Downloaded from hlayiso.com ELECTRICAL TECHNOLOGY: POWER SYSTEMS EXAMINATION GUIDELINES GRADE 12 2021 These guidelines consist of 23 pages. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 2 DBE/2021 Examination Guidelines TABLE OF CONTENTS Page 1. INTRODUCTION 3 2. ASSESSMENT IN GRADE 12 4 3. ELABORATION OF CONTENT FOR GRADE 12 (CAPS) 6 4. PREPARING LEARNERS FOR THE NSC: ELECTRICAL TECHNOLOGY 17 5. FORMULA SHEET: POWER SYSTEMS 22 6. CONCLUSION 23 Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 3 DBE/2021 Examination Guidelines 1. INTRODUCTION The Curriculum and Assessment Policy Statement (CAPS) for Electrical Technology: Power Systems outlines the nature and purpose of the subject Electrical Technology. This guides the philosophy underlying the teaching and assessment of the subject in Grade 12. The purpose of these Examination Guidelines is to:  Provide clarity on the depth and scope of the content to be assessed in the Grade 12 National Senior Certificate (NSC) Examination in Electrical Technology.  Assist teachers to adequately prepare learners for the NSC examinations. This document deals with the final Grade 12 external examinations. It does not deal in any depth with the School-based Assessment (SBA), Performance Assessment Tasks (PATs) or final external practical examinations as these are clarified in a separate PAT document which is updated annually. These Examination Guidelines should be read in conjunction with:  The National Curriculum Statement (NCS) Curriculum and Assessment Policy Statement (CAPS): Electrical Technology  The National Protocol of Assessment: An addendum to the policy document, the National Senior Certificate: A qualification at Level 4 on the National Qualifications Framework (NQF), regarding the National Protocol for Assessment (Grades R–12)  The national policy pertaining to the programme and promotion requirements of the National Curriculum Statement, Grades R–12 Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 4 DBE/2021 Examination Guidelines 2. ASSESSMENT IN GRADE 12 2.1 Structure/Format of the Question Paper: QUESTION TOPIC MARKS TIME GENERIC – ALL 1 Multiple-choice Questions 15 14 min. 2 Occupational Health and Safety 10 9 min. GENERIC – POWER SYSTEMS and ELECTRONICS 3 RLC Circuits 35 32 min. SPECIFIC 4 Three-phase AC Generation 35 31 min. 5 Three-phase Transformers 30 27 min. 6 Three-phase Motors and Starters 35 31 min. 7 Programmable Logic Controllers 40 36 min. TOTAL 200 180 min. 2.2 Cognitive Levels Bloom's Taxonomy consists of six levels, as shown below. DESCRIPTION OF SKILLS LEVEL EXPLANATION ACTION VERBS COGNITIVE LEVEL DEMONSTRATED The learner creates new  Generating devise, predict, invent, ideas and information  Planning propose, construct, using the knowledge  Producing generate, make, previously learned or at  Designing develop, formulate, hand. At the extended  Inventing improve, plan, design, abstract level, the learner  Devising produce, forecast, makes connections, not  Making compile, originate, only within the given imagine CREATING 4 subject area, but also beyond it and generalises and transfers the principles and ideas underlying the specific instance. The learner works with relationships and abstract ideas. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 5 DBE/2021 Examination Guidelines DESCRIPTION OF SKILLS LEVEL EXPLANATION ACTION VERBS COGNITIVE LEVEL DEMONSTRATED The learner makes  Checking combine, integrate, decisions based on in-  Hypothesising modify, rearrange, depth reflection, criticism  Critiquing substitute, compare, and assessment. The  Experimenting prepare, generalise, learner works at the  Judging rewrite, categorise, EVALUATING 4 extended abstract level.  Testing combine, compile,  Detecting reconstruct, organise, justify, argue, prioritise,  Monitoring judge, rate, validate, reject, appraise, rank, decide, criticise The learner appreciates  Organising analyse, separate, the significance of the  Comparing order, explain, parts in relation to the  Deconstructing connect, classify, whole. Various aspects of  Attributing arrange, divide, the knowledge become  Outlining compare, select, infer, integrated, the learner  Finding break down, contrast, shows a deeper  Structuring distinguish, draw, ANALYSING 3 understanding and the illustrate, identify,  Integrating ability to break down a outline, point out, whole into its component relate, question, parts. Elements appraise, argue, embedded in a whole are defend, debate, identified and the relations