NATIONAL
SENIOR CERTIFICATE
GRADE 12
SEPTEMBER 2016
MECHANICAL TECHNOLOGY
MARKS: 200
TIME: 3 hours
*MCHTE*
This question paper consists of 21 pages, including a 3-page formula sheet.
Skip to contentAll 2016 papers





View all
_Afrikaans_hlayiso.com_--aadd113c-5a3b-4f4d-a4c4-3a80cd86f882/v1-fd2ca7edf910eab03a55/card.webp)
%20GR12%20MEMO%20SEPT2024_Afrikaans_hlayiso.com_--2f874dd1-8c03-49a9-8c70-41ac528693d0/v1-55f44edf9664bf65cf74/card.webp)

%20MG%20Eng--ed5ab6d3-088f-425c-ade8-86186a031594/v1-3e0bd44f4bc86cf3bb1d/card.webp)
%20MG%20Afr--03c703c8-8125-4d5a-a124-37013b381c7a/v1-02788e8df50b92af342d/card.webp)
Mechanical Technology Grade 12 Eastern Cape Mock 2016 QP
Grade 12 Mechanical Technology question paper from the Eastern Cape Mock Exam 2016 (English), 21 pages. Read online or download the free PDF.
Mechanical Technology · Grade 12 · Eastern Cape Mock Exam · 2016. Question paper, 21 pages. Read online or download the PDF.
- Subject
- Mechanical Technology
- Grade
- Grade 12
- Document type
- Question paper
- Year
- 2016
- Exam period
- Eastern Cape Mock Exam
- Curriculum
- CAPS
- Pages
- 21
- File size
- 1.4 MB
Free to read online, no sign-up needed
Loading document…
Loading document…
1 of 21
This exam
Eastern Cape Mock Exam 2016
Document textSearch extracted text and jump to a page.
2 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
INSTRUCTIONS AND INFORMATION
1. Write your centre number and examination number in the spaces provided
on the ANSWER BOOK.
2. Read ALL the questions carefully.
3. Answer ALL the questions.
4. Number the questions correctly according to the numbering system used in
this question paper.
5. Start EACH question on a NEW page.
6. Show ALL calculations and units. Round off final answers to TWO decimal
places.
7. Candidates may use non-programmable scientific calculators and drawing
instruments.
8. Take the value of gravitational force as 10 m/s2.
9. All dimensions are in millimetres, unless stated otherwise in the question.
10. A formulae sheet for your use is attached at the back of this question paper.
11. Use the criteria below to assist you in managing your time.
TIME
QUESTION CONTENT COVERED MARKS
(MINUTES)
1 Multiple-choice 20 15 minutes
2 Safety 10 10 minutes
3 Tools and equipment 12 10 minutes
4 Materials 13 10 minutes
5 Terminology 30 20 minutes
6 Joining methods 25 25 minutes
7 Forces 30 30 minutes
8 Maintenance 15 15 minutes
9 Systems and control 25 25 minutes
10 Turbines 20 20 minutes
TOTAL 200 180 minutes
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 3
QUESTION 1: MULTIPLE-CHOICE QUESTIONS
Various options are provided as possible answers to the following questions.
Choose the answer and write only the letter (A–D) next to the question number
(1.1–1.20) in the ANSWER BOOK, for example 1.21 D
1.1 Which ONE of the following safety procedures is applicable to the cylinder
leakage test?
A Screw the adapter into the plug hole.
B Do not exceed the prescribed pressure in the cylinder.
C Place the spring on top of the tester.
D Make certain the dipstick is in the hole. (1)
1.2 Which of the following safety measures apply to a torsion tester?
A Fasten the tester to a workbench.
B Be careful of metal particles coming off after the metal fractures.
C Determine the strength of the bolts keeping the framework together.
D All the abovementioned. (1)
1.3 What safety measure is applicable to shears and guillotines in terms of
workshop practices?
FIGURE 1.3
A Use the guillotine as a work bench.
B Guards should be removed when cutting metals.
C Do not use gloves when handling plates.
D Choose the correct blade for the job. (1)
1.4 Which of the following equipment is used to test the properties of electrical
components?
A Brinell tester
B Rockwell tester
C Multimeter
D Terminal tester (1)
Copyright reserved Please turn over
4 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
1.5 A beam bending tester is used to determine the … of various given pieces
of material.
A distortion
B description
C deflection
D deterioration (1)
1.6 Cementite is also known as …, a compound of iron and carbon.
A metal carbide
B steel carbide
C iron carbide
D All the above mentioned (1)
1.7 What is the correct heat treatment temperature for piston rings?
FIGURE 1.7
A 380 °C - 420 °C
B 480 °C - 520 °C
C 580 °C - 620 °C
D 680 °C - 720 °C (1)
1.8 Determine the width of a keyway to be used on a 100 mm shaft.
A 20 mm
B 35 mm
C 40 mm
D 25 mm (1)
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 5
1.9 Which engine part below can be machined with a face milling cutter?
FIGURE 1.9
A Crankshaft
B Cylinder head
C Connecting rod
D Camshaft (1)
1.10 What is the reason for applying the Nick-bend test on a welded joint?
A To determine the percentage of elongation of the weld metal
B To test the skill of the welder
C To check the magnitude of the weld
D To approve welds and welders to certain standards (1)
1.11 What is the reason for using visual examination in testing of welds?
A To train welders
B To check for size of the weld
C To test the welder
D To test the strength of the weld (1)
1.12 Identify a single force that can be representing the entire system of forces
as shown in the diagram below.
15 N N
W E
3N 10 N
S
FIGURE 1.12
A Polygon
B Equilibrium
C Equilibrant of forces
