Information Technology Grade 12 Paper 1 KZN Prelim 2020 Memo

Downloaded from hlayiso.com TRIAL EXAMINATION SEPTEMBER 2020 MARKING GUIDELINES & MEMORANDUM INFORMATION TECHNOLOGY P1 MARKS: 150 EXAMINERS : Mr N Brijlal Mrs S Bramdaw TIME: 3 hours MODERATOR: Ms EC Moodley This Memorandum consists of 14 pages. Page 1 of 14

Downloaded from hlayiso.com QUESTION 1 QN Description Max Learner 1.1 Correctly assigns property settings in panel: Panel Caption : ‘Welcome to Rainbow Tours’ ✓ Panel Color: clYellow✓ Panel Font Style: [fsBold] ✓ Panel Font Size: 16✓ Loading Image : Use of correct code : ImgPic.Picture.LoadFromFile ✓ 7 Correct Image file loaded : 'Rainbow.jpg' ✓ Property set : ImgPic.Stretch := true; ✓ 1.2 Extracts the amount from the edit ✓ Use of Case/Selection statement ✓ Assigning exchange rate values to corresponding option selected ✓✓ Calculation of Rand Value : rAmount * rRate ✓ 7 Display Rand Value Amount✓ in Currency Format ✓ 1.3 Initialise counters✓ Extract password from the edit✓ Find length of the password ✓ Set up string scan loop ✓ Check if single character ✓ is in given list ✓ then increment counter1 ✓ Check if single character is a numeric digit ✓ then increment counter2 ✓ After loop check if password contains : ten characters ✓ AND three or more special characters ✓AND three or more numeric digits ✓ then display confirmation message ✓ 14 else display message indicating password invalid ✓ 1.4 Follow algorithm given : Initialise all variables ✓ Start outer loop bound by the number of months ✓ Randomly generate the number ✓ Initialise the string variable ✓ Start inner loop bound by the randomly generated value ✓ Generate stars and create a new string ✓ Close inner Loop Display month number✓, stars✓ as well as how many stars ✓ Calculate Total Nights booked for the year ✓ 13 Close outer loop Display Total Nights ✓ Calculate Total Cost ✓ Display Total Cost ✓ SUB-TOTAL 41 Page 2 of 14

Downloaded from hlayiso.com POSSIBLE SOLUTION (Q1): 1.1 procedure TForm1.FormCreate(Sender: TObject); begin pnlQu1_1.Caption := 'Welcome to Rainbow Tours';  pnlQu1_1.Color := clYellow;  pnlQu1_1.Font.Style := [fsBold];  pnlQu1_1.Font.size := 16;  ImgPic.Picture.LoadFromFile ('Rainbow.jpg');  ImgPic.Stretch := true;  end; (7) 1.2 procedure TForm1.btnQu1_2Click(Sender: TObject); var rAmount, rRandValue, rRate: real; begin rAmount := strToFloat(edtAmount.Text);  case cmbCurrency.ItemIndex of  0: rRate := 16.46; 1: rRate := 21.16; 2: rRate := 19.27;  3: rRate := 0.22; end; rRandValue := rAmount * rRate;  edtRandValue.Text := floatToStrF (rRandValue, ffCurrency, 6, 2);  end; (7) 1.3 procedure TForm1.btnQu1_3Click(Sender: TObject); var iChar, k, iNum, iLen: integer; scode: string; begin iChar := 0; iNum := 0;  scode := edtPassword.Text;  iLen := length(scode);  for k := 1 to iLen do  begin if scode[k]  in ['*', '?', '#', '%'] then inc(iChar);  if (scode[k]) in ['0' .. '9'] then  inc(iNum);  end; if (iLen = 10) and (iChar >= 3)  and (iNum >= 3) then ShowMessage('Valid Password')  Page 3 of 14