criticise, probe, among the elements are examine, investigate, recognised. experiment The learner has the ability  Implementing apply, demonstrate, to use (or apply)  Carrying out calculate, complete, knowledge and skills in  Using illustrate, show, solve, other familiar situations  Executing examine, modify, and new situations. relate, change, APPLYING classify, experiment, discover, construct, manipulate, prepare, produce, draw, make, compile, compute, 2 sequence, interpret The learner grasps the  Exemplifying summarise, describe, meaning of information by  Comparing interpret, calculate, interpreting and  Explaining contrast, associate, UNDERSTANDING translating what has been  Inferring distinguish, estimate, learned.  Classifying differentiate, discuss, AND ROUTINE extend, comprehend, APPLICATIONS convert, explain, give example, rewrite, infer, review, observe, give main idea The learner is able to  Recognising list, define, tell, recall, remember and  Listing describe, identify, restate facts and other  Describing show, know, label, REMEMBERING 1 learned information.  Identifying collect, select,  Retrieving reproduce, match,  Recalling recognise, examine,  Naming quote, name Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 6 DBE/2021 Examination Guidelines BASIC SKILLS LINKED TO THE SUBJECT: The following skills are measured in the question paper. Visibility of these skills gives an indication of the overall skills required in the subject:  Ability to follow instructions  Identifying labels/labelling/making drawings/diagrams/schematic representations  Plotting and interpretation of graphs/data  Working out and interpreting calculations ‚  Organising/Recording and categorising data  Extraction and/or manipulation and/or evaluation of data  Explaining functional operation of circuits and/or components NOTE: CALCULATIONS WAVEFORMS/FLOWCHARTS/CIRCUITS Generally the criteria used for calculations are as Waveforms will be assessed according to the follows: following criteria:  Correct formula  Type of waveform (input/output)  Substitution of values  Correct labelling  Simplifying of values  Correct plotting of values (correct  Answer and correct units values, proportional plotting)  Labelling and units on Y-axis  Labelling and units on X-axis  Phase relationship 3. ELABORATION OF CONTENT FOR GRADE 12 (CAPS) TOPIC PRESCRIBED CONTENT MARKS Multiple-choice Covers all content 15 Occupational OHS Act, 1993 (Act 85 of 1993) health and  Definitions safety  Purpose of the Act  General duties of employers to their employees  General duties of employers and self-employed persons to persons other than their employees  General duties of manufacturers and others regarding articles and substances for use at work  Duty to inform  General duties of employees at work  Duty not to interfere with, damage or misuse devices/items  Functions of health and safety representatives  Report to inspector regarding certain incidents  Victimisation forbidden  Offences, penalties and special orders of court Safety Revision  Unsafe actions  Unsafe conditions  Dangerous practices  Risk analysis  Human rights in the workplace  Work ethics  Revision of emergency procedures (Grade 10) 10 Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 7 DBE/2021 Examination Guidelines RLC circuits  Effect of alternating current on R, L and C components in series and (generic) parallel circuits.  Describe/Define/Explain the following concepts and terminologies of RLC series and parallel circuits in words (not formulae):  Impedance  Inductive reactance  Capacitive reactance  Power factor  Phase angle  True power,  Resonant frequency  Q-factor  Bandwidth  Calculating the following in RLC series and parallel circuits containing ONE resistor, ONE capacitor and ONE inductor:  Frequency  Inductance  Inductive reactance  Capacitance  Capacitive reactance  Impedance  True power  Power factor  Phase angle  Voltage drop  Total current  Capacitive current  Inductive current  Q-factor  Bandwidth  Resonant frequency  Drawing of the phasor and wave representation of RLC circuits  Applications of RLC circuits  Conditions of series and parallel resonant circuits  Drawing of phasor diagrams of series, parallel and resonant circuits  Drawing of the characteristics curve and phasor diagram of resonant circuits  Illustrate the effect of changing frequency in an RLC circuit toward resonance Calculations  Series RLC circuits containing ONE resistor, ONE capacitor and ONE inductor  Parallel RLC circuits