D Resultant (1)
Copyright reserved Please turn over
6 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
1.13 Determine the compressive stress in a 20 x 20 mm square bar if it is
subjected to a compressive load of 10 kN.
A 25 MPa
B 2,5 MPa
C 0,25 MPa
D 0,025 MPa (1)
1.14 Which ONE of the following is NOT a function of lubricating oil?
A It must prolong the engine life.
B It must increase the engine speed.
C It must reduce engine noise.
D It must act as a seal. (1)
1.15 What is the ‘W’ known as in the classification of the SAE 20W50 oil?
FIGURE 1.15
A ‘Winner grades’
B ‘Winter grades’
C ‘Wheel grades’
D ‘Wheel bearing’ (1)
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 7
1.16 The gear ratio of the compound gear in FIGURE 1.16 is …
T-60
T-15
T-15
T-60
FIGURE 1.16
A 1 : 16
B 1:4
C 16 : 1
D 4:1 (1)
1.17 What is the name of the pulleys with the attached rope or chain known as in
the FIGURE 1.17 below?
FIGURE 1.17
A Pulley and idler
B Wheel and axle
C Block and tackle
D Open belt pulley system (1)
Copyright reserved Please turn over
8 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
1.18 What do we call the braking system used on the bike in FIGURE 1.18
below?
FIGURE 1.18
A Air brake system
B Ignition system
C ABC Braking system
D ABS braking system (1)
1.19 A supercharger is driven by …
A steam.
B exhaust gasses.
C mechanical drive.
D inlet gasses. (1)
1.20 Identify the water turbine in FIGURE 1.20:
FIGURE 1.20
A Francis
B Tyson
C Kaplan
D Gorlov (1)
[20]
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 9
QUESTION 2: SAFETY
2.1
FIGURE 2.1
State TWO safety measures to be observed while the milling machine as in
FIGURE 2.1 is in operation. (2)
2.2
FIGURE 2.2
List TWO safety precautions that should be followed when using the oxy-
acetylene apparatus in FIGURE 2.2. (2)
2.3 Name THREE safety rules when using the beam bending tester. (3)
2.4 State THREE common measures to be observed when using the Metal Arc
gas-shielded welding (CO2 and Argon). (3)
[10]
Copyright reserved Please turn over
10 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
QUESTION 3: TOOLS AND EQUIPMENT
3.1
FIGURE 3.1
Explain the principle of the Rockwell Hardness test method. (4)
3.2 State TWO functions of the cooling tester. (2)
3.3 Describe the purpose of the following tests below.
3.3.1 Fuel pressure test (2)
3.3.2 Multimeter (2)
3.4
FIGURE 3.4
What is the reading on the micrometer as shown in FIGURE 3.4 above? (2)
[12]
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 11
QUESTION 4: MATERIALS
4.1 Describe each of the iron-carbon equilibrium diagram structures below.
4.1.1 Perlite (2)
4.1.2 Carbon content (2)
4.1.3 Martensite (2)
4.2 Which TWO methods are used for controlling material properties? (2)
4.3 What is the purpose of heat treatment? (2)
4.4 Describe in your own words what an iron-carbon diagram is. (2)
4.5 What is cementite also known as? (1)
[13]
QUESTION 5: TERMINOLOGY
5.1 With the aid of a sketch, show how you would centralise a cutter on a milling
machine to cut a keyway on a round shaft. (6)
5.2 Explain the TWO milling processes below.
5.2.1 Conventional milling (2)
5.2.2 Climb milling (2)
5.3 A machinist has to turn a gear with 43 teeth on a milling machine. Calculate
the indexing required completing the job. (4)
5.4 List the FOUR general screw thread fit classes and give a brief explanation
of each. (8)
5.5
FIGURE 5.5
IDENTIFY and NAME the cutting procedure in FIGURE 5.5 above. (2)
Copyright reserved Please turn over
12 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
5.6
A C D
B
E
F
FIGURE.5.6
FIGURE 5.6 shows a screw-thread micrometer. Write down the letters in
your ANSWER BOOK and the correct names of the parts next to the
corresponding letters. (6)
[30]
QUESTION 6: JOINING METHODS
6.1 When mild steel is welded, numerous errors occur. Identify ONE possible
defect and ONE preventive method when:
6.1.1 Atmospheric contamination is a cause. (2)
6.1.2 The weld bead does not penetrate the entire thickness of the base
plate. (2)
6.1.3 Non-metallic solids are entrapped in the weld. (2)
6.2 Name THREE destructive tests exerted onto metals. (3)
6.3 Identify SIX basic components of the MIG welding machine. (6)
6.4
FIGURE 6.4
Describe how you would apply a Nick break test on a fillet weld. (6)
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 13
6.5
A
B
D
C
FIGURE 6.5
Label the MIG welding machine in FIGURE 6.5 above. (4)
[25]
Copyright reserved Please turn over
14 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
QUESTION 7: FORCES
7.1 A load of 40 kN causes a tensile stress of 8 MPa in a mild steel round bar.
The original length of the bar is 275 mm and Young’s Modulus for mild steel
is 60 GPa.
Calculate the following:
7.1.1 The diameter of the mild steel bar (6)
7.1.2 The strain caused by the load (3)
7.1.3 The change in length caused by the load (3)
7.2 A hydraulic jack is being used to lift a vehicle with a mass of 35 kN. The
maximum force that can be exerted onto the 34 mm plunger is 320 N.
? mm
35 kN
34 mm
plunger
FIGURE 7.2
Calculate the following:
7.2.1 The fluid pressure in the hydraulic system (3)
7.2.2 The diameter of the ram (4)
7.3 A beam of 10 mm rests on TWO supports. The ONE support is at the left
end and the other support is 8 m from the left end. The beam carries a
