NATIONAL SENIOR CERTIFICATE GRADE 12 SEPTEMBER 2016 MECHANICAL TECHNOLOGY MEMORANDUM MARKS: 200 This memorandum consists of 10 pages.
2 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016) QUESTION 1: MULTIPLE-CHOICE QUESTIONS 1.1 D Make certain the dipstick is in the hole. (1) 1.2 D All the abovementioned. (1) 1.3 B Guards should be removed when cutting metals. (1) 1.4 C Multimeter (1) 1.5 C deflection (1) 1.6 C iron carbide (1) 1.7 B 480 °C - 520 °C (1) 1.8 D 25 mm (1) 1.9 B Cylinder head (1) 1.10 A To determine the percentage of elongation of the weld metal. (1) 1.11 B To check for size of the weld (1) 1.12 D Resultant (1) 1.13 A 25 MPa (1) 1.14 B It must increase the engine speed. (1) 1.15 B ‘Winter grades’ (1) 1.16 C 16 : 1 (1) 1.17 C Block and tackle (1) 1.18 D ABS braking system (1) 1.19 C mechanical drive. (1) 1.20 C Kaplan (1) [20] QUESTION 2: SAFETY 2.1 Make sure all the guards are in place. Do not use or come close to its moving parts while wearing loose clothing. Keep any cleaning material such as waste and rags away from rotating parts. Check that there are no oil or grease on the floor around the machine. Do not leave spanners or keys on rotary parts. (Any 2 x 1) (2) 2.2 The welding operator should know how to operate the oxy-acetylene welding plant safely. The work place should be partitioned off effectively. The operator should wear protective equipment. Never use damaged equipment. Never use oil or grease near oxygen equipment. (Any 2 x 1) (2) 2.3 Ensure that the beam is clamped parallel to the back board. Do not leave plastic beams loaded for any length of time. Gently drop the weights onto the hanger. (3) 2.4 The operator should be instructed to use the machine safely. The work place should be effectively partitioned off. An operator uses protective equipment while using the equipment. The operator should ensure that the insulation of electric leads are satisfactory. (Any 3 x 1) (3) [10] Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 3 QUESTION 3: TOOLS AND EQUIPMENT 3.1 It involves the indenting of the test material with a diamond cone or hardened steel-ball indenter. The indenter is forced into the test material under a preliminary minor load (FO), usually 10 kgf. The permanent increase in depth of penetration, resulting from the application and removal of the additional major load, is used to calculate the Rockwell Hardness Number. (4) 3.2 To test the system for leaks. To pump compressed air into the cooling system of a motor car to determine whether there are any leaks in the system. To test if the pressure cap on the cooling system operates according to the prescribed pressure of the system. (Any 2 x 1) (2) 3.3 3.3.1 To determine the fuel operating pressure in the system. To test the pressure of the fuel in the fuel line that runs to the direct injection system. (2) 3.3.2 To test different electrical components and concepts. To test current, voltage, resistance, continuity, transistors and diodes. (2) 3.4 1 mm + 0,5 mm + 0,25 mm = 1,75 mm (2) [12] QUESTION 4: MATERIALS 4.1 4.1.1 Pearlite is a type of crystal formed before hardening when the steel contains 0,83% carbon. (2) 4.1.2 Carbon Content is the mixture that is added to steel to change the property of the metal. (2) 4.1.3 Martensite is the structure obtained when austenite is quenched suddenly. (2) 4.2 Alloying Heat treatment (2) 4.3 To increase service life of a product or to prepare the material for improved manufacturability. (2) 4.4 A map of the temperature at which different phase changes occur on very slow heating and cooling in relation to carbon. (2) 4.5 Iron carbide (which is a component of Iron carbon (Fe2C) found in steel and cast iron. (1) [13] Copyright reserved Please turn over
4 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016) QUESTION 5: TERMINOLOGY 5.1 side and face cutter arbor with spacers/collars ruler keyway workpiece square milling machine table (6) 5.2 5.2.1 Conventional milling also regarded as up-cut milling is the process whereby the cutter turns against the direction of feed as the work piece moves toward it from the side where the teeth are moving upwards. (2) 5.2.2 Climb milling also regarded as down-cut milling is the process where all looseness in the table-feed screw must be eliminated, where the motion of the cutter tends to pull the work piece into the cutter. (2) 5.3 Indexing required: Number of turns = = There will be no turns but 40 holes in a 43 hole plate. (4) 5.4 Class 1: for screw thread work in which shake or play is not objectionable Class 2: for threaded parts that can be put together with the fingers(hand tight) Class 3: for higher grade of threaded parts, requiring greater accuracy Class 4: for the finest threaded work (8) 5.5 Identify: Milling process Name: Gear cutting (2) 5.6 A Anvil B Screw thread C Barrel D Thimble E Spindle F Frame (6) [30] Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 5 QUESTION 6: JOINING METHODS DEFECT PREVENTION 6.1 6.1.1 Porosity Do not use dirty or wet electrodes Do not use rusted MIG wire Ensure the weld surface is not contaminated (Any 1 x 2) (2) 6.1.2 Incomplete Incorrect welding current penetration Travel speed to slow Incorrect torch, gun or stick angle (Any 1 x 2) (2) 6.1.3 Slag Chip the slag off thoroughly from the previous inclusion weld runs and brush the weld bead with a