containing ONE resistor, ONE capacitor and ONE inductor (35) Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 8 DBE/2021 Examination Guidelines Three phase AC Principle of three-phase AC generation generation  Distribution networks – (outline generation network to distribution (specific) network)  Generation  Transmission  Distribution  Advantages of three phase over single phase  Disadvantages of single phase over three phase  Waveform of single- and three-phase systems  Know how to draw a fully labelled waveform of a three-phase system  The labelling of a waveform should be according to universally adopted sequence which is R.Y.B  Phasor diagram of single- and three-phase systems  Phasor diagram of a single- and three-phase systems  Know how to draw a fully labelled phasor diagram for a three- phase systems  Show phase angles.  Show the direction of rotation Three Phase Systems (3ϕ)  Star connection and symbol  Delta connection and symbol  Delta vs. Star (Know difference between the two)  Schematic (sketch without indication of components)  Diagrammatic (sketch with components) representations of three- phase systems.(overview of distribution network, power station to end users)  Only balanced loads Power in Three-phase (3ɸ) Systems and Calculations  Describe/Define/Explain the following:  Active Power  Reactive Power  Apparent Power  Calculations  Active power (True power) P = 3 × V ×L IL × Cos θ  Reactive Power Q ( PR ) = 3 × VL × IL × Sin θ s  Papp  = 3  VL  IL  Apparent Power NOTE: Know power formula as the formula sheet is the guide not all formulae are there. Manipulation of formulae is key to the calculations in this section Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 9 DBE/2021 Examination Guidelines Introduction to Star and Delta Calculations Star  Line voltage and current VL = 3 VPH and IL = IPH Delta  Line voltage and current VL = VPH and IL = 3 IPH  Losses  Efficiency output power Input - losses η  100% or η   100% input power input power Importance of power factor correction for consumers and suppliers: No calculation Only Application of Meters in Three Phase (3ϕ)  Wattmeter  kWh meter (Energy meter)  Power factor meter  Two- and three-wattmeter connection/method  Calculation of two- and three-wattmeter  Methods of connections 35 Three-phase Introduction of three-phase transformers transformer  Principle of operation and connections of three-phase transformers (specific)  Describe/Explain the principle of operation of three-phase transformer in the correct order of processes.  Connection of three-phase transformer o Delta/star o Star/star o Star/delta o Delta/delta  Concept, explanation and understanding of losses  Copper losses (IR2): Losses due to the resistance of the wire.  Iron losses (core losses): Heat losses occurring due to the hysteresis of the core and eddy current o Eddy current o Hysteresis losses  Conceptual meaning of losses  Sources of heat generation in a transformer  Factors contributing to heat  Three-phase transformers compared to single-phase transformers  Comparison of single-phase transformers and three-phase transformers  Application of delta/star connection transformers  Construction of transformers  Know the types of the transformer construction  The comparison between the types of transformers  Application of transformers  Know and understand the : o Application of a transformer o The main function of a transformer Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 10 DBE/2021 Examination Guidelines  Cooling  Understand the cooling methods  Safety  Know the importance of safety in the workshop when working with a transformer  Protection  Identify/Describe/Explain the use of the protection devices in transformers Calculations (Balanced Loads only)  Know, understand and apply the formula to :  Calculate the: o Transformation ratio o Number of turns o Line and Phase current, voltage and power o Know how to manipulate the formula  Power factor o Define/Explain power factor  Power o Know the calculations of power  Load including losses and efficiency o Know how to describe/Explain losses in transformers o Calculate efficiency 30 Three-phase Introduction to Three-phase (3ϕ) Motors motors and  Three-phase squirrel-cage induction motor starters (specific)  Know and Understand : o How to read and interpret the details on the name plate of the motor o The purpose of three phase squirrel-cage induction motor o Explain the function/use of starter to start the induction motor  Principle of operation  Explain and know the function of each parts of squirrel-cage motor  Describe/Explain the operation of three-phase squirrel-cage induction motor  Know how the rotating magnetic field is produced or created  Construction  Describe the construction of a squirrel-cage motor  Explain and know the function of each parts of squirrel-cage motor  Advantages  Know and understand the: o Advantages of three phase squirrel-cage induction motor compared to single-phase motor.  