-pass and inlet
ports is bolted to the engine block.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
THERMOSTAT
It is the function of the thermostat to regulate the cooling system to achieve
quick heating and a constant working temperature.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
THE BYPASS
The bypass system allows the water to re-circulate between the cylinder
head and the cylinder block while the thermostat is closed. The bypass port
connects the water outlet port in the cylinder head with the inlet port of the
water pump.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
WATER DISTRIBUTING TUBES
Special distribution tubes with holes or nozzles are built into water jackets at
suitable spots in order to direct jets of coolant onto these components.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
RADIATOR SHUTTERS
Radiator shutters are usually operated by thermostats, although there are
also manual systems, where a blind is pulled across the radiator opening.
Radiator shutters have failsafe devices that open them to prevent
overheating if the thermostats should fail and there is usually a manual
override as well.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 8: Cooling systems (continued)
OVERHEATING
There are many reasons for an overheating engine, mostly because of
coolant loss in water-cooled engines and failed fans or shrouds in air-cooled
models. Overheating in an engine can cause severe damage – cylinder
heads can warp, pistons can be destroyed by pre-ignition and bearings can
“run”.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 9: Batteries
BATTERIES
The battery stores electricity in the form of chemical energy, which can be
converted back to electricity when needed. The battery loses its chemical
energy when supplying electricity, but it is recharged by the vehicle’s
alternator (or generator) while the engine runs.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
BATTERY CHECKING AND CHARGING
• Electrolyte levels must be checked occasionally and the battery topped up
with distilled water to the specified upper level marked on the case.
• To check the battery charge, the specific gravity of the electrolyte must be
measured and a load test performed. The battery condition can be
determined from the results of both.
• Batteries may need to be charged before putting into a vehicle. There are
two methods,Downloaded
a quick charge or afrom
slow charge.
hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
SULPHATION
Sulphation is the name given to a particular lead sulphate crystal formation
that grows on the plates of a battery, and which adversely affects the
electrical performance of the cells.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
TESTING A BATTERY WITH A V METER
A battery voltage test is the only test that can be used on maintenance-free
batteries.
• Connect the meter across the battery terminals and turn on the car’s
headlights or heater fan to provide a light load.
• Take a reading with the meter.
• A well-charged battery should register over 12 V, but if the meter reads
about 11,5 V, Downloaded
the battery is not necessarily defective.
from hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
CARE AND MAINTENANCE OF THE BATTERY
Battery maintenance should be done periodically during engine tune-ups,
lubrication services, or at any time when symptoms indicate battery
problems.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
REMOVING A BATTERY
• Remove the cable carefully so that you do not damage the terminals.
• Loosen the battery nut, open up the connector’s open end sufficiently and
pull the cable straight up.
• Loosen the battery clamp nut, remove the bolt, remove the clamp, and lift
the battery case.
• Lift the battery case straight up - tilting it to one side may allow the
electrolyte to Downloaded
spill out. from hlayiso.com
www.futuremanagers.com
Module 9: Batteries (continued)
CONNECTING BATTERIES IN SERIES OR PARALLEL
• Series circuit: When two 12V batteries are connected in series, they form
a 24V battery that has the capacity for starting heavy-duty vehicles
equipped with a 24V system.
• Parallel circuit: When two 12V batteries are connected in parallel, they
form a 12V battery with more power, greater cranking ability and a longer
useful life than a single 12V battery.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres
TYPES OF WHEELS AND RIMS
• Disc wheels;
• Pressed-steel disc wheels;
• Cast light-alloy disc wheels; and
• Single-piece rim wheels.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres (continued)
TYRES AND TUBES
The modern car tyre is a complicated structure, designed to provide all the
features motorists demand, such as long life, good braking and road holding
and comfort.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres (continued)
TUBES TYRES AND TUBELESS TYRES
A tyre with a tube has a separate rubber inner tube to retain pressurised air
inside the tyre. The tyre valve, which protrudes through a hole in the wheel
rim, is bonded to the inner tube. Tubed tyres are being replaced by tubeless
tyres as tyre designs progress.
The tubeless tyre has no inner tube. The pressurised air is held in by an
inner liner, a specially- formulated thick rubber lining with high sealing
effectiveness. Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres (continued)
TYRE PRESSURES AND LOADS
It is important to check the pressure of the tyre while the tyre is cold. If a tyre
is checked when hot and the pressure is found to be greater than the
manufacturer’s specifications, air should not be let out (‘bled’) from the tyre
because if this is done, the ‘cold’ pressure will be less and the tyre will be
under-inflated when it cools down.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres (continued)
INFLATION AND TYRE WEAR
Although tyres are made up of more or less airtight materials, they still allow
minute quantities of air to leak over time. Tyre pressures must therefore be
checked regularly and adjusted to the specified pressure.
Downloaded from hlayiso.com
www.futuremanagers.com
Module 10: Wheels and tyres (continued)
MATCHING TYRES
A dual-wheel arrangement: A tandem-wheel arrangement:
Downloaded from hlayiso.com
www.futuremanagers.com
Study this subject
Notes, quizzes and topic questions for this subject.
Recommended for this subject
More papers and memos for this grade and subject.