uniformly distributed load of 2 N/m between the supports.
50 N 30 N
2 N/m 4m 2m
●●●●●●●●●●●●●●●●
8m
L R
FIGURE 7.3
The beam also carries the following concentrated loads: 50 N 4 m from the
left end; 30 N on the right end. Calculate the reaction at the supports. (6)
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 15
7.4
70 N
90ᵒ 65 N
130ᵒ
100 N
FIGURE 7.4
Calculate the magnitude and direction of the resultant force (R) in the system
of forces above. (5)
[30]
QUESTION 8: MAINTENANCE
8.1
A
C B
D
FIGURE 8.1
Identify the labels in the manual transmission in FIGURE 8.1 above. (4)
8.2 Why is it important for engine oil to have a high flashpoint? (2)
8.3
FIGURE 8.3
Explain the use of cutting fluid as applied in FIGURE 8.3 above. (3)
Copyright reserved Please turn over
16 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
8.4
A
B
C
E
D
F
FIGURE 8.4
Write down the letters A–F of the mechanical clutch assembly IN YOUR
ANSWER BOOK and then the correct labels for FIGURE 8.4 next to the
corresponding letters. (6)
[15]
QUESTION 9: SYSTEMS AND CONTROL
9.1 FIGURE 9.1 below shows a gear drive system. Driver gear A has 16 teeth
and meshes with gear B with 32 teeth on a countershaft. On this countershaft
is another driver gear C with 14 teeth that meshes with gear D with 42 teeth
on the output shaft.
Driver Driven gear D –
Gear B –
gear A - 42 teeth
12 teeth
16 teeth
TTEETH
Gear C – 14 teeth
FIGURE 9.1
Determine by means of calculations:
9.1.1 The rotational frequency of the output shaft, if the input shaft rotates
at 1330 r/min (revolutions per minute) (3)
9.1.2 The velocity ratio between the input shaft and the output shaft (2)
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 17
9.2 In a hydraulic press, a force of 400 N is applied to Piston A. Piston A moves
30 mm downwards. The diameter of Piston B is 145 mm and moves up by
14 mm.
400 N
145 Ө
Piston A 14 mm Piston B
30 mm …………...
……
FIGURE 9.2
Make use of the specification in FIGURE 9.2 to calculate the following:
9.2.1 The fluid pressure in the hydraulic system (3)
9.2.2 The load that can be lifted (2)
9.3 FIGURE 9.3 shows a belt-drive system. A pulley with a diameter of 40 mm
drives a driven pulley with a diameter of 120 mm. The driver pulley rotates at
100r/min.
12 mm
40 mm
MM
MM
100 r/min
Driver Pulley Driven Pulley
FIGURE 9.3
Determine by means of calculations:
9.3.1 The rotational frequency of the driven pulley in r/min (2)
9.3.2 The power transmitted (2)
9.3.3 The belt speed of the system in meters per second (2)
9.4 An acetylene gas cylinder has a pressure and volume of 300 kPa (kN/m²)
and 0,35 m³ respectively. The gas is being expanded until a new volume of
0,9 m³ is reached while the temperature remains constant. What will the new
pressure be? (4)
9.5 Briefly explain the purpose of air bags in motor vehicle. (5)
[25]
Copyright reserved Please turn over
18 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
QUESTION 10: TURBINES
10.1 Study the turbine in FIGURE10.1
FIGURE 10.1
Label the letters A to F in your ANSWER BOOK. (6)
10.2 In which TWO groups are water turbines divided into? (2)
10.3 Explain the operation of a gas turbine with the Brayton cycle. (4)
10.4 Name FOUR advantages of a steam turbine. (4)
10.5 Name FOUR advantages of a gas turbine. (4)
[20]
TOTAL: 200
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 19
FORMULA SHEET
1. BELT DRIVES
1.1 Belt speed =
1.2 ( )
Belt speed = (t = belt thickness)
1.3 Belt mass = (A = thickness width)
1.4 Speed ratio =
1.5 Belt length (Flat) = [ (D + d) x 1,57 ] + (2 x centre distance)
1.6 Open-belt length =
( ) ( )
1.7 Crossed-belt length =
( ) ( )
1.8 Power (P) =
1.9 Ratio of tight side to slack side =
1.10 ( )
Power (P) = where = force in the tight side
1.11 Width =
1.12 Torque = Force x radius
2. STRESS AND STRAIN
2.1 Stress = or ( )
2.2 Strain =
2.3 Young’s modulus (E) = of ( )
Copyright reserved Please turn over
20 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2016)
3. HYDRAULICS
3.1 ( )
Pressure (P) =
( )
3.2 Volume = Cross sectional area x stroke length (l or s)
3.3 Work done = Force x Distance
3.4 x = x
4. GEAR DRIVES
4.1 Power (P) =
4.2 Gear ratio =
4.3 Torque = Force x radius
4.4 Torque transmitted = gear ratio x input torque
4.5 ( )
Module (m) =
( )
4.6 ( ) ( )
Pitch-circle diameter (PCD) =
4.7 Outside diameter (OD) = PCD + 2 module
4.8 Addendum (a) = module (m)
4.9 Dedendum (b) = 1,157 m or Dedendum (b) = 1, 25 m
4.10 Cutting depth (h) = 2, 157 m or Cutting depth (h) = 2,25 m
4.11 Clearance (c) = 0,157 m or Clearance (c) = 0,25 m
4.12 Clearance pitch (CP) = m X
5. PULLEY DRIVES
5.1 =
5.2 Power (P) =
5.3 Velocity Ratio =
5.4 r/min of driving pulley =
Copyright reserved Please turn over
(EC/SEPTEMBER 2016) MECHANICAL TECHNOLOGY 21
6. KEYS
6.1 Width of key =
6.2 Thickness of key =
6.3 Length of key = 1,5 x diameter of shaft
6.4 Standard taper of key : 1 in 100 or 1 : 100
7. CINCINNATI DIVIVIDING HEAD TABLE FOR MILLING MACHINE
7.1 Hole circles
Side 1 24 25 28 30 34 37 38 39 41 42 43
Side 2 46 47 49 51 53 54 57 58 59 62 66
7.2 Standard change gears
24 x 2 28 32 40 44 48 56 64 72 86 100
Indexing formula = (Where N = number of divisions)
Copyright reserved Please turn over
Study this subject
Recommended for this subject

