Downloaded from hlayiso.com INSTRUCTIONS AND INFORMATION 1. This question paper consists of FOUR questions. 2. Answer ALL the questions. 3. ALL drawings are in first-angle orthographic projection, unless otherwise stated. 4. ALL drawings must be completed using instruments, unless otherwise stated. 5. ALL answers must be drawn accurately and neatly. 6. ALL the questions must be answered on the QUESTION PAPER as instructed. 7. ALL the pages must be re-stapled in numerical sequence, irrespective of whether the question was attempted. 8. Time management is essential in order to complete all the questions. 9. Print your examination number in the block provided on every page. 10. Any details or dimensions not given must be assumed in good proportion. NATIONAL SENIOR CERTIFICATE FOR OFFICIAL USE ONLY QUESTION MARKS OBTAINED ½ SIGN MODERATED ½ SIGN GRADE 12 1 2 3 ENGINEERING GRAPHICS AND DESIGN P1 4 NOVEMBER 2013 TOTAL 2 0 0 2 0 0 MARKS: 100 FINAL CONVERTED MARK CHECKED BY TIME: 3 hours _______ 100 COMPLETE THE FOLLOWING: This question paper consists of 6 pages. CENTRE NUMBER CENTRE NUMBER EXAMINATION NUMBER EXAMINATION NUMBER *BASIC-EDUCATION* Copyright reserved Please turn over

Engineering Graphics and Design/P1 Download DBE/November 2013 ELECTRICAL ‘SUPPLY E7245 v9) NOTE: Contractors must verify all dimensions and levels on site before commencing work. Architects to be notified immediately of any discrepancies. QUESTION 1: ANALYTICAL (CIVIL) Given: The site plan for a proposed new guest house, a title panel and a table of questions. The drawing has not been prepared to the indicated scale. Instructions: Copyright reserved BAS TC. FE DUGAT 43.0] 8900 a5 ; Complete the table below by neatly answering the questions, which all refer to the accompanying drawing and 19. In the space below, draw, in Gs 5 title panel [30] 1500 BL neat freehand, the front view SAND and top view of the SANS 10143 g| venous sat gtaphical symbol. (convention) QUESTIONS ANSWERS /© existing for a SINGLE KITCHEN SINK. / OUTBUILDING 1 | How many revisions have been made to the drawing? 1 7 an 4 ! ! 2 | How many signatures are required on the site plan? 1 i i mo | 3. | What is the project number? 1 \ \ ! ! 4 | How wide Is the motor vehicle entrance in metres? 1 i i f H 5 | What does the abbreviation MH stand for? 1 ' Lo n\n a 6 | How high is the security fence in metres? 1 , PROPOSED NEW ba4--54-p-4 GUEST HOUSE ve J 7 | What does the feature at 1 indicate? 1 8 | What does the line at 2 indicate? 1 REE a NEW SEPTIC TANK aii 9 | Name the feature at 3. 1 TAND BUILT TO 3 . as sENOneeRS, 8 (2) |ascnitecrs stonarure 10 | What does the number at 4 indicate? 1 — CLIENTS SIGNATURE 11 | What does the line at 5 indicate? 1 XY 42 | |f'scale 1 : 50 was used for the site plan, what would the 1 avocano dimension at 6 read? 13 | What is the reference number of the electrical supply? 1 2 |2013.06-12| septic tank | 14 | What type of tree is found on the stand? 1 + |o013-0525| priveway __ | 15 | In what SI unit are the dimensions? 1 16 | Is corner C of stand 1435 higher or lower than Titren Road? 2 ~ REVISION DATE DESCRIPTION &| a, One 47 | What is the shortest distance in metres from the proposed 2 “| 8 new guest house to Titren Road? Fa PROPOSED NEW GUEST HOUSE - — - - FOR MR R VAN DER LINDE ON If the side of the existing house that faces Titren Road is the use. STAND 1435 AT 5 TITREN ROAD 4g | South-west elevation, draw, in the space provided below the 4 ster tauK (5) | SEAVIEW. site plan and in neat freehand, a correctly orientated 4 SANS 10143 north-point symbol AND SOAK PIT 7521 PRINTED BY DATE OF PRINT Pi ud STAND 1 4 STAND SPEEDPRINT 2013-07-01 In the space provided in the title panel, draw, in neat 1436 \ 1434. | ORAWNG TE 19 | freehand, the front view and top view of the SANS 10143 4 scone. SITE PLAN graphical symbol (convention) for a single kitchen sink. - S 20 | In the space below, determine the perimeter of the new guest 3 D 27000 Cj house in metres. es a PROUECT NOWEER DRAWING NOWBER MUNICIPAL * 114 903 10500 secu OO HGH TS SERVITUDE ANSWER 18 REFERENCE CODE DRAWN BY DATE ANSWER 20 nn TOTAL | 30 EN i ee nee re on Q1P1-Nov-2013_| JASON _2013.03-14] Show ALL calculations. NEW GUEST El SOE GHECKEDEY DATE 3 House | % SITE PLAN 1:200 MINK! 2013-03-18 s| q SCALE 1 : 200 CM ARCHITECTS XQ 21ST FLOOR THE SQUARE 40500 | (320 SMITH STREET DURBAN 17000. EXAMINATION NUMBER Tet: 031 352 6709/9 EXAMINATION NUMBER: [2 ° Please tum over

