Downloaded from hlayiso.com NATIONAL SENIOR CERTIFICATE GRADE 11 NOVEMBER 2017 INFORMATION TECHNOLOGY P2 MARKING GUIDELINE MARKS: 150 This marking guideline consists of 10 pages.

Downloaded from hlayiso.com 2 INFORMATION TECHNOLOGY P2 (EC/NOVEMBER 2017) QUESTION 1 1.1.1 B  It is very fast compared to RAM. (1) 1.1.2 C  You will increase the level of efficiency (1) 1.1.3 A  a coding error (1) 1.1.4 D  Virtual Private Network (1) 1.1.5 B  HTML5 (1) 1.1.6 D  Images (1) 1.1.7 B  Rich Internet Application (1) 1.1.8 B  Currency (1) 1.1.9 D  Can adapt to user needs and preferences. (1) 1.1.10 B  Capturing and entering data in a database (1) 1.2.1 POST  (1) 1.2.2 RAID  (1) 1.2.3 Streaming  (1) 1.2.4 Field  (1) 1.2.5 Entity Relationship Diagrams (ERD)  (1) [15] Copyright reserved Please turn over

Downloaded from hlayiso.com (EC/NOVEMBER 2017) INFORMATION TECHNOLOGY P2 3 QUESTION 2 2.1 2.1.1 Intel  (1) 2.1.2 2.00 GHz  (1) 2.2 2.2.1 Graphic Processing Unit  – This processor processes graphics and videos  (2) 2.2.2 Fetch, Decode, Execute, Transfer  (4) 2.3 2.3.1 ROM  (1) 2.3.2 Firmware is software  that is permanently installed on ROM chips used to control the basic operation of a device.  (2) 2.3.3 Newer features,  Security updates  Bug Fixes  (3) 2.3.4 Wiping all existing contents and replacing with an updated version.  (1) 2.4 2.4.1 Virtualisation is creating an entity that only exists in software  (1) 2.4.2 Step 1 – Install the main operating system  Step 2 – Install the virtual machine software  Step 3 – Install the different operating software on the virtual machine  Step 4 – Install the app on the virtual operating software  Step 5 – Repeat step 3 to 5 many for each operating system you want to test.  (5) [21] Copyright reserved Please turn over

Downloaded from hlayiso.com 4 INFORMATION TECHNOLOGY P2 (EC/NOVEMBER 2017) QUESTION 3 3.1 3.1.1 Any TWO of   To share resources  To share data  To communicate  Entertainment (2) 3.1.2 Any TWO of   Purchasing the network cabling and file servers can be expensive.  Managing a large network is complicated, requires training and a network manager usually needs to be employed.  If the file server breaks down the files on the file server become inaccessible. E-mail might still work if it is on a separate server. The computers can still be used but are isolated.  Viruses can spread to other computers throughout a computer network.  There is a danger of hacking, particularly with wide area networks. Security procedures are needed to prevent such abuse, e.g. a firewall (2) 3.1.3 Advantages (any TWO)   Faster speeds  Reliable  More secure (2) 3.2 3.2.1 3G  and ADSL  (2) 3.2.2 Any ONE of   WiMax is faster  WiMax has bigger bandwidth. (1) 3.2.3 A Router  (1) 3.3 3.3.1 Voice Over Internet Protocol  (1) 3.3.2 Any TWO   Skype  Viber  Whatsapp call  Facebook messenger, etc. (2) Copyright reserved Please turn over

Downloaded from hlayiso.com (EC/NOVEMBER 2017) INFORMATION TECHNOLOGY P2 5 3.4 3.4.1 They generally include (ANY TWO)   A touchscreen interface and  Multiple sensors such as gps,  Accelerometer,  Gyroscope, etc. (2) 3.4.2 ANY THREE of,   Android  Windows CE  Windows Mobile  iOs  Blackberry OS, etc. (3) 3.4.3 It refers to software or programs designed to run on portable devices.  (1) 3.4.4 Any TWO of   They need to transfer less data leading to faster speeds.  They give users a better interface and more control over what they can do.  They allow users to receive automatic updates and notifications when content on the web is changed or added. (2) 3.5 3.5.1 Protocol  A set of rules for encoding and decoding data for transmission across networks  (2) 3.5.2 HTTPS is a protocol used for secure encrypted communication over the internet.  (1) 3.6 3.6.1 RSS is a web or news feed that automatically provides users with updated content or notifications of new content. This content can then be accessed from a central application without having to check each website separately.  (1) 3.6.2 Any ONE of   To be alerted to new blog entries on blogs that you subscribe to.  To be informed of items that match the search criteria you have set to track searches on websites such as Google, Bing and Yahoo.  To keep track of new video clips on YouTube channels that you have subscribed to.  To be alerted to new music on iTunes.  To be alerted whenever your name or your company’s name pops up in web searches. (1) [26] Copyright reserved Please turn over

