© Lesson\videos for every section of these SmartPrep theory summaries available on www.-scienceclinic.co.za
VIDEO LESSONS! We have free video lessons for every topic in this book! These videos can only be accessed via Science Clinic's website - follow these steps to access this amazing resource! DOWNLOAD A BOOK Visit our website to download a SmartPrep book. We'll send you an email with download links. VIDEOS WEBPAGE Go to our Videos webpage. Log in with the email address that you used to download a book. SELECT YOUR TOPIC From your videos page, select a topic. You'll be redirected to a playlist with video lessons. ABOUT OUR SMARTPREP BOOKS Our SmartPrep books provide crystal-clear summaries of the essential theory for Grade 8-12 Core Mathematics and Grade 10-12 Physical Science. Our books are available in English and Afrikaans. COPYRIGHT NOTICE AND LICENSE The content in this SmartPrep Book is the original work of Science Clinic (Pty) Ltd. You may distribute this material, provided that you adhere to the conditions in our copyright notice and license: ¢ If you copy and distribute this book electronically or in paper form, you must keep this copyright notice intact. ¢ If you use questions or syllabus summaries from this book, you must acknowledge the author. ¢ This Smart Prep Book is meant for the benefit of the community and you may not use or distribute it for commercial purposes. * You may not broadcast, publicly perform, adapt, transform, remix, add on to this book and distribute it on your own terms. ° By exercising any of the rights to this Smart Prep Book, you accept and agree to the terms and conditions of the license provided on this link: CONTENT ACKNOWLEDGEMENT Thank you to all the amazing people involved in the production, translation and moderation of this book: R_ Bartholomew, L Couperthwaite, N Cullinan, W Cloete, C de Beer, S Dippenaar, T Fairless, | Govender, C Hare, L Kroukamp, R Lodge, K Munnik, C Orchison, M Peyper, S Pienaar, Y Patterson, R Ramsugit, S Roberts, C Steyn, K Storm, S Sapsford, X Sithenjwa, A Theron, C Visser, B Ward QD ww sciencectinie.coza © exciencectinic EB ew acodook.comisciencectiniesa
TABLE OF CONTENTS CORE THEORY SUMMARIES Physics Physics Data Sheet 1 Pulses and Waves 2 Sound & Electromagnetic radiation 6 Magnetism 10 Electrostatics 11 Electricity 12 Vectors and Scalars 15 Motion in 1D 16 Energy 23 Chemistry Chemistry Data Sheet 24 Classification of Matter 26 Names and Formulae 28 Kinetic Theory of Matter 30 The Atom 31 The Periodic Table 35 Chemical Bonding 37 Physical and Chemical Change 40 Reactions in Aqueous Solutions 42 Quantitative Aspects of Chemical Change 45 Hydrosphere 49 www
Physics (fw). scienceclinic.co.za © 2022@.:
Information sheets – Paper 1 (Physics) TABLE 1: PHYSICAL CONSTANTS/TABEL 1: FISIESE KONSTANTES NAME/NAAM SYMBOL/SIMBOOL VALUE/WAARDE Acceleration due to gravity g 9,8 m·s-2 Swaartekragversnelling Speed of light in a vacuum c 3,0 x 108 m·s-1 Spoed van lig in 'n vakuum Planck's constant h 6,63 x 10-34 J·s Planck se konstante Charge on electron e -1,6 x 10-19 C Lading op elektron Electron mass me 9,11 x 10-31 kg Elektronmassa TABLE 2: FORMULAE/TABEL 2: FORMULES MOTION/BEWEGING v f = v i + a Δt Δx = v i Δt + 21 aΔt 2 ⎛ v + vi ⎞ 2 2 v f = v i + 2aΔx Δx = ⎜ f ⎟ Δt ⎝ 2 ⎠ WORK, ENERGY AND POWER/ARBEID, ENERGIE EN DRYWING 1 1 U = mgh or/of EP = mgh K= mv 2 or/of E k = mv 2 2 2 WAVES, SOUND AND LIGHT/GOLWE, KLANK EN LIG 1 v=fλ T= f c E = hf or/of E = h λ ELECTRIC CIRCUITS/ELEKTRIESE STROOMBANE 1 1 1 Q = I Δt = + + ... R p R1 R 2 W R s = R1 + R 2 + ... V= Q
Grade 10 Science Essentials Transverse Pulses SCIENCE CLINIC 2022 © Pulse: A single disturbance in a medium. INTERFERENCE OF PULSES Transverse pulse: A pulse in which the particles of the medium move at Interference: The overlapping of two pulses when they coincide. They meet at the same point at the same time. right angles to the direction of motion of the pulse. Superposition: The algebraic sum of the amplitudes of two pulses that occupy the same space at the same time. Constructive interference: The phenomenon where the crest of one pulse overlaps with the crest of another to produce a pulse of increased amplitude. Destructive interference: The phenomenon where the crest of one pulse overlaps with the trough of another, resulting in a pulse of reduced amplitude. When two pulses meet: CONSTRUCTIVE INTERFERENCE Before During After 2a The particles in the rope move vertically up and down as the pulse moves to a a a a the right (particles are moving perpendicular to the direction of movement of the pulse). X Y X+Y Y X Amplitude X Y X+Y Y X (a) a a a a Rest posi)on Pulse length 2a Rest position: The position from which all particles start from and return to after a pulse or wave has passed. Amplitude: The maximum displacement of particles from the rest position. Pulse length: The distance between the start and end of a pulse. DESTRUCTIVE INTERFERENCE Before During After A pulse moves through a medium at a certain speed (v): distance (m) speed of pulse (m ⋅ s− 1) a Y a X-Y Y D v= X a a X Δt time (s) EXAMPLE: A pulse travels a distance of 300m in 2 minutes. Determine the speed of the pulse. D v= a Y X-Y Y a Δt 300 X b-a X v= b b 120 v = 2,5 m ⋅ s− 1 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 2
Grade 10 Science Essentials Transverse Waves SCIENCE CLINIC 2022 © FORMATION OF TRANSVERSE WAVES CALCULATIONS Each disturbance in a medium creates a transverse pulse. Many disturbances of Frequency (f) Period (T) Wave speed (v) transverse pulses repeated at regular intervals creates a transverse wave. Frequency: The number of waves per Period: The time taken for one com- Wave Speed: The distance travelled by second. plete wave. a point on a wave per unit time. Hand moves up → back to rest position, and then down → back to rest position. Unit: Hz (hertz) Unit: s (seconds) speed (m ⋅ s− 1) distance (m) D v= time (s) Δt Example: Calculate the speed of a Rest posi)on wave that travels 50m in 7s. number of waves D frequency = total time v= total time period = Δt number of waves 50 v= = 7,14 m ⋅ s− 1 Example: Example: 7 5 waves pass a point in 4 s, calcu- 5 waves pass a point in 4 s, calcu- Wave speed (v) late the frequency of the waves. late the period of the waves. This motion continues at regular intervals to form a transverse wave. Wave Speed: The distance travelled by a number of waves total time frequency = period = point on a wave per unit time. total time number of waves frequency (Hz) Transverse wave: A wave in which the particles of the medium vibrate at right 5 4 T= = 1,25 Hz T= = 0,8 s angles to the direction of motion of the wave. A transverse wave is a succession of 4 5 v = fλ wavelength (m) transverse pulses. speed (m ⋅ s− 1) RELATIONSHIP BETWEEN FREQUENCY AND PERIOD Example: Calculate the speed of a wave with a frequency of 28 Hz and a f- frequency (Hz) wavelength of 5 mm. 1 1 T= OR f= v = fλ f T T- period (s) v = (28)(5 × 10− 3) v = 0,14 m ⋅ s− 1 ONE TRANSVERSE WAVE MULTIPLE TRANSVERSE WAVES + Crest + IN phase: Distance (m) λ A–E B–F Amplitude A–I (a) B F Distance (m) D–H C λ G I Rest posi9on Distance (m) Wavelength (λ) or Time (s) A λ E Distance (m) TOTALLY OUT of D H or Time (s) phase: A–C (a) λ B–D - A-G D–F Trough Points in phase: Two points in phase are separated by a whole number (1; 2; 3; …) multiple PARTIALY OUT of - of completed wavelengths. Points in phase follow the exact same path (have identical motion). phase: Amplitude (a): the maximum displacement of particles from the rest position. Points totally out of phase: two points following exactly the opposite path. A–B Wavelength (λ): the distance between two consecutive points in phase. Points partially out of phase: Points that are not separated by a whole number multiple of B–E Crest: the highest point (peak) on a wave. completed wavelengths. Two points which follow different paths. A-F Trough: the lowest point on a wave. D–E Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 3
Grade 10 Science Essentials Longitudinal Waves SCIENCE CLINIC 2022 © When a series of forwards and backwards move- ments are made to a spring in consecutive inter- vals it creates a longitudinal wave. IN phase: When particles are pushed closer together a com- A–C pression is formed and when particles are drawn ion c3 n ion c3 n ion C–E pr pr pr apart a rarefaction is formed. es s re o es s re o es s B–D fa fa Wavelength is represented by the distance be- Co m Ra Co m Ra m Co A–E tween consecutive compressions or consecutive rarefactions. Longitudinal wave: a wave in which the parti- TOTALLY OUT cles of the medium vibrate parallel to the direc- A B C D E of phase: tion of motion of wave. λ A–B Compression: A region of high pressure in a B–C longitudinal wave. λ C–D Rarefaction: A region of low pressure in a longi- A–D tudinal wave. λ Rarefaction: The maximum displacement of a particle from its rest position. CALCULATIONS Frequency (Hz) Period (T) Wave speed (v) Frequency: the number of waves that pass a point in one second. Period: the time taken for one wave to pass a point. Wave Speed: the distance a wave travels in one second. Unit: Hz (hertz) Unit: s (seconds). speed (m ⋅ s− 1) distance (m) D frequency = number of waves frequency = number of waves v= total time total time Δt time (s) Example: Calculate the speed of a wave that travels 60 km in 5 min. Example: Example: D 8 waves pass a point in 3 s, calculate the frequency of the v = 8 waves pass a point in 3 s, calculate the period of the waves. Δt waves. 6000 v = total time 300 number of waves period = frequency = number of waves v = 20m ⋅ s− 1 total time 3 8 f = f = 8 3 f = 0,38 s Wave equation f = 2,67 Hz frequency (Hz) Relationship between frequency and period v = fλ wavelength (m) Example: Example: speed (m ⋅ s− 1) 1 1 Determine the period of a wave Determine the frequency of a T= OR f= that has a frequency of 75 Hz wave that has a period of 0,3 s Example: f T Determine the speed of a wave with a 20 mm wavelength and a 1 1 frequency of 600 Hz. T = f = f T v = fλ f- Frequency (Hz) 1 1 T = 75 f = 0,3 v = (600)(20 × 10− 3) T- period (s) T = 0,013 s f = 3,33 Hz v = 12 m ⋅ s− 1 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 4
Grade 10 Science Essentials Pulses and Waves- The Essentials SCIENCE CLINIC 2022 © A pulse is a single disturbance that is propagated from a source through a medium. A wave is a repetition of pulses at regular intervals. TRANSVERSE LONGITUDINAL Longitudinal pulse: a pulse in which the particles of the medium move parallel to the direction of Transverse pulse: a pulse in which the particles of the medium move perpendicular to the direction of movement of the pulse. propagation of the pulse. ion pres s m Co Amplitude (a) Rest posi)on Pulse length A transverse wave is a succession of transverse pulses, eg water waves. + Crest A longitudinal wave is a succession of longitudinal pulses. e.g. sound waves Distance (m) ion n ion n ion Amplitude pres s c3 o pres s c3 o pres s (a) Co m Ra refa Co m Ra refa m Co Rest posi9on Distance (m) Wavelength (λ) or Time (s) A B C D E (a) λ λ λ Trough - Frequency(f): the number of waves per second. 1 f = T Superposition: The algebraic sum of the amplitudes of two pulses that oc- cupy the same space at the same time. Period(T): the time taken for one complete wave. Unit: s (seconds). Constructive interference: The phenomenon where the crest of one pulse overlaps with the crest of another to produce a pulse of increased amplitude. 1 Destructive interference: The phenomenon where the crest of one pulse T = f overlaps with the trough of another, resulting in a pulse of reduced amplitude Wavelength(λ): the distance between two consecutive points in phase. Wave speed (v): The speed of a wave through the medium. Amplitude: the maximum displacement of a particle from the rest position. v = fλ Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 5
Grade 10 Science Essentials Sound SCIENCE CLINIC 2022 © SOUND WAVES WAVE PROPERTIES & SOUND Sound is created by vibrations in a medium in the direction of propagation (longitudinal wave). The vibrations cause regular varia- FREQUENCY- What the human ear perceives as pitch. tion in pressure in the medium. Measured in hertz (Hz) Pitch is directly proportional to frequency Sound waves are 3D longitudinal waves that travel through solids, • A high pitch = high frequency. liquids and gases but not through a vacuum → a medium is neces- (i.e. brakes of a car squealing) sary for the propagation of sound. The denser the medium, the • A low pitch = low frequency. greater the speed of sound through that medium. (i.e. a bass guitar) A loudspeaker has a paper cone which is able to move back and AMPLITUDE- what the human ear perceives as volume (loudness). forth, producing a series of compressions and rarefactions through Measured in decibels (dB). the air. The small changes in pressure are detected by the ear and Loudness is directly proportional to amplitude we perceive this as sound. The waves move away from the • A high volume = large amplitude. speaker in 3 dimensions getting weaker the further they travel. • A low volume = small amplitude. The amplitude diminishes and the loudness decreases. ULTRASOUND ECHOES EXAMPLE: The time taken for an echo to be heard by a listener on a ship is meas- • Humans can hear sounds between 20 Hz and 20 kHz. Sound waves are reflected by large hard flat surfaces such as build- ured and is found to be 0,8 s. The speed of sound in water is 1480 • Ultrasound Refers to sound waves of a higher frequency than we ings walls and cliffs. m·s−1 . Determine the depth of the water at this point. can hear. (20 kHz to 100 kHz) The reflection of the sound wave is known as an echo. An echo D v = Δt Uses can be used to calculate unknown distances. D •Treatment of sports injuries: waves are fed through the skin to 1480 = 0,8 increase blood flow to the injured area. REMEMBER: D = (1480)(0,8) When a wave reflects/echoes, the wave had to travel to the object D = 1184 m •Imaging in pregnancy: When and back. It has therefore travelled double the distance between an ultrasound wave encounters a the source and the reflection surface. The sound has to travel to the bottom and then reflect back to the boundary in a medium, part of ship at the surface. the wave is reflected, part ab- sorbed and part is transmitted SOURCE Source depth = D through the boundary. The re- sound 2 flected waves are detected in the 1184 depth = 2 same way as echoes and can be depth = 592 m used to form an image (sonar imaging). http://en.wikipedia.org/wiki/Ultrasound#/media/File:CRL_Crown_ rump_lengh_12_weeks_ecografia_Dr._Wolfgang_Moroder.jpg EXAMPLE: A man stands 250 m from a wall and hears the echo of his gunshot Using sonar can produce a safe method of early diagnosis of fetal after 1,5 s. Calculate the velocity of sound under the circumstances. conditions and early treatment can be implemented. LISTENER Echo distance traveled by sound = 2 × 250 •Bats: use ultrasound to locate insects and to navigate in the dark. = 500 m d D v = Δt 500 Boats: use sonar to v = 1,5 locate fish and measure the depth of the v = 333,33 m ⋅ s− 1 Echo Sound ocean. ∴ speed of sound = 333,33 m ⋅ s− 1 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 6