Engineering Graphics and Design/P1 Downloaded from hlayiso.com — Copyright reserved EAS ee DAT LON QUESTION 2: INTERPENETRATION AND DEVELOPMENT Given: © The incomplete front view and top view of a right square prism that has been shaped to fit around a right equilateral triangular prism. The axes of both prisms lie in a common vertical plane. © The auxiliary views of the square prism. Instructions: Draw, to scale 1 : 1, the following: 2.1. The given top view 2.2. The complete front view clearly showing the curve of interpenetration 2.3. The development of the surface of the square prism. Make AB the seam * Show ALL hidden detail Show ALL necessary construction and fold lines [33] AB IS THE SEAM. ASSESSMENT CRITERIA 4 | TOP VIEW Th 2 | FRONT VIEW 14 3 | DEVELOPMENT 11% TOTAL 33 EXAMINATION NUMBER EXAMINATION NUMBER [3 Please tum over

Engineering Graphics and Design/P1 Downloaded from hlayiso.com — QUESTION 3: PERSPECTIVE Given: Two views of a recreational area and the information needed to draw a two-point perspective drawing. PP ~ Picture plane HL - Horizon line GL - Ground line SP - Station point Instructions: Complete the perspective drawing * Align the drawing sheet with the ground line (GL) © Determine and label the vanishing points. * Show ALL necessary construction. NO hidden detail is required. [41] PP HL GL STEP | FIREPIT | ASSESSMENT CRITERIA 1 | CONSTRUCTION + VPs 7 + 2 | WALLS 13% SP 3 | BUILDING + ROOF 9 4] ARCH+CONSTR'+PIT | 11% Copyright reserved BAS TC» £0UCAT LON TOTAL 41 EXAMINATION NUMBER EXAMINATION NUMBER [4 Please tum over

