Downloaded from hlayiso.com
2 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 1: MULTIPLE-CHOICE QUESTIONS (GENERIC)
1.1 C (1)
1.2 B (1)
1.3 C (1)
1.4 A (1)
1.5 B (1)
1.6 C (1)
[6]
QUESTION 2: SAFETY (GENERIC)
2.1 Gas welding (PPE)
Eye protection
Overall / leather apron
Safety boots
Gloves (Any 2 x 1) (2)
2.2 Safety rules that must be followed whilst the surface grinder
is in operation:
Make sure that the sparks are of no danger to co-workers.
Do not force the material onto the grinding wheel.
Do not plunge grind.
Bring the material slowly into contact with the grinding wheel.
Never clean or adjust the machine whilst it is in motion.
Use cutting fluid.
Know where the emergency stop is located.
Stop machine before any adjustment
Keep tools clear from moving parts. (Any 2 x 1) (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 3
2.3 Completing a task on any machine
Switch the machine off. (1)
2.4 TWO safety precautions before switching the angle grinder on
Make sure that there are no cracks or chips on the disc.
Make sure that the emery disc that is fitted is rated above the
revolutions at which it is turned by the motor.
Make sure that the space between the tool rest and the emery disc
does not exceed 3 mm.
Ensure that guards are in place.
When switching on the machine, do not stand in front of it, until it
reaches its full speed.
Do not force or bump the work piece against the emery disc.
Grind only on the front surface of the wheel, not the sides.
All grinding machines must have a sign indicating the revolutions at
which the spindle rotates. (Any 2 x 1) (2)
2.5 Importance of a welding helmet
To protect your eyes and face from ultra-violet rays and radiation (1)
2.6 Types of workshop layouts:
Process layout
Product layout (2)
[10]
Copyright reserved Please turn over
Downloaded from hlayiso.com
4 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 3: MATERIALS (GENERIC)
3.1 DIFFERENT TYPES OF TESTS
MATERIALS
Sound Filing Bend
Cast iron Very dull Easy Cannot bend /
sound Snaps/breaks /
Fractures easily
Mild steel Medium metallic Easy Bends easily
sound (6)
3.2 Heat treatment process
Is the heating and cooling of metals in their solid state so as to
change their properties (1)
3.3 Hardness factors:
Workpiece size
Quenching rate
Carbon content (Any 2 x 1) (2)
3.4 Heat treatment processes:
3.4.1 Tempering
Is a process applied to steel and it relieves the strains
induced during the hardening process
Decreases the degree of hardness
Increases toughness
Reduces brittleness
Gives steel fine grain structure (Any 2 x 1) (2)
3.4.2 Annealing
Relieves internal stress
Softens the metal
Makes metal ductile
Refines the grain structure
Reduces brittleness (Any 2 x 1) (2)
3.5 Hardness of steel depends upon
Carbon content (1)
[14]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 5
QUESTION 4: MULTIPLE-CHOICE QUESTIONS (SPECIFIC)
4.1 B (1)
4.2 D (1)
4.3 D (1)
4.4 A (1)
4.5 A (1)
4.6 B (1)
4.7 A (1)
4.8 B (1)
4.9 B (1)
4.10 A (1)
4.11 B (1)
4.12 B (1)
4.13 C (1)
4.14 B (1)
[14]
Copyright reserved Please turn over
Downloaded from hlayiso.com
6 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 5: TERMINOLOGY (LATHE AND MILLING MACHINE)
(SPECIFIC)
5.1 Lathe components
5.1.1 Chuck is a lathe component used to mount and hold the
workpiece at one end. (1)
5.1.2 Tool post is securely clamped to the compound slide and is
used to support and fasten the cutting tool in the proper
position for cutting action. (1)
5.1.3 Compound slide is situated on top of the cross slide and is
used for turning operations such as taper turning and thread
cutting. (1)
5.2 Milling Cutters Classes
5.2.1 Arbor cutters
Examples: plain cutter , side cutter, staggered-tooth cutter,
slitting-saw cutter, angular cutter, profile/form cutters, side-and-
face cutter, helical cutter (2)
5.2.2 Shank cutters
Examples: end mill; shell end mill; T-slot cutter and Woodruff
keyseat cutter (2)
5.3 Taper-turning calculations
Θ = 8,5°
θ/2 = 4,25°
Tan θ/2 = (D – d )/ 2L
Tan 4,25 x 2 x 250 = (55-d)
d = 17,84 mm
d = 18 mm (4)
5.4 Dividing head components
A – Index plate
B – Index crank
C – Sector arms
D – Single-start worm
E ‒ Worm wheel/gear (5)
5.5 Lead calculations
Lead = No. of starts x pitch
= 3 x 1,75 mm
= 5,25 mm (2)
[18]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 7
QUESTION 6: TERMINOLOGY (INDEXING) (SPECIFIC)
6.1 Gear calculations:
6.1.1 Dividing head: it breaks up the circumference of a circular
workpiece into a number of equal parts. It is mounted between
centers in cunjunction with the tailstock; or it can be fitted with
a chuck for direct mounting of work. (1)
6.1.2 Index plate: to enable one revolution of the crank to be further
subdivided into fractions of a revolution, especially where the
fraction is the factor of 40. (1)
6.1.3 Sector arm: to enable indexing where fractions of turns are
required, so that it can be adjusted to any angle that would
contain a specific number of holes. (1)
6.2 Procedure to cut external metric V-screw thread using compound
slide method.
