Downloaded from hlayiso.com
2 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
INSTRUCTIONS AND INFORMATION
1. This question paper consists of:
SECTION A (25 marks)
SECTION B (75 marks)
SECTION C (50 marks)
2. Answer ALL the questions.
3. Number the answers correctly according to the numbering system used in
this question paper.
4. Start EACH question on a NEW page.
5. Do NOT write in the right-hand margin.
6. Leave a line between each sub-question.
7. In general, one mark is allocated per fact. A 2-mark question would
therefore require TWO facts, et cetera.
8. Write neatly and legibly.
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 3
SECTION A
QUESTION 1: MATCHING ITEMS
Choose a term/concept from COLUMN B that best matches a description in
COLUMN A. Write only the letter (A–P) next to the question number (1.1–1.10) in
the ANSWER BOOK, for example 1.11 Q.
COLUMN A COLUMN B
1.1 A test to determine whether it is a human being A CSV
interacting with the computer
1.2 Additional data stored about a file that describes B CPU
the contents of the file, such as the name of the
author
1.3 A unit used to describe the brightness of the image C DIGG
of a data projector
1.4 An example of an online storage facility or service D FAT
1.5 A text file which uses commas to separate the E CAPTCHA
values in each line
1.6 A table used internally by the operating system to F Dropbox
indicate the actual physical location of files on a
disk
1.7 A painful compression of the nerves in the wrist G En dash
caused by repetitive manual action, such as
keyboarding
1.8 A social news website featuring user-submitted H Metadata
news stories
1.9 The hardware component of the computer that I PDF
executes all the instructions of programs
1.10 A horizontal line a little longer than a hyphen used J CTS
to express ranges and parenthetical expressions
K Lumen
L RSI
M WAP
N Motherboard
O Intranet
P Em dash
(10 x 1) [10]
Copyright reserved Please turn over
Downloaded from hlayiso.com
4 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
QUESTION 2: MULTIPLE-CHOICE QUESTIONS
Various options have been provided as possible answers to the following questions.
Choose the most appropriate answer and write only the letter (A–D) next to the
question number (2.1–2.10) in the ANSWER BOOK, for example 2.11 E.
2.1 The technology that is used to get information from different websites
automatically, is called …
A RSI.
B EULA.
C RSS.
D FAT. (1)
2.2 Which ONE of the following would be the most suitable for creating a library
management system?
A Word processor
B Database
C Spreadsheet
D Presentation program (1)
2.3 Which ONE of the following Internet websites does NOT require a password,
user name and/or pin code in order to use its functions?
A Facebook
B Internet banking site
C Twitter
D Wikipedia (1)
2.4 Many libraries save money by installing and using inexpensive networked
computers known as thin client computers. What main computer part do
these thin client computers often NOT have?
A Motherboard
B Hard drive
C Power supply
D RAM (1)
2.5 The school library promotes green computing. Which ONE of the following is
NOT directly associated with green computing?
A Recycling paper
B Sleep mode
C Security webcam
D Paperless office (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 5
2.6 A learner did a Google web search and found information on a web
page. Which ONE of the following would be the best option for the
bibliography?
A Gates, Bill. The future of technology.
http://microsoft.gates.htm. Accessed 20 October 2016.
B Google
C Gates, Bill. The future of technology.
D http://microsoft.gates.htm. Gates, Bill. The future of technology. (1)
2.7 A public location where wireless Internet access can be obtained for
mobile computers is called a ...
A Wi-Fi.
B Hot spot.
C MySpace.
D Cyber café. (1)
2.8 A code in Access which forces data capturers to enter data in a
specific format is known as a ...
A validation rule.
B primary key.
C input mask.
D validation text. (1)
2.9 Which ONE of the following specifications is the most likely to
indicate that a computer is a notebook?
A 1 TB HDD
B Touchpad
C Windows 10 Home (64 bit)
D USB 3.0 (1)
2.10 Which ONE of the following components forms an integral part of the
motherboard?
A DIMM slots
B DVD-ROM
C USB drivers
D HDD (1)
[10]
Copyright reserved Please turn over
Downloaded from hlayiso.com
6 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
QUESTION 3: TRUE/FALSE
Indicate whether the following statements are TRUE or FALSE. Choose the
answer and wrtie ‘true’ or ‘false’ next to the question number (3.1–3.5) in the
ANSWER BOOK. Correct the statement if it is FALSE. Change the
underlined word(s) to make the statement TRUE. (You may not simply use the
word ‘NOT’ to change the statement. NO mark will be awarded if only FALSE
is written down.)
EXAMPLES:
QUESTION ANSWER
Google is the world’s most popular True
search engine.
An NIC has slots for hardware False − motherboard
components such as the CPU.