Grade 10 Science Essentials Electromagnetic Radiation SCIENCE CLINIC 2022 © Electromagnetic radiation behaves like a WAVE PARTICLE when it travels when it interacts with other materials WAVE NATURE OF ELECTROMAGNETIC RADIATION PARTICLE NATURE OF ELECTROMAGNETIC RADIATION • Accelerating charges are the source of all Electromagnetic Radiation. • The accelerating charges create a constantly changing electric field which travels away from the source • Electromagnetic radiation transfers energy to other matter in “packets” called photons. in 3 dimensions. The continuously changing electric field then induces a changing magnetic field that is • Photons have a set amount of energy → called a quantum. perpendicular to the electric field.The changing magnetic field in turn produces an electric field. • The amount of energy is directly proportional to the penetrating ability of the specific EM-radiation. • A Photon is a quantum of EM radiation (which carries a set amount of energy) Electromagnetic waves are created by oscillating magnetic and electric fields which move at right angles to each other and to the direction of the propagation of the wave. Energy of a photon can be calculated using the formula: Continuously Continuously Electromag- energy (J) frequency (Hz) Accelerating produce which then a… changing electric changing magnetic netic wave is charges induces field field at 90⁰ created E= hf Electric field Planck's constant (6,63 × 10− 34 ) Direc/on of Magne/c propaga/on field Planck's constant (6,63 × 10− 34 ) energy (J) hc speed of light (3 × 108 m ⋅ s− 1) E= λ wavelength (λ) WAVE EQUATION (EM) EXAMPLE: EXAMPLE: EXAMPLE: The wave is propagated at a speed of 3×108 m·s−1. Determine the wavelength of ultraviolet waves Calculate the energy of a microwave with a fre- Determine the energy of gamma ray with a wave- This is called c (speed of light). with a frequency of 1,6 × 1016 Hz quency of 4,5 × 1010 Hz. length of 4 × 10− 14 m. All electromagnetic waves travel at the speed of hc E = hf E = c = fλ λ light. E = (6,63 × 10− 34 )(4,5 × 10− 10 ) (6,63 × 10− 34 )(3 × 108 ) 3 × 108 = (1,6 × 1016 )λ E = wave speed (m ⋅ s− 1) wavelength (m) E = 2,98 × 10− 43 J (4,5 × 10− 14 ) λ = 1,88 × 10− 8 m EXAMPLE: E = 4,42 × 10− 12 J Determine the frequency of a radio wave with a c = fλ wavelength of 300 m PENETRATING ABILITY The penetrating ability of a wave refers to its ability to penetrating ability α Energy c = fλ 3 × 108 = f(300) move through matter. frequency (Hz) penetrating ability α Frequency f = 1 × 106 m The higher the energy, the greater the penetrating ability. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 7
Grade 10 Science Essentials Electromagnetic Radiation- Spectrum SCIENCE CLINIC 2022 © INCREASING FREQUENCY INCREASING WAVE ENERGY INCREASING WAVELENGTH Visible light Infrared Ultraviolet light EM Radiation: Radio waves Microwaves radiation (IR) (UV) X-rays Gamma rays R O Y G B I V Frequency (Hz): 1 x 106 1 x 1010 1 x 1012 4 x 1014 to 7 x 1014 1 x 1016 1 x 1019 1 x 1022 Wavelength (m): 1 x 102 1 x 10-2 1 x 10-4 7 x 10-9 to 4 x 10-9 1 x 10-8 1 x 10-10 1 x 10-14 Radio and TV Telephone and Remote controls; Objects reflect, refract Light bulbs; x-rays; CT scans; Radiation of broadcasts; radio cell phone optical fibers or transmit light that sterilization security scans cancer telescopes connections; we are able to see; Advantages: communication photosynthesis satellites; microwave ovens; radar systems Damage to eyes and Damage to skin Damage to tissue; skin and underlying nuclear radiation Disadvantages: tissue Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 8
Grade 10 Science Essentials Sound and EM Waves-The Essentials SCIENCE CLINIC 2022 © Sound EM Radiation •Sound waves are created by vibrations in a medium. • Accelerating charges are the source of all Electromagnetic Radiation. • Propagates as electric and magnetic fields which are perpendicular to each other. •The speed of sound in air = 340 m·s-1 • The wave is propagated at a speed of 3x108 m.s-1 in a vacuum. This is called c (speed of light) • Does not need a medium to propagate through; can travel through a vacuum. •Sound is a longitudinal wave that travels through solids, liquids and gases but not through a vacuum. • Electromagnetic radiation behaves like a transverse wave when it propagates. • Electromagnetic radiation behaves like a particle when it interacts with other materials Frequency: Amplitude: What the human ear perceives as pitch. What the human ear perceives as volume. Measured in decibels (dB). WAVE NATURE PARTICLE NATURE •A high pitch = high frequency. (I.e. brakes of a car squealing) •A high volume = large amplitude. wave speed (m ⋅ s− 1) wavelength (m) • Electromagnetic radiation transfers energy in •A low pitch = low frequency. •A low volume = small amplitude. “packets” called photons (I.e. a bass guitar) c = fλ Photon: quanta (energy packets) that transfer energy to particles of matter frequency (Hz) • Energy of a photon can be calculated using: ECHOES energy (J) frequency (Hz) Sound waves are reflected by large hard flat surfaces such as buildings walls and cliffs. The reflection of As the frequency increases, the wavelength the sound wave is known as an echo. An echo can be used to calculate unknown distances. decreases. E= hf In any given medium, the speed remains con- SOURCE Source stant. Planck′s constant (6,63 × 10− 34 ) sound Electromagnetic Spectrum Planck′s constant (6,63 × 10− 34 ) Waves hc speed of light (3 × 108 m ⋅ s− 1) f λ E= Echo Radiowaves λ wavelength (λ) LISTENER Microwaves energy (J) Infrared d Visible light In the picture: Ultraviolet The greater the energy of a photon, the higher distance to wall and back = v ×t its frequency and its penetrating ability (and the 2D = v ×t X-Rays smaller/ shorter the wavelength) Gamma Rays where v is the speed of sound in air; v = 340 m ⋅ s− 1 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 9
Grade 10 Science Essentials Magnetism SCIENCE CLINIC 2022 © Magnetic field: region in space where another magnet or ferromagnetic material will experience a non-contact force Earth’s Magnetic Field Non-contact force: A force exerted on an object without touching the object. The Earth behaves as if it has a giant bar magnet running through it, with its mag- Magnet: an object with a pair of opposite poles, called north and south netic field looping around the earth Magnets can be made from ferromagnetic materials; materials which are strongly attracted by magnets and are easily mag- The arrow of the compass is the North pole of the compass, and points towards mag- netised. Common ferromagnetic materials include iron, cobalt, nickel and their alloys. netic North Pole of the Earth. When two magnets are brought close to each other: In reality, the North pole of the Earth is actually the South pole of the imaginary mag- ~ Like poles → REPEL each other net through the Earth. ~ Unlike poles → ATTRACT each other The point in the Northern Hemisphere where the Earth’s axis meets the surface of the Earth is the geographical or true North Pole. A compass will not point to this, but Even if a magnet is cut into little pieces it will form smaller magnets, each with their own north and south poles rather to the magnetic North Pole – which is actually the South pole of the imaginary magnet through Earth. The angle between the true North Pole and the magnetic North Pole is called the an- gle of declination. N S NS N S N S Geographical north pole: Point in the northern hemisphere where the rotation axis of the earth meets the surface. Magnetic north pole: The Point where the magnetic field lines of the earth enters • Magnetic field lines are imaginary lines around a magnet indicating the direction and the strength of the magnetic field the earth.It is the direction in which surrounding the magnet (iron filings on paper can be used to indicate the field lines) The field lines occur inside the magnet and 3 dimensionally outside it. They come out of the magnet near the north pole and enter near the south pole again forming a loop. Magne)c North Pole Geographical Bar magnet Magne&c North Pole Geographical North Pole Properties of magnetic field Other “fields” in physics North Pole Angle of lines Magnetic field declina&on • Imaginary lines Area in which a magnetic material S • Continuous experiences a magnetic force S • 3 dimensional Electric field Area in which an electric charge N S • Never cross or touch N • Arrows indicate the direction experiences an electric force Gravitational field Geographical N of the field (N to S) South Pole • Are more concentrated at the Area in which a mass experiences poles where field is stronger a gravitational force Magne)c South Pole Attraction between unlike poles Repulsion between like poles Magnetic Phenomena The sun releases particles (mainly electrons and protons) which travel outwards in all directions at speeds of up to 900 m.s⁻¹. More particles are released during a solar storm called a coronal mass ejection. When these particles come close to the Earth, the Magnetosphere protects the Earth by deflecting most of the particles, however some penetrate the Magneto- N S N S N S S N sphere and are pulled towards our North and South Poles. They enter the upper atmosphere at high speed and collide with nitrogen and oxygen molecules caus- ing them to glow with different colours. These are known as the Aurora Borealis (Northern lights) and Aurora Australis (Southern lights). Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 10
Grade 10 Science Essentials Electrostatics SCIENCE CLINIC 2022 © • All materials contain positive charges (pro- Methods by which a neutral object can become charged tons) and negative charges (electrons) Friction Contact Induction • A neutral object has an equal number of • Also known as tribo-electric charging When a charged conductor touches an identi- A method of charging whereby the objects do not touch protons and electrons and has no net • Rub two objects together such as a glass rod and cal neutral conductor, electrons are trans- one another. Neutral electroscope is charged by induction. charge. a woolen cloth. Electrons are transferred from one ferred to make the charge on the conductors • A positively charged object has lost elec- object to the other (this depends on which materials equal. Temporary charge Posi%ewe Tydelike lading trons (electron deficient) Positive rod are used) staaf(polarized)+ + • A negatively charged object has gained • The one object loses electrons and the other gains Positive conductor touches a neutral conduc- + + Neutral Neutraal + + electrons (excess of electrons) + + them tor → negative charges are transferred from + -+ -+ -+ - - - - - - - Electroscope is • A charged object can also be attracted to a neutral conductor because of the move- Glass rod and woolen cloth neutral to positive charge - + + polarized with 3e¯ 5e¯ 1e¯ 7e¯ + + ment of charges in the conductor • A charged object can also be attracted to 3p⁺ 5p⁺ 3p⁺ 5p⁺ Transfers nega5ve - -+ Polarisation+ + the top negatively charged and + + an insulator because of the movement of Fric-on -1,4C charge - - + the bottom positively charged polarised molecules present in the insula- e¯ 0C tor +2,8C neutral +1,4C +1,4C A positive rod is e⁻ are attracted to the posi- • Charged objects exert forces on each brought close to a tive rod. Positively charged other when brought close together touch leaves repel each other neutral electroscope • Like charges exert REPULSIVE forces on neutral neutral Posi-vely Nega-vely Nega%ewe Nega%ewe each other charged charged Negative conductor touches a neutral conduc- Negative Nega%ewe - - Semi-permanent Semi-permanente Semi-permanente - --- Semi-permanente lading- • Opposite charges exert ATTRACTIVE (e¯ deficient) (e¯ excess) tor → negative charges are transferred from Neutral staaf rodstaaf staaf- - - - charge ladinglading - --- Neutraal Neutraal - Neutraal - - - - Nega%ewe - - - -- forces on each other PVC rod and woolen cloth: negative to neutral charge + - ++ --+ +- --+ - --+ - +- - staaf + + + + - + + +-+++++++ ++ ++ + lading Semi-permanente 4e¯ 5e¯ 7e¯ 2e¯ - - -Neutraal - - - - + + ++++++ + + + - 4p⁺ 5p⁺ 4p⁺ 5p⁺ QUANTISATION OF CHARGE Electroscope is + -+ with- + ++ +- +++ +- The charge on a single electron is Transfers nega5ve charge - --+ - -polarized - - + and the e¯ e¯++ ++++ +++++ + the top positively q e = − 1,6 × 10− 19 C Fric-on + + + charged e¯ -2,3C 0C - - -- bottom + -+ -negatively -charged- + e¯ + + + + -4,6C -2,3C -2,3C + + Principle of charge quantisation: all charges in the universe consist of an integer neutral - - e¯ + touch A negative rod is brought Electroscope is earthed allowing multiple of the charge of an electron: Nega-vely Posi-vely neutral neutral close to a neutral electro- extra e-s to come towards the rod. A charge of e− ( − 1,6 × 10− 19 ) charged charged scope. The e-s are repelled. semi-permanent charge is created. (e¯ excess) (e¯ deficient) charge (C) Q = nqe PRINCIPLE OF CONSERVATION OF CHARGE Principle of conservation of charge: the net charge of an isolated system remains constant during any physical process. Eg. When identical objects with differ- ent charges touch, charges will be transferred between conductors. The two conductors will then have equal charge. number of electrons EXAMPLE: Two identical charges on insulated stands, +5 mC and -9 mC respectively, touch and move apart again. Determine (a) the new charge on each, (b) the Examples: amount of charge transferred and (c) the amount of electrons transferred. Calculate the number of electrons gained or a) New charge on each: Amount of charge transferred: c) Number of electrons transferred: lost by (a) +4,5 nC and (b)-9 µC Q1 + Q 2 Q = nq e Q = nq e Q new = ΔQ = Qf − Qi ΔQ = Q f − Q i 2 7 × 10− 3 = n(− 1,6 × 10− 19 ) + 4,5 × 10− 9 = n(− 1,6 × 10− 19 ) (+ 5 × 10− 3) + (− 9 × 10− 3) Q new = ΔQ = (− 2 × 10− 3) − (+ 5 × 10− 3) n = 4,38 × 1016 n = − 2,81 × 1010 2 Q new = − 2 × 10− 3 C each ΔQ = − 7 × 10− 3 C ∴n = 4,38 × 1016 e− ∴ = 2,81 × 1010 electrons lost OR OR Charge new original Q = nq e charge ΔQ = Q f − Q i Q = nq e transferred charge − 9 × 10− 6 = n(− 1,6 × 10− 19 ) (C) on before ΔQ = (− 2 × 10− 3) − (− 9 × 10− 3) − 7 × 10− 3 = n(− 1,6 × 10− 19 ) each contact n = 5,63 × 1013 electrons gained ΔQ = − 7 × 10− 3 C n = 4,38 × 1016 e− (you can use either of the original charges in this step) Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 11
