Information Technology Grade 12 P1 2023 Memo (Afr)

MemorandumInformation TechnologyGrade 12202320 pages

Grade 12 Information Technology Paper 1 memorandum from the Eastern Cape Mock Exam 2023 (Afrikaans), 20 pages. Read online or download the free PDF.

Free to read online, no sign-up needed

Answer online

Loading document…

Loading document…

Questions in this paper

Document textSearch extracted text and jump to a page.
NASIONALE SENIORSERTIFIKAAT GRAAD 12 SEPTEMBER 2023 INLIGTINGSTEGNOLOGIE V1 NASIENRIGLYN PUNTE: 150 Hierdie nasienriglyn bestaan uit 20 bladsye.
2 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) NAAM VAN LEERDER: TOTAAL TOTAAL TOTAAL TOTAAL TOTAAL VRAAG 1 VRAAG 2 VRAAG 3 VRAAG 4 /40 /35 /35 /40 /150 MAKS PUNTE VRAAG 1 PUNTE BEHAAL 1.1 KNOPPIE: [V1.1 – Bepaal koste] Gebruik ʼn if / case stelling ✓ 4 Bepaal die lisensietipe uit die radio group ✓ Vertoon die lisensietipe ✓ asook die koste van die lisensie in die Koste-label komponent ✓ 1.2.1 KNOPPIE: [V1.2.1 – Voeg voorste wiel by] Skep dinamiese vorm: shpVoorsteWiel ✓ Stel ‘parent’ van shpFrontWheel na die paneel pnlV1_2_Ligte ✓ Verander die eienskappe van shpVoorsteWiel: 6 Type → Circle ✓ Top → 25 ✓ Left → 35 Width → 50 ✓ Height → 50 Colour → White ✓ 1.2.2 KNOPPIE: [V1.2.2 – Lig landingsrat op] 1 Verander die kleur van al drie vorme na Rooi ✓ 1.2.3 KNOPPIE: [V1.2.3 – Sit landingsrat neer] 1 Verander die kleur van al drie vorme na Groen ✓ 1.2.4 KNOPPIE: [V1.2.4 – Toets landingsrat] Gebruik ʼn case of if statement, bepaal die toestand van die ligte en skep die korrekte boodskap met ‘n Message DLG 8 As al 3 ligte = Rooi ✓ → MessageDLG ✓ (‘Katastrofiese fout’) ✓ Else ✓ As al 3 ligte = Groen ✓ → MessageDLG(‘Veilig om te land’) ✓ Else ✓ MessageDLG(‘Waarskuwing, nie veilig om te land nie’) ✓ Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 3 1.3 KNOPPIE: [V1.3 Hoogtepunt van Daling] Vertikale Spoed Kry BeginSpoed Kry EindSpoed ✓ Kry Wind Kry Helling GemiddeldeSpoed = (BeginSpoed + EindSpoed) / 2 + Wind ✓✓ VertikaleSpoed_NM_P_Min = (tan(Helling * DEG_TO_RAD) * GemiddeldeSpoed) / 60 ✓✓ VertikaleSpoed := VertikaleSpoed_NM_P_Min * NM_TO_FT ✓ Afstand Kry BeginHoogte ✓ Kry EindHoogte 20 DeltaHoogte = BeginHoogte – EindHoogte ✓ Afstand = (DeltaHoogte * FT_TO_NM) / tan(Helling * DEG_TO_RAD); ✓✓ DeltaSpoed = BeginSpoed - EindSpoed; ✓ Afstand = Afstand + ceil(DeltaSpoed / 10) ✓ Afstand = Afstand + ceil(Windspoed / 10) ✓ Tyd Geskatte tyd = (Afstand / GemiddeldeSpoed) * 60 ✓ Maak rich edit skoon Voeg by rich edit: Vertikale Spoed: VertikaleSpoed (fpm) – geformateer na 2 desimale ✓✓ Afstand: Afstand (nm) – geformateer na 2 desimale ✓✓ Geskatte Tyd: Geskatte tyd (min) – geformateer na 2 desimale ✓✓ Vraag 1 Totaal 40 Kopiereg voorbehou Blaai om asseblief
