Engineering Graphics and Design Grade 12 2012 QP

Downloaded from hlayiso.com Engineering Graphics and Design/P1 EC DoE/SEPTEMBER 2012 Ss Cag ° QUESTION 3: PERSPECTIVE Given: A plan and an elevation of a house, as well as the Picture Plane (PP), Horizon Line (HL), Ground Line (GL) and Station Point (SP). Instructions: © Determine the vanishing points and label them. © Draw the two point perspective view of the model Notes: No hidden detail must be shown. Show all the construction lines. 138] ASSESSMENT CRITERIA Vanishing points and labels | 4 Constructions 5 Roof 12 Walls 8 Door 3 Windows 6 TOTAL | 38 PP PP HL HL GL + NAME NAME t/ Copyright reserved Please tum over