Downloaded from hlayiso.com 6 INFORMATION TECHNOLOGY P2 (EC/NOVEMBER 2017) QUESTION 4 4.1 4.1.1 (a) Any ONE of  CustomerID, OrderID, ProductID, UnitPrice, Quantity, Total (1) (b) Any one of  the rows in the table (1) (c) MyClientsTB  (1) 4.1.2 The field Total  it can be calculated  (2) 4.1.3 (a) It uniquely identifies each record  (1) (b) OrderID  (1) 4.2 4.2.1 (a) Distributed Databases are very big databases that are spread across servers in different locations.  (1) (b) You just need a small database in an office.  (1) 4.2.2 A desktop database  (1) 4.2.3 Any ONE of   Ms Access  Base  Filemaker Pro (1) 4.2.4 Yes it would be possible.  It allows many people to connect and make changes to the database at the same time.  (2) 4.3  Inserting or adding of new records.   Deleting records that are no longer required.   Updating or maintaining records to make sure that data is accurate.  (3) 4.4 4.4.1 A relational database containing many tables linked together through relationships.  (1) 4.4.2 Foreign keys are used to link  one table to another table.  (2) 4.4.3 A Customer orders Product CUSTOMER orders PRODUCT symbols  (5) [24] Copyright reserved Please turn over

Downloaded from hlayiso.com (EC/NOVEMBER 2017) INFORMATION TECHNOLOGY P2 7 QUESTION 5 5.1 5.1.1 It is a variable or an argument that is provided as input to a subroutine.  (1) 5.1.2 Return means that the function will produce a result.  (1) 5.1.3 Any acceptable simple function with parameter e.g. StrToInt(); IntToStr() (1) 5.1.4 A function returns a value  A procedure does not return a value  (2) 5.1.5 sSurname ← Get Surname  sPass ← ‘’ (blank string)  i ← length of sSurname  Loop from 1 to i  If sSurname[i]  is NOT a vowel  sPass ← sPass + SSurname[i] (creates new string) end Loop  (8) 5.2 5.2.1 The while loop is used because the length of the file is not initially known.  (1) 5.2.2 (a) the reset procedure opens a file given by FileHandle for read (1) (b) The Append procedure opens a file given by FileHandle to allow subsequent writes to add lines to the end of the file (1) (c) The AssignFile procedure assigns a value to FileHandle for a FileName in preparation for reading or writing to that file (1) 5.3 5.3.1 An array is a data structure that contains a group of variables containing values of the same type.  (1) 5.3.2 One of the variables in an array.  (1) 5.3.3 y x Index Result [3] [2] [1] - 5 0 - - - 1 2 1 - - - 0 1 2 - 0 - 1 0 3 1 - - (8) [25] Copyright reserved Please turn over

Downloaded from hlayiso.com 8 INFORMATION TECHNOLOGY P2 (EC/NOVEMBER 2017) QUESTION 6 6.1 6.1.1 An attempt to manipulate or ‘con’ someone into giving out sensitive personal information/data or installing malware.  (1) 6.1.2 Spoofing  – Using electronic technologies to fool people into believing that the communication is coming from another legitimate person or institution  OR Phishing Attempts from people, generally employing e-mails to direct people to fake websites, where they are tricked into releasing personal information. (2) 6.1.3 Any TWO of:   Guard your personal information.  Pay attention to the URL of the website you are on to at least see that its ‘legit.’  Use e-mail and web browser software that has anti-phishing features to warn you of potential phishing threats.  Any other acceptable answer. (2) 6.2 6.2.1 Location Based Computing  (1) 6.2.2 GPS  or 3G (1) 6.2.3 Advertising/Marketing  – Specific adverts depending on the location of the person can be sent/pushed to the device of the user.  (2) 6.2.4 (a) Basic data used to describe other data.  (2) (b) Geo tag  (1) 6.3 6.3.1 Internet is a worldwide computer network consisting of computers, devices and networks connecting to other networks.  (1) 6.3.2 IPTV: Delivers traditional television broadcasts over the internet  It is scheduled just like normal TV.  VOD: Viewers watch content or programs on demand Similar to a catch up service.  (4) 6.4 6.4.1 End-user Acceptable Use Policy documents outline the rights and responsibilities of users on a network.  (1) Copyright reserved Please turn over

Downloaded from hlayiso.com (EC/NOVEMBER 2017) INFORMATION TECHNOLOGY P2 9 6.4.2 Any TWO of   A code of conduct educating users and governing their behaviour when using the network or internet.  Details on where and when portable media such as flash drives may be used.  Details on restrictions on installing or uninstalling software.  Clear consequences of violating conditions spelt out in the document.  Any other acceptable aspect. (2) 6.4.3 The network managers need to monitor what users do on the network.  When violations a detected, take clear, visible action against the offender.  (2) 6.5 6.5.1 Any THREE of  Have software programming skills  Have graphic design skills  Have creativity and imagination  Keep up to date with the advances in computer technology (3) 6.5.2 Any TWO of  Produce new content and write it in an interesting way  Source artwork and images to be used  Maintain ad update the website regularly (2) 6.5.3 No. He/she will have to learn some web programming or graphic design skills OR Yes, most web authors have these skills already before becoming authors. (2) 6.6 6.6.1 Any TWO of  Poorly written and designed software systems  Information overload and the need to verify information  Profitability  Availability of skilled people  Poor support infrastructure  Limiting government policies (2) 6.6.2 Any TWO of  Improving and enhancing the ability to communicate  Automating repetitive tasks  Collecting and mining data at an incredibly large scale  Increasing awareness  Making stores of information readily available (3) Copyright reserved Please turn over

Downloaded from hlayiso.com 10 INFORMATION TECHNOLOGY P2 (EC/NOVEMBER 2017) 6.7 6.7.1 Crowd-funding refers to situations where groups of people pool their money together, often via the Internet and organisations like Kickstarter who then use this money for projects they feel have merit.  (2) 6.7.2 Any THREE of   The effective exchange of information,  Global trade  Immigration  Critical technologies such as communications and transport (especially air transport). (3) [39] TOTAL: 150 Copyright reserved Please turn over