Downloaded from hlayiso.com else ShowMessage('Invalid Password');  end; (14) 1.4 procedure TForm1.btnQu1_4Click(Sender: TObject); var iRan, iNights, k, l: integer; sStars: string; rTotal: real; begin // Given Code - Do NOT Alter ! redDisplay.clear; redDisplay.Paragraph.tabcount := 1; redDisplay.Paragraph.tab[0] := 50; redDisplay.Lines.add('Month' + #9 + 'No of Nights'); rTotal := 0; iNights := 0;  for k := 1 to 12 do  begin sStars := '';  iRan := Random(20)+1;  for l := 1 to iRan do  begin sStars := sStars + '*';  end; redDisplay.Lines.add(inttostr(k)  + #9 + sStars + inttostr(iRan));  iNights := iNights + iRan;  end; rTotal := iNights * 450;  redDisplay.Lines.add('Total No of Nights booked: ' + inttostr(iNights));  redDisplay.Lines.add('Total Income for the year: ' + floatToStrF(rTotal, ffCurrency, 7, 2));  end; (14) TOTAL QUESTION 1 : 41 Page 4 of 14

Downloaded from hlayiso.com QUESTION 2 2.1 : SQL statements 2.1.1 sSQL := 'Select GuestName, GuestSurname, DepositAmount From tblAccom  Where DepositAmount between 2000 and 3000';  (4) 2.1.2 sSQL := 'Select AccomName,AccomType,StarRating From tblRates Where len (StarRating) >=3';  (4) 2.1.3 sSQL := 'Select Count(*) as [Number of guests with NO deposit]  from tblAccom Where Depositpaid = false  and YEAR (DateIn) = 2019'; (5) 2.1.4 sSQL := 'Select AccomName, SUM (DateOut-DateIn)  As [No of days Booked]  From tblAccom,tblRates  Where tblAccom.AccomID = tblRates.AccomID  Group by  AccomName';  (7) ALTERNATIVE SOLUTIONS 2.1.1 sSQL := 'Select GuestName, GuestSurname, DepositAmount From tblAccom  Where DepositAmount >= 2000  and DepositAmount <= 3000';  2.2 Code Construct QN Description Max Learner 2.2.1 Sets ado-table to first record ✓ Loops through table ✓ Extracts first 2 digits of ID number(year of birth) ✓ Adds the century to the year of birth ✓ Use current year✓ to calculate age ✓ 8 Displays details with calculated age ✓ Moves to next record ✓ End loop 2.2.2 Sets ado-table to first record Loops through table ✓ Sets ado-table to edit mode ✓ Finds the position of key words (“Country” , “Guest”) in accommodation name ✓ If “Country” ✓found or “Guest” ✓Found Update ✓the rate field using appropriate formula✓ 10 Commit the transaction ✓ Move to next record ✓ End loop Display confirmation message ✓ Page 5 of 14

Downloaded from hlayiso.com POSSIBLE SOLUTION (Q2.2): 2.2.1 procedure TfrmQuestion2.btn2_2_1Click(Sender: TObject); var sDriverTel: String; iAge,iYr : integer; sYear,sY : string; begin //Provided code - DO NOT CHANGE redQ2.SelAttributes.Style := [fsBold]; redQ2.Lines.Add('Name'+#9+'Surname'+#9+' Age'); // QUESTION 2.2.1 tblAccom.Open; tblAccom.First;  iYr := StrToInt(copy(IntToStr(CurrentYear),3)); while not tblAccom.Eof do  begin sYear := copy(tblAccom['GuestIDNo'],1,2);  if StrToInt(sYear) > iYr then begin sYear := '19'+sYear;  end else begin sYear := '20'+sYear; end; iAge := CurrentYear-StrToInt(sYear);  redQ2.Lines.Add(tblAccom['GuestName']+#9+tblAccom['GuestSurname']+#9+ IntToStr(iAge));  tblAccom.Next;  end; end; (8) Page 6 of 14

Downloaded from hlayiso.com 2.2.2 procedure TfrmQuestion2.btn2_2_2Click(Sender: TObject); var iPos1, iPos2 : integer; begin // QUESTION 2.2.2 tblRates.First; while not TblRates.Eof do  begin tblRates.Edit;  iPos1 := Pos('Country',tblRates['AccomType'] );  iPos2 := Pos('Guest',tblRates['AccomType']); if (iPos1 > 0)  OR (iPos2 >0) then begin tblRates['Ratepernight']  := tblRates['Ratepernight']*1.05;  end; tblRates.Post;  tblRates.Refresh; tblRates.Next;  end; ShowMessage('Updated Completed !');  end; (10) TOTAL QUESTION 2 : 38 Page 7 of 14

