2 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
QUESTION 1: MULTIPLE-CHOICE QUESTIONS (GENERIC)
1.1 B✓ (1)
1.2 A✓ (1)
1.3 C✓ (1)
1.4 C✓ (1)
1.5 A✓ (1)
1.6 D✓ (1)
[6]
QUESTION 2: SAFETY (GENERIC)
2.1 Gas cylinder safety precautions:
• Always store and use gas cylinders in an upright position. ✓
• Never stack cylinders on top of one another. ✓
• Do not bang or work on the cylinders. ✓
• Never allow cylinders to fall. ✓
• No oil and grease should come into contact with gas cylinders or fittings. ✓
• Keep the caps on the cylinders for protection. ✓ (Any 2 x 1) (2)
2.2 Employers’ responsibility regarding safety:
• Provide and maintain working systems, work area, equipment and tools in
a safe condition. ✓
• Eliminate or reduce any hazard or potential hazard. ✓
• Produce, handle, store and transport goods safely. ✓
• Ensure that every person employed complies with the requirements of this
Act. ✓
• Enforce measures, if necessary, in the interest of health and safety. ✓
• Appoint a person who is trained and who have the authority to ensure that
employee take precautionary measures. ✓ (Any 2 x 1) (2)
2.3 Safety precautions before switching on the angle grinder:
• Make sure that there are no cracks or chips on the disc. ✓
• Make sure that there are no flammable materials nearby. ✓
• Ensure that guards are in place. ✓
• Wear the appropriate PPE especially eye protection. ✓ (Any 2 x 1) (2)
2.4 Welding goggles:
• To protect your eyes against sparks. ✓
• To protect your eyes against heat. ✓
• To see where to weld. ✓ (Any 2 x 1) (2)
2.5 Disadvantages of process layout:
• Production is not always continuous. ✓
• Transportation costs between process departments may be high. ✓
• Additional time is spent in testing and sorting as the product moves to the
different departments. ✓
• Damage to fragile goods may result from extra handling. ✓ (Any 2 x 1) (2)
[10]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 3
QUESTION 3: MATERIALS (GENERIC)
3.1 Reason to cut from the unmarked end:
• Marking does not get lost ✓
• Be able to identify the material ✓ (Any 1 x 1) (1)
3.2 Heat-treatment processes properties:
PROCESS PROPERTY
3.2.1 Hardening Very hard, high tensile strength and brittle ✓
3.2.2 Tempering Tough, hard ✓
3.2.3 Annealing Soft, ductile, low tensile strength ✓
3.2.4 Normalising Tough and machinable ✓ (4)
3.3 Heat-treatment process steps:
• Heat the metal slowly to a temperature below the critical temperature. ✓
• Soak it at that temperature for a period. ✓
• Quench / cool in an appropriate quenching medium. ✓ (3)
3.4 Quenching media:
• Water
• Brine
• Oil (3)
3.5 Types of tests:
3.5.1 Filing test ✓ (1)
3.5.2 Spark test ✓ (1)
3.5.3 Bending test ✓ (1)
[14]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
4 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
QUESTION 4: MULTIPLE-CHOICE QUESTIONS (SPECIFIC)