3.1 File sharing is a system whereby the resources of different computers
are shared and used at the same time to solve a single problem. (1)
3.2 Aspect ratio is the number of steps between the darkest black and the
brightest white that a display device can produce. (1)
3.3 A patch is a collection of software updates over the past period of time
put into one big unit for easier installation. (1)
3.4 DOTX is the file extension for a Microsoft Word Template. (1)
3.5 A switch is a network device used to connect two or more networks to
each other. (1)
[5]
TOTAL SECTION A: 25
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 7
SECTION B
QUESTION 4: SYSTEM TECHNOLOGIES
4.1 The managers at Spar were given a choice to use one of the following
two devices to perform their tasks during the countrywide Angry Birds
competition.
DEVICE SPECIFICATIONS
Laptop - Intel Core i7 2.4 GHz CPU
- 8 GB RAM
- 1.5 TB HDD
Tablet - nVidia Tegra 1.2 GHz CP
- 1 GB RA
- 32 GB SSD
4.1.1 Give TWO reasons why the managers requested to be issued
with the laptop rather than the tablet. (2)
4.2 A tablet uses an SSD for the storage of data and files.
4.2.1 What does the acronym SSD stand for? (1)
4.2.2 List THREE comparative differences between the features and
performance of an SSD and an HDD in table format. (3)
4.2.3 Why have SSDs not completely replaced HDDs, even though
they have so many benefits? Do NOT refer to cost in your
answer. (1)
4.3 Both a tablet and a laptop use cache memory. Explain the purpose of
cache memory in a computer system. (3)
4.4 Give TWO reasons why a tablet and a laptop cannot use the same type
of RAM. (2)
4.5 The managers have been told that they can use FireWire 800 or
USB 3.0 to upload video material of the performances of contestants to
the competition’s website.
4.5.1 State TWO advantages of USB over FireWire. (2)
4.5.2 Would the software used for the editing of videos be considered
application software or system software? (1)
4.6 Cellular modems are used to connect to the Internet and upload the
results of the competition each week. The results are stored in a ‘cloud’.
4.6.1 Name the type of connection the modem will use with the
uploading of the results. (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
8 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
4.6.2 Explain what is meant by the term cloud in this context. (2)
4.7 Each week the managers have a group conference call to discuss
results and some of the outstanding performances. It is suggested that
they use VoIP in order to save costs.
4.7.1 Briefly explain the basic concept VoIP. (2)
4.7.2 Name a VoIP client that the managers could use to host the
conference call. (1)
4.7.3 Name ONE other way (besides a conference call), in which the
managers could have discussions and collaborate online. (1)
4.8 Identify the image below that appears on Spar’s newsletter AND explain
how it would be used, by referring to a suitable example.
(3)
[25]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 9
QUESTION 5: INTERNET AND NETWORK TECHNOLOGIES
5.1 Friends and family of the contestants requested the managers to e-mail
them the video footage as an attachment. Give TWO reasons why this
request is possibly not feasible. (2)
5.2 The managers made the videos available as podcasts.
5.2.1 Explain the concept of podcasting. (1)
5.2.2 Name TWO examples of an electronic medium that can be used
to inform friends and family when a new podcast is available. (2)
5.3 Friends and family who want to download multimedia files of all the
events, must preferably have a broadband Internet connection.
5.3.1 Explain the term broadband. (1)
5.3.2 ADSL is an example of a wired broadband connection.
(a) Is ADSL a digital or an analogue connection? (1)
(b) Give an example of another wired broadband connection. (1)
5.4 One of the managers is not familiar with using e-mail and has a few
questions regarding the e-mail window.
5.4.1 What is the function of the paperclip icon next to the “send”
icon? (1)
5.4.2 He noticed that there is an option between Plain Text and Rich
Text. Explain the difference between these two options. (2)
5.5 How does a social network such as Facebook make most of its money? (1)
5.6 Explain TWO advantages of e-books compared to printed versions of
books. (NOTE: Cost factors should NOT form part of your answer.) (2)
5.7 What is the purpose of the ‘History’ button or tab in a web browser? (1)
[15]
Copyright reserved Please turn over
Downloaded from hlayiso.com
10 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
QUESTION 6: INFORMATION MANAGEMENT
6.1 The regional manager of Spar has to coordinate a number of meetings
with local Spar managers regarding the competition. He has found that
there is a great deal of administration involved regarding the competition
and that it is quite difficult to set up these meetings.
6.1.1 Mention TWO ways an e-mail calendar function will help in this
context. (2)
6.1.2 The manager finds that he often has to scribble reminders of
tasks on slips of paper.