4 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) MAKS PUNTE VRAAG 2 PUNTE BEHAAL 2.1.1 Knoppie [V2.1.1] 'SELECT Naam, Van, Ouderdom, Epos FROM tblVlieeniers WHERE Ouderdom > 35 AND Ouderdom < 43 ORDER BY Ouderdom DESC' SELECT vier korrekte velde ✓ 4 FROM korrekte tabel ✓ WHERE Ouderdom in die reeks van 36 (insl) en 42 (insl) ✓ ORDER BY korrekte veld DESC ✓ 2.1.2 Knoppie [V2.1.2] 'SELECT * FROM tblVlugte WHERE Bestemming LIKE’ + QuotedStr('%' + sLine + '%') SELECT * (alle velde) ✓ 4 FROM korrekte tabel ✓ WHERE Bestemming LIKE ✓ QuotedStr(‘%’ + sLine + ‘%’) ✓ 2.1.3 Knoppie [V2.1.3] 'SELECT count(*) AS [Vlugte in September] FROM tblVlugte WHERE Month(VertrekDatum) = 9' SELECT count(*) ✓AS [Vlugte in September] 3 FROM tblVlugte WHERE Month ✓ (VertrekDatum) = 9 ✓ 2.1.4 Knoppie [V2.1.4] ‘SELECT Bestemming, Format(sum(VlieenierKostePerVlug), "Currency") AS [Vlieenierkoste], Format(sum(Vlugkoste), "Currency") AS [Vlugkoste], Format(sum(VlieenierKostePerVlug) + sum(VlugKoste), "Currency") AS [Totale Koste] FROM tblVlieeniers, tblVlugte WHERE tblVlieeniers.VlieenierID = tblVlugte.VlieenierID GROUP BY Bestemming' SELECT Bestemming ✓ , Format ✓ (sum ✓ (VlieenierKostePerVlug) ✓, "Currency"✓) AS [Vlieenierkoste] ✓, 12 Format(sum(Vlugkoste), "Currency") AS [Vlugkoste] ✓, Format((sum(VlieenierKostePerVlug) ✓ + sum(Vlugkoste) )✓, "Currency") AS [Totale Koste] FROM albei tabelle ✓ (tblVlieeniers, tblVlugte) WHERE verbinding tussen tabelle ✓ (tblVlieeniers.VlieenierID = tblVlugte.VlieenierID) GROUP BY Bestemming ✓ 2.1.5 Knoppie [V2.1.5] 'UPDATE tblVlieeniers SET VlieenierKostePerVlug = VlieenierKostePerVlug * 1.07 WHERE LisensieTipe = "KVL"' UPDATE korrekte tabel ✓ 3 SET VlieenierKostePerVlug = VlieenierKostePerVlug * 1.07 ✓ WHERE LisensieTipe = “KVL” ✓ Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 5 2.2.1 Knoppie [V2.2.1] if FieldByName(‘Ouderdom').AsInteger < 21 then ✓ delete ✓ 3 else next; ✓ 2.2.2 Knoppie [V2.2.2] begin if Bestemming = sBestemming then ✓ begin if LisensieVereiste = 'KVL' then inc(iKVL) else if LisensieVereiste = 'PVL' then ✓ inc(iPVL) else if LisensieVereiste = 'MVL' then 6 inc(iMVL); if MedeVlieenier = True then ✓ inc(imedevlieenier) end ✓ NB: Medevlieenier moet binne die begin en end wees, anders tel dit op l die medevlieeniers vir al die bestemmings. Next ✓ end Afvoer ('KVL: ' + IntToStr(iKVL) + #13 + 'PVL: ' + IntToStr(iPVL) + #13 + 'MVL: ' + IntToStr(iMVL) + #13 + ✓ 'Medevlieenier nodig: ' + IntToStr(imedevlieenier)); Vraag 2 Totaal 35 Kopiereg voorbehou Blaai om asseblief