Grade 10 Science Essentials Electricity SCIENCE CLINIC 2022 © Electricity is the process of giving energy to a charge and then using that energy A torch is an example of a simple circuit. The arrows indicate the flow of conven- to do work. The most basic circuit is made of a POWER SOURCE, a LOAD and the The POWER SOURCE gives elec- tional current. conducting wires carrying the charge around the circuit. trical energy to the charge. Some examples are generators, Conductor takes energized batteries, photovoltaic cells. charge to load The POWER SOURCE The LOAD is a de- Cell gives electrical energy vice that uses the (Chemical Energy into to the charge. energy of a charge. Light Bulb Electrical Energy) The LOAD is a device which (Electrical Energy dissipates/uses the energy. into Light Energy) Some examples are resistors, light A battery goes “flat” when all of the stored chemical energy in the battery has bulbs, motors, speakers, chargers. been converted to electrical energy. Conductor returns charge to power The electrical energy is converted into other forms: heat, light, kinetic, chemical source to get more energy CURRENT is the rate of flow of charge. POTENTIAL DIFFERENCE (p.d.) across the ends of a conductor is RESISTANCE & OHM’S LAW: Opposition to the flow of electric current. the energy transferred per unit electric charge that flows The greater the potential difference across Q through it. the ends of a particular conductor, the I= greater the current in it. In a metal conduc- t W tor, the charge carriers are electrons. The I is the current strength, Q is the charge in coulombs and t is V= the time in seconds. The SI unit of current is the ampere (A). Q valence electrons of the metal atoms swarm Typical values for electric current: around randomly in between the positive V is Potential difference in V (volts), W is Work done or energy trans- metal ions. When a voltage is applied across ferred in J (joules) and Q is Charge in C (coulombs). two points of the metal, the electrons mi- Situation Current grate towards the positive point and collide Note that 1V = means 1 joule per coulomb of charge. with the particles of the metal. The kinetic Lightning 10 000 A energy of the electrons is transferred to the positive metal ions causing them to vibrate Starter motor in car 200 A faster and get hot. Fan heater 10 A Chemical energy → Electrical energy → Heat energy Toaster 3A In cell charge carriers metal particles Light bulb 0,4 A Note: DEFINITION: Ohm's Law states that the current in a conductor is 1. Emf is the voltage measured across the terminals of a battery when no directly proportional to the potential difference across it provided its V = IR Pocket calculator 0,005 A current is flowing through the battery (the switch is open). The emf is temperature remains constant. the work done per unit charge by the source Nerve fibre in the body 0,000 001 A R is referred to as the electrical resistance of the conducting material, resisting the 2. V term or potential difference (pd) is the voltage measured across the flow of charge through it. DEFINITION: The coulomb(C) is that quantity of charge terminals of a battery when current is flowing through the battery. This which passes a fixed point in a conductor in one second when Resistance (R) is the ratio of the potential difference (V) across a resistor and is also known as the operating voltage. the conductor carries a current of one ampere. the current (I) in it. The unit of resistance is called the ohm (Ω). EXAMPLE: EXAMPLE: EXAMPLE: An electric current of 7.5 A flows through an electric A battery transfers 60 kJ of energy to 5 kC of electric charge. circuit for 3 minutes. Calculate the amount of charge Calculate the voltage of the battery. A battery has a voltage of 12 V. The current that flows through the resistor in the circuit is flowing through the circuit. 6 A. Calculate the resistance of the resistor. V V = W R = I Q = It Q 12 Q = (7,5)(3 × 60) V = 60000 R = 6 5000 Q = 1350 C V = 12 V R = 2Ω Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 12
Grade 10 Science Essentials Electricity- Series and Parallel SCIENCE CLINIC 2022 © Series Circuits: A 1,5 V cell is connected to 3 identical bulbs in series. This creates 3 times more resis- Parallel circuits: A 1,5 V cell is connected to 3 identical bulbs in parallel. The cell has to supply 1,5 V to tance than one bulb, so the current is 3 times less each bulb at the same time, so the current is 3 times more 1. There is only one path for the current to follow. 2. The current is the same everywhere. 1. The current splits into three equal parts for each of the branches. 3. If the circuit is broken at any point, the current will stop flowing. 2. If one branch breaks, the other two will still conduct current. 4. The 1,5V supplied by the cell is divided up into 3 equal parts (0,5 V) across each bulb. 3. Each bulb receives the full 1,5 V provided by the cell across it RESISTORS IN SERIES RESISTORS IN PARALLEL • Current is the same through each resistor • Current is split up through resistors. • Voltage is split up across resistors. • The current is inversely proportional to the R1 •The voltage is directly proportional to the resistance in resistance. The smaller resistance, the more 1 1 1 RTOTAL = R1 + R2 . . . the series combination. Most voltage will be across the current going through it. • Voltage is the same across each resistor in the R1 R2 = + R2 largest resistance. •“Voltage divider” parallel combination. RTOTAL R1 R2 . . . •Dimmer switches, Christmas lights • “Current divider” • Cars, houses COMBINATION CIRCUITS. TO SOVLE: Identify the separate series and parallel combinations in the circuit. Apply Ohms Law to each resistor, or each combination of resistors or the whole circuit consistently. EXAMPLE: Calculate the current through each resistor and the voltage across each resistor in the combination circuit. STEP 1: STEP 2: STEP 3: STEP 4: Find the total resistance Find the total current Apply known variables Apply Ohm’s law to unknown resistors to circuit components 1 1 1 V = + I = RP R2 R3 R R1 and R2 are in series VR1 = IR VR 4 = IR 1 1 60 = + 1 I = 15 ∴ ITOT = IR = IR = 4 A 1 4 VR1 = (4)(5) VR 4 = (4)(6) RP 8 8 1 2 I = 4A = VR1 = 20 V VR 4 = 24 V RP 8 IR + IR = 4A 2 3 ∴ RP = 4Ω and IR = IR 2 3 VR = VR = IR RTOT = R P + R1 + R 4 ∴ IR = IR = 2 A 2 3 2 3 VR = VR = (2)(8) RTOT = 5+ 4+ 6 2 3 RTOT = 15 Ω VR = VR = 16 V 2 3 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 13
Grade 10 Science Essentials Electricity - The Essentials SCIENCE CLINIC 2022 © Quantity Current (I) Potential Difference (V) Resistance (R) Definition The rate of flow of charge. The energy transferred per unit electric charge. The ratio of potential difference across a resistor to the current through it. Unit A (amperes) V (volts) Ω (ohms) Equation I = Q /t V=W/Q R = V /I Meaning How much charge passes every second How much energy each coulomb of charge How many volts are required to sustain transfers between 2 points a current of 1 ampere. The coulomb (C) is that quantity of charge Emf is the voltage measured across the Ohm's Law states that the current in a which passes a fixed point in a conductor terminals of a battery when no current is flowing conductor is directly proportional to the in one second when the conductor carries through the battery potential difference across it provided its a current of one ampere V term or potential difference (pd) is the temperature remains constant. voltage measured across the terminals of a Resistance of a material is dependent on the battery when current is flowing through the type of material, as well as the length, thickness battery. and temperature of the conductor RESISTORS IN SERIES RESISTORS IN PARALLEL COMBINATION CIRCUITS. R1 RTOTAL = R1 + R2 . . . R1 R2 1 1 1 R2 = + RTOTAL R1 R2 . . . •Current is the same through each resistor •Current is split up through resistors. The current • Identify the separate series and parallel •Voltage is split up across resistors. The voltage is inversely proportional to the resistance. The combinations in the circuit. is directly proportional to the resistance in the smaller resistance, the more current going • Apply Ohms Law consistently to: series combination. through it. o each resistor, •‘Voltage divider’ •Voltage is the same across each resistor in the o or each combination of resistors •Eg. Dimmer switches parallel combination. o or the whole circuit. •‘Current divider’ Current is measured with an ammeter, • Eg Cars, houses. which is connected in series. Potential difference is measured in parallel using a voltmeter. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 14
Grade 10 Science Essentials Vectors and Scalars SCIENCE CLINIC 2022 © Scalar Vector NET OR RESULTANT VECTOR • Net or resultant vector: the single vector that has the same effect as two or more vectors together. A physical quantity with A physical quantity with both • Net vector is greatest when vectors are in the same direction. magnitude only magnitude and direction • Net vector is smallest when vectors are in the opposite direction. E.g. E.g. Vectors in same direction Vectors in opposite directions Multiple vectors in different direc- mass (kg); distance (m); Force (N); weight (N); tions speed (m.s⁻¹); time (s); displacement (m); velocity Determine the net force when a 5 N force Determine the net force when a 12 N force energy (J); temperature (K) (m.s⁻¹); acceleration (m.s⁻²) acts to the right and a 10 N force also acts acts to the right and a 7 N force acts to Determine the net force when a 8 N force to the right. the left. acts to the right, a 10 N force acts to the Graphical representation of a vector right, a 25 N force acts to the left and a 12 Vector is represented by an arrow. N acts to the left. Length of arrow = magnitude of vector. Direction of arrow = direction of vector. e Head = ud nit Direc3on ag M Let to the right be positive: Let to the right be positive: Let to the right be positive: θ Tail = Origin Fnet = F1 + F2 Fnet = F1 + F2 Fnet = F1 + F2 + F3 + F4 + and – is used to indicate direction of a vector. = 5 + 10 = 12 + (− 7) = 8 + 10 + (− 25) + (− 12) = 15 N right = 5 N right = − 19 N e.g. right is + +5 N = 19 N left left is – –3N 3 METHODS TO DESCRIBE THE DIRECTION OF A VECTOR (the same vectors are used and described in each example) On a graph Bearing Compass (Cardinal Points or directions) Use North as 0⁰ and always measure clockwise NOTE: South-West, North-West, FA: 10 N at 30⁰ above the positive x-axis FA: 10 N on a bearing of 60⁰ FA: 10 N at 30⁰ North of East North-East and South east can FB: 8 N at 12⁰ left of the negative y-axis FB: 8 N on a bearing of 192⁰ FB: 8 N at 12⁰ West of South only be used if the angle is 45° FC: 5 N at 65⁰ above the negative x-axis FC: 5 N on a bearing of 335⁰ FC: 5 N at 65⁰ North of West Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 15
Grade 10 Science Essentials Motion in 1 Dimension SCIENCE CLINIC 2022 © FRAME OF REFERENCE AND POSITION DISTANCE AND DISPLACEMENT • Position (x): the place where an object is relative to a specific reference point. Distance Displacement Position is a vector. Unit is meter(m) Difference in position in space. Displacement • Reference point: a point from which the position of the object is measured (zero point). Total path length travelled is measured from start to final position • One dimensional motion: motion that occurs either vertically or horizontally along a straight line. Scalar Vector EXAMPLE: Symbol: D Symbol: ∆x (or ∆y) Let to the right be positive: Unit: meter (m) Unit: meter (m) EXAMPLE: A boy runs from position A to E in a clockwise motion as shown in the diagram. Describe his distance and displacement at position B,C and E using A as the starting (reference) point. (a) Describe the position of objects A and C by using object B as a reference point as in the diagram. Object A is -3 m from B (3m to the left) B: distance is 100 m, displacement is 80 m at 25⁰ East of South Object C is +5 m from B (5m to the right) C: distance is 200 m, displacement is 120 m South E: distance is 400 m, displacement is 0 m (b) Describe the position of objects B and C by using object A as a reference point as in the diagram. Object B is 3 m right of A Object C is 8 m right of A SPEED VELOCITY ACCELERATION • Speed ( v ): rate of change of distance with time. • Velocity ( v ⃗ ): rate of change of position. • Acceleration ( a ⃗ ): rate of change of velocity. Scalar, unit is m.s⁻¹ Vector, unit is m.s⁻¹ Vector, unit is m.s⁻2 In other words → how much distance is travelled every second. In other words → how much the position changes every second. In other words → how much the velocity changes every second. • Constant acceleration: a constant increase or decrease in velocity • Constant speed: covers equals distances in equal time intervals. • Constant velocity: covers equals displacement in equal time inter- in equal time intervals. vals. change in velocity (m ⋅ s− 1) • Average speed: total distance covered over the total time taken. acceleration (m ⋅ s− 2 ) • Average velocity: total displacement covered over the total time taken. Δv vf − vi speed (m ⋅ s− 1) distance (m) − velocity (m ⋅ s )1 displacement (m) a ⃗ = = Δt Δt time (s) D Δx v= v⃗= Remember + and – refers to direction of the vectors t Δt Let us say right is + and left is – in this case: 1. Positive acceleration: Increasing velocity in + direction (speeding up right) OR decreasing velocity in the – direction (slowing down left) time (s) time (s) 2. Negative acceleration: Decreasing velocity in + direction (slowing down right) OR increasing • Instantaneous velocity: the velocity of an object at a specific mo- velocity in the – direction (speeding up left) • Instantaneous speed: the speed of an object at a specific mo- ment in time [if change in velocity and acceleration is in the same direction it is ment in time. e.g. 1. Let the specific time be 2 seconds – then the instantaneous speeding up and if in opposite directions it is slowing down] e.g. 1. Let the specific time be 2 seconds – then the instantaneous velocity will be annotated by V2. 3. Deceleration: speed will be annotated by V2. e.g.2. the initial instantaneous velocity will be Vi. Non-scientific term that means an object is slowing down. In science e.g.2. the initial instantaneous speed will be Vi. we rather refer to acceleration → direction and context describe whether it is speeding up or slowing down. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 16
Grade 10 Science Essentials Motion in 1D- Equations of Motion SCIENCE CLINIC 2022 © VARIABLES CALCULATIONS: A racing car starting from rest on the grid, travels straight along the track and reaches the 400 m mark after 8,6 s. u vi Initial velocity a) What was its average acceleration? v vf Final velocity a a acceleration Let forward be positive. s ∆x Displacement u 0 1 2 t ∆t Time taken Δx = viΔt + 2 at v / 1 a ? 400 = 2 a8,62 Equations for constant acceleration in one dimension: −2 s 400 m a = 10,82 m ⋅ s forward Old symbols New symbols Leaves out t 8,6 s v = u + at vf = vi + aΔt s or Δx 1 1 b) What was its velocity at the 400 m mark? s= 2 (u + v)t Δx = (v + 2 i vf )Δt a 1 1 vf = vi + aΔt s= u t + 2 at 2 Δx = viΔt + 2 aΔt 2 v or vf vf = 0 + (10,82)(8,6) v 2 = u + 2as 2 vf2 = vi2 + 2aΔx t or Δt vf = 93,05 m ⋅ s− 1 forward Steps to using the equations: c) At the 400 m mark, the brakes are applied and the car slowed down at 2 m.s-2 to come to rest. Calcu- a) Identify each stage of the motion, where the acceleration has changed. late the time it took for the car to stop. b) Choose a positive direction and stick to your convention. c) Record the information given and value required by writing next to each variable. Check the unit and NB! New stage of motion. Find the new value of each variable. direction. d) Select correct equation and solve for unknown. Let forward be positive. e) Include units and direction in your answer. vf = vi + aΔt Remember: u 93.05 m.s-1 0 = 93,05 − 2t v 0 ‘starting from rest’ means: u or vi = 0 t = 46,53 s ‘comes to a stop’ means: v or vf = 0 a -2 m.s-2 ‘Slowing down’ means: acceleration is negative (a < 0), while still moving in a positive direc- tion. s / Constant velocity means: a =0, u = v or vi = vf t ? Use a new set a variables for each stage of the motion. Conversion of units: 1 m.s-1 = 3,6 km.h-1. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 17