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2016 QP

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2016 Memo

Question paper
Mechanical Technology Grade 12 NSC Supplementary 2016 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP
More from Grade 12 Mechanical Technology

Annual teaching plan
Gr 12 Weld Met ATP 2023 24
_Afrikaans_hlayiso.com_--aadd113c-5a3b-4f4d-a4c4-3a80cd86f882/v1-fd2ca7edf910eab03a55/card.webp)
Memorandum
Mechanical Technology Grade 12 Eastern Cape Prelim 2024 Memo
%20GR12%20MEMO%20SEPT2024_Afrikaans_hlayiso.com_--2f874dd1-8c03-49a9-8c70-41ac528693d0/v1-55f44edf9664bf65cf74/card.webp)
Memorandum
Mechanical Technology Grade 12 Eastern Cape Prelim 2024 Memo

Memorandum
Mechanical Technology Grade 12 Eastern Cape Prelim 2024 Memo
%20MG%20Eng--ed5ab6d3-088f-425c-ade8-86186a031594/v1-3e0bd44f4bc86cf3bb1d/card.webp)
Memorandum
Mechanical Technology Grade 12 November 2024 NSC Memo (Eng)
%20MG%20Afr--03c703c8-8125-4d5a-a124-37013b381c7a/v1-02788e8df50b92af342d/card.webp)
Memorandum