4.1 A✓ (1)
4.2 D✓ (1)
4.3 C✓ (1)
4.4 C✓ (1)
4.5 B✓ (1)
4.6 A✓ (1)
4.7 C✓ (1)
4.8 B✓ (1)
4.9 C✓ (1)
4.10 D✓ (1)
4.11 A✓ (1)
4.12 C✓ (1)
4.13 B✓ (1)
4.14 D✓ (1)
[14]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 5
QUESTION 4: MULTIPLE CHOICE QUESTION (SPECIFIC)
4.1 B✓
4.2 A✓
4.3 A✓
4.4 C✓
4.5 C✓
4.6 C✓
4.7 D✓
4.8 D✓
4.9 C✓
4.10 B✓
4.11 B✓
4.12 D✓
4.13 A✓
4.14 D✓ [14]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
6 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
QUESTION 5: TERMINOLOGY (LATHE AND MILLING MACHINE) (SPECIFIC)
5.1 Included angle:
𝜃 D−d
Tan = ✓
2 2𝑙
𝜃 40 − 31,6
Tan = ✓
2 2 × 60
𝜃
= tan-1 (0,07)
2
𝜃
= 4º ✓
2
𝜃 = 8º ✓ (4)
5.2 Keyway
5.2.1 D
Width =4
48
= ✓
4
= 12 mm ✓ (2)
5.2.2 D
Thickness =6
48
= ✓
6
= 8 mm ✓ (2)
5.2.3 Length = 1,5 × D
= 1,5 × 48 ✓
= 72 mm ✓ (2)
5.2.4 Distance between cutter and engineering square
diameter of workpiece − thickness of cutter
𝜒 = ✓
2
48 − 12
= ✓
2
= 18 mm ✓ (3)
5.3 Labels A–E:
A – Workpiece ✓
B – Keyway ✓
C – Steel ruler ✓
D – Cutter ✓
E – Engineering square ✓ (5)
[18]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 7
QUESTION 6: TERMINOLOGY (INDEXING) (SPECIFIC)
6.1 Index plate enables one revolution of the crank to be further subdivided into
fractions of a revolution, especially where the fraction is the factor of 40. ✓✓ (2)
6.2 Gear terminology
6.2.1 PCD
M = T
108
= 36 ✓
= 3 mm ✓ (2)
6.2.2 OD = PCD + 2 (m)
= 108 + 2 (3) ✓
= 114 mm ✓ (2)
6.3 Spur gear cutting
6.3.1 Simple indexing
40
Indexing = A ✓
40
= 120 ✓
1 8
=3×8
8
= 24
Indexing is 8 holes in 24-hole circle ✓ (3)
6.3.2 Change gears
Driver A−N 40
= × 1 ✓
Driven A
120 −129 40
= × ✓
120 1
−3 24
= 1 × 24
−72
= 24 ✓
Driver has 72 teeth ✓
Driven has 24 teeth ✓ (5)
6.3.3 Index plate rotates in the opposite direction than the crank arm. ✓ (1)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
8 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
6.4 Dovetail calculations
Calculate distance “X” between rollers:
Χ = 150 + 2(AB) – 2(CD) – 2 (r)
BC
Tan 𝜃 = AB ✓
35
Tan 60º = AB ✓
35
AB = tan 60
= 20,21 mm ✓
θ DE
Tan 2 = CD ✓
15
Tan 30º = CD ✓
15
CD = tan 30
= 25,98 mm ✓
Χ = 150 + 2(AB) – 2(CD) – 2 (r) ✓
= 150 + 2(20,21) – 2(25,98) – 2(15) ✓
= 150 + 40,42 – 51,96 – 30
= 108,46 mm ✓ (9)
6.5 Balancing methods
• Static balancing ✓
• Dynamic balancing ✓ (2)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 9
6.6 Balancing advantages:
• Prevents vibration ✓
• Prevents poor finish / ensure good finish ✓
• Prevents wear on bearings / components ✓
• Prevents accidents ✓
• Improve production ✓
• Promotes accuracy ✓
• Prevents damage to workpiece ✓
• Prevents components from loosening ✓ (Any 2 x 1) (2)
[28]
QUESTION 7: TOOLS AND EQUIPMENT (SPECIFIC)
7.1 Brinell and Rockwell hardness testers
Brinell hardness tester:
• The Brinell hardness test involves indenting the test material with a piece
of hardened steel or carbide ball of 10 mm. The diameter of the indentation
left in the test material is measured with a low-powered microscope. ✓✓
Rockwell hardness tester:
• Rockwell hardness test method involves indenting the test material with a
diamond cone or hardened steel-ball indenter. ✓✓
(4)
7.2 ONE function of a moment tester:
• To determine the reactions on either side of simply loaded beam. ✓
• To illustrate the concept of the triangle of forces. ✓ (Any 1 x 1) (1)
7.3 Precision measuring instruments:
• Outside micrometer ✓
• Inside micrometer ✓
• Depth micrometer ✓ (3)
7.4 Micrometer reading
✓ ✓ ✓ ✓
100 + 11,00 + 0,50 + 0,09
= 111,59 mm ✓ (5)
[13]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
10 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
QUESTION 8: FORCES (SPECIFIC)
8.1 System of forces
8.1.1 Sum of horizontal components:
∑HC = ‒350 cos 0 + 280 cos 50 ‒ 300 cos 30 ‒ 200 cos 35
= ‒350 ✓ + 179,98 ✓– 251,81 ✓ ‒ 163,83 ✓
= ‒593,66 N ✓ (5)
8.1.2 Sum of vertical components:
∑VC = -350 sin 0 + 280 sin 50 -300 sin 30 - 200 sin 35
= 0 + 214,49 ✓– 150 ✓ – 114,72 ✓
= 249,77 N ✓
OR
Force 𝜽 Vertical components Horizontal components
350 180 350 sin 180 0 350 cos 180 ‒350
280 50 280 sin 50 214,49 280 cos 50 179,98
300 150 300 sin 150 150 300 cos 150 ‒259,81
200 215 200 sin 215 ‒114,72 200 cos 215 ‒163,83
TOTAL Y 249,77 N X ‒593,66 N (4)
8.1.3 Magnitude of the resultant:
R2 = X2 + Y 2
= (593,66)2 + (249,77)2 ✓
= √414 817, 25
R = 644,06 N ✓ (2)
8.1.4 Angle and the direction of the resultant:
Y
Tan 𝜃 = ✓
X
249,77
= ✓
593,66
= tan-1 (0,4207 …)
𝜃 = 22,82º N of W ✓ OR 157,82º (3)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 11
8.2 UDL BEAM
8.2.1 Uniform distributed load
6 x 100 ✓
= 600 N ✓ (2)
8.2.2 Calculate A
Taking moments about B
∑CWM = ∑ACWM
(2 500 x 4) + (600 x 7) +(1 400 x 10) = (A x 12) ✓
10 000 + 4 200 + 14 000 = A ✓
12 1
A = 2 350 N ✓ (3)
8.2.3 Calculate B
Taking moments about A
∑CWM = ∑ACWM
(1 400 x 2) + (600 x 5) +(2 500 x 8) = (B x 12) ✓
2 800 + 3 000 + 20 000 = B✓
12 1
B = 2 150 N ✓ (3)
8.3 Stress and strain
8.3.1 Stress
20 mm = 0,02 m
50 kN = 50 x 103
A = 𝜋 r2
= 𝜋 (0,01)2 ✓
= 3,14 × 10-4 m2 ✓
F
𝜎 = ✓
A
= 50 × 103 ✓
3,14 × 10-4
= 1,59 × 108 Pa ✓ OR 159, 15 MPa (5)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
12 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
8.3.2 Strain
∆𝑙
𝜀 = ✓
𝐿
605 – 600
= ✓
600
= 8,33 x 10-3 ✓ (3)
8.3.3 Young’s modulus of elasticity
𝜎
K = 𝜀
✓
= 1,59 x 108 ✓
8,33 x 10-3
= 1,91 x 1010 Pa ✓ OR 19,1 GPa (3)
[33]
QUESTION 9: MAINTENANCE
9.1 Failure to do maintenance:
• Risk of possible injury or death e.g. brake failure ✓
• Financial loss due to damages caused by part failure ✓
• Loss of production time ✓ (3)
9.2 Coefficient of friction factors:
• Contact pressure ✓