Grade 10 Science Essentials Motion in 1D- Graphs of Motion SCIENCE CLINIC 2022 © Tips on reading graphs: 1. Check which variable is on the vertical axis 2. Check which direction is positive. 3. The velocity at any specific time, can be calculated from gradient of the x-t graph at that time. 4. The acceleration at any specific time, can be calculated from gradient of the v-t graph at that time. 5. The displacement up to a specific time can be calculated from the area under the v-t graph up to that time. 6. The change in velocity up to a specific time can be calculated from the area under the a-t graph up to that time. 1 Δy area of triangle = l ×b g r a d i e nt = Δx 2 y2 − y1 = x 2 − x1 area of rectangle = l × b Identify the separate stages of the motion (Forward direction positive): 1. Positive acceleration (accelerating forward) from rest. 2. Constant positive velocity (forward). 3. Negative acceleration (decelerating forward) to rest. 4. At rest 5. Negative acceleration (accelerating backwards) from rest. 6. Constant negative velocity (backwards). 7. Positive acceleration (decelerating backwards) to rest. ( i.e. Accelerating forwards) EXAMPLE: The graph shows two cars A and B are traveling at 40 m.s⁻¹ when the brakes are applied and they decelerate to rest. a) What is the initial speed of the cars in kmh-1? 40 × 3,6 = 144 km ⋅ h− 1 b) Which car had the greatest deceleration? Car A, because the gradient is more steep. c) How far did car B travel after the brakes were applied? 1 Area under triangle B = b×h 2 1 = (6)(40) 2 = 120 m Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 18
Grade 10 Science Essentials Examples of Graphs of Motion SCIENCE CLINIC 2022 © Consider the racing car we used to illustrate the equations of motion: A racing car starting from rest on the grid, travels straight along the track and reaches the 400m mark after 8,6 s. At the 400 m mark, the brakes are applied and the car slowed down at 2 m.s-2 to come to rest. The two stages of the motion can be represented by x –t, v – t and a – t graphs: x-t: a. Describe the motion of the object from 0 to 8 seconds. The displacement is always increasing, the 0-3 s: Negative acceleration from 12 to 3 m.s-1 in forward direction car always moves forward. 3-8 s: Constant velocity of 3 m.s-1 forward. Gradient of s-t at point = velocity at that b. What does the gradient of the line AB represent? point. The acceleration from A to B. The car starts from rest and ends at rest c. Calculate this value. where gradient = 0. a = gradient vf − vi a = The max gradient is at 8,6 s. t 3 − 12 a = 3 a = − 3 m ⋅ s− 2 v-t: The velocity is always positive, the car al- ∴ a = 3 m ⋅ s− 2 in the opposite direction to motion ways moves forward. d.What is the acceleration between B and C? The gradient from 0 to 8,6 s is positive, a(BC) = 0 m.s-2 because gradient = 0 the car is accelerating forward. e. Calculate the total displacement of the object in 8 seconds. 1 The gradient from 8,6 to 55,1 s is nega- Δx = area = bh + lb + lb 2 tive, the car is decelerating while traveling = 1 (3)(9) + (3)(3) + (5)(3) forward. 2 = 13,5 + 9 + 15 = 37,5 m f. Draw the corresponding a – t graph for the motion: a-t: Constant positive acceleration of +10,82 m.s-2 from 0 to 8,6 s. Constant negative acceleration of -2 m.s-2 from 8,6 s to 55,1 s. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 19
Grade 10 Science Essentials Ticker Timers SCIENCE CLINIC 2022 © Measuring Instantaneous Velocity Measuring Acceleration A ticker timer produces a series of dots on a tape which can be analyzed to determine the displace- If we know the instantaneous velocity at two times, we can calculate the acceleration between ment between two points and the time taken between the two points. the points using Δx vf − vi vaverag e = a= t Δt ∆x is measured in meters with a ruler. Here is a section of tape from a ticker timer which vibrates at 50 Hz. 1 t can be calculated from the period of the timer. T = and is measured in seconds. f When t is small we are calculating the instantaneous velocity over the time taken. When t is large we are calculating the average velocity over the time taken. 1 To calculate the instantaneous velocity at a certain point (Z) on a tape: The time interval between the dots is = 0,02 s 1. Mark off one or more spaces before the point Z. 50 2. Mark off the same number of spaces after the point Z. 3. Z will occur at half the time of the interval. Divide the tape into two intervals, C to E and A to C, to find vf and vi respectively. 4. Measure the length of the interval in meters. This is the displacement s. 0,042 0,018 5. Count the spaces in the time interval to calculate t. NOTE: t = number of spaces x T. vCE = 0,04 vAC = 0,04 Δx 6. Velocity at Z is called VZ. VZ = t = 1,05 m ⋅ s− 1 = 0,45 m ⋅ s− 1 REMEMBER: The footnotes used are simply a descriptor of the At which dot was the instantaneous velocity = 1,05 m.s-1 ? D time point to which the velocity refers to. At which dot was the instantaneous velocity = 0,45 m.s-1? B vD − vB vi means velocity at the initial time point a = t B to D v4 means velocity at the 4th time point (4th second) 1,05 − 0,45 vb means velocity at time point B a = 0,04 a = 15 m ⋅ s− 2 Use the pattern of the dots to describe the motion of each object: REMEMBER: The average velocity across the a time section (from A to C) is equal to the instantaneous veloc- ity in the middle of that time interval (at B) a) acceleration from rest The instantaneous velocity at B = average velocity from A to C The instantaneous velocity at C = average velocity from B to D OR from A to E The instantaneous velocity at D = average velocity from C to E b) constant speed, and then suddenly accelerates This only applies to constant acceleration or zero acceleration. Because acceleration is rarely constant in real life, this could lead to inaccuracy. In real life, the variability in acceleration is overcome by making the time across which the aver- c) accelerating, then moving age velocity is calculated shorter. at constant velocity and then decelerating Shorter average velocity time = more accurate instantaneous velocity d) slowly decelerating Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 20
Grade 10 Science Essentials Motion in 1D - The Essentials SCIENCE CLINIC 2022 © Quantity Definition Vector/scalar Unit Position (x) The place where an object is relative Vector m to a specific reference point. Distance(D) Length of path taken by a moving Scalar m object Displacement (∆x) Change in position with respect to a Vector m start point Speed (v) Rate of change of distance. Scalar m.s⁻¹ Velocity (v) Rate of change of position. Vector m.s⁻¹ Acceleration (a) Rate of change of velocity. Vector m.s⁻2 Average ! !!"#$!%# = speed ∆! Average ∆! !!"#$!%# = velocity ∆! Instantaneous the velocity of an object at a specific moment in time. velocity Eg. Vi is initial velocity. Vf is final velocity. Acceleration !! − !! != ∆! Negative Decreasing velocity in + direction OR increasing velocity in the – acceleration direction Positive acceleration Increasing velocity in + direction OR decreasing velocity in the – direction FORMULAE Old symbols New symbols Leaves out v = u + at vf = vi + aΔt s or Δx 1 1 s= 2 (u + v)t Δx = (v + 2 i vf )Δt a s= u t + 12 at 2 Δx = viΔt + 12 aΔt 2 v or vf v 2 = u + 2as 2 vf2 = vi2 + 2aΔx t or Δt Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 21
Grade 10 Science Essentials Graphs of Motion- The Essentials SCIENCE CLINIC 2022 © Displacement-Time • 1 is positive acceleration GRADIENT: • 2 is constant velocity Velocity • 3 is negative acceleration AREA: • 4 is at rest n/a Velocity-Time • 1 is positive acceleration GRADIENT: • 2 is constant velocity Acceleration • 3 is negative acceleration AREA: • 4 is at rest Displacement Acceleration-Time • 1 is positive acceleration GRADIENT: • 2 is constant velocity (a = 0) n/a • 3 is negative acceleration • 4 is at rest, but negative accelera- AREA: tion still applies Change in velocity Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 22
Grade 10 Science Essentials Energy SCIENCE CLINIC 2022 © ENERGY PRINCIPLE OF CONSERVATION OF MECHANICAL ENERGY The ability to do work Principle of conservation of mechanical energy: The total mechani- Unit: joules (J) EMECHA = EMECHB cal energy in an isolated system remains constant. The law of conser- Scalar quantity vation of mechanical energy applies when there is no friction or air resis- (EP + EK )A = (EP + EK )B tance acting on the object. In the absence of air resistance, or other forces, 1 1 Gravitational Potential Energy (EP) Kinetic Energy (EK) the mechanical energy of an object moving in the earth’s gravitational field (m g h + 2 m v 2 )A = (m g h + 2 m v 2 )B The energy an object possesses The energy an object pos- due to its position in the gravita- sesses as a result of its mo- in free fall, is conserved. tional field relative to a reference tion Law of conservation of energy: The total energy of an isolated system remains constant. point. In the following instances the gravitational potential energy of an object is converted to kinetic energy (and vice versa), while the me- Amount of energy transferred when an Amount of energy transferred chanical energy remains constant object changes position relative to the to an object as it changes earth’s surface. speed. EXAMPLE 1: Object moving vertically 1 2 A 2 kg ball is dropped from rest at A, determine the maximum velocity of the ball at B just before impact. EP = mg h EK = mv (EP + EK )A = (EP + EK )B 2 1 (m g h + 2 m v 2 )A = (m g h + 1 2 m v 2 )B -2 g = 9,8m.s , m is mass in kg, 1 1 (2)(9,8)(4) + 2 (2)(0 2 ) = (2)(9,8)(0) + 2 (2)v 2 m is mass in kg, v is velocity in m.s-1 h is height in m 2 78,4 + 0 = 0 + 1v Example: Example: v = 78,4 Determine the gravitational potential Determine the kinetic energy v = 8,85 m ⋅ s− 1 downwards energy of a 500 g ball when it is placed of a 500 g ball when it travels on a table with a height of 3 m. with a velocity of 3 m.s -1. EXAMPLE 2: Object moving on an inclined plane EP = mgh EK = 1 mv 2 A 2 kg ball rolls at 3 m·s−1 on the ground at A, determine the maximum height the ball will reach at B. 2 = (0,5)(9,8)(3) = 1 (0,5)(32 ) (EP + EK )A = (EP + EK )B = 14,7 J 2 1 1 = 2,25 J (m g h + 2 m v 2 )A = (m g h + 2 m v 2 )B 1 1 (2)(9,8)(0) + 2 (2)(32 ) = (2)(9,8)(h ) + 2 (2)(0 2 ) Mechanical Energy (EM) 0+ 9 = 19,6h + 0 The sum of gravitational potential and kinetic energy at a point 9 = h EM = EP + EK 19,6 h = 0,46 m 1 EM = mg h + 2 mv 2 EXAMPLE 3: Rollercoaster The 2 kg ball rolls on a toy rollercoaster from A, at 20 m above the ground, to B where its height is 8 m and velocity is 14 m·s−1. EXAMPLE: Calculate its starting velocity at A. A ball, mass 500 g, is thrown horizontally through the air. The ball travels at a velocity of 1,8 m·s−1 and is 2,5 m from the ground. Determine the (EP + EK )A = (EP + EK )B mechanical energy of the ball. 1 1 (m g h + 2 m v 2 )A = (m g h +2 m v 2 )B EM = EP + E K 1 1 (2)(9,8)(20) + 2 (2)(v 2 ) = (2)(9,8)(16) + 2 (2)(142 ) 1 EM = mgh + mv 2 2 2 392 + v = 313,6 + 196 1 EM = (0,5)(9,8)(2,5) + 2 (0,5)(1,82 ) v = 313,6 + 196 − 392 EM = 13,06 J v = 10,84 m ⋅ s− 1 to the right Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 23
@ | @- o~ 6 Chemistry (fw) scienceclinic.co.za © 2022 @:
Information sheets – Paper 2 (Chemistry) TABLE 1: PHYSICAL CONSTANTS/TABEL 1: FISIESE KONSTANTES NAME/NAAM SYMBOL/SIMBOOL VALUE/WAARDE Standard pressure pθ 1,013 x 105 Pa Standaarddruk Molar gas volume at STP Vm 22,4 dm3·mol-1 Molêre gasvolume by STD Standard temperature Tθ 273 K Standaardtemperatuur Charge on electron e -1,6 x 10-19 C Lading op elektron Avogadro's constant NA 6,02 x 1023 mol-1 Avogadro-konstante TABLE 2: FORMULAE/TABEL 2: FORMULES m n= N n= M NA n m V c= OR c = n= V MV Vm
TABLE 3: THE PERIODIC TABLE OF ELEMENTS/TABEL 3: DIE PERIODIEKE TABEL VAN ELEMENTE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 (I) (II) (III) (IV) (V) (VI) (VII) (VIII) 1 Atomic number 2 KEY/SLEUTEL Atoomgetal H He 2,1 1 4 3 4 29 5 6 7 8 9 10 Electronegativity Symbol Li Be Elektronegatiwiteit 1,9 Cu Simbool B C N O F Ne 1,0 1,5 63,5 2,0 2,5 3,0 3,5 4,0 7 9 11 12 14 16 19 20 11 12 13 14 15 16 17 18 Na Mg Approximate relative atomic mass Aℓ Si P S Cℓ Ar 0,9 1,2 Benaderde relatiewe atoommassa 1,5 1,8 2,1 2,5 3,0 23 24 27 28 31 32 35,5 40 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 K Ca Sc Ti V Cr Mn Fe Co Ni Cu Zn Ga Ge As Se Br Kr 0,8 1,0 1,3 1,5 1,6 1,6 1,5 1,8 1,8 1,8 1,9 1,6 1,6 1,8 2,0 2,4 2,8 39 40 45 48 51 52 55 56 59 59 63,5 65 70 73 75 79 80 84 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 Rb Sr Y Zr Nb Mo Tc Ru Rh Pd Ag Cd In Sn Sb Te I Xe 0,8 1,0 1,2 1,4 1,8 1,9 2,2 2,2 2,2 1,9 1,7 1,7 1,8 1,9 2,1 2,5 86 88 89 91 92 96 101 103 106 108 112 115 119 122 128 127 131 55 56 57 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 Cs Ba La Hf Ta W Re Os Ir Pt Au Hg Tℓ Pb Bi Po At Rn 0,7 0,9 1,6 1,8 1,8 1,9 2,0 2,5 133 137 139 179 181 184 186 190 192 195 197 201 204 207 209 87 88 89 Fr Ra Ac 58 59 60 61 62 63 64 65 66 67 68 69 70 71 0,7 0,9 226 Ce Pr Nd Pm Sm Eu Gd Tb Dy Ho Er Tm Yb Lu 140 141 144 150 152 157 159 163 165 167 169 173 175 90 91 92 93 94 95 96 97 98 99 100 101 102 103 Th Pa U Np Pu Am Cm Bk Cf Es Fm Md No Lr 232 238
Grade 10 Science Essentials Classification of Matter SCIENCE CLINIC 2022 © All matter is made up of particles whose properties determine the observable CLASSIFICATION characteristics and reactivity. Elements of the periodic table can be classified into 3 different categories: Ions Atoms Molecules Non-metals, Metals and Metalloids Par:cles Non-metals Metals Metalloids Eg. Sulphur Eg. Copper Eg. Silicon Poor electrical conductors (i.e. insulators) Poor electrical conductors but conductivity All ma9er Good electrical conductors (except graphite) increases with an increase in temperature Pure Poor thermal conductors Mixtures Good thermal conductors Varied thermal conductivity substances (except diamond) Dull appearance Lustre (shiny) Lustre (shiny) Brittle Malleable and ductile Brittle Elements Compounds Low melting and boiling points High melting and boiling points Melting and boiling points differ vastly Can be solids, liquids or gases at room All solids except mercury (Hg) at Solids at room temperature Non- temperature room temperature Metals Metalloids metals MIXTURES AND PURE SUBSTANCES ELECTRICAL CHARACTERISTICS Pure substances Insulator Electrical conductor Semi-conductor Mixture Compound Element A material that prevents the flow A material that allows the flow of A substance that can conduct electricity under of charge charge certain conditions Consists of different Non-metals Metals Metalloids Consists of two or more Consists of only particles, not elements chemically bonded one type of atom Eg. Diodes and LEDs (light emitting diodes) and chemically joined. Eg. Plastic and rubber Eg. Electrical cables integrated circuits. Components can be Cannot be Components can only be MAGNETIC PROPERTIES separated into separated into separated into simpler sub- simpler substances simpler stances by chemical means Ferromagnetic materials by physical means substances Non-magnetic materials Materials can be influenced by a magnet Materials which are not influenced by a magnet Smallest sample Soft magnetic materials Hard magnetic materials Smallest particles are Smallest particles will reflect the Are easily magnetised but lose Not easily magnetised but retain molecules or ions or formula are atoms or Cannot become magnetised composition of magnetism easily magnetism for a long time units molecules mixture Eg. Iron (Fe) Eg. Cobalt (Co), Nickel (Ni), Uses: Temporary magnets such as Steel Eg. Other elements including metals such as No fixed ratio Fixed ratio between the electromagnets in metal scrap Uses: Permanent magnets and aluminium (Al), zinc (Zn),Copper(Cu) between the smallest particles yards and loud speakers compasses different particles. Eg. Sand in water Eg. H2O, MgSO4 Eg. Cu, H2 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 26
