Engineering Graphics and Design Grade 12 2013 QP

Downloaded from hlayiso.com INSTRUCTIONS AND INFORMATION 1. The question paper consists of FOUR questions. 2. Answer ALL the questions. 3. All drawings must be drawn to scale 1:1, unless stated otherwise. 4. The questions must be answered on the answer sheets provided. 5. All the answer sheets must be re-stapled in numerical sequence and handed in irrespective of whether the question was answered or not. 6. Careful time management is essential in order to complete all the questions. ISEBE LEMFUNDO LEMPUMA KOLONI 7. Print your name in the block provided on every answer sheet. EASTERN CAPE EDUCATION DEPARTMENT 8. All answers must be drawn accurately and neatly. OOS-KAAP ONDERWYSDEPARTEMENT 9. Any detail or dimensions not given must be assumed in good proportion. FOR OFFICIAL USE ONLY NATIONAL MODERATED MARK SENIOR CERTIFICATE 1 2 3 4 TOTAL GRADE 12 2 0 0 FINAL CONVERTED CHECKED BY MARK ENGINEERING GRAPHICS AND DESIGN P1 SEPTEMBER 2013 100 TRIAL EXAMINATIONS COMPLETE THE FOLLOWING: NAME NAME MARKS: 200 EXAMINATION CENTRE TIME: 3 hours EXAMINATION CENTRE This question paper consists of 6 pages. Copyright reserved Please turn over 1
