Downloaded from hlayiso.com NATIONAL SENIOR CERTIFICATE GRADE 12 INFORMATION TECHNOLOGY P2 NOVEMBER 2017 MARKING GUIDELINES MARKS: 150 These marking guidelines consist of 16 pages. Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 2 DBE/November 2017 NSC – Marking Guidelines SECTION A: SHORT QUESTIONS QUESTION 1 1.1 1.1.1 A (1) 1.1.2 D (1) 1.1.3 A (1) 1.1.4 C (1) 1.1.5 B (1) 1.2 1.2.1 Hotspot  (1) 1.2.2 Hot swappable/pluggable  (1) 1.2.3 Computer worm  (1) 1.2.4 Botnet/Bots/Zombie PC's  (1) 1.2.5 Wiki  (1) 1.2.6 Firewall  (1) 1.2.7 (Update/delete) anomaly  or redundancy (1) 1.2.8 Push  technology/notification (1) 1.2.9 Rootkit  (1) 1.2.10 Overflow  (1) TOTAL SECTION A: 15 Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 3 DBE/November 2017 NSC – Marking Guidelines SECTION B: SYSTEMS TECHNOLOGIES QUESTION 2 2.1 2.1.1 Windows  (1) 2.1.2 Any THREE functions of an operating system:  • Supply an interface/GUI/UI • Manage all the processes and tasks/apps/software • Manage the computer memory/RAM • Manage the input and output to and from the computer system • Manage all disk drives/hardware (3) 2.1.3(a) Multitask processing: The computer appears to run multiple programs  at the same time/simultaneously by sharing processing time of the CPU  between processes/tasks Concepts: • Any indication of multiple programs/applications • Sharing of CPU time between programs (2) 2.1.3(b) Multithreading: When a single program is broken up into independent parts/threads that run at the same time . Concepts: • Program/application is split into parts/threads • Independent processing (2) 2.2 4/multiple processor cores  on one CPU chip (1) 2.3 Any TWO  • The amount of RAM that can be addressed by the operating system (32 bit and 64 bit operating system) is limited • The number of RAM slots on the motherboard is limited • The cost of RAM – expensive • RAM stores current instructions being processed • The hard drive is storage of all data/software (2) 2.4 2.4.1 Any ONE  • Allows connection/access to the Internet/different networks • Explanation of routing (1) 2.4.2 LTE/Wi-Fi  (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 4 DBE/November 2017 NSC – Marking Guidelines 2.5 A graphics card generates images  faster using the GPU (graphics processor unit). The use of a separate video card will allow the CPU to focus on carrying out program instructions  thus reducing the load on the CPU. Concepts: • Generation of images/graphics card has own processor • Taking load away from CPU/GPU is faster at generating images (2) 2.6 Cache memory is high speed memory that stores data and instructions  most likely to be needed next by the CPU, preventing the CPU from having to load it from the slower RAM  Concepts: Any TWO • Cache is high speed memory • CPU does not have to fetch data and instructions from slower RAM • Stores data and instructions most likely to be needed next by the CPU 1 mark only: Caching is preventing a slow process from slowing down a faster process (2) 2.7 2.7.1 The operating system detects the new device and installs the drivers automatically  OR The flash drive makes itself known to the operating system and then the operating system configures the drivers for use Concepts: • Operating system detects new device • Installation of device drivers/automated configuration (2) 2.7.2 By sending a hardware interrupt signal (IRQ)  (1) 2.8 Allows the user to access the latest version of the files  on different devices.  OR Changes in files are automatically updated between devices NOTE: Do not accept: add or access from anywhere/online/backup (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 5 DBE/November 2017 NSC – Marking Guidelines 2.9 Indexing the files means that the operating system has an index that includes the text inside the files as well as the file names.  It allows you to search for words or phrases that you can remember that might be inside the document instead of just for a file name.  