Grade 10 Science Essentials Classification of Matter-The Essentials SCIENCE CLINIC 2022 © Physical Properties of materials Ions Atoms Molecules Strength: the ability of a material to resist stress and strain Thermal conductivity: the ability of material to conduct heat Electrical conductivity: the ability of a material to conduct electricity Par:cles Brittle: hard but likely to break Malleable: Ability to be hammered or pressed into shape without breaking or cracking All ma9er Ductile: the ability to be stretched into a wire Pure Magnetic: a material which can be attracted or repelled by a magnet Mixtures (its domains are aligned) substances Non-magnetic: a material which is not attracted or repelled by a mag- net (its domains are misaligned) Elements Compounds Density: the mass per unit volume of a substance Melting point: The temperature at which a solid becomes a liquid. Boiling point: the temperature of a liquid at which its vapour pressure Non- equals the external (atmospheric) pressure Metals Metalloids metals A substance that cannot be separated into simpler Pure Substance Pure copper, O2 components by physical methods Pure substance consisting of only one type of Argon, mercury, silicon, Element atom gold Pure substance consisting of two or more elements Water, carbon dioxide, Compound chemically bonded in a fixed ratio sodium chloride Consists of different particles mixed together, but Mixture Milk, air, salt water not chemically joined. Homogenous A mixture of uniform composition and in Eg: air, brine, steel mixture which all components are in the same phase Heterogeneous A mixture of non-uniform composition and of Sand and rock mixture, mixture which the components can be easily identified Pizza toppings Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 27
Grade 10 Science Essentials Names and Formulae SCIENCE CLINIC 2022 © BASIC CONCEPTS • Atoms combine in very specific ratios to TABLE OF COMMON ELEMENTS form certain compounds. H Hydrogen Ne Neon K Potassium Zn Zinc E.g. carbon dioxide consists of 1 carbon and 2 oxygen atoms. CARBON He Helium Na Sodium Ca Calcium Br Bromine Li Lithium Mg Magnesium V Vanadium Sn Tin •These ratios remain fixed for that com- pound. The ratio is given by the formula. OXYGEN OXYGEN Be Beryllium Al Aluminium Cr Chromium Pt Platinum e.g. CO2 B Boron Si Silicon Mn Manganese Ag Silver C Carbon P Phosphorus Fe Iron Au Gold •Simple ions are single atoms which carry a charge. They are also called mona- N Nitrogen S Sulphur Co Cobalt Hg Mercury tomic ions. O Oxygen Cl Chlorine Ni Nickel Pb Lead Polyatomic ions are groups of atoms bonded together which collectively carry a F Fluorine Ar Argon Cu Copper Xe Xenon charge. TABLE OF COMMON COMPOUNDS TABLE OF COMMON CATIONS AND ANIONS Formula Chemical name Common name SINGLE CHARGE DOUBLE CHARGE TRIPLE CHARGE H2O Hydrogen oxide Water ANIONS (NEGATIVE IONS) CO2 Carbon dioxide Carbon dioxide All Group 7 All Group 6 All Group 5 NH3 Hydrogen nitride Ammonia OH¯ Hydroxide ion SO4²¯ Sulphate ion PO4³¯ Phosphate ion HCℓ Hydrogen chloride Hydrochloric acid NO3¯ Nitrate ion SO3²¯ Sulfite ion H2SO4 Hydrogen sulphate Sulphuric acid NO2¯ Nitrite ion CO3²¯ Carbonate ion HNO3 Hydrogen nitrate Nitric acid MnO4¯ Permanganate ion CrO4²¯ Chromate ion H2CO3 Hydrogen carbonate Carbonic acid CℓO3¯ Chlorate ion Cr2O7²¯ Dichromate ion H3PO4 Hydrogen phosphate Phosphoric acid CℓO¯ Hypochlorite ion O2²¯ Peroxide ion CH3COOH Ethanoic acid Vinegar HCO3¯ Hydrogen carbonate ion NaCℓ Sodium chloride Table salt HSO3¯ Hydrogen sulfite ion NaOH Sodium hydroxide Caustic soda HSO4¯ Hydrogen sulphate ion NaHCO3 Sodium hydrogen carbonate Baking soda (bicarbonate of soda) H2PO4¯ Dihydrogen phosphate ion Na2CO3 Sodium carbonate Washing soda CH3COO¯ Acetate ion NaNO3 Sodium nitrate Chile saltpetre CATIONS (POSITIVE IONS) KOH Potassium hydroxide Caustic potash All Group 1 All Group 2 All Group 3 KNO3 Potassium nitrate Saltpetre NH4+ Ammonium ion CaCO3 Calcium carbonate Marble/ chalk/ lime stone H3O + Hydronium ion CaSO4 Calcium sulphate Gypsum MgSO4 Magnesium sulphate Epsom salts CuSO4 Copper sulphate Blue vitriol CH4 Methane Natural gas Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 28
Grade 10 Science Essentials Names and Formulae SCIENCE CLINIC 2022 © WRITING CHEMICAL FORMULAE BALANCING CHEMICAL EQUATIONS Follow these basic steps to write chemical formulae for ionic substances: A chemical equation represents the chemical changes that occur when a reaction takes place. 1. Write symbol for the positive ion first, then for the negative ion. The Law of conservation of matter means that matter cannot be created or destroyed, merely transferred from one The ions could be monatomic ions or polyatomic ions. substance to another. •A chemical equation must be balanced in order to conform to the above law. 2. Write ionic charges at top right of symbols •Compounds have fixed ratios, thus only the number of compounds on either side of the arrow can be changed . • Monatomic ion → the ion of one single element only, so you can use periodic table to •Numbers are placed in front of compounds on either side of the arrow to balance the equation. determine the charge. •The total number of each atom should be the same on either side of the equation. • Polyatomic ion → you must memorise the charges. Steps for balancing reaction equations: 1.Identify all reactants and products of the reaction. 3. “Cross multiply” the numbers so that the total charge of the 2.Start from the word equation where possible. compound is 0. 3.Write the correct formula for the compounds of the reactant and products and separate them with an arrow. 4.Indicate the phases of each compound. 4. Write final compound: 5.Count the number of atoms of each element on either side of the arrow, and add numbers in front of • ends in –ide → monatomic ion compounds in order to get it to balance. Eg. Hydrogen Sulphide = H2S 6.Check the total number of atoms of a certain element in reactants must equal the total number atoms of the same element in the product. • the name ends in –ate or –ite if it includes oxygen • Roman numerals (II) → ionic charge of the metal EXAMPLE: Eg. Copper(II)sulphate → Cu2 SO4 In the Synthesis of water, Hydrogen reacts with oxygen to form water. EXAMPLE: Step 1. Hydrogen + oxygen → water. Aluminium oxide Step 2. H2 + O2→ H2 O 3+ Aℓ O2- (“cross-multiply” numbers ) Step 3. H2 (g) + O2(g) → H2 O(g) Step 4a. Add a 2 in front of H2O to balance the oxygen atoms. Aℓ 2 O 3 (the total charge must be zero) H2 (g) + O2(g) → 2H2 O(g) Step 4b. Add a 2 in front of H2 to balance the hydrogen atoms. 2H2 (g) + O2(g) → 2H2 O(g) Step 5. Reactants have 4 H atoms and 2 oxygen atoms. Products have 4 H atoms and 2 oxygen atoms. Equation is balanced. PHASES OF A COMPOUND NOTE: These steps are a systematic approach to balancing Phases are represented as subscripts after the formulae as follow: chemical equations. You don’t have to show all the steps in your working out. Usually only the final balanced equation is required. (s) solid state (ℓ) liquid state (aq) aqueous solution (g) gaseous state Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 29
Grade 10 Science Essentials Kinetic Theory of Matter SCIENCE CLINIC 2022 © STATES OF MATTER CHANGES OF STATE HEATING AND COOLING CURVES FOR WATER •All matter has mass and takes up space (volume). Sublima/on condensing Temperature (oC) Temperature (oC) boiling •Matter occurs in one of three states, solid, liquid or gas, Mel/ng Boiling/ depending on the temperature. evapora/on •The state of matter depends on its melting point (MP) and boiling point (BP). If the temperature is below the Solid Liquid Gas freezing MP, it is a solid. If the temperature is above the MP, but mel+ng below the BP, it is a liquid. If the temperature is above the BP, it is a gas. Freezing Condensa/on Time (min) Time (min) Desublimation/ Deposition Deposi/on Hea+ng Curve Cooling Curve EVIDENCE FOR THE KINETIC THEORY OF MATTER The Kinetic Theory of Matter states that: Diffusion is the movement of atoms or molecules Brownian motion is the random move- from an area of high concentration to an area of ment of microscopic particles sus- •All matter is made of tiny particles with spaces in between them. lower concentration. The higher the temperature, pended in a gas or liquid. When we •The tiny particles are constantly moving, but the particles lose no kinetic the faster diffusion takes place. use a microscope to study smoke par- energy when they collide with other particles or with the walls of their con- ticles in air or pollen particles in water, tainer. dye these particles jiggle about in a com- •The kinetic energy of the particles depends on how fast they are moving. molecules water pletely random way. The tiny particles At any given time, some particles are moving slowly while others are moving molecules equilibrium of air or water, which are too small to fast. The temperature is a measure of the average kinetic energy of the parti- be seen with the microscope, are in cles. constant motion. They collide with the •The potential energy of the particles depends on how far they are apart bigger particles of smoke and pollen, and depends on their state (solid, liquid or gas). causing the bigger particles to change •There are attractive forces between the particles which become stronger as direction and speed. the particles move closer. Properties of Spaces between Forces between Arrangement of Movement of states of Particle diagram Volume Shape particles particles particles particles matter Close together. Fixed Vibrate about fixed Solid Fixed volume Fixed shape Touching each other Strong positions in a set pattern. positions Definite Takes the shape Slide past each other Liquid Touching each other Medium Random – no fixed pattern volume of the container switching places. No definite shape or volume. On their own Gas Expands to fill container or Far apart Very weak Fast and free space in which it is Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 30
Grade 10 Science Essentials The Atom- Atomic models SCIENCE CLINIC 2022 © J.J Thomson (1897) 1.Thomson used a cathode- James Chadwick (1932) ray tube to show that there Electrons Niels Bohr (1913) 1. Discovered the neutron which is a are small negative parti- •Electrons travel around the nu- particle in the nucleus. cles inside atoms. He called cleus in circular, definite paths 2. Neutrons have no charge, and their them “electrons”. - called orbits- like planets orbit mass is almost the same as a proton. 2. Electrons are found in all around the sun. - atoms. They have the same - •Each orbit has a ‘certain energy.’ charge and mass regardless Electrons in the same orbit have Schrödinger (1926) of which substance they - - the same energy. 1. It is not possible to find the exact position of an come from. •The further the orbit is from the electron, but only the most probable regions where - 3. He used the current bun nucleus, the higher the energy. the electrons move. (A.K.A Plum pudding) model - 2. The regions inside an atom where electrons are •Electrons can jump from one or- to explain that the negative likely to be found are called orbitals. Uniform, posi1vely bit to another. electrons are found inside a charged sphere •When an electron moves to higher solid positive mass. energy level it gains energy. TIMELINE OF THE HISTORY OF THE ATOM Democritus John Dalton Ernest Rutherford (1909) ( +/- 440 BC) (1803) Rutherford conducted an experiment in which he shot a beam of alpha particles towards a sheet of very thin gold foil . 1. All elements are Most of the particles continued in a straight line, but some were deflected He deduced that: 1. Democritus pro- made up of small, i.The positive charge is not evenly distributed as suggested by Thomson but is in the centre of the atom, in the nucleus. posed that if you kept indestructible, ii.Mass is concentrated in the nucleus. The nucleus has a large enough mass to deflect the alpha particles. cutting a substance in solid spheres iii.The nucleus is small compared to the atom because most of the particles passed undisturbed through the gold foil. half repeatedly, you called atoms. iv.Electrons are extremely small and far from the nucleus and make up practically the whole volume of the atom. would eventually end 2. A t o m s o f t h e v.The volume of the atom is 10 000 greater than the volume of the nucleus. The atom is mostly empty space. up with an “uncutta- same element ble” particle. are identical: metal foil 2. He called these same size, shape flourescent particles atoms. and mass. screen undeflected 3. An atom is the α-par&cle source α-par&cles solid smallest particle of an element which can take nucleus part in a chemical reaction. 4. Compounds are formed when the atoms of two or more elements combine with one another in fixed whole number ratios. Shortcomings: 1. Atoms are not solid spheres. 2. All atoms of an element are not identical. There deflected are different isotopes of elements. α-par&cles gold 3. Atoms consist of sub-particles. atom Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 31
Grade 10 Science Essentials The Atom SCIENCE CLINIC 2022 © WHAT IS AN ATOM? Atomic Number (Z) and Atomic Mass (A) Consider the atom shown here: •Atoms are the very small particles of which all An atom is identified by the contents of its nucleus. It has 6 protons. This means it is a 6 Protons elements are made- they are the basic building An atom is represented by the notation: Carbon atom. 6 Neutrons block of all matter – including your own body, your hair, your organs, the earth, the sun are all E Symbol of the element E - A made of different combinations of atoms. It has 6 neutrons. This means it has 12 - - A Atomic Mass (A) is the number of nucleons nucleons and a mass of 12 amu. •E.g. Your body is made of 65% Oxygen, 19% Carbon and 10% Hydrogen by mass. Z Z Atomic Number (Z) is the number of protons It has 6 electrons so it has a total + + + •All known elements are arranged on the peri- charge of 6 + (-6) = 0. It is neutral. odic table in order of increasing atomic number. - The diameter of an atom varies for - •Periodic refers to ‘repeating patterns.’ Elements •Elements in the periodic table are arranged in order of in- each type of atom. The diameter is - creasing atomic number (Z). about 1 x 10 -10 m. are arranged into groups (vertical columns) and periods (horizontal rows). •The number of protons (Z) gives each element its unique Carbon Atom properties. •Elements in within a group have similar physical •Z also indicates how many electrons are present in the atom 7 EXAMPLE 1: Lithium 3 Li and chemical properties. as the atom is electrically neutral. •A indicates the mass of the atom how many nucleons are (Z) Atomic number is 3: 3 protons, therefore 3 electrons •Atomic theory is the basis for understanding the present in the atom. (A) Atomic Mass is 7: 3 protons and (7 - 3) = 4 neutrons interactions and changes in matter. •Number of neutrons = Atomic mass number - Number of pro- tons (N = A - Z) 32 ATOMS AND SUB-ATOMIC PARTICLES EXAMPLE 2: Sulphur 16 S •There are three subatomic particles that are (Z) Atomic number is 16: 16 protons, therefore 16 electrons found inside the atoms, i.e. protons, neutrons Table showing the mass and charge of subatomic particles (A) Atomic Mass is 32 : 16 protons and (32 - 16) = 16 neutrons and electrons. •The nucleus is in the centre of the atom and 13 contributes most of the mass. The nucleus is proton p+ neutron n0 electron e- EXAMPLE 3: Carbon-13 6 C made of the protons and neutrons which are called nucleons. (Z) Atomic number is 6: 6 protons, therefore 6 electrons •Because subatomic particles have extremely Mass 1,677 × 10−27 1,677 × 10−27 9,11 × 10−31 (A) Atomic Mass is 13 : 6 protons and (13 - 6) = 7 neutrons small masses, the atomic mass unit amu is used. (kg) (1 amu) ( 1 amu) 1 amu = 1,677 × 10−27 kg. Relative Atomic Mass (RAM) •The mass of an atom is measured relative to RAM indicates how many times the average mass of an atom of a certain Units of element is heavier than 1/12 the mass of a carbon atom. the mass of carbon-12 atom. Carbon-12 is ex- +1 0 -1 charge Isotopes in an element are responsible for the RAM of elements NOT being actly 12 amu, therefore 1 amu is one-twelfth the mass of carbon-12 atom. whole numbers. Isotopes of elements EXAMPLE Consider these three atoms of hydrogen. They each have Hydrogen exists as isotopes. one proton, but they have different numbers of neutrons. 99,65% of H atoms are 1 1 H They are called isotopes. 0,30% of H atoms are 1 2 H n 0,05% of H atoms are 1 3 H + + n + n Isotopes have the same: number of protons 99,65 × 1 0,30 × 2 0,05 × 3 number of electrons RAM(H) = 100 + 100 + 100 chemical properties. - - - Isotopes have different: = 1,004 1 2 3 number of neutrons 1 H 1 H 1 H different masses Hydrogen Deuterium Tri2um Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 32