Give the general or generic name given to the e-mail function
that can be used to remind the user of tasks and the due dates
of these tasks. (1)
6.2 State TWO advantages of using electronic forms when gathering data in
a survey. (2)
6.3 Give ONE reason for using a table on a form to fill in numbers, such as
an ID number, as shown below.
(1)
6.4 State ONE feature of a spreadsheet that can be used to meaningfully
arrange large quantities of data. (1)
6.5 Give TWO examples where you would use a database instead of a
spreadsheet to process data. (2)
6.6 Briefly explain the concept of plagiarism. (1)
[10]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 11
QUESTION 7: SOCIAL IMPLICATONS
7.1 Name ONE legally acceptable use of a file-sharing application, such as
BitTorrent. (1)
7.2 Give your opinion regarding the following statement by giving TWO
reasons or examples to support your answer:
'The Internet offers its users some privacy.' (2)
7.3 Many cameras have the capability to ‘geotag’ photographs.
7.3.1 Explain the term geotagging. (1)
7.3.2 Why do some game reserves discourage visitors from placing
geotagged photographs of rhinos on social media? (1)
7.4 State ONE possible way of preventing other users from tagging you in
photographs on Facebook. (1)
7.5 State TWO advantages of cars that are connected to the Internet. (2)
7.6 State TWO typical ways in which your computer may be misused by
cybercriminals, if they use your computer as part of their botnet. (2)
[10]
Copyright reserved Please turn over
Downloaded from hlayiso.com
12 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
QUESTION 8: SOLUTION DEVELOPMENT
8.1 Some of the learners in your school are planning a field trip to a book fair.
Below is a spreadsheet of their budget.
8.1.1 In the calculation for the Total cost for transport, in cell C4, the
formula was: =B4*$E$1. The formula was then copied down
(Autofill) for the other items.
Name the TWO types of cell references used in the formula and
explain the difference between the two. (4)
8.1.2 When the data was formatted for currency, the $-sign appeared
instead of the R-sign.
Explain TWO ways in which this can be corrected. (2)
8.1.3 The pie chart represents the breakdown of costs for each learner
for the field trip.
Name THREE items that should be added to the pie chart, to make
it meaningful and easy to interpret. (3)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 13
8.2 Many modern businesses make use of databases.
8.2.1 Indicate in which section the function =Count(*) must be placed
in a database report, in order to count the number of records for
each group of records in the report. (1)
8.2.2 Identify the type of database object in which you are likely to find
the formula below.
Total:[Price]*[Quantity] (1)
8.2.3 The database formula VAT:[Price*0.14] currently produces an
error. Correct the formula for it to work properly. (1)
8.3 What is a citation in a document and when should it be used? (2)
8.4 Name the word processing feature that must first be used or applied,
before an automatic table of contents will work. (1)
[15]
TOTAL SECTION B: 75
Copyright reserved Please turn over
Downloaded from hlayiso.com
14 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
SECTION C
QUESTION 9: INTEGRATED SCENARIO
During the final round of the Idols competition the audience in the State Theatre
votes for contestants to determine a winner. They have been provided with
remote voting controllers that allow them to press a button to transmit their vote
wirelessly via Bluetooth technology to a local server at the Theatre.
9.1 Is Bluetooth a suitable technology to use in this scenario? Motivate your
answer. (2)
9.2 A member’s voting controller does not connect to the wireless network,
although the member is within range of the server.
Name TWO troubleshooting steps that can be followed to solve the
problem. Replacing the voting controller is not an option. (2)
9.3 The live broadcast of the final round of the event can be streamed.
9.3.1 Explain what is meant by streamed. (2)
9.3.2 Name TWO components that are required to be able to stream a
live event. (2)
9.3.3 State ONE potential disadvantage of using live streaming. (1)
9.3.4 Which type of software can be used for input by visually
impaired users? (1)
9.4 A cabled network is used at the event theatre to transmit the scores
electronically to the server. The organisers are planning to use a
wireless network for this purpose in future.
9.4.1 State TWO advantages of a wireless network over a cabled
network. (2)
9.4.2 State TWO additional hardware components that are required to
create the wireless network. (2)
9.4.3 Which upgraded version of Wi-Fi will be suitable to use for the
wireless network? (1)
9.4.4 Give TWO examples of what NFC (near field communication)
can be used for. (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 15
9.4.5 Describe TWO ways in which the organisers can prevent their
computers from being accessed by unauthorised software. (2)