Set up the workpiece in the centre lathe and turn the part to be
threaded to the required diameter of the thread.
Set the compound slide to 30º to the left of the centre line of that
cross-slide and accurately set up the cutting tool in the tool post.
Consult the index plate of the quick-change gear box and shift the
levers accordingly for the necessary pitch of the screw thread.
Start the centre lathe and set the cutting tool at touching point on
the workpiece.
Move the cutting tool a short distance off, to clear the end of the
workpiece and feed the compound slide 0,05 mm inwards.
With the centre lathe revolving, engage the half nuts at the correct
line on the threading dial, putting the first cut of the screw thread in
progress.
Stop the centre lathe and check the screw thread pitch with a
screw thread pitch gauge. (Any 5 x 1) (5)
6.3 Definition of Indexing: It is the process of evenly dividing the
circumference of a circular work piece into equally spaced divisions,
such as in cutting gear teeth, cutting splines, milling grooves in the
reamers and taps. (1)
6.4 Milling methods
Up-cut milling
Down-cut milling (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
8 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
6.5 Differential indexing
6.5.1 Indexing required
40
Indexing =
𝐴
= 40/120
1 22
= x
3 22
= 22/66
Indexing is 22 holes in a 66-hole circle. (3)
6.5.2 Change of gears
𝐷𝑟𝑖𝑣𝑒𝑟 𝐴−𝑁 40
Gear ratio : = x
𝐷𝑟𝑖𝑣𝑒𝑛 𝐴 1
120 −113
= x 40
120
7 8
=+ x
3 8
= 56/24
The driver gear has 56 teeth.
The driven gear has 24 teeth. (5)
6.5.3 The direction of motion is clockwise.
The crank handle will turn the same direction as the index
plate (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 9
6.6 Dove tail calculations:
Find the difference of distance over the rollers (L):
L = (M ‒ R) – (m ‒ r)
= (127,64 ‒ 25) – (100,32 ‒ 15)
= 102,64 – 85,32
L = 17,32 mm
For the angle θ
Tan θ/2 = (R ‒ r) / L
= 10/17,32
Θ = 30 x 2
Θ = 60° (6)
6.7 Constraints to balancing
Requires specialised machinery
Difficult to ascertain the exact point of unbalance
Requires accurate removal or addition of material’s weight to the
object.