Grade 10 Science Essentials The Atom SCIENCE CLINIC 2022 © ELECTRON ARRANGEMENT IN THE ATOM IONS 1. In neutral atoms, the number of electrons in the cloud around the nucleus equals CATIONS ANIONS the number of protons in the nucleus. Cations are positive ions which are formed when the elec- Anions are negative ions which are formed when electrons 2. The electrons closer to the nucleus have less energy than the electrons further trons from the outermost energy level are separated from attach to an atom to fill the outermost energy level of the away from the nucleus. the atom. atom. 3. The electrons occur in energy levels (n). 4. Different energy levels are able to accommodate different numbers of electrons The atoms become charged atoms known as ions. These The atoms become charged atoms known as ions. These (Total electrons = n2). charges need to be considered when completing Aufbau charges need to be considered when completing Aufbau 5. The electrons are found in certain regions within an energy level, referred to as diagrams or electron configurations. diagrams or electron configurations. orbitals. Each orbital can accommodate 2 electrons. +3 EXAMPLE: 13Al EXAMPLE: 9F- Electrons are always found in positions of lowest possible energy (as close to the A neutral atom of aluminium contains 13 protons and 13 A neutral atom of fluorine contains 9 protons and 9 elec- nucleus as possible) electrons. trons. This aluminium ion has a charge of +3, indicating it has 3 This fluorine ion has a charge of -1, indicating it has 1 • energy level 1: 1s2 orbital protons more than electrons. electron more than protons. • energy level 2: 2s2 and 2p6 orbitals The number of protons does not change for a given ele- The number of protons does not change for a given ele- • energy level 3: 3s2, 3p6 and 4s2 orbitals ment, thus it has lost 3 electrons and has 10 electrons. ment, thus it has gained electron and has 10 electrons. Shapes of the orbitals Orbital box (Aufbau) diagrams Spectroscopic Electron Con- Lewis dot diagrams figuration (spd) notation: Aufbau diagrams is most detailed description of the way the This is a concise way to indicate the electron Lewis dot diagrams are used to show the posi- 1s orbital orbitals are filled with electrons. The orbitals are filled from arrangement in an atom. This is similar to the tion of the valence electrons around an ele- Energy level 1 the lowest energy at the bottom in the following way: Aufbau diagram, but represents it in a simpler ment. The valence electrons are related to the Spherical in shape way. group of the element. EXAMPLE: In all of the examples below, X represents any Valence electrons are 2 2 5 4s in the outer most en- 9F = 1s 2s 2p element in the group. 2 2 6 2 1 ergy level and take 13Al = 1s 2s 2p 3s 3p 2 2 6 2 6 2 2s orbital part in bonding. 20Ca = 1s 2s 2p 3s 3p 4s Group 1 Group 2 Energy level 2 3p Spherical in shape We can also concisely represent the Electron Electrons spend more 3s Configuration of ions in this way: X X Energy time further from nu- cleus Negative ions have gained electrons Positive ions have lost electrons Group 3 Group 4 2p EXAMPLE: 2px, 2py, 2pz orbitals 2s Core electrons are in full energy levels and are not involved - 2 9F = 1s 2s 2p 13Al +3 2 6 = 1s2 2s2 2p6 X X Energy level 2 in bonding. +2 = 1s2 2s2 2p6 3s2 3p6 Dumbbell shapes along 20Ca Group 5 Group 6 x,y and z axes 1s We can also write the electron configuration Flourine according to noble gas notation. Noble gas notation makes use of the first pre- ceding noble gas, which has a completely filled X X As the energy level(n) increases Pauli’s exclusion principle: Maximum of two electrons per outer energy level. •the size of their s and p orbitals also in- orbital provided that they spin in opposite directions. (arrows Group 7 Group 8 creases. in opposite directions) EXAMPLE: 2 5 9F = [He] 2s 2p •The number of orbitals increases. •We encounter d and f orbitals which are more complicated shapes. Hund’s rule: No pairing in p orbitals before at least one elec- tron in each of them. 2 13Al = [Ne]3s 3p 20Ca = [Ar]4s 2 1 X X Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 33
Grade 10 Science Essentials The Atom - The Essentials SCIENCE CLINIC 2022 © Atomic models Mass and charge of subatomic particles Isotopes have the same number of protons (Z) but differ- ent number of neutrons (A) 1. All elements are made up of proton p+ neutron n0 electron e- Relative Atomic Mass (RAM) John Dalton small, indestructible, solid spheres RAM indicates how many times the average mass of an (1803) called atoms like billiard balls. atom of a certain element is heavier than 1/12 the mass 2. Atoms of the same element are Mass 1,677 × 10−27 1,677 × 10−27 9,11 × 10−31 of a carbon atom. identical. (kg) (1 amu) ( 1 amu) J.J Thomson Electrons are negative particles, Electron arrangement (neutral atom) (1897) found inside a solid positive mass, 1. Number of electrons = Z Units of like raisins in a current bun. +1 0 -1 2. The electrons occur in energy levels (n). charge 3. The closer to the nucleus, the less the energy. 1. The positive charge is in the 4. Total electrons in a level = n2 centre of the atom, in the nucleus. Representing atoms 5. The electrons are found in orbitals. Each orbital 2. Mass is concentrated in the can accommodate 2 electrons. Ernest nucleus. E Symbol of the element A E Rutherford 3. The nucleus is small compared Orbitals (1909) to the atom. A Atomic Mass (A) is the number of nucleons • level 1: 1 s orbital 4. Electrons are extremely small and travel far from the nucleus. • level 2: 1 s and 3 p orbitals 5. Most of the atom is empty Z Atomic Number (Z) is the number of protons • level 3: 1 s, 3 p and 5 d orbitals space. Electrons travel around the nucleus Z Valence electrons are found in the outer energy level. Niels Bohr in circular, definite paths called Notations for Electron Configuration (1913) orbits. Each orbit has a ‘certain Aufbau: orbitals are shown as boxes. Electrons are shown energy’. In a neutral atom: as arrows in the boxes. Number of protons = Z James spd: 1s2 2s2 2p6 3s2 3p6 4s2 The neutron is a particle in the Number of electrons = Z Chadwick Number of neutrons = A - Z nucleus with no charge, and almost (1932) the same mass as a proton. Valence electrons are 4s in the outer most en- ergy level and take part in bonding. 3p 3s Energy IONS CATIONS ANIONS 2p Cations are positive ions which are formed when the elec- Anions are negative ions which are formed when elec- trons from the outermost energy level are separated from trons attach to an atom to fill the outermost energy level the atom. of an atom. 2s Core electrons are in full energy levels and are not involved The atoms become charged atoms known as ions. These The atoms become charged atoms known as ions. These in bonding. charges need to be considered when completing Aufbau charges need to be considered when completing Aufbau diagrams or electron configurations. diagrams or electron configurations. 1s Flourine Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 34
Grade 10 Science Essentials The Periodic Table SCIENCE CLINIC 2022 © GROUPS (COLUMNS) s-block PERIOD (ROWS) •Groups are the vertical columns in the periodic table. 1s p-block 1s •Periods are the horizontal rows in the periodic table. •Elements in a group have similar outer electron con- •There is a gradual change in the physical and chemi- figurations. 2s 2p cal properties as we move across a period. •This means they have similar chemical properties. 3s d-block 3p •The Period number tells us the energy level where •The group number corresponds to the number of va- the outermost electrons are found. lence electrons. 4s 3d 4p •Eg All of Group 2 elements have two valence elec- •Eg Period 3: outermost electrons in the 3rd energy trons. 5s 4d 5p level. 6s 5d 6p IMPORTANT GROUPS TO REMEMBER: EXAMPLE: Locating an element. 1: Alkali metals 7s 6d 2: Alkali Earth metals 1. Silicon is in group 4 and period 3. Group 1: Group 18: 17: Halogens Group 2: Group 17: Noble gases 2. Calcium is in group 2 and period 4. 18: Noble gases Alkali Alkali Earth Halogens metals metals TRENDS OF THE PERIODIC TABLE IONISATION ENERGY (IE) ATOMIC RADIUS ELECTRON AFFINITY (EA) Energy needed per mole to remove an electron from an atom The distance from the nucleus to the border of the outer orbital. The energy released when an electron is is attached to an in the gaseous phase. atom or molecule to form a negative ion. •Atomic radii decrease across a period because as electrons are being First ionization energy is the energy required to remove the added to the same energy level, protons are being added to the nucleus, first electron (outermost electron in the highest energy sub- which pulls the electrons with a stronger force. level) •Atomic radii increase down a group because a)electrons enter a whole new energy level in the next period b)the core electrons shield the outer electron from the pull of the nucleus. F Gains F− outer electron Na Loses Na+ Atomic radii (pm) outer Fluorine atom Fluorine ion electron 1A 2A 3A 4A 5A 6A 7A 8A The electron affinity is also a description of how likely an atom is to accept an electron Sodium atom Sodium ion 37 31 The smaller the atom, the more the force of attraction by the Li Be B C N O F Ne The smaller the atom, the greater the ability of an atom to nucleus on the outer electron, hence the higher the ionization receive an electron due to proximity to the nucleus. energy. 152 112 85 77 75 73 72 71 • EA increase across a period •IE increases across a period • EA decreases down a group •IE decreases down a group Na Mg Al Si P S Cl Ar ELECTRONEGATIVITY (EN) The tendency of an atom in a molecule to attract bonding elec- Interesting trend: trons. Electronegativity range from 0,7 (Cs) to 4,0 (F). 186 160 143 118 110 103 100 98 Melting point, Boiling point and Density increase from • EN increases across a period group 1 to 4, then drop in Group 5 and start increasing again • EN decreases down a group from Group 5 to 8. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 35
Grade 10 Science Essentials Periodic Table-The Essentials SCIENCE CLINIC 2022 © TABLE 3: THE PERIODIC TABLE OF ELEMENTS GROUPS (COLUMNS) •Elements in a group have similar outer elec- 1 2 13 14 15 16 17 18 3 4 5 6 7 8 9 10 11 12 (I) (II) (III) (IV) (V) (VI) (VII) (VIII) tron configurations and similar chemical prop- erties. 1 Atomic number 2 •The group number corresponds to the num- KEY/SLEUTEL 2,1 H Atoomgetal He ber of valence electrons. 1 4 3 4 29 5 6 7 8 9 10 Symbol PERIOD (ROWS) 1,0 Li 1,5 Be Electronegativity 1,9 Cu Simbool 2,0 B 2,5 C 3,0 N 3,5 O 4,0 F Ne 7 9 Elektronegatiwiteit 63,5 11 12 14 16 19 20 •There is a gradual change in the physical and chemical properties as we move across a period. 0,9 11 Na 1,2 Mg 12 Approximate relative atomic mass 1,5 13 Aℓ 1,8 14 Si 2,1 15 P NON- S Cℓ 2,5 16 Ar 3,0 17 18 •The Period number tells us the energy level where the outermost electrons are found. 23 19 24 20 21 22 23 Benaderde relatiewe atoommassa 24 25 26 27 28 29 30 27 31 28 32 31 33 METALS 32 34 35,5 35 40 36 0,8 K 1,0 Ca 1,3 Sc 1,5 Ti 1,6 V 1,6 Cr 1,5 Mn 1,8 Fe 1,8 Co 1,8 Ni 1,9 Cu 1,6 Zn 1,6 Ga 1,8 Ge 2,0 As 2,4 Se 2,8 Br Kr 39 40 45 48 51 52 55 56 59 59 63,5 65 70 73 75 79 80 84 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 0,8 Rb 86 1,0 Sr 88 1,2 Y 89 1,4 Zr 91 Nb 92 1,8 METALS Mo Tc Ru 96 1,9 101 2,2 2,2 Rh 103 2,2 Pd 106 1,9 Ag 108 1,7 Cd 112 1,7 In 115 1,8 Sn 119 1,9 Sb 122 2,1 Te 128 2,5 I 127 Xe 131 IMPORTANT GROUPS TO REMEMBER: 55 56 57 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 1: Alkali metals 0,7 Cs 0,9 Ba La 1,6 Hf Ta W Re Os Ir Pt Au Hg 1,8 Tℓ 1,8 Pb 1,9 Bi 2,0 Po 2,5 At Rn 2: Alkali Earth metals 133 137 139 179 181 184 186 190 192 195 197 201 204 207 209 17: Halogens 87 88 89 18: Noble gases 0,7 Fr 0,9 Ra Ac 58 59 60 61 62 63 64 65 66 67 68 69 70 71 226 Ce Pr Nd Pm Sm Eu Gd Tb Dy Ho Er Tm Yb Lu 140 141 144 150 152 157 159 163 165 167 169 173 175 90 91 92 93 94 95 96 97 98 99 100 101 102 103 Th Pa U Np Pu Am Cm Bk Cf Es Fm Md No Lr 232 238 EN INCREASES EA INCREASES AR DECREASES IE INCREASES Electronegativity (EN) Electron affinity (EA) Atomic radius (AR) Ionization Energy (IE) EN DECREASES EA DECREASES AR INCREASES IE DECREASES The tendency of an atom The energy released The distance between The energy required to to attract a bonding pair when an electron is the nucleus and the remove an electron from of electrons. Electronega- added to a neutral atom outermost orbital. an atom in the gaseous tivity range from 0,7 (Cs) to form a negative ion. phase. to 4,0 (F). Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 36
Grade 10 Science Essentials Chemical Bonding SCIENCE CLINIC 2022 © CHEMICAL BONDS are INTRAMOLECULAR BONDS which occur between • If two non-metal atoms approach, they tend to share their va- atoms within molecules. lence electrons and form a covalent bond. Atoms tend to gain, lose, or share electrons until they are surrounded by a • If a metal and a non-metal atom approach, the metal transfers full electron shell. A full shell makes the atom more stable like a noble gas. its valence electrons to the non-metal. They form an ionic bond. This is known as The Octet Rule: Each atom requires 8 electrons in the • If two metal atoms approach, they release their valence elec- outer shell, except for H and He. trons to surround them and form a metallic bond. A) Covalent Bonding B) Ionic Bonding C) Metallic Bonding 1. Sharing of at least one pair of electrons by two non-metal atoms. 1. Occurs between a metal and a metal atom. 2. Results in simple molecules with only a few atoms connected to 1. Involves a complete transfer of electron(s). 2. The metal atoms release their valence electrons to surround each other. 2. Metal atom gives e- to non-metal. them. There is a strong but flexible bond between the positive 3. Metal forms a positive cation. metal kernels and a sea of delocalised electrons. Eg. H2, H2O, CO2, Cl2 , CH4. 4. Non-metal forms a negative anion. Single Covalent 5. Electrostatic attraction of ions leads to formation of giant crystal Metal atoms are very closely packed, so that the outermost energy lattice. levels overlap. E.g. H − H The valence electrons are able to move from their respective atoms. Each H atom needs one more electron to fill Ionic Bonding takes place in two steps. They are called delocalised electrons or free electrons. the outer shell with 2 electrons. 1. Donation of e-(s) to form ions As the hydrogen atoms come closer so their 2. Electrostatic attraction The bond is between the positive metal kernels and the sea of elec- orbitals overlap. The sharing of electrons re- trons. sults in a lower energy for both electrons. A single bond is formed. Double Covalent E.g. O = O Each O atom needs two more electrons to fill the outer shell with 8 electrons. The diagram shows two oxygen atoms com- Na+ Cl- ing closer so their orbitals overlap. They each share 2 outer electrons. A double bond is formed. Triple Covalent E.g. N ≡ N Each N atom needs three more electrons to fill the outer shell with 8 electrons. The diagram shows two nitrogen atoms coming closer so their orbitals overlap. Diagrams show the crystal lattice They each share 3 outer electrons. A tri- IONIC BONDING made of alternate ions. ple bond is formed. maintains the la2ce structure between ions Delocalised electrons Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 37