Applications  State where to use the induction motor  Calculations on slip, power and efficiency  Describe/Explain the conceptual meaning of the following: o Slip o Efficiency o Power Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 11 DBE/2021 Examination Guidelines  Know the calculation of : o Slip – revs per minute: S  ns  nr ns  nr S o Per unit slip: ns ns  nr S  100% o Percentage slip: ns o Efficiency o Power NOTE: Know and understand all the formulae as the formula sheet is the guideline and not all formulae are there  Understand the:  Relationship of speed vs torque  How the maximum torque is determined  Characteristic curve of torque vs speed Synchronous Speed  What is synchronous speed? Knowledge and understanding the:  Conceptual meaning of synchronous speed  The equation of calculating synchronous speed  Relationship between synchronous speed and generated power Electrical and Mechanical Aspects of Three-phase (3ϕ) Motors  Fault-finding/Troubleshooting  Motor testing. Know and understand the  Insulation resistance test  Continuity test  Loose connection test  Bearing test  Commissioning. The process involved in preparing the motor and starter to be used by the operator  Understand the checklist for commissioning a new installed motor. Understand the starting of an electrical induction motor 3Φ Direct-on-line Starter with Overload  Function of components on diagrams  Identifying the components from the given circuit diagram  Know the description of each components  Describe/Explain the function of the starter  Principle of operation  Describe/Explain the operation of direct-on-line motor starter  Diagram  Identifying the control circuit  Know how to draw the circuit diagram  Wiring on a panel  Understand the wiring and working of the panel  Calculation of the overload value and setting of the overload  Calculate the power at full load. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 12 DBE/2021 Examination Guidelines 3Φ Forward and Reverse Starter with Overload  Function of components on diagrams  Know all the components and their description.  Know the function of each component in the starter circuit.  Principle of operation  Know and understand: o In chronological order describe/explain the 3Φ forward and reverse starter with overload o How the direction of rotation of three-phase motors can be reversed  Diagram  Identifying the control circuit  Know how to draw the circuit diagram  Wiring on a panel  Understand the wiring and working of the panel  Explain the direction of rotation of a three-phase motor  Calculation of the overload value and setting of the overload 3Φ Sequence Motor Control Starter with Overload (Without Timer)  Function of components on diagrams  Know all the components and their description  Know the function of each component  Principle of operation:  Describe/Explain the operation of 3Φ sequence motor control starter with overload  Diagram  Identifying the type of the control circuit  Know how to draw the circuit diagram  Wiring on a panel 3Φ Sequence Motor Control Starter with Overload (With Timer)  Function of components on diagrams  Know all the components and their description  Know the function of each component  Principle of operation  Describe/Explain the sequential operation of 3Φ sequence motor control starter with overload (with timer)  Diagram  Identifying the type of the control circuit  Know how to draw the circuit diagram  Wiring on a panel Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 13 DBE/2021 Examination Guidelines 3Φ Automatic Star Delta Starter with Overload  Function of components on diagrams  Know all the components and their description  Know the function of each component.  Principle of operation  In chronological order the operation of 3Φ automatic star delta starter with overload  Diagram  Identifying the control circuit  Know how to draw the circuit diagram  Wiring on a panel  Understand the wiring and working of the panel  Calculation of the overload value and setting of the overload Programmable Introduction to the Programmable Logic Control Device logic controllers  History of the PLC (PLCs) (specific)  Method used for automated control for industrial production and processes at the time before PLC where developed.  