wire brush, before doing any further welding Incorrect current setting (Any 1 x 2) (2) 6.2 Nick-break test Nick-bend test Machinability test (3) 6.3 Continuous wire reel Wire feed unit Power cable Gun conduit Welding gun Shielding gas cylinder Regulator Flow meter Gas hose (Any 6 x 1) (6) 6.4 Use a hacksaw and cut both edges through the centre of the weld approximately 6,5 mm deep. Place the saw-nicked specimen on two steel supports and use a sledge hammer to break the specimen by striking it in the zone where you made the saw cuts. The weld metal exposed in the break should be completely fused, free from slag inclusion and contain no gas pockets greater than 1,6 mm. There should not be more than one pore or gas pocket per square centimetre visible. (6) 6.5 A Motor B Tension roller C Consumable wire reel D Wire liner (4) [25] Copyright reserved Please turn over
6 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016) QUESTION 7: FORCES 7.1 7.1.1 Diameter : Stress = 8 x 106 = Area = = D = √ D = √ D = 0,079788 m or 79,79 mm (6) 7.1.2 Young’s Modulus = Strain = Strain = Strain = 0,0001333 or 1,333 x 10-4 (3) 7.1.3 Change in Length: Strain = Change in Length = Strain x Original Length = 0,0001333 x 275 = 0,0366575 mm (3) 7.2 7.2.1 = = 0,00090792 m2 P = P= P = 352453,8532 kN (3) 7.2.2 Diameter of the Ram: = = = 0,09930378 BUT: Area = = D =√ =√ = 0,3555805 m Diameter of Ram = 35,5 mm (4) Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 7 7.3 L :(R x 8 = (8 x 2) + (50 x 4) + (30 x 10) = 16 + 200 + 300 R= R = 64,5 N R : (L x 8) + (30 x 2) = (50 x 4 ) + (8 x 6) (L x 8) + 60 = 200 + 48 RL = RL = 23,5 N To check if the beam is in equilibrium: Downward forces = Up ward forces 8 + 50 N + 30 N = 64,5 N + 23,5 N 88 N = 88 N (6) 7.4 Solution: The horizontal component of the resultant is: H = 15 Cos 30° + 20 Cos 60° – 10 Cos 10° AND The vertical components is: 15 N V = 15 Sin 30° – 20 Sin 60° – 10 Sin 10° H = 12,99 + 10 – 9,85 0° = 13,14 N V = 7,5 – 17,32 – 1,74 10 Cos 10° 30° 15 Cos 30° = - 11,56 N 60° 20 Cos 60° 10 Sin 10° 10 N To Calculate the Resultant: 20 N = + = √ + = 17,499 N Tan = = = 41,34° The Resultant is therefore 17,499 N at 131,34° (5) [30] QUESTION 8: MAINTENANCE 8.1 A Gear lever B Selector for gear changes C Splined input shaft D Lay shaft (4) 8.2 Because it gives of vapours which ignite and therefore a high flashpoint is required. (2) 8.3 It is used in the turning process on a lathe as illustrated by the drawing, cutting a thread on a shaft. (3) Copyright reserved Please turn over
8 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016) 8.4 A Flywheel B Diaphragm C Crankshaft D Clutch plate E Throw-out release lever F Pressure plate (6) [15] QUESTION 9: SYSTEMS AND CONTROL 9.1 9.1.1 Rotational Frequency of the output shaft: Output shaft = x x = x x 1330 = 591,11 r/min (3) 9.1.2 Velocity Ratio: VR = = Velocity Ratio = 2,25 revs/min (2) 9.2 9.2.1 Fluid Pressure: = = = 0,00384845 = 3,848 x = = = 103937,9 Pa = 103,937 kPa (3) 9.2.2 Load that can be lifted: = = = 0,0165 BUT = = F = x = 103937,9 x 0,0165 = 1716,32 N = 1,716 kN (2) 9.3 9.3.1 Rotational Frequency of the driven pulley. x = x = = = 3,33 r/min (2) Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 9 OR = = 120 (Speed of driven pulley B) = 40 x 100 Speed of driven pulley = = 3,33 r/min 9.3.2 Power transmitted: P = = Power transmitted = 14,6 watt (2) 9.3.3 Belt speed: V = = = 0,209 m/sec (2) 9.4 New Pressure: = OR = 300 x 0,35 = x 0,9 = = 116,66 kN/ = 116,66 kPa (4) 9.5 Purpose of airbags: It provides protection for the head and upper body of the driver and passengers of a motor vehicle during a collision. In head on collisions, drivers and passengers are thrown forward inside the vehicles and when the airbags is activated, it inflates instantly and creates a firm barrier which counters the forward motion of the driver or front seat passenger. It is designed to prevent the occupants from hitting the windscreen or dashboard of the vehicle. It is also designed to work in conjunction with seat belts. (5) [25] Copyright reserved Please turn over
10 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016) QUESTION 10: TURBINES 10.1 A Wicket gate B Blades C Water flow D Rotor E Stator F Shaft (6) 10.2 Reaction turbines Impulse turbines (2) 10.3 Air is compressed isentropically, combustion occurs at constant pressure and expansion over the turbine occurs isentropically back to the starting pressure. (4) 10.4 Advantages of steam turbines: It has greater thermal efficiency and higher power-to-weight ratio. It is suited to drive an electrical generator. It does not require a linkage mechanism to convert reciprocating motion to rotary motion. It uses multiple stages in the expansion of the steam, which results in greater efficiency. It is compact. No lubrication is required. Can be more accurately regulated. A variety of fuels can be used to obtain steam. It converts heat energy into mechanical energy (Any 4 x 1) (4) 10.5 Advantages of gas turbines: It has smooth vibration It is easy to start It has no rubbing parts such as pistons No internal friction and wear Higher power output from a given weight of engine Can use a wide range of fuels No water cooling system needed Require little routine maintenance Very little trouble with pollution (Any 4 x 1) (4) [20] TOTAL: 200 Copyright reserved Please turn over