Grade 10 Science Essentials Chemical Bonding- Properties of Substances SCIENCE CLINIC 2022 © Properties of simple covalent (molecular) substances Giant Covalent Network Structures: These occur when a non-metal atom forms covalent bonds with more than • Low Melting and Boiling Points because molecules are not bonded to one other non-metal atom. This allows a giant covalent lattices to form. each other, but only loosely held together. They are easily separated. E.g. nitrogen has a BP of -1830C. EXAMPLE 1: Diamond. • Highly volatile. (High tendency of a substance to vaporize.) Each C is bonded to four other carbon atoms. Diamonds and Graphite are both allotropes of carbon. • Insulators – there are no free charge carriers. Properties: 1. Hard: Many strong covalent bonds holding the structure together-making it a very strong crystal. Properties of ionic substances 2. Very high melting point: Many strong covalent bonds hold • Hard, crystalline solids because the Ions held together by strong ionic the structure together. It requires massive amounts of energy to bonds. pull it apart- about 35000C • flat sides and regular shapes because the ions are arranged in 3. Insulator: All of the valence electrons are used in bonding. straight rows in a pattern. None of the electrons are free to move. • Melting points & Boiling points are very high because there are Allotropes are different forms of the same element but has different physical strong ionic bonds between cations and anions. A large amount of en- ergy is required to separate the ions e.g. NaCl melts at 808ºC and boils at 1465ºC. • Low volatility because there are strong ionic bonds between the ions. • Solid ionic compounds don’t conduct electricity, because the ions cannot move, there are no free charge carriers. EXAMPLE 2: Graphite. • Molten or dissolved ionic compounds conduct electricity because Each C is bonded to three other atoms to form a layer. in these situations the ions can move and carry charge, which allows cur- and chemical properties due to the difference in particle arrangement. rent to flow. Properties: 1. The bonds between the layers are weak and thus the layers can slide over each other- making graphite slippery and can be used as a lubricant. Properties of metallic substances 2. Because only three electrons out four valence electrons are The sea of delocalised electrons and tightly packed metal kernels are re- used for bonding, the fourth electron is free to move around. sponsible for the properties of metals: This is why graphite, unlike other non-metals, can conduct elec- • High density tricity. • Good conductors of electricity • The delocalised electrons are free to move randomly throughout the metal, but if a cell is connected across the terminals, the electrons will drift towards the positive end. • Good conductors of heat • Delocalised electrons can also transfer heat energy from a region of high temperature to a region of low temperature, because they move so freely. • Metals have high melting and boiling points because of the strength of the metallic bond. EXAMPLE 3: Silicon Dioxide. • Metals are malleable and ductile- they can be easily flattened, shaped Silicon dioxide (SiO2), also called silica. Many precious gems con- or drawn into threads without breaking. This is because the metals kernels tain silica. are not attracted to one specific electron. This makes them different from There are no discrete SiO2 units. Every Si is bonded to two O an ionic compound which is brittle. atoms. • Metallic lustre: The sea of electrons would reflect all frequencies of light to give a shiny surface. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 38
Grade 10 Science Essentials Chemical Bonding - The Essentials SCIENCE CLINIC 2022 © Inter-atomic bonding/ Intramolecular bonding COVALENT IONIC METALLIC BONDING BONDING BONDING Between 2 or more non-metals Between 2 or more metal and Between 2 or more metal atoms non-metal atoms Molecules of an element Covalent network structures Ionic network structures Metallic network structures Example: Example: Crystals made from a net- Positive kernels and a sea of elec- Diatomic gases diamond work of cations and anions. trons P4 graphite S8 SiO2 Example: C60 (buckyballs) NaCl KMnO4 Molecules of compounds Example: water (H2O) Ammonia (NH3) Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 39
Grade 10 Science Essentials Physical and Chemical Change SCIENCE CLINIC 2022 © PHYSICAL CHANGE CHEMICAL CHANGE 1. Usually easy to reverse. 1. Usually hard to reverse. 2. No new substances formed. 2. New substances formed. 3. Small energy changes involved. 3. Large energy changes involved. 4. Eg. Melting, evaporation, separation of mixtures. 4. Eg. Decomposition, synthesis, burning, rotting, rusting. The particles stay the same, but their arrangement changes. The particles change, because the bonding between their atoms changes. Example of Physical change: Water EXAMPLE: Decomposition of Hydrogen peroxide Consider liquid water evaporating to form water vapour. Each water molecule consists of one O Reactants Products oxygen atom bonded to two hydrogen atoms. H H Word Equation Hydrogen peroxide forms water and oxygen Balanced chemical 2 H2 O2 → 2 H2 O + O2 equation Particle diagram Evapora'on 2H2O2 2H2O + O2 Hydrogen Peroxide Water Oxygen Water water vapor EXAMPLE: Synthesis of water Spaces between Touching each other Far apart water molecules Reactants Products Word Equation Hydrogen + oxygen forms Water No forces, except when Forces between Balanced chemical Medium forces they come close to each 2 H2 + O2 → 2 H2 O water molecules equation other there are weak forces Movement of Slide past each other Particle diagram Flying freely at high speeds water molecules switching places slowly. Chemical Reac+on During evaporation, the actual water molecules do not change. The mass of water and the number of molecules does not change. Energy is absorbed to overcome the forces between the molecules. This changes their arrangement and movement. This change could be represented as follows: Reactants Products Word Equation water forms water vapor These two reactions are chemical changes because new substances are formed. Huge energy changes are involved. The bonds between the atoms of the reactants are broken and new bonds are formed to create the molecules of the products. Every atom in the reactants becomes an atom in Balanced chemical equation H2O (l) → H2O (g) the products. The mass is conserved, but the atoms have been rearranged. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 40
Grade 10 Science Essentials Chemical Change- Chemical Reactions SCIENCE CLINIC 2022 © Law of constant composition Law of conservation of matter In any particular chemical compound, all samples of that In a chemical reaction, the sum of the mass of the reactants equals the sum of the mass of the compound will be made up of the same elements in the products. same proportion or ratio as per its chemical formula. This is also know as the Law of conservation of matter, which indicates that matter particles can not be created or destroyed, but can be rearranged in chemical reactions. For example, any water molecule is always made up of two hydrogen atoms and one oxygen atom in a ratio according to the formula H2O. + OR + 2 Parts Hydrogen 1 Part Oxygen 1 Part Water 4 Parts Hydrogen 2 Parts Oxygen 2 Parts Water Consider the following reaction to form ammonia: any ammonia molecule is always made up of three hydrogen atoms and one nitrogen atom in a ratio according to the formula NH3. The different parts of the reaction are summarised in the table below: Reactants before Products after React to Word equation Hydrogen + nitrogen ammonia form Chemical equation 3 H2 + N2 → 2 NH3 6H 6H Atoms → 2N 2N Total mass of all 2 x (14 + 1+1+1) = 3 x ( 1+1) + 1 x (14+14)= 34 → atoms 34 Energy used to break: Energy released when forming 6 x Energy 3 x H-H bonds → N-H bonds And 1 N-N bond Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 41
Grade 10 Science Essentials Reactions in Aqueous Solutions SCIENCE CLINIC 2022 © Ionic network structure Ions in aqueous solution Reactions in aqueous solutions Because cations and anions are oppositely Ions are atoms or groups of atoms which carry charge. Cations are positively charged, Reactions in aqueous solutions are reactions of chemicals that have charged, they attract each other. In solid and anions are negatively charged. The table below has examples of common ions: been dissolved. form, giant ionic crystals are created, such as sodium chloride and magnesium nitrate. A solution is formed when a solute dissolves in a solvent. Many reac- Ion Formula Charge tions in chemistry and in living systems are carried out in aqueous solu- Nitrate NO3 -1 -1 tion. This means that water is the solvent. -1 Chloride Cl -1 In order for a reaction to occur the particles of the reactant need to col- Ammonium NH4+1 +1 lide with each other. Sodium Na+1 +1 For the collision to be successful, there needs to be a transfer of either : A. ions – these are known as ion exchange reactions Magnesium Mg+2 +2 B. electrons – these are known as redox reactions. +3 Aluminium Al +3 Polar nature of water Hydration of ions The ions of the solute become totally surrounded by water molecules. This is called hydration. Water is the solvent in all aqueous solutions. The When the water molecules surround the ions, they keep the ions apart. charge in a water molecule is not evenly distrib- uted. The oxygen atom is slightly negative (δ-), and the hydrogen atoms are slightly positive δ+). We say that water is polar. The negative dipole of one water molecule is at- tracted to the positive dipole of another water mole- cule. Dissolving of ionic substances Water molecules are attracted to each other, but also to ionic compounds with the oxygen (δ-) closest to the cation(+) and the hydrogen (δ+) closest to the anions(-). If the ions are pulled free from the crystal, the crystal dissolves. Electrolytes Ba0ery Dissolving is a physical process because no new sub- Electrolytes are aqueous solutions which contain stances are formed. When all the ions are separated, the ions, such as NaCl (aq) or KNO3 (aq). Because the ions are free to move, electrolytes conduct electric- Crocodile ionic crystal has dissolved. ity. A simple circuit can be used to test the conduc- Ammeter A clip tivity of the electrolyte, by measuring the current through the solution with an ammeter. The more ions in solution the better the electrolyte conducts the current. EXAMPLE: Certain substances, like sugar, are also soluble in NaCl (s) → Na+(aq) + Cl-(aq) water, but do not form ions in solution, and do not affect conductivity. Test substance Circuit diagram for testing the conductivity of a solution. Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 42
Grade 10 Science Essentials Reactions in Aqueous Solutions- Reaction Types SCIENCE CLINIC 2022 © A. Ion exchange reactions An ion exchange reaction is where the cations exchange their respective anions. There are 3 types of ion-exchange reaction, classified according to the reactants and products involved. 1. Precipitation reactions 2. Acid-base reactions 3. Gas forming reactions In precipitation reactions, anions and cations bond with new partners to form insolu- Acid-base reactions take place between acids and bases. In gas forming reactions, anions and cations have bonded ble salts. Certain cations and anions attract each other so well that they will not be Through the exchange of ions, the products formed will be with new partners and through the exchange of ions a gas is pulled from the ionic crystal. These salts are insoluble and form a precipitate. water and an ionic salt. formed. EXAMPLE: EXAMPLE: There are 4 types of acid-base reactions: NaI (aq) is added to AgNO3 (aq). There are Na+, l-, Ag+ and NO3- ions present in Acid+ Metal carbonate → salt + water + carbon dioxide 1. Acid + metal → salt + hydrogen solution. When the I- and Ag+ ions attract, they from an insoluble salt AgI(s) 2. Acid + metal oxide → salt + water Na2CO3 (s) + 2HCl(aq)→ 2NaCl(aq) + H2O(ℓ) + CO2 (g) which a yellow cloudy precipitate. 3. Acid + metal hydroxide → salt + water 4. Acid + metal carbonate → salt + water + carbon dioxide NaI (aq) + Ag NO3 (aq) → AgI(s) + NaNO3 (aq) EXAMPLE: EXAMPLE: acid + metal → salt + hydrogen Precipitation reactions can be used to test for the presence of certain anions. An H2SO4+Mg → MgSO4 + H2 Metal hydroxide + acid → salt + water environmental scientist analyses water for pollutants. The following table shows NaOH(aq) + HCl(aq)→NaCl(aq) + H2O(ℓ) how to test for some of these anions. Anion Test Positive result Precipitate The sodium ions from the sodium hydroxide swap Gas Test Result places with the hydrogen in the hydrogen chloride Plunge a lighted White precipitate forms 1. Add a few drops of AgNO3 forming sodium chloride. At the same time the hydrox- wooden splint into a makes a popping Chloride after step 1, and AgCl(s) Hydrogen (H2) 2. Acidify with Dilute HNO3 ide and the hydrogen combine to form water. test tube of sound remains after step 2. hydrogen. Bromide Add a few drops of AgNO3 Cream precipitate AgBr(s) EXAMPLE: Plunge a glowing Iodide Add a few drops of AgNO3 Yellow precipitate AgI(s) Metal oxide + acid → salt + water Oxygen (O2) wooden splint into a splint relights CuO(aq) + 2HCl(aq) → CuCl2(aq) + H2O(l) test tube of oxygen. White precipitate forms 1. Add a few drops of BaNO3 Sulphate after step 1, and BaSO4 Bubble the test gas 2. Acidify in Dilute HNO3 The copper ions from the copper oxide swap places Carbon dioxide remains after step 2. Carbon dioxide through limewater - with the hydrogen in the hydrogen chloride forming turns the limewater (CO2) calcium hydroxide White precipitate forms copper(II) chloride. At the same time the oxide ion(-) cloudy white 1. Add a few drops of BaNO3 solution. Carbonate after step 1, and BaCO3 and the hydrogen combine to form water. 2. Acidify in Dilute HNO3 dissolves after step 2. B. Redox reactions Redox reactions occur when one reactant gains electron(s) called reduction, and another reactant loses electron(s) called oxidation. The atom or group of atoms which loses electron(s) becomes more positive, while the atom or group of atoms which gains electron(s) becomes more negative. EXAMPLE: Hydrochloric acid reacts with zinc to form zinc OIL RIG EXAMPLE: O oxidation Copper Sulphate reacts with zinc to form zinc chloride and hydrogen gas. sulphate and Copper. 2HCl(aq) + Zn(s) → ZnCl2 + H2 I is a CuSO4(aq) + Zn(s) → ZnSO4(aq) + Cu(s) L loss of electrons We show the transfer of electrons as follow: R reduction We show the transfer of electrons as follows: Zn(s) → Zn 2+ + 2e- (Oxidation) I is a Zn(s) → Zn 2+ + 2e- (Oxidation) 2 H+ + 2 e- → H2 (g) ( Reduction) G gain of electrons Cu2+ + 2 e- → Cu(s) ( Reduction) Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 43