• Surface roughness ✓
• Temperature ✓
• Sliding velocity ✓
• Type of lubricant ✓
• Type of material ✓ (Any 3 x 1) (3)
9.3 Cutting fluid:
To reduce friction ✓
Remove metal chips ✓
Take away chips, cool cutting tool and prevent rust ✓ (Any 1 x 1) (1)
9.4 Preventative maintenance:
9.4.1 V-belt drive:
Checking for wear and tear on belt ✓
Checking belt alignment ✓
Checking the tension setting ✓
Checking tensioning devices, for example jockey ✓ (Any 2 x 1) (2)
9.4.2 Gear drive:
• Checking and replenishment of lubrication levels ✓
• Ensuring that gears are properly secured to shafts ✓
• Cleaning and replacement of oil filters ✓
• Reporting excessive noise and wear, vibration and overheating
for expect attention ✓ (Any 2 x 1) (2)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 13
9.5 Reasons for using glass fibre to manufacture motor vehicle bodies:
• Durable and strong ✓
• Can be cut and drilled ✓
• Can be polished to fine finish ✓
• Can be coloured ✓
• Fire resistance ✓
• Low maintenance ✓
• Weather resistant ✓
• Lightweight ✓
• Corrosion resistance ✓
• Chemical resistance ✓ (Any 2 x 1) (2)
9.6 Element used to enhance the strength of a glass fibre.
• Polyester resins ✓ (1)
9.7 Thermo-hardened or a thermoplastic composite:
9.7.1 Thermoplastic ✓ (1)
9.7.2 Thermo-hardened ✓ (1)
9.7.3 Thermo-hardened ✓ (1)
9.7.4 Thermoplastic ✓ (1)
[18]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
14 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
QUESTION 10: JOINING METHODS (SPECIFIC)
10.1 Most common screw thread used in South Africa
• Metric screw thread ✓ (1)
10.2 Included angle of screw threads:
10.2.1 V-screw thread 60º ✓ (1)
10.2.2 Square screw thread 90º ✓ (1)
10.3 M24 x 2,5
• 2,5 is the thread pitch ✓ (1)
10.4 Square thread calculations:
10.4.1 Lead = Pitch x number of starts
=5x2✓
= 10 mm ✓ (2)
10.4.2 1
Pitch diameter = OD ‒ 2 pitch
1
= 82 ‒ 2 (5) ✓
= 79,5 mm ✓ (2)
10.4.3 lead
Helix angle: tan 𝜃 = ✓
pitch circumference
10
tan 𝜃 = 𝜋 × 79,5 ✓✓
𝜃 = tan-1 (0,04)
𝜃 = 2,29º ✓ (4)
10.4.4 Leading tool angle = 90º – (helix + clearance angle)
= 90º – (2,29º + 3º) ✓
= 84,71º ✓ (2)
10.4.5 Following tool angle = 90º + (helix ‒ clearance angle)
= 90º + (2,29º ‒ 3º) ✓
= 89,29º ✓ (2)
10.5 A multi-start thread allows for a faster travel or movement and is more efficient
compared to single-start thread. ✓✓ (2)
[18]
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 15
QUESTION 11: SYSTEMS AND CONTROL (DRIVE SYSTEMS) (SPECIFIC)
11.1 Factors to determine the use of gear drives:
• Where high levels of torque and power have to be transmitted ✓
• Where direction of power transmission has to change ✓
• Where there are restricted spaces ✓
• Where varying rotating speeds are needed ✓ (Any 2 x 1) (2)
11.2 Gear drives:
11.2.1 Rotation frequency of the output:
Ninput Product of the drivens
Noutput = Product of the drivers ✓