Disadvantages of using relays for automated control as compared to PLCs  Know and understand why the PLC's where developed  Hard wiring vs. Soft wiring, know and understand the:  Conceptual meaning of hard wiring and soft wiring  Advantage of soft wiring vs hard wiring  Disadvantage of hard wiring vs soft wiring  Conceptual meaning of each advantage and disadvantage of hard wiring and soft wiring  The programmed scan cycle of a PLC  Steps that a PLC undergo to complete one programmed scan cycle (input scan, process scan and output scan)  Sequential operation of the PLC  Safety measures to be considered during programming of the PLC PLC Software and Devices Difference between analogue and digital/discrete inputs  Know and understand the conceptual meaning of:  Analogue input  Digital input  Know the importance of converting:  Analogue input to digital input  Digital output into analogue output Logic gates and truth tables of AND, OR, NAND, NOT, NOR inputs to a PLC (Digital) (Can this be removed)  Relate either the given logic gate symbol, the truth table and the ladder diagram to:  Truth table  Ladder logic diagram  Symbol Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 14 DBE/2021 Examination Guidelines Input devices to PLC  Examples of:  Switches as input devices o Push button (N/O) and (N/C) o N/O and N/C contacts/switch  Sensors as input devices o Proximity sensor o Temperature sensor o Light sensor o Level sensor o Overload sensor Know the application/use of each sensor as input devices to PLC:  Proximity  Temperature  Light  Level  Overload Outputs on a PLC  Transistor/Relay  Operation of transistor/relays  Contactors/relays:  Operation of contactors/relays (revision)  Correct symbols as used in: o Hard wiring and o Soft wiring circuit  Timers:  The purpose of timers as used in the operation of a PLC's logic circuit  Explaining/describing the following: o On delay timer contact o Off delay timer contact  Know when each timer contact is applied to the PLC logic circuit  Know and use the symbols of on delay and off delay timer contact in the PLC's logic circuit  Explain/Describe the sequential operation of the ladder logic diagram with timer function  Latching concepts (retaining circuits):  Identification of the 'latching/retaining' circuit in a control circuit  Understanding the use/function of the latching circuit  Interlocking:  Conceptual meaning of interlocking as used in the control circuit  Correct symbols used for interlocking  Markers/Flags (Memory elements): Purpose of markers as used in the ladder logic diagram Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 15 DBE/2021 Examination Guidelines  Conversion of hard-wired schematics (Control circuits) to ladder logic and labelling of symbols (motor starters only)  Identify the type of the control circuit to be converted  Know how to draw: o The power rails of the ladder logic diagram o Rungs with input and outputs between the power rails of the ladder logic diagram  Know the function of each components as in the control circuits  Know the sequence in which ladder logic operate NOTE: Use the Engineering Graphics and Design (EGD) approach and not crude freehand drawings and that ladder logic circuit is drawn from left to right and operate from top to bottom. Applications of PLCs: The PLC as a motor starter  The variable speed drive (VSD) as a programmable motor controller (concepts only)  Know and understand the function of VSD as used in motors  Explain/describe the positive effect of applying VSD in motors Basic principle of operation  Input to VSD,  Output of VSD to the motor  Relationship between the speed of an AC motor and the frequency supplied to the motor  Introduction to VSD, know and understand the following:  Part (sections) of the VSD, namely: o Rectifier circuit o Filter circuit o Inverting circuit  Understand how the switches functions  Understand the effect the switching time has on the output waveform and the frequency  Function of each part  Sequential operation of the VSD  Methods of speed control  The V/Hz  Vector drives  Conception understanding of V/Hz and vector drive  Basic block diagram  Types of motors used with a VSD  Know the types of motors used with a VSD and where they are used. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 16 DBE/2021 Examination Guidelines (40)  Regenerative braking  Conceptual understanding of the term regenerative breaking  Understand the conversion from one form of energy to another during the braking process  Conceptual understanding of the term regenerative energy  Purpose of the braking resistor as used in the motor control circuit  Examples of regenerative braking  Know and understand the diagram showing how regenerative braking is applied to a motor control circuit  Basic applications of VSD  Application of VSD  Safety aspects to consider in the application of VSD  Start-up and run profiles (with applications) (programming – optional)  Characteristics curve of speed vs torque  Understand the relationship between speed and torque  Know and understand the speed range of (e.g. breakdown speed)  Characteristics curve of current vs torque  Understand the relationship between current and torque 200 Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 17 DBE/2021 Examination Guidelines 4. PREPARING LEARNERS FOR THE NSC: ELECTRICAL TECHNOLOGY Learners do not intuitively know how to answer a question paper successfully. Teachers need to prepare learners to have the skills needed to negotiate a question paper successfully. This preparation process starts in Grade 10 and culminates in Grade 12. Learners need to be coached in some of the following skills, which will help them in answering the question paper effectively: Manipulation of formulae: The learners must learn how to use the standard formula, manipulate the formula correctly, correctly substitute values and remember to always add a value/unit with an answer. Prefixes and units: Learners must have a clear understanding of the conversion and uses of units and abbreviations, such as kilo, milli, micro, nano, etc. Teachers should drill leaners on this skill. Learners must be taught on how to approach a question paper and ANSWER BOOK. Planning the answers: Learners must know how to answer in a chronological order of sequence and know how much space should be taken up by a typical answer. Do not break questions up and answer it haphazardly out of order. Ensure the numbering convention in the question paper is followed in the ANSWER BOOK. Open spaces in the ANSWER BOOK: Teachers should encourage learners to answer ALL questions, including subquestions, and not leaving open spaces. Even when learners are unsure of the expected response, they are urged to answer to the best of their ability. This may lead their train of thoughts in the correct direction leading the learner to a correct or partially correct answer. Where learners leave an open space to proceed with the question paper, they should be taught to return to that space when the rest of the question paper is completed. Teachers are urged to pay attention to Bloom's Taxonomy and should prepare learners to answer basic recall questions as well as more complex and intricate sentence-type questions, e.g. the paragraph- type answers such as the operation of a transformer. Learners should be coached to regularly read questions and answers to homework and tests aloud in the class. Teachers must encourage learners to engage in intelligent debate and discussion around subject content and on how an answer should be constructed. Learners must know how to structure their sentences in order to communicate what they are trying to say. Learners must learn how to list facts. Answers are assessed on the principle of a single mark for a single fact. Teachers must show the learners the difference between a sketch, a symbol and what a block diagram represents. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 18 DBE/2021 Examination Guidelines Below is an example of a sketch. It was drawn freehand and is a resemblance of a real-world device. Marks are awarded for drawings WITH LABELS. A drawing cannot be assessed without labels. FIGURE 1: SKETCH Symbols: Symbols are simple representations of electronic devices and relates to the theory of how the device works and not necessarily to the appearance of the device. Without labelling and a title, it cannot be marked effectively.    The NPN transistor NOTE: The symbol must be drawn correctly and then 1 mark will be awarded for every correct label. FIGURE 2: SYMBOL AND HOW IT IS MARKED Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 19 DBE/2021 Examination Guidelines Block diagrams: Block diagrams are used extensively in Electrical Technology. It usually relates to processes and how devices operate. They are representative of the operation of a system/device and may not contain any physical resemblance to the device. Note that block diagrams may be given semi-complete, requiring the learner to fill or complete the other sections.    