9.4.6 What is the function of a driver? (1)
9.5 ICT provides more effective solutions for the capturing of data and
generating results than a paper-based voting system.
9.5.1 Motivate why the above statement is valid by referring to the
following TWO aspects:
(a) Faster and improved data processing (2)
(b) Improved data storage (2)
[24]
Copyright reserved Please turn over
Downloaded from hlayiso.com
16 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
QUESTION 10
The organisers of the Idols competition will be responsible for the accuracy of
all information, as well as to create surveys.
10.1 Explain the difference between a survey and an interview. (2)
10.2 Give TWO reasons why one should always check the reliability and
accuracy of information found on the Internet. (2)
10.3 Explain what information overload is. (1)
10.4 Which social networking service is associated with the term ‘hash-tags’? (1)
10.5 One of the organisers received the following e-mail, which was
supposedly sent by an official at Empire Bank. Examine the e-mail
carefully and answer the questions below.
From: Empire Bank [mailto:john@empirebank.co.za]
Sent: 17 May 02:38 PM
To: Sibu_100@gmail.com
Subject: Empire Bank Verification - Sibu_100@gmail.com
Dear valued Empire Bank Member
This e-mail was sent by the Empire Bank server to verify your e-mail
address. You must complete this process by clicking on the link below
and entering in the small window your Empire Bank and Password.
This is done for your protection. To verify your details, click on the link
below:
Click here to update your data.
10.5.1 What general name is given to this kind of scam? (1)
10.5.2 Should the organiser click on the link? Motivate your answer by
explaining what would happen if he did. (2)
10.5.3 What is the generic name given to techniques that rely on
convincing people to give out information or to grant access by
pretending to be someone who has the right to access this
information? (1)
10.5.4 Banks offer their online banking clients peace of mind by
providing a number of security measures designed to make
online banking as safe as possible.
Give TWO of these measures, besides the use of encryption. (2)
10.5.5 Briefly explain what a computer virus is by referring to TWO of
its general aims in your answer. (2)
10.5.6 What is a Trojan? (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) COMPUTER APPLICATIONS TECHNOLOGY P2 17
10.6 The organiser of the Idols has tried to create a basic website to
advertise the event for next year. Study the HTML code below.
<title>
Idols
<hr />
</title>
<body>
<h1> DATES FOR THE IDOLS AUDITIONS </h1>
<font colour=”red”>
</font> <br />
Auditions kick off in Cape Town!
</body>
Explain how you would correct the following mistakes:
10.6.1 The horizontal line is not displayed. (1)
10.6.2 The heading ‘DATES FOR THE IDOLS AUDITIONS’ should be
smaller. (1)
10.6.3 The text ‘Auditions kick off in Cape Town!’ should be displayed
in red font, but it is displayed in black. (1)
10.7 A database was created to keep track of the current entries for the
competition.
10.7.1 Study the screenshot below and name the data type that should
be used for the Specifications field to enter a large amount of
text.
(1)
10.7.2 Why is the AutoNumber data type always suitable to use for a
primary key field? (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
18 COMPUTER APPLICATIONS TECHNOLOGY P2 (EC/SEPTEMBER 2017)
10.7.3 The query below was designed to show all the names that start
with an S, and the age is either less than 20 or more than 30.
Identify TWO errors in the design of this query that are causing
it to display the incorrect information. (2)
10.8 Briefly explain what each of the following would be used for in a word
processing application:
10.8.1 Continuous section break (2)
10.8.2 Bookmark (1)
[26]
TOTAL SECTION C: 50
GRAND TOTAL: 150
Copyright reserved Please turn over
Downloaded from hlayiso.com
Downloaded from hlayiso.com
Downloaded from hlayiso.com
Downloaded from hlayiso.com
Downloaded from hlayiso.com
Downloaded from hlayiso.com
Study this subject
Recommended for this subject

Question paper
Computer Applications Technology Grade 12 P2 2022 QP (Eng)

Question paper
Computer Applications Technology Grade 12 P2 2022 QP (Eng)

Question paper
Computer Applications Technology Grade 12 P2 2021 QP (Eng)

Question paper
Computer Applications Technology Grade 12 P2 2020 QP (Eng)

Memorandum
Computer Applications Technology Grade 12 P2 2019 Memo (Eng)

Question paper
Computer Applications Technology Grade 12 P1 2020 QP (Eng)
More from Grade 12 Computer Applications Technology

Memorandum
Computer Applications Technology Grade 12 P1 2025 Memo (Eng)

Memorandum
Computer Applications Technology Grade 12 P2 2025 Memo (Afr)

Memorandum
Computer Applications Technology Grade 12 P1 2025 Memo (Eng)

Memorandum
Computer Applications Technology Grade 12 P1 2024 Memo (Eng)

Memorandum
Computer Applications Technology Grade 12 P2 2024 Memo (Eng)

Errata