Concepts: • Storing additional information about the files/content of files • Faster/easier location of files (2) 2.10 2.10.1 Any ONE  • SSD • ROM • EEPROM • Hard drive (HDD) (1) 2.10.2 Any TWO  • Smaller display areas • Input constraints/limited number of input devices • Limitation in hardware/processing capabilities • Limited memory • Limited storage space on mobile devices • Extending battery life/limiting power usage • Availability of facilities such as GPS/Accelerometer, etc. • Compatibility between devices • The amount of data that the application will use (2) TOTAL SECTION B: 27 Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 6 DBE/November 2017 NSC – Marking Guidelines SECTION C: COMMUNICATION AND NETWORK TECHNOLOGIES QUESTION 3 3.1 3.1.1 Any ONE  • UTP/STP (CAT 5/CAT 6) • fibre optic cables Also accept: co-axial cables (1) 3.1.2 Star  (1) 3.1.3 (a) TCP/IP (IPv4/IPv6) /Internet protocol  (1) 3.1.3 (b) http/https  (1) 3.2 The user can log on over a public network  like the Internet with the same, if not better, benefits of privacy and security  of a LAN. Concepts: • Secure log on/secure connection • From remote location/over Internet/public network (2) 3.3 3.3.1 Invisible  data capturing (1) 3.3.2 Any ONE real life example of data capturing and explanation  • Buying with credit card or using a loyalty card – type of products you buy/information on your lifestyle • Completing forms – extra information that is not always relevant to form/form does not only go to intended recipient • Via the Net – sites you visit or bookmark/comments on social networks/content of e-mails • Using e-tags – travel habits/locations visited • Telecommunication system – who you call/where you are – predict lifestyle etc. Or any other valid example that leaves an electronic trail NOTE: Do not accept any indication of theft of personal information (2) 3.3.3 Purpose of targeted marketing/supplied information.  (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 7 DBE/November 2017 NSC – Marking Guidelines 3.4 Any THREE:  • JavaScript/Browser side scripting • Server side instructions/scripting/code • SQL stored procedures • AJAX • Applescript • HTML4/HTML5 • PHP • jQuery • Python • Ruby Or any acceptable verifiable scripting language (3) 3.5 3.5.1 Cookie: A text file  stored on your local computer that is used to save user settings/preferences  for a website. (2) 3.5.2 Any ONE effect of deleting a cookie:  • Loss of interactivity • The next time you open that webpage only default settings are available • Website/page loads more slowly (1) 3.6 Any TWO disadvantages of using VoIP:  • Need an Internet connection • Both users need the same software • Need to purchase credits to call phones not on the Internet • Poor call quality (when using a slow connection) • Data cap can be reached quickly/uses data (2) 3.7 Any ONE  • Allows one to locate the position of devices/people • Navigation capabilities • Global position system • Geotagging Or any other acceptable positioning example (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 8 DBE/November 2017 NSC – Marking Guidelines 3.8 3.8.1 DRM (Digital Rights Management) refers to any software which uses some form of encryption  and manages access  to the content of electronic media Concepts: • Software using encryption/prevents copying • Manages access/rights to electronic content/media (2) 3.8.2 Any ONE area of application of DRM software  • Digital books • Movies/music • Computer games/software/apps (1) TOTAL SECTION C: 22 Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 9 DBE/November 2017 NSC – Marking Guidelines SECTION D: DATA AND INFORMATION MANAGEMENT QUESTION 4 4.1 4.1.1 Any ONE reason why ID field may not be integer data type:  • Leading 0's will not be saved • Size of ID numbers will exceed integer capacity/storage size of an integer/number of bytes (1) 4.1.2 Any ONE reason why no other field can be the primary key: • All the other fields can contain duplicate values • Only JobCardNumber will contain unique values (1) 4.1.3 Since the DateStarted and DateCompleted fields are available , the NumDaysTaken field can be calculated (1) 4.1.4(a) ID  (1) 4.1.4(b) tblJobCards  (1) 4.2 Any ONE explanation of verifying information:  • Ensuring that information corresponds to original information at the source • Ensuring that one can prove that data is correct/confirming correctness (1) 4.3 • Extract only the first character of the gender entered  • Change the character to uppercase  Also accept: code/algorithm. (2) 4.4 4.4.1 SELECT OrderNum, Description, OrderDate  FROM tblEquipment  WHERE Delivered = false  AND year(OrderDate) = 2016  