FIGURE 3: BLOCK DIAGRAM All sketches, symbols, diagrams and waveforms must always be labelled and have a caption. Learners must be shown how to interpret and use waveforms to support their answers. Ladder logic: Ladder logic diagrams must be labelled and have each of the operands identified.       FIGURE 4: LADDER LOGIC Sketches, diagrams and waveforms should be clear, not too small and easily interpretable. Guard against small and illegible drawings. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 20 DBE/2021 Examination Guidelines Circuit diagrams: Circuit diagrams are marked on the following premise:  The circuit or portion of the circuit must be correct.  All components must have labels.  Note that whole circuits or portions of a circuit may be given and interrogated.          FIGURE 5: CIRCUIT DIAGRAM Calculations: Calculations should be done showing ALL steps. Values must be placed correctly. Units allocated to the calculation must be shown. Wrong units will result in the answer being marked wrong. No units will result in the answer being marked wrong. It is good practice to draw a line underneath the final answer ending it in a small arrow. This indicates that the calculation is done. 1 Fr   2 LC 1   2 0.15 x 47 x10 6  59.94 Hz  FIGURE 6: A CALCULATION AND HOW TO MARK IT Lines must be drawn between questions. Rough work should be labelled as rough work and have a line drawn through it. Power factor (Cosθ): When using the power factor, learners should note whether they are given the power factor or the phase angle. Learners use the power factor as an angle, resulting in their answers being incorrect. Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 21 DBE/2021 Examination Guidelines Phasor diagrams should always include an arrow showing its direction of rotation. As a phasor is a rotating vector and always rotates anticlockwise, it is required of learners to show this when doing graphical representations of phasors.    Direction of rotation  FIGURE 7: PHASOR DIAGRAM Input and output waveforms: It is common in Electrical Technology to enquire from the learner what the result of an input waveform in a circuit may have on the output of the circuit. This is because the principle of input, process, output forms the cornerstone of how electric and electronic circuits operate. By placing input and output waveforms directly underneath each other, in a synchronised fashion, the manner in which a circuit will affect a waveform is easily illustrated. The same applies to digital circuits.         FIGURE 8: INPUT AND OUTPUT WAVEFORMS Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 22 DBE/2021 Examination Guidelines 5. FORMULA SHEET: POWER SYSTEMS NOTE: This formula sheet is only a guide and may not contain ALL the formulae as in the prescribed textbook and/or CAPS policy document. FORMULA SHEET THREE-PHASE AC GENERATION RLC CIRCUIT 1 STAR XL = 2fL and Xc = 2fC VL = 3 VPH and VPH = IPH × ZPH 1 FO = IL = IPH 2π LC DELTA SERIES VL = VPH and IL = 3 × IPH IT = IR = IC = IL VPH = IPH × ZPH Z = R2 + (XL XC )2 POWER VL = I XL and VC = I XC ( ) S Papp = 3 × VL × IL VT = I Z and VT = VR2 + (VL VC )2 Q ( PR ) = 3 × VL × IL × Sin θ VT IT = Z P R Cos θ = Cos θ = S Z P = 3 × V ×L IL × Cos θ VR Cos θ = VT TWO-WATTMETER METHOD XL XC VL VC 1 L P = P1 + P2 Q= = = = = Z Z VS VS R C PARALLEL THREE-PHASE TRANSFORMERS VT = VR = VC = VL STAR VL = 3 VPH and IL = IPH VR VC VL IR = and IC = and IL = R XC XL DELTA IL = 3 IPH and VL = VPH IT = IR 2 + (IL IC )2 I POWER Cosθ = R IT ( ) S Papp = 3 × VL × IL Q XL X C IL IC 1 L     Z Z IS IS R C Q ( PR ) = 3 × VL × IL × Sin θ P Cos θ = S Copyright reserved Please turn over

Downloaded from hlayiso.com Electrical Technology: Power Systems 23 DBE/2021 Examination Guidelines 6. CONCLUSION It is envisaged that these Examination Guidelines will serve as an instrument to strengthen and empower teachers to set valid and reliable assessment items in all their classroom activities. This Examination Guidelines document is meant to articulate the assessment aspirations espoused in the CAPS document. It is therefore not a substitute for the CAPS document which teachers should teach to. Qualitative curriculum coverage as enunciated in the CAPS cannot be over-emphasised. Copyright reserved