Can lead to interference with parts of the machine when weights
are added to parts (Any 2 x 1) (2)
[28]
Copyright reserved Please turn over
Downloaded from hlayiso.com
10 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 7: TOOLS AND EQUIPMENT (SPECIFIC)
7.1 Hardness testers:
7.1.1
Brinell hardness tester
(3)
7.1.2
Rockwell hardness tester
(3)
7.2 Hardness measure of a metal
Resistance to penetration
Elastic hardness
Resistance to abrasion (3)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 11
7.3 Screw-thread micrometres
6 + 0,5 + 0,3 = 6,80 mm (2)
7.4 Micrometre reading 41,25 mm
(2)
[13]
Copyright reserved Please turn over
Downloaded from hlayiso.com
12 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 8: FORCES (SPECIFIC)
8.1 Resultant force calculations:
Xcom = 80 cos 30 – 40 cos 75 – 70 cos 25 – 50 cos 40
= 80,0686 N
Ycom = 50 sin 40 – 80 sin 30 – 70sin 25 – 40 sin 75
= ‒16,91 N
R = √(𝑋 2 + 𝑌²)
R = 81,836 N
Tan θ = y/x
Tan Θ = 16,91/80,0
Θ = 360 ‒ 11,925°
= 348,075°
Equilibrant = Resultant BUT IN THE OPPOSITE DIRECTION
Equilibrant = 81,836 N at 168,075° (12)
8.2 Moments
Converting the UDL to point lolad
1 x 10 = 10 kN @ 5 mm from eft hand end
Calculation of the reactions.Taking moments:
RD x 20 = (5 x 5) + (10 x 30) + (20 x 15)
= 31,25 kN
(Ra x 20) + (10 x 10) = (20 x 5) + (5 x15)
= 3,75 kN
(5)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 13
8.3 Stress calculations:
8.3.1 Tensile Stress Calculations
F = 10 kN; d = 20 mm: L = 2 m : E = 200 PGa
𝐹
𝛿=
𝐴
𝐴 = 𝜋𝑟 2
A = π x 0,01²
A = 3,141 x 10^-4 m²
𝐹
δ=
𝐴
= 10 000/3.141 x 10 ^-4
= 318,31 x 10⁶ Pa
= 318,31 MPa
(4)
8.3.2 The change in length calculations.
𝛥𝐿 = ?; E = 200 GPa; F = 10 kN; L = 2 m; Ϭ = 318,31 MPa
𝑆𝑥𝐿
𝛥𝐿 =
𝐸
= 318,31 x 10⁶ x 2) / 200 x 10⁹
= 0,318 mm (4)
8.4 Stress/Strain diagram:
A – Limit of proportionality
B – Elastic limit
C – Yield point
D – Maximum force / point
E – Point of fracture (6)
8.5 FOS stands for Factor OR Safety or Safety Factor. (1)
8.6 Young’s modulus states that stress in metal is directly proportional to the
strain it causes, provided the limit of proportionality is not exceeded. (1)
[33]
Copyright reserved Please turn over
Downloaded from hlayiso.com
14 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 9: MAINTENANCE (SPECIFIC)
9.1 Purpose of composites:
9.1.1 Bakelite can be used in disc brake cylinders, saucepan handles,
distributor rotors, electrical plugs and switches, and parts for
electrical irons. (2)
9.1.2 Fibre glass is used as a surface covering, woven cloth, wearing
fibres, plastic covers and stuffing for pillow. (2)
9.1.3 Carbon fibre is used for sport equipment like tennis, squash and
badminton racquets, racing bicycle frames, construction skis,
surfboards and boat masts, compressor blades for jet
engines. (2)
9.2 Reasons for using cutting fluid when working on the centre lathe:
It prolongs the life of a cutting tool.
It prevents the shavings or metal chips from sticking and fusing to the
cutting tool.
It will carry away the heat generated by the turning process.
It flushes away shavings/metal chips.
It improves the quality of the finish of the turned surface.
(Any 1 x 1) (1)
9.3 Mechanical drives:
Gear drives
Chain drives
Belt drives (3)
9.4 Reasons for the use of carbon fibre:
It is light in weight
It is tougher and stronger
It can be bent to any shape when heated above 150 ºC (Any 2 x 1) (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 15
9.5 ONE property and ONE use of each composite
COMPOSITE PROPERTY USES
9.5.1 PVC - Durable - Bank credit cards
- Very versatile - Shoe soles
- High load bearing - Wallpaper
strength - Floor tiles
- High chemical - Drip bags
resistance - Cooking oil bottles
- Very low co-efficient of (Any 1 x 1)
friction (Any 1 x 1)
9.5.2 Vesconite - Withstands high - Orthopaedic and
temperatures prosthetic
- Self-lubrication appliances
- Resistant to water, - Hearing aids
grease, heat and - Upholstery
corrosion (Any 1 x 1)
- Good machinability
(Any 1 x 1)
9.5.3 Nylon - Toughness - Bushes, toys,
- Hard-wearing curtain hooks
- Cheap - Gears
- Needs little - Pulleys
maintenance (Any 1 x 1)
(Any 1 x 1)
(6)
[18]
Copyright reserved Please turn over
Downloaded from hlayiso.com
16 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
QUESTION 10: JOINING METHODS (SPECIFIC)
10.1 Square thread calculations:
10.1.1 PCD = T x m
= 60 x 4 = 240 mm (2)
10.1.2 Add = Module = 4 (2)
10.1.3 Clearance = 0,157 x m
= 0,628 mm (2)
10.1.4 Ded = 1,157 x m
= 4,628 mm (2)
10.1.5 OD = PCD + 2 x m
= 248 mm (2)
10.2 Left-hand square screw-thread:
A – Leading angle
B – Following or Trailing Angle
C – Clearance
D – Helix angle (4)
10.3 A multi-start thread allows for faster travel or movement and is more efficient
as it loses less power to friction compared to single-start thread. (2 )
10.4 Screw-thread fit is a combination of allowances and tolerances and a
measure of tightness or looseness between the bolt and nut. (2)
[18]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2020) MECHANICAL TECHNOLOGY: FITTING AND MACHINING 17
QUESTION 11: SYSTEMS AND CONTROL (SPECIFIC)
11.1 Gear drives work on the principle that the turning motion of one gear be
transferred to another gear if the gears are mounted close so that they mesh or
engage. (2)