Alternative statements: • AND OrderDate like "2016%" • AND Year(OrderDate) like "2016%" • AND OrderDate between #2016/01/01# and #2016/12/31# • AND MID(Str(OrderDate),1,4) = "2016" • AND OrderDate > = #2016/01/01# AND OrderDate = < #2016/12/31# • AND OrderDate > #2016/01/01# AND OrderDate < #2016/12/31# NOTE: AND should be marked with the second condition (4) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 10 DBE/November 2017 NSC – Marking Guidelines 4.4.2 UPDATE tblEquipment  SET Delivered = true  WHERE Description = "Broom"  Alternative: WHERE Description like "Broom%" (3) 4.4.3 SELECT Teacher,  count(*) as numOrders  FROM tblClassroom, tblEquipment  WHERE tblClassroom.RoomNumber = tblEquipment.RoomNumber  GROUP BY Teacher  OR SELECT Teacher, count(*) as numOrders FROM tblClassroom INNER JOIN tblEquipment ON tblClassroom.RoomNumber = tblEquipment.RoomNumber GROUP BY Teacher NOTE: • Can use LEFT JOIN or INNER JOIN • Make use of aliases • Count any field (5) TOTAL SECTION D: 20 Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 11 DBE/November 2017 NSC – Marking Guidelines SECTION E: SOLUTION DEVELOPMENT QUESTION 5 5.1 5.1.1 Any TWO advantages of modular programming:  • Easier to debug/fewer bugs • Reuse of code/Avoids duplication of code • Can be used by other classes/units/programs • Allows library programs to be inserted thereby saving time. • Different programmers can work on specific modules based on their expertise • Collaboration/many programmers can work on same progam • Shorter algorithms makes the module easier to trace and understand (2) 5.1.2 A private function is only accessible from within  the class / unit /form A public function is accessible from outside  the class/project /form (2) 5.2 5.2.1 True  (1) 5.2.2 False  (2) 5.3 Loop from 1 to length of word  reverseWord ( addition)  word[loop] + reverseWord; (order) OR Loop from length of word down to 1 reverseWord  reverseWord + word[loop] Concepts: • Loop through word • Extract character (logic of code must be correct) • Add onto new word • Order of addition (4) 5.4 5.4.1 iSum := iSum + arrLightBulbs  [loop , loop ]; Also accept: 4 marks - iSum := iSum + arrLightBulbs[r, r]; 3 marks – if any other letter is use for both index values e.g. iSum := iSum + arrLightBulbs[x,x] If hard coded – max 2 marks (4) 5.4.2(a) Syntax  (1) 5.4.2(b) Logical  (1) 5.4.2(c) Syntax  (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 12 DBE/November 2017 NSC – Marking Guidelines 5.4.3 Reset: (any ONE)  • Opens an existing text file for reading • Moves the file pointer to the first record Rewrite: (any ONE)  • Creates a new text file • It clears the content of the existing file Do not accept: Writing to file (2) 5.5 5.5.1(a) Any ONE:  • Object cannot create/instantiate itself • Object does not exist • Need to use class name with create Do not accept: • Not allocated to a variable • Rewriting of code (1) 5.5.1(b) Incorrect order of arguments/parameters  (1) 5.5.1(c) Any ONE  • Incorrect data type/type mismatch – string and integer • There should not be inverted commas around the number (1) 5.5.2(a) Mutator  Also accept: Auxiliary (1) 5.5.2(b) Auxiliary  (1) TOTAL SECTION E: 25 Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 13 DBE/November 2017 NSC – Marking Guidelines SECTION F: INTEGRATED SCENARIO QUESTION 6 6.1 Any TWO  • IT technician • Network engineer • Network architect • Network administrator • Network analyst Do not accept: • Programmer • Any job related to database/database administrator (2) 6.2 6.2.1(a) Biometrics: The use of personal characteristics  to authenticate the identity of a person Also accept: Use parts of the body for access control (1) 6.2.1(b) Any ONE suitable example of biometrics in this scenario:  • Retina/eye • Fingerprint • Voice recognition • Facial recognition • Palm readers (1) 6.2.2 Any TWO  • RFID cards can be read from a distance that can trigger the unlocking of the room even when not required • Cards do not validate the identity of the user • Cards can be stolen/lost • Cards can be cloned • Inconvenience of carrying cards around • Cost of manufacturing cards (2) 6.3 6.3.1 Virtual memory: Hard drive space/storage  reserved by the operating system to be used as RAM/memory  Also accept for 2 marks: Hard drive space to be used when the RAM is full (2) 6.3.2 Operating system  (1) 6.3.3 Any ONE way to limit the use of virtual memory:  • Add more RAM • Do not open too many applications/Close applications not in use (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 14 DBE/November 2017 NSC – Marking Guidelines 6.4 Lossless – no data is lost  Lossy – some insignificant data is lost  (2) 6.5 6.5.1 Protocol: A set of rules  for transmission of data across a network/encoding and decoding data for transmission.  (2) 6.5.2 (Sending) e-mail  (1) 6.6 6.6.1 Distributed database: Parts of a database  are spread over multiple servers in different locations  Concepts: • Splitting database • Multiple locations (2) 6.6.2 Any TWO advantages of distributed database:  • Eliminate congestion on a single server • Can handle a large number of simultaneous users • The branches of a company can be spread over a large geographical area • If one server is down, other databases can still be used • Lower cost of communication as less data is being communicated (2) 6.7 6.7.1 Any ONE : Web 1.0:  • Mainly static web pages • Each user sees the same content every time/no interactivity. Also accept for 1 mark: Few content creators, many users (2) 6.7.2(a) The Semantic Web: Has the ability to interpret information  like humans and provide useful content tailored to user needs/personalization.  (2) 6.7.2(b) The Internet of Things  (1) 6.8 6.8.1 Online seminar  (1) 6.8.2 Any ONE  • Comfort of own office/home • Saving on travel costs/time • Expand knowledge base OR any other acceptable answer (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 15 DBE/November 2017 NSC – Marking Guidelines 6.9 6.9.1 SaaS: Software as a Service  (1) 6.9.2 Any ONE - Cloud applications:  • Software where most of the processing is done in the cloud/the processing is done by servers which are accessible via the Internet • The interface is created on the web servers/on local computers using apps or interface is accessed through a web browser Concepts: Any TWO • Local user interface • Software/applications run on servers on the web • Servers/service are accessible via Internet (2) 6.9.3 Any TWO disadvantages associated with using online services: • Software is not owned and a regular fee needs to be paid. • Cost of data used when everything is transferred from the cloud can be high. • When Internet is down, software cannot be accessed. • When the service is down, software cannot be accessed. • Exposure to security issues when documents are stored in cloud. • Too many users can slow down the service. (2) 6.10 RSS is a web or news feed/automatic provision to users of updated content and/or notifications of new content from websites (2) 6.11 6.11.1 Any TWO responsible uses of social networking sites  • Limit time on web/Turn off notifications when doing important work/Switch off mobile device at specific times • Try to remove yourself from FOMO • Refrain from insulting other people/Bullying • Be aware that all posts are public • Be aware that the Internet never forgets information/cannot delete information from the Internet • Do not share personal information e.g. ID number or bank account numbers • Do not befriend strangers OR any suitable answer (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Information Technology/P2 16 DBE/November 2017 NSC – Marking Guidelines 6.11.2 Any TWO reasons why cybercrime is prevalent:  • Low risk of physical danger to criminal/not physically present when crime is committed • Difficult to detect a crime • Difficult to trace who committed the crime • Increase use of Internet • Increased number of online financial transactions • People's general ignorance and carelessness (2) 6.11.3 Piggybacking  (1) 6.12 6.12.1 A machine that have a certain amount of autonomous flight capabilities, while still being controlled by a human. OR any similar explanation Accept: control of flying object (1) 6.12.2 Any TWO benefits of 3D printing  • No other complicated machinery needed for manufacturing • Parts can be computer designed and directly printed • Easy to change design and print again • Parts that fail can easily be printed again • No waiting period for ordered parts • More cost effective for small numbers OR any other acceptable answers (2) TOTAL SECTION E: 41 GRAND TOTAL: 150 Copyright reserved
