INSTRUCTIONS AND INFORMATION
1. This question paper consists of FOUR questions.
2. Answer ALL the questions.
3. ALL drawings are in first-angle orthographic projection, unless otherwise stated.
4. ALL drawings must be completed using instruments, unless otherwise stated.
5. ALL answers must be drawn accurately and neatly.
6. ALL the questions must be answered on the QUESTION PAPER as instructed.
7. ALL the pages must be re-stapled in numerical sequence, irrespective of
whether the question was attempted.
8. Time management is essential in order to complete all the questions.
9. Print your examination number in the block provided on every page.
10. Any details or dimensions not given must be assumed in good proportion.
NATIONAL
SENIOR CERTIFICATE
FOR OFFICIAL USE ONLY
QUESTION MARKS OBTAINED ½ SIGN MODERATED ½ SIGN
GRADE 12 1
2
3
ENGINEERING GRAPHICS AND DESIGN P1 4
NOVEMBER 2012 TOTAL
2 0 0 2 0 0
MARKS: 100
FINAL CONVERTED MARK CHECKED BY
TIME: 3 hours
_______
100
COMPLETE THE FOLLOWING:
This question paper consists of 6 pages. CENTRE NUMBER
CENTRE NUMBER
EXAMINATION NUMBER
EXAMINATION NUMBER
BASIC-EDUCATION
Copyright reserved
Please turn over