Grade 10 Science Essentials Reactions in Aqueous Solutions - The Essentials SCIENCE CLINIC 2022 © AQUEOUS SOLUTIONS REACTIONS Water A. Ion exchange reactions Water is the solvent in all aqueous solutions. Water is polar. Polar molecules are molecules that have 1.Precipitation reactions oppositely charged poles and are known as dipoles. In precipitation reactions, anions and cations bond with new partners to form insoluble salts. NaI (aq) + Ag NO3 (aq) → AgI(s) + NaNO3 (aq) Water dissolves ionic substances which are made up of Cati- ons (positively charged), and anions (negatively charged) Precipitation reactions can be used to test for the presence of certain anions 2. Acid-base reactions Water molecules pull the ions free from the ionic crystal. This There are 4 types of acid-base reactions: is called dissolution. 1. Acid + metal → salt + hydrogen 2. Acid + metal oxide → salt + water 3. Acid + metal hydroxide → salt + water 4. Acid + metal carbonate → salt + water + carbon dioxide 3. Gas forming reactions In gas forming reactions, anions and cations have bonded with new partners and through the ex- change of ions a gas is formed Gas Test Result Plunge a lighted wooden splint Hydrogen (H2) makes a popping sound The ions become totally surrounded by water molecules. This is called hydration. into a test tube of hydrogen. Plunge a glowing wooden splint Electrolytes Oxygen (O2) splint relights into a test tube of oxygen. Electrolytes are aqueous solutions which contain ions, such as NaCl (aq) or KNO3 (aq). Because the ions are free to move electrolytes conduct electricity. The more ions in solution the better the electro- lyte conducts the current. This can be tested with the use of a simple circuit as shown below. Bubble the test gas through Carbon dioxide turns Carbon dioxide (CO2) limewater - calcium hydroxide the limewater cloudy Ba0ery solution. white Crocodile B. Redox reactions Ammeter A clip One reactant gains electron(s) → reduction; another reactant loses electron(s) → oxidation. Iron + copper(II)sulphate → Copper + iron (II) sulphate Eg. Fe(s) + CuSO4 (aq) → Cu (s) + FeSO4 (aq) Cu 2+ ions gained 2 electrons → Cu atoms Fe atoms lost 2 electrons → Fe 2+ ions Test substance Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 44
Grade 10 Science Essentials Quantitative Aspects of Chemical Change SCIENCE CLINIC 2022 © The Mole Percentage Composition Atoms, molecules and ions are too small to count, and there are so many particles in even the smallest sample of a Percentage composition is the mass of each atom present in the compound expressed as a substance. percentage of the total mass of the compound. There are more particles of water in a teaspoon then there are teaspoons of water in all the oceans. molar mass of element Percentage composition of element = × 100 Rather than dealing with the particles individually, we deal with a special number of particles. MR of compound The mole is a name for a special number. Many numbers have names, such as: 2 = pair Consider these iron ores: haematite and magnetite – which contains more iron by 3 = hat-trick mass? 12 = dozen Ore Haematite Magnetite A mole of particles is an amount of 6,02 x 1023 particles. 6,02 x 1023 is known as Avogadro’s number, NA. Avogadro’s number (NA) is too big to imagine. Formula Fe2O3 Fe3O4 Relative (2 x 56) + (3 x 16) (3 x 56) + (4 x 16) 602 000 000 000 000 000 000 000 . molecular mass =160 =232 This many grains of sand, piled on the surface of the earth would almost reach the moon. [(2 x 56) /160] x 100 [(3 x 56) / 232] x 100 % iron by mass The mole is defined as the amount of substance having the same of particles or atoms in 12,0 g of Carbon -12. = 70% = 72% Molar Mass ∴ magnetite contains more iron Particles are too small to weigh individually. Molar mass (M) is defined as the mass of one mole of particles (atoms, molecules or formula units) and is meas- Different types of Chemical Formulae ured in the unit g.mol-1. mass of substance (g) Consider the substance ethane. m number of mole (mol) n= M molar mass (g·mol−1) Ball and stick model of ethane Relative atomic mass (Ar) is the average mass of an atom compared to the mass of a Carbon 12 atom. It is measured in atomic mass units (amu). Molar mass (M) of an element is equal to the magnitude of relative atomic mass (Ar) in amu. This is found on the periodic table. See the table below for other substances: It also can be represented using a formula. There are three types of formulas we use: Type of Molar mass Actual number of each Eg. C2H6 Particles Example Formula Molecular formula substance (g.mol-1) atom. Element Atoms Neon Ne 20 Simplest whole number ratio Eg.C1H3 → CH3 Empirical formula Covalent Usually Carbon 12+32 of the atoms. CO2 compound Molecules dioxide = 44 Shows how the atoms are Ionic Ions (formula 23+35,5 joined. Salt NaCl Structural formula compound units) = 58,5 Positive kernels Metallic and delocalized Gold Au 197 compound electrons EXAMPLE: EXAMPLE: EXAMPLE: EXAMPLE: What is the relative formula mass of Calcium sulphate (CaSO4)? What is the molar mass of What is the relative molecular mass of sucrose (C12H22O11)? What is the molar mass of MR (CaSO4) = AR (Ca) + AR (S)+ (4 x AR (O)) Calcium sulphate (CaSO4)? MR (C12H22O11) = 12 x AR (C) + 22 x AR (H)+ 11 x AR (O) sucrose(C12H22O11) ? = 40 + 32 + (4 x 16) 136 g.mol-1 = (12x 12) + (22x1) + (11 x 16) 342 g.mol-1 = 136 (no unit) = 342 (no unit) Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 45
Grade 10 Science Essentials Quantitative Aspects of Chemical Change SCIENCE CLINIC 2022 © Concentrations of solutions Molar Volumes of Gases Solutions are homogeneous (uniform) mixtures of two or more substances. A solution If different gases have the same volume under the same conditions of temperature and pressure, they will have the is formed when a solute dissolves in a solvent. same number of molecules. The solvent and solute can be a gas, liquid or solid. The most common solvent is liq- This is known as Avogadro’s Law: One mole of any gas occupies the same volume at the same tempera- uid water. This is called an aqueous solution. ture and pressure. Solution Solute Solvent salt water Salt water Soda water Carbon dioxide water Concentration The concentration of a solution is the number of mole of solute per unit vol- ume of solution. number of moles (mol) n concentration (mol ⋅ dm-3) c= volume (dm3) V The molar volume of a gas, VM, is the volume occupied by one mole of the gas. can also be calculated with VM for all gases at STP is 22.4 dm3·mol−1. m c= MV Standard Temperature and Pressure (STP) is 273 K (0°C) and 1,01x105 Pa. i.e. The number moles of solute per 1 dm3 of solu- Note: This also means that for reactions at constant temperature and pressure, gas volumes will react in the same ratio as tion i.e. mol. dm-3. If a solution of potassium per- 1000 cm3 = 1 dm3 (= 1 litre) the molar ratio. manganate KMnO4 has a concentration of 2 mol.dm-3 it means that for every 1 dm3 of solution, 1 cm3 = 0,001 dm3 1 cm3 = 1 ml N2 + 2O2 → 2NO2 there are 2 moles of KMnO4 dissolved in the solvent. 1 mol + 2 mol → 2 mol EXAMPLE: EXAMPLE: A solution contains 10 g of sodium hy- Calculate the mass of solute in 600 cm3 1 dm3 + 2 dm3 → 2 dm3 droxide, NaOH, in 200 cm3 of solution. Calculate the concentration of the solu- of 1,5 mol·dm-3 sodium chloride solu- tion. V volume of gaseous substance (dm3) tion. V = 600 cm3 = 0,6 dm3 number of moles (mol) n= VM m n(NaOH) = M 10 = 23 + 16 + 1 M(NaCl) = 23 + 35,5 molar gas volume at STP (22,4 dm3·mol−1) = 0,25 mol = 58,5 g ⋅ mol− 1 V = 200 cm3 = 0,2 dm3 n = cV EXAMPLE: A gas jar with a volume of 224 cm3 is full of chlorine gas, at STP. How = 1,5 × 0,6 many moles of chlorine gas are there in the gas jar? n c(NaOH) = V = 0,9 mol V 0,25 n = VM = 0,2 m = nM = 0,224 = 1,25 mol ⋅ dm− 3 = 0,9 × 58,5 22,4 = 52,65 g = 0,01 m ol Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 46
Grade 10 Science Essentials Quantitative Aspects of Chemical Change SCIENCE CLINIC 2022 © Water of crystallization EXAMPLE: Calculating the Empirical Formula of a Compound from Mass Some ionic crystals trap a certain number of water 13,2 g of a sample of zinc sulphate, ZnSO4.xH2O, was molecules between the ions as they are forming. heated in a crucible. Calculate the number of moles of Empirical formula is the chemical formula of a compound that shows These water molecules are known as “Water of crys- water of crystallisation if 7.4 g of solid remained. the smallest whole number ratio of the atoms. tallization”. 1 . m(H2 O) = 13,2 g − 7,4 g Eg. Hydrated copper sulphate: CuSO4 · 5 H2O has 5 water molecules per formula = 5,8 g To calculate the empirical formula of a compound from mass: unit. When the hydrated salt crystals are heated, the water molecules evaporate off, leaving the anhy- m 1.Determine the mass of the elements. 2 . n(H2 O) = M drous salt behind. 2.Determine mol of each substance. 5,8 3.Simplify the atomic ratio. = 18 CuSO4 · 5 H2O(s) → CuSO4 (s) + 5 H2O(g) = 0,32 mol EXAMPLE: To calculate the number of moles of water of crystalli- m In a combustion reaction 0,48 g of magnesium ribbon is burnt. The amount of mag- zation: 3 . n(ZnSO4 ) = M nesium oxide produced is 0,80 g. 7,4 Calculate the empirical formula for magnesium oxide. 1. Calculate the mass of water that evaporated off. = 161 2. Calculate the moles of water. 3. Calculate the moles of anhydrous salt. = 0,046 mol Steps Magnesium Oxygen 4. Determine the ratio of water to anhydrous salt. Step 1: mol water 0.48 g 0.80 – 0.48 = 0.32 g 5. Write the formula for the hydrated salt. 4 . ratio = mol anhydrous salt Mass of element 0,32 n=m/M n=m/M = Step 2: Note: 0,046 = 0.48 / 24 = 0.32 / 16 Mol (divide by mass of 1 mol) The dot in the formula ( · ) between the = 0,02 mol = 0,02 mol = 1:7 salt and the water means that a light bond Step 3: is formed. It is NOT a multiplication dot. 5 . ∴ formula = Z nSO4 ⋅ 7H2O Atom ratio 1 1 (divide by smallest no in ratio) Calculating the Empirical Formula from Percentage Composition Empirical formula: MgO The empirical formula of a compound can also be found from its percentage composition. We assume that 100 g of the compound is analysed, then each percentage gives the mass of the element in grams in 100 g of the compound. EXAMPLE: An oxide of sulphur contains 40% sulphur and 60% oxygen by mass. Determine the empirical for- A sample of an oxide of copper contains 8 g of copper combined with 1 g of oxy- mula of this oxide of sulphur. gen. Find the empirical formula of the compound. Steps Sulphur Oxygen Step 1: 40 60 Steps Copper Oxygen % of element Step 1: 8g 1g Step 2: 40 60 Mass of element Mass of element (g) Step 2: n=m/M n=m/M Step 3: n=m/M n=m/M Mol = 8 / 63,5 = 1 / 16 Mol = 40 / 32 = 60 / 16 (divide by mass of 1 mol) = 0,126 mol = 0,0625 mol = 1,25 mol = 3,75 mol Step 3: 0,125/0,0625 0,0625/0,0625 Step 4: 1,25 / 1,25 3,75 /1,25 Atom ratio ≈2 =1 Smallest mol ratio =1 =3 (divide by smallest no in ratio) Empirical formula: Cu2O Empirical formula: SO3 Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 47
Grade 10 Science Essentials Quantitative Aspects of Chemical Change SCIENCE CLINIC 2022 © - The Essentials Calculating the Empirical Formula of a Compound from To calculate the number of moles of water of crystallization: Empirical formula is the chemical formula of a compound that shows the small- est whole number ratio of the atoms. 1. Calculate the mass of water that evaporated off 2. Calculate the moles of water 3. Calculate the moles of anhydrous salt Mass 4. Determine the ratio of water to anhydrous salt. 5. Write the formula for the hydrated salt. To calculate the empirical formula of a compound from mass: 1.Determine the mass of the elements 2.Determine mol of each substance 3.Simplify the atomic ratio Number of Mass of pure par,cles Molar mass (M) is defined as the mass substance (in grams) of one mole of particles # != ! 6,02×10!" != ! Solu,on Number of The mole is the same num- The concentration of a solution ber of particles or atoms in is the amount of solute per unit volume of solution. ! = !" moles 12,0 g of Carbon -12. ! != 22,4 The molar volume of a gas, Mv, is the volume occupied by one mole of Volume of gas the gas. at STP (in dm3) M v for all gases at STP is 22.4 dm3.mol-1. Standard Temperature and Pressure (STP) is 0°C and 101.3 kPa Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 48
Grade 10 Science Essentials Hydrosphere SCIENCE CLINIC 2022 © Water SYSTEMS OF THE EARTH Water exists in 3 forms: •Solid: snow caps at the poles, icebergs and permafrost •Liquid: surface water (oceans, lakes, dams, rivers) and ground water Systems influenced •Vapour: water vapour in the atmosphere by the ATMOSPHERE LITHOSPHERE BIOSPHERE HYDROSPHERE Water is important for: •All living organisms depend on water → cells consist mainly of water, substances in cells are suspended or dis- solved in water, substances are transported to and from cells in water Hard crust of the earth, •Drinking water, habitat, photosynthesis. All gaseous Components of semi-solid rocks, hot All living organisms on •Cooking, cleaning, manufacturing processes, agriculture etc. components of the system liquid rocks and molten earth earth iron core HYDROSPHERE •The water cycle (also known as hydrosphere) describes the continuous movement of water through the ground (lithosphere), living organisms (biosphere) and the atmosphere. Processes Evaporation, Surface run-off and Photosynthesis, •Importance of water cycle influenced by condensation and percolation metabolism etc. -Water is recycled water precipitation -Water is purified CLOUDS Energy from the sun Precipitation filters Water is essential for all causes water to through the soil. A living organisms. Plants Condensa8on evaporate and form certain portion flows Precipita8on water vapour which across the surface as require water for Water droplets Water vapour collects and Description condenses to form run-off and the other photosynthesis, animals and humans require become too heavy droplets form which s.ck clouds and becomes portion seeps deeper water for metabolism together and form clouds too heavy and falls to into underwater rivers. and fall to the earth the earth as Water collects in lakes, and various other intracellular processes. precipitation. dams and oceans. Water vapour Precipita.on: Rain, hail, snow Transpira8on Evapora8on INFLUENCE OF DAMS Water is released Liquid water is Environmental Influence from plants and converted to a vapour •Flooding in surrounding areas → affects the plant and animal life evaporates •A dam has a large surface area resulting in increased evaporation which may affect the local OCEANS, LAKES, climate in the area DAMS, RIVERS, •Erosion and deepening of rivers due to initial emptying of rivers and periodical release of wa- PLANTS STREAMS ter from the dam •Silting up of dams Surface run-off •Altering of temperature of water in dam due to large surface area Water runs over the surface of •Fish migration is prevented the ground •Dams provide water for agricultural use SOIL Surface and ground water •Dams produce water used in households and various industrial processes •Production of hydroelectricity Percola8on Water filters through the Economical Influence ground and collects in •Cost of buying private land to build the dam on underground streams and dams •Cost of building the dam •Cost of buying electricity (energy) to run the dam Follow us on Instagram: @science.clinic Visit www.scienceclinic.co.za to download a free copy of these SmartPrep summaries, or to join interactive online Maths & Science classes. Page 49