1440 ✓ 40 x 48 x 90 ✓
Noutput = 24 x 20 x 42
Noutput = 1 440 x 24 x 20 x 42
40 x 48 x 90
= 168 r/min ✓ (4)
11.2.2 Velocity ratio
VR = Ninput
Noutput
= 1 440 ✓
168
= 8,6 : 1 ✓
OR
Product of the drivens
Gear ratio =
Product of the drivers
40 × 48 × 90 ✓
= 24 × 20 × 42
= 8,6 : 1 ✓ (2)
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
16 MECHANICAL TECHNOLOGY (FITTING AND MACHINING) (EC/SEPTEMBER 2024)
11.3 Belt-drive system:
11.3.3 Rotation frequency
NA × DA = NB × DB
NA × 0,35 = 1 000 × 0,25 ✓
1 000 x 0,25
NA = ✓
0,35
= 714,29 r/min ✓ (3)
T2
11.3.3 Belt speed =
𝜋𝐷𝑁
✓
60
𝜋 × 0,25 × 1 000
= ✓
60
= 13,09 m/s ✓ (3)
11.3.4 Power = (T1 – T2) V ✓
= (200 - 90) 13,09 ✓
= 1439,9 W ✓ OR 1,44 kW (3)
11.4 Hydraulics:
11.4.1 Fluid pressure:
38 mm = 0,038 r (0,019)
175 mm = 0,175 r (0,0875)
AA = 𝜋 r2
= 𝜋 (0,019)2 ✓
= 1,13 x 10-3 m2 ✓
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Downloaded from hlayiso.com
(EC/SEPTEMBER 2024) MECHANICAL TECHNOLOGY (FITTING AND MACHINING) 17
F
P = ✓
A
= 300 ✓
1,13 x 10-3
= 265 486, 72 Pa ✓ OR 265,49 kPa (5)
11.4.4 The load that can be lifted by piston B
AB = 𝜋 r2
= 𝜋 (0,0875)2 ✓
= 2,41 × 10-2 m2 ✓
F
P = ✓
A
load
265 486, 72 = ✓
2,41 x 10-2
Load = 265 486, 72 × 2,41 × 10-2 ✓
= 6398,22 N ✓ (6)
[28]
TOTAL: 200
,
Copyright reserved Please turn over
Hosted by www.ecexams.co.za.
Study this subject
Recommended for this subject
%20Eng--10859467-be3e-41fb-aee0-b797c385437d/v1-986e8982bfb6b966a34d/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2024 QP (Eng)

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2020 Memo
%20MEMO%20SEPT%202018_English_hlayiso.com_--b985e4dd-9a08-4ec2-a07b-64edd6f727ea/v1-e5704410f2b7cfd49bb6/card.webp)
Memorandum
Mechanical Technology Grade 12 Automotive 2018 Memo (Eng)
%20GR12%20MEMO%20SEPT%202018_English_hlayiso.com_--1b0b4dd6-b53e-485d-9068-6f378eb8c9f3/v1-7320b22b5b5eecec97b6/card.webp)
Memorandum
Mechanical Technology Grade 12 2018 Memo (Eng)

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2023 QP

Question paper
Mechanical Technology Grade 12 Eastern Cape Mock 2020 QP
More from Grade 12 Mechanical Technology

Annual teaching plan
Gr 12 Weld Met ATP 2023 24
%20Eng--5d2e2bd0-b02f-4218-849f-e7933bc6c4d1/v1-2dba8a1dc6758c98b205/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Eng)
%20Afr--1e7205e4-aef1-4cc4-afdf-aac93562ae67/v1-094abcfa5c3eff1cb995/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Afr)
%20Afr_hlayiso.com_--7d638feb-7218-4b3c-9f4c-ce95803d6e4f/v1-e8a08d94a30d7d50ccd0/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2023 QP (Afr)
%20Eng_hlayiso.com_--1523a16f-2012-4f13-a922-86cbb5900666/v1-5068227f3cbbba17b78f/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2023 QP (Eng)
%20Afr_hlayiso.com_--8d31d25d-e192-4aa9-b448-efab233391a1/v1-28cf2259fca9bcde2f63/card.webp)
Question paper