Downloaded from hlayiso.com QUESTION 3 3.1 Object Class QN Description Max Learner 3.1.1 Constructor header correct (including parameters) ✓ String attributes set correctly ✓ Integer attributes set correctly ✓ Calculate the Total Cost attribute✓ using rate value passed 5 Assigning Discount attribute to zero✓ 3.1.2 Extract the month✓ from the Date attribute ✓ Check if month✓ is one ✓of the designated months✓ then assign a discount /percentage ✓ set Discount ✓attribute to calculated value✓ based on discount 9 value/percentage ✓ 3.1.3 Procedure header correct (including parameter) ✓ 3 Update Total Cost✓ attribute by subtracting discount ✓ 3.1.4 Function header correct (including return type) ✓ 2 Returns the Discount ✓ attribute 3.1.5 Displays the correct captions ✓ With corresponding attribute values✓ On separate lines (using token) Correct conversions for : 5 Number of people attribute ✓ Discount attribute ✓ Total Cost attribute ✓ 3.2.1 Extracts tour date and number in group from components ✓ Extracts search destination from Combo Box✓ Check if file exists✓ then Links logical and physical files✓ Opens file for reading✓ Sets up loop ✓ Reads a line from textfile ✓ Locates the position of destination in the line ✓ If destination found then (using string handling) Isolates booking number ✓ Isolates destination ✓ Isolates rate ✓ 15 End loop Else Error message / Close application✓ Create method called correctly ✓ with correct parameters sent ✓ Confirmation message displayed ✓ 3.2.2 Method(s) called correctly ✓ and discount displayed ✓ 2 3.2.3 Method(s) called correctly ✓ and displayed ✓ 2 SUB-TOTAL 43 Page 8 of 14

Downloaded from hlayiso.com POSSIBLE SOLUTION 3.1.1 constructor TTravel.create(sBooking, sDestination,sDate:string; iPeople: integer; rRate: real); begin fBooking:=sBooking; fDestination:=sDestination;  fDate:=sDate; fPeople:=iPeople;  fTotal:=rRate*iPeople;  fDiscount:=0;  (5) end; 3.1.2 procedure TTravel.calcDiscount; var iMonth:integer; rDiscount:real; begin iMonth:=strToInt(copy(fDate,4,2));  if iMonth IN [2,5,8,11]  then begin rDiscount:=5;  end else rDiscount:=0; fDiscount := rDiscount/100 * fTotal;  end; (9) 3.1.3 procedure TTravel.calcTotal;  begin fTotal := fTotal-fDiscount;  end; (3) 3.1.4 function TTravel.getDiscount: real;  begin result := fDiscount;  end; (2) Page 9 of 14

Downloaded from hlayiso.com 3.1.5 function TTravel.toString: string; var sLine : string; begin sLine:= 'Booking No :'+#9+fBooking+#13 +'Destination :'+#9+ fDestination+ #13;  sLine := sLine +'Date of Booking :'+#9+fDate +#13+'No in Group :'+intToStr (fPeople)+#13; sLine := sLine+ 'Discount :'+floatToStrF(fDiscount,ffCurrency,8,2) +#13+'Final Amount :' +#9+floatToStrF(fTotal,ffCurrency,8,2);  result := sLine; end; (5) 3.2.1 procedure TForm2.Button1Click(Sender: TObject); var sTourDate,sBookNo : string; iNumG ,iPos: integer; sDest ,sLine: string; rRate : real; tFile : textfile; begin sTourDate := edtTourDate.Text; iNumG := sedPeople.Value;  sDest := cmbDest.Items[cmbDest.ItemIndex];  if FileExists('Destinations.txt') then  begin AssignFile(tFile,'Destinations.txt');  reset(tfile);  while not eof(tfile) do  begin readln(tfile,sLine);  iPos := pos(sDest,sLine);  if iPos >0 then  begin iPos := pos(';',sLine); sBookNo := copy(sLine,1,iPos-1); delete(sLine,1,iPos);  iPos := pos(';',sLine); sDest := copy(sLine,1,iPos-1); delete(sLine,1,iPos);  rRate := StrToFloat(sLine);  end; Page 10 of 14