D Engineering Graphics and Design/P1 DOOR AND WINDOW SCHEDULE fn 2000 H TOFIT 1 500 ‘500 425. £25 Re S \ ‘ rg : : P 7 i WINDOW (W1) NOTE: 175 x 20 FIBRE CEMENT -L___ FRONT AND LEFT VIEW OF FRONT DOOR FRAME WITH SIDE PANELS (D2) SILL UNDER ALL WINDOWS TOFIT 2100 2100 i LL FRONT DOOR (02) INTERNAL DOOR AND FRAME (D1) ROOF COMPONENTS: 75 x 50 PURLINS xX =< L] 200 x 20 FASCIA BOARD. 114 x 38 WALL PLATE 125 x 100 GUTTER ownloaded from hlayiso.com 200 x 20 BARGE BOARD 125 x 100 GUTTER 2100 mm RWDP W1 WINDOW 2100 2100 FRONT DOOR FLOOR LEVEL GROUND LEVEL FIXTURES Dt INTERIOR DOOR OPENINGS D2 FRONT DOOR OPENING W1 WINDOW OPENINGS we TOILET WB WASHBASIN BIC BUILT-IN CUPBOARD ELECTRICAL FITTINGS 4. SINGLE-POLE LIGHT SWITCH 2. CEILING LIGHT 3.2x 40 W FLUORESCENT TUBES. 4, SWITCH SOCKET OUTLET NOTE: THE ARROW SHOWS THE LIGHT CONNECTION TO THE SWITCH. ROOF NOTES: ROOF COVER 15 mm CORRUGATED IRON ON 75 x 50 mm PURLINS @ 1800 cic 114 x 38 mm ROOF TRUSSES ON 114 x 38 mm WALL PLATES. ROOF PITCH 20° WITH 200 x 20 mm FASCIA BOARD ON BOTH ENDS 125 x 100 mm GUTTER ON BOTH ENDS PLASTER CEILING BOARD ON 6 STRIPS OF 38 x 38 mm BRANDERING, EVENLY | ore) 850 780 400 6 S = S aA «& e4 [Ss WASHBASIN (WB) TOILET (WC) x Kk CJ TOFIT 7 BUILT-IN CUPBOARD (BIG) ROOF CAP 300 SPACED a ELECTRICAL SANITARY FIXTURES SYMBOLS 450 2600 400 500 py | 500 < INCOMPLETE FOUNDATION AND EXTERNAL WALL DETAIL 700 GROUND LEVEL Copyright reserved Bl _ Sani 3s SOUTH-EAST ELEVATION Re ror-stnt ae ee —_ | 4 i WB Wc. | 3 | [- | | o4 * = | Fl 3g —k 2-——2 | q aH] | 52 | a t | | | | | | ! EQUAL —= 71 2» |-—— SIDE OPENING BIC 3 | HEIGHT 2700 FROM 2 GROUND LEVEL SCHEMATIC DIAGRAM OF A ROOF TRUSS 4100 50, 500 INCOMPLETE FOUNDATION AND INTERNAL WALL DETAIL BAS TC. FE DUGAT ° FLOOR FINISH ROOM 1: CARPET ROOM2; CARPET TOILET: wood RECEPTION: WOOD T TOWLET ROOM RECEPTION Trouser ROOM2 ROOM DESIGNATIONS WITH FLOOR FINISHES. DBE/November 2013 QUESTION 4: CIVIL DRAWING Given: «The complete south-east elevation of new consulting rooms, showing the walls, the window, the front door, the roof and notes © The incomplete floor plan, showing the walls, position of the windows, doors, fixtures and the electrical fittings Roof notes and a schematic diagram of a roof truss «Incomplete foundation and wall detail The floor finishes and a diagram showing the room designations * A door and window schedule * A table of roof components © A table of electrical symbols * A table of sanitary fixtures The incomplete floor plan of the new consulting rooms, drawn to scale 1 : 50, on page 6 Instructions: * Answer this question on page 6. Using the given incomplete floor plan, draw, in first-angle orthographic projection and to scale 1 : 50, the following views of the new consulting rooms: 4.1 The complete floor plan 4.2 A sectional elevation on cutting plane A-A 4.3 The north-east elevation *ALL drawings must comply with the guidelines and graphical symbols contained in the SANS 10143. SPECIFICATIONS: THE FLOOR PLAN Add the following features to the drawing: ALL doors and windows ALL the sanitary fixtures as indicated by the abbreviations © ALL the electrical fittings as indicated by the numbers * ALL hatching detail THE SECTIONAL ELEVATION Show the following features on the drawing: * The complete foundation, wall, slab, roof and celling detail * The window detail, with a double lintel, and the door detail © The sanitary fixtures * ALL hatching detail THE NORTH-EAST ELEVATION Show the following features on the drawing: © The outside walls and finished floor level *The roof detail, including the gutter, fascia board and rain-water downpipe © The window detail Label the following: The room designations with floor finishes « The sectional elevation and north-east elevation Using the correct abbreviations, label the following features in the correct view: ground level and damp-proof course. NOTE: * ALL substructure hatching may be drawn in freehand. [96] Bl Please tum over

° ee Downloaded from hlayiso.com — ASSESSMENT CRITERIA FLOOR PLAN oe + Juses 4 vr T a | 1 | [2 [pecrmen 4 | t I | [3 [rmnes 6 | [+ [ities | 14 | | | [5 [paren 3 Al | | SUBTOTAL 38 | | A \A SECTIONAL ELEVATION | | | 4 | Roo 16 | ——— | a eee a 3 | wnoow | | | 4 | uses | | I 5 | HaTcHING | ———ie | 6 | rxrures I I I SUBTOTAL 42 | | | NORTH-EAST ELEVATION | | J Cy | (jwise [os l l l ROOF + | | | 2 | cutters 5 | | 3 | | | 7 | 3 | wnoow 5 RWDP | 5 | 4 | ses 1 | | IRWDP| SUBTOTAL 16 Loe toe ROOF LINE _-_ | TOTAL 96 FLOOR PLAN EXAMINATION NUMBER: SCALE 1:50 HN ———e— I Copyright reserved