11.2 Hydraulic system calculations:
11.2.1 Calculate the force applied on Piston A.
da = 30 mm; Db = 130 mm; M = 2 000 kg
Weight Calculation (W)
W=mxg
= 2 000 x 10
= 20 Kn
(2)
11.2.2 A = π (r)²
= π x 0,065²
= 0,0133 m ²
𝐹
𝑃=
𝐴
= 20 000/0,0133
= 1,507 MPa
(4)
11.2.3 A = 𝜋Da²/4
= 𝜋 (0,03)²/4
−4
= 7,0686 x10 m²
F= PxA
= 1,507 x 10 ⁶ x 7,068 x 10−4
Force = 1065,235 N (4)
11.2.4 Hydraulic system applications:
Machine tools, motor vehicle, hydraulic jacks (Any 1 x 1) (1)
11.3 Velocity ratio is defined as the ratio of a distance through which any part of a
machine moves, to that which the driving part moves during the same
time. (2)
11.4 Belt drive calculations:
Nmotor x Dmotor = Nblade x Dblade
135 x 1 200 = 395 x Dblade
Dblade = 410,127 rpm
(3)
Copyright reserved Please turn over
Downloaded from hlayiso.com
18 MECHANICAL TECHNOLOGY: FITTING AND MACHINING (EC/SEPTEMBER 2020)
11.5 Pneumatic drives:
Vehicle painting
Air brakes
Opening and closing doors
Dismantling vehicle tire (Any 3 x 1) (3)
11.6 Simple gear calculations:
TA = 56 teeth; NA = 700 rpm
11.6.1 𝑇𝐴 x 𝑁𝐴
TB =
𝑁𝐵
= (56 x 700)/ 980
= 40 teeth (3)
11.6.2 𝑁𝐵 x 𝑇𝐵
Nc =
𝑇𝑐
= (40 x 980)/ 64
= 612,5 rpm (3)
11.6.3 Driven gear will rotate anti-clockwise (1)
[28]
TOTAL: 200
Copyright reserved Please turn over
Study this subject
Recommended for this subject

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2020 Memo

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2023 QP
%20MEMO%20SEPT%202018_English_hlayiso.com_--b985e4dd-9a08-4ec2-a07b-64edd6f727ea/v1-e5704410f2b7cfd49bb6/card.webp)
Memorandum
Mechanical Technology Grade 12 Automotive 2018 Memo (Eng)
%20GR12%20MEMO%20SEPT%202018_English_hlayiso.com_--1b0b4dd6-b53e-485d-9068-6f378eb8c9f3/v1-7320b22b5b5eecec97b6/card.webp)
Memorandum
Mechanical Technology Grade 12 2018 Memo (Eng)
More from Grade 12 Mechanical Technology

Annual teaching plan
Gr 12 Weld Met ATP 2023 24
%20Eng--5d2e2bd0-b02f-4218-849f-e7933bc6c4d1/v1-2dba8a1dc6758c98b205/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Eng)
%20Afr--1e7205e4-aef1-4cc4-afdf-aac93562ae67/v1-094abcfa5c3eff1cb995/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Afr)
%20Eng--10859467-be3e-41fb-aee0-b797c385437d/v1-986e8982bfb6b966a34d/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2024 QP (Eng)
%20Afr_hlayiso.com_--7d638feb-7218-4b3c-9f4c-ce95803d6e4f/v1-e8a08d94a30d7d50ccd0/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2023 QP (Afr)
%20Eng_hlayiso.com_--1523a16f-2012-4f13-a922-86cbb5900666/v1-5068227f3cbbba17b78f/card.webp)
Question paper