Downloaded from hlayiso.com end; closefile(tfile); end else begin ShowMessage('Error !'); Application.Terminate;  end; ObjTravel := TTravel.create(sBookNo,sDest,sTourDate,iNumG,rRate);  ShowMessage('Booking Reservation Made');  end; (15) 3.2.2 procedure TForm2.Button2Click(Sender: TObject); begin travelObj.calcDiscount;  redOut.Lines.Add('Discount:'+FloatToStrF(travelObj.getDiscount ,ffCurrency,7,2)); end; (2) 3.2.3 procedure TForm2.Button3Click(Sender: TObject); begin redOut.Clear; travelObj.calcTotal;  redOut.Lines.Add(travelObj.toString);  end; (2) TOTAL QUESTION 3 : 43 Page 11 of 14

Downloaded from hlayiso.com QUESTION 4 QN Description Max Learner 4.1. Creates a procedure display that: Displays correct header  Sets up outer loop  Initialise string to name of flight Sets up inner loop  Builds row  7 End inner loop Displays row  End outer loop Calls procedure in button 4.2 Links logical file and physical file  Creates a new file to read for the first time  Set up outer loop Sets up inner loop  Checks if array value less than 70 then  Builds string with name of flight and correct time (column)  Writes to text file 9 Ends inner loop Ends outer loop Closes file  Display confirmation message  Code to load textfile in memo  4.3 Read the position (row) of option selected from combo-box  Set up sort outer loop  Set up sort inner loop  Compare values  Swop flight values  Set up column loop  Swop rows of 2D array  12 End column loop End inner loop End outer loop Display message  13 Page 12 of 14

Downloaded from hlayiso.com POSSIBLE SOLUTION 4.1 procedure TForm2.display; var r: Integer; c: Integer; str : string; I: Integer; begin redDisplay.Clear; str := 'FLIGHTS'+#9; for I := 1 to 6 do begin str := str+IntToStr(i+11)+':00'+#9;  end; redDisplay.Lines.Add(str); redDisplay.Lines.Add('----------------------------------------------------------------------------------------'); for r := 1 to 10 do  begin str := arrFlights[r]+#9#9;  for c := 1 to 6 do  begin str := str + IntToStr(arrPass[r,c])+#9;  end; redDisplay.Lines.Add(str);  end; end; procedure TForm2.btnQ4_1Click(Sender: TObject); begin display;  end; (7) 4.2 procedure TForm2.btnQ4_2Click(Sender: TObject); var r: Integer; c: Integer; str : string; tFile : TextFile; sLine : string; begin AssignFile(tFile,'CancFlights.txt');  rewrite(tfile);  for r := 1 to 10 do begin for c := 1 to 6 do  Page 13 of 14

Downloaded from hlayiso.com begin if arrPass[r,c] < 70 then  begin sLine := (arrFlights[r]+#9+IntToStr(c+11)+':00');  writeln(tFile,sLine);  end; end; end; closeFile(tFile);  showMessage('Contents written to File !');  MemOut.Lines.LoadFromFile('CancFlights.txt');  end; (9) 4.3 procedure TForm2.btnQ4_3Click(Sender: TObject); var iNum,i,j,k : integer; sTemp : string; iTemp : integer; begin iNum := cmbFlight.ItemIndex+1;  for I := 1 to 9 do  begin for j := i+1 to 10 do  begin if arrPass[i,iNum]> arrPass[j,iNum] then  begin sTemp := arrFlights[i];  arrFlights[i] := arrFlights[j];  arrFlights[j] := sTemp;  for k := 1 to 6 do  begin iTemp := arrPass[i,k];  arrPass[i,k] := arrPass[j,k];  arrPass[j,k] := iTemp;  end; end; end; end; ShowMessage('Flight Details for '+cmbFlight.Text+' sorted according to capacity :');  display; end; (12) TOTAL QUESTION 4 : 28 TOTAL = 150 Page 14 of 14
