Downloaded from hlayiso.com Province of the uceegoy EASTERN CAPE EDUCATION NATIONAL SENIOR CERTIFICATE ENGINEERING GRAPHICS AND DESIGN P1 SEPTEMBER 2021 PREPARATORY EXAMINATION MARKS: 200 TIME: 3 hours This question paper consists of 6 pages. Copyright reserved INSTRUCTIONS AND INFORMATION agen Se ene The question paper consists of FOUR questions Answer ALL the questions. All drawings must be drawn to scale 1 : 1, unless otherwise stated. The questions must be answered on the answer sheets provided. All the answer sheets must be re-stapled in numerical sequence and handed respective of whether the question was attempted or not. Careful time management is essential in order to complete all the questions Print your name in the block provided on every ANSWER SHEET. All answers must be drawn accurately and neatly. Any details or dimensions not given, must be estimated In good proportion. ALL drawings are in first angle orthographic projection, unless stated otherwise. FOR OFFICIAL USE ONLY MODERATED MARK WwW) NM) — TOTAL 2/0/0 2/0/0 FINAL CONVERTED CHECKED BY MARK 100 COMPLETE THE FOLLOWING: NAME NAME EXAMINATION CENTRE EXAMINATION CENTRE Please turn over 1