6 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) MAKS PUNTE VRAAG 3 PUNTE BEHAAL 3.1.1 Konstruktor Create Korrekte opskrif en parameters ✓✓ fNaam := sNaam fVervaardiger := sVervaadiger fSpoed := rSpoed fHoogte := rHoogte fAfstand := rAfstand fGewig := rGewig 5 fVlerkspan := rVlerkspan fVuurkrag := iVuurkrag fPrentjieNaam := sPrentjieNaam fLand := sLand fBeskrywing := sBeskrywing Korrekte toekenning van al die attribute ✓✓✓ 3.1.2 Mutator Metode – setWaardes Korrekte opskrif (prosedure setWaardes) ✓ 5 Korrekte omskakeling van elke attribuut ✓✓✓✓ 3.2.1 OnChange gebeurtenis van cmbV3_KiesVliegtuig 1. Kry die gebruikers se keuse uit die combo box ✓ 2. Toets om te sien of tekslêer bestaan en ken lêer toe. As die lêer nie bestaan nie, vertoon ‘n boodskap en exit AssignFile(MyFile, 'Vliegtuig_Lys.csv'); ✓ Try ✓ Reset(MyFile); ✓ except ShowMessage('lêer nie gevind nie'); ✓ Exit; ✓ end; Of alternatief: if not (fileexists(textfile) = true) then 3. Lus deur die tekslêer totdat die vliegtuig gevind is. bFound := False; ✓ while (not eof(MyFile)) ✓ AND (bFound = False) ✓ do if pos(UpperCase(sSearch),UpperCase(sOneline)) ✓ <> 0 ✓ then bFound := True; ✓ 25 4. As die vliegtuig gevind is, dan: Lus en onttrek die inligting van die tekslêer //Vliegtuignaam iPos := pos(',',sOneLine); ✓ sNaam := copy(sOneLine,1,iPos-1); ✓ delete(sOneLine,1,iPos); ✓ //Ander velde ✓✓ Instansieer (skep) die objek objVliegtuig. objVliegtuig := TVliegtuig.Create ✓(sNaam, sVervaardiger, rSpoed, rHoogte, rAfstand, rGewig, rVlerkspan, iVuurkrag, sPrentjieNaam, sLand, sBeskrywing); ✓✓ 5. Roep die setWaarde-metode ✓ 6. Laai die objekdata in die komponente ✓✓✓✓ Vraag 3 Totaal 35 Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 7 MAKS PUNTE VRAAG 4 PUNTE BEHAAL 4.1 Kry die bestemming uit die combo box ✓ 6 Ken die bestemmingskikking aan die ar2Bespreking toe ✓✓✓✓✓ 4.2 1. Kry die sitpleknommer ✓✓ Lus deur die skikking en bepaal of die sitplek bespreek is ✓✓ Vertoon ‘n boodskap as die sitplek reeds bespreek is ✓ 2. Bespreek die sitplek in ar2Bespreking ✓ Kry al die data ✓ Bepaal klas ✓ Bepaal prys ✓ If Besigheidsklas * 1.95 ✓ 17 Vertoon opskrif Besprekinginligting ✓ in bold ✓ Vertoon besprekingskaartjie-inligting geformateer: 'Naam en Van: ' + #13#9 + sNaamVan + #13 + ✓ 'Bestemming: ' + #13#9 + sBestemming + #13 + 'Datum en Tyd: ' + #13#9 + sDatum + #13 + #9 + sTyd + ' vlug' + #13 + 'Klas: ' + #13#9 + sKlas + #13 + 'Sitpleknommer: ' + #13#9 + cCol ✓+ IntToStr(iRow + 1)✓+ #13 + 'Koste: ' + #13#9 + FloatToStrF✓ (rPrice,ffCurrency✓,10,2); 4.3 1. Kry die bestemming ✓ 2. Lus deur ar2Bespreking en vermeerder die aantal passasiers: Besigheidsklas Lus deur Rye 0 to 1 ✓ Lus deur kolomme 0 to 4 ✓ if ar2Bespreking[Row,Col] = 'B' then ✓ vermeerder(besigheidsklas teller) ✓ en Ekonomiese Klas Lus deur rye 2 tot 14 ✓ Lus deur kolomme 0 tot 4 if ar2Bespreking[Row,Col] = 'B' then ✓ vermeerder(ekonomiese klas teller) 17 3. Bepaal koste vir besigheidsklas ✓✓ en ekonomiese klas ✓✓ 4. Vertoon besprekinskaartjie-inligting geformateer 'Passasiers' + #13 + #9 + 'Besigheidsklas: ' + IntToStr(iBusClass) + #13 + ✓ #9 + 'Ekonomiese klas: ' + IntToStr(iEcoClass) + #13 + ✓ #9 + 'Totaal: ' + IntToStr(iBusClass + iEcoClass) + #13#13 + ✓ 'Koste' + #13 + #9 + 'Besigheidsklas: ' + FloatToStrF(rBusPrice,ffCurrency,10,2) + #13 + ✓ #9 + 'Ekonomiese klas: ' + FloatToStrF(rEcoPrice,ffCurrency,10,2) + #13 + ✓ #9 + 'Totale Koste: ' + FloatToStrF(rBusPrice + rEcoPrice,ffCurrency,10,2);✓ Vraag 4 Totaal 40 Kopiereg voorbehou Blaai om asseblief
8 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) VOORBEELDE EN OPLOSSINGS VRAAG 1 ////////// 40 punte ////////// ////////// Vraag 1.1 – 4 punte ////////// procedure TfrmQuestion1.btnQ1_1_CostClick(Sender: TObject); begin case rgpQ1_1_License.ItemIndex of 0 : lblQ1_1_Cost.Caption := 'Microlight Pilot License = R37 000'; 1 : lblQ1_1_Cost.Caption := 'Private Pilot License = R110 451'; 2 : lblQ1_1_Cost.Caption := 'Commercial Pilot License = R761 379'; end; end; ////////// Vraag 1.2.1 – 6 punte ////////// procedure TfrmQuestion1.btnQ1_2_1Click(Sender: TObject); begin shpFrontWheel := TShape.Create(frmQuestion1); shpFrontWheel.Parent := pnlQ1_2_Lights; with shpFrontWheel do begin Shape := stCircle; Top := 25; Left := 35; Height := 50; Width := 50; Brush.Color := clWhite; end; end; ////////// Vraag 1.2.2 – 1 punt ////////// procedure TfrmQuestion1.btnQ1_2_2_UpClick(Sender: TObject); begin btnQ1_2_1.Click; //Provided code, DO NOT DELETE shpFrontWheel.Brush.Color := clRed; shpLeftWheel.Brush.Color := clRed; shpRightWheel.Brush.Color := clRed; end; ////////// Vraag 1.2.3 – 1 Punt ////////// procedure TfrmQuestion1.btnQ1_2_3_DownClick(Sender: TObject); begin btnQ1_2_1.Click; //Provided code, DO NOT DELETE shpFrontWheel.Brush.Color := clGreen; shpLeftWheel.Brush.Color := clGreen; shpRightWheel.Brush.Color := clGreen; end; Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 9 ////////// Vraag 1.2.4 – 8 punte ////////// procedure TfrmQuestion1.btnQ1_2_4_TestClick(Sender: TObject); begin btnQ1_2_1.Click; //Provided code, DO NOT DELETE RandomColours; //Provided code, DO NOT DELETE if (shpFrontWheel.Brush.Color = clRed) AND (shpLeftWheel.Brush.Color = clRed) AND (shpRightWheel.Brush.Color = clRed) then MessageDLG('Catastrophic failure!',MTError,[MBOk],0) else if (shpFrontWheel.Brush.Color = clGreen) AND (shpLeftWheel.Brush.Color = clGreen) AND (shpRightWheel.Brush.Color = clGreen) then MessageDLG('Safe to land',MTInformation,[MBOk],0) else MessageDLG('Caution, not safe to land',MTInformation,[MBOk],0); ALTERNATIEWE OPLOSSING var iFront, iLeft, iRight, iTotal : Integer; iFront := 0; iLeft := 0; iRight := 0; iTotal := 0; if shpFrontWheel.Brush.Color = clGreen then iFront := 1; if shpLeftWheel.Brush.Color = clGreen then iLeft := 1; if shpRightWheel.Brush.Color = clGreen then iRight := 1; iTotal := iFront + iLeft + iRight; case iTotal of 0 : MessageDLG('Catastrophic failure!',MTError,[MBOk],0); 1,2 : MessageDLG('Caution, not safe to land',MTInformation,[MBOk],0); 3 : MessageDLG('Safe to land',MTInformation,[MBOk],0); end; end; Kopiereg voorbehou Blaai om asseblief
10 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) ////////// Vraag 1.3 - 20 Punte ////////// procedure TfrmQuestion1.Q1_3_TopOfDescentClick(Sender: TObject); const DEG_TO_RAD = 0.0174532925; const NM_TO_FT = 6076.11549; const FT_TO_NM = 1 / NM_TO_FT; var rAverageSpeed, rStartSpeed, rEndSpeed, rVerticalSpeed, rWind : Real; rGlideSlope, rVerticalSpeed_NM_P_Min : Real; rStartAltitude, rEndAltitude : Real; rDistance, rDeltaAltitude, rDeltaSpeed : Real; rEstimatedTime : Real; begin //Vertical Speed rStartSpeed := StrToFloat(edtQ1_3_StartSpeed.Text); rEndSpeed := StrToFloat(edtQ1_3_EndSpeed.Text); rWind := StrToFloat(edtQ1_3_Wind.Text); rGlideSlope := StrToFloat(edtQ1_3_GlideSlope.Text); rAverageSpeed := (rStartSpeed + rEndSpeed) / 2 + rWind; rVerticalSpeed_NM_P_Min := (tan(rGlideSlope * DEG_TO_RAD) * rAverageSpeed) / 60; rVerticalSpeed := rVerticalSpeed_NM_P_Min * NM_TO_FT; //Distance rStartAltitude := StrToFloat(edtQ1_3_StartAltitude.Text); rEndAltitude := StrToFloat(edtQ1_3_EndAltitude.Text); rDeltaAltitude := rStartAltitude - rEndAltitude; rDistance := (rDeltaAltitude * FT_TO_NM) / tan(rGlideSlope * DEG_TO_RAD); rDeltaSpeed := rStartSpeed - rEndSpeed; rDistance := rDistance + ceil(rDeltaSpeed / 10); rDistance := rDistance + ceil(rWind / 10); //Time rEstimatedTime := (rDistance / rAverageSpeed) * 60; redQ1_3.Clear; redQ1_3.Lines.Add('Vertical Speed: ' + FloatToStrF(rVerticalSpeed,ffFixed,10,2) + ' (fpm)' + #13 + 'Distance: ' + FloatToStrF(rDistance, ffFixed, 10, 2) + ' (nm)' + #13 + 'Estimated Time: ' + FloatToStrF(rEstimatedTime, ffFixed, 10, 2) + ' (min)'); end; Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 11 VRAAG 2 ////////// 35 punte ////////// ////////// Vraag 2.1.1 – 4 punte ////////// procedure TfrmQuestion2.btnQuestion2_1_1Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sSQL1: String; begin /// Enter your code below /// sSQL1 := 'SELECT FirstName, Surname, Age, Email ' + 'FROM tblPilots ' + 'WHERE Age > 35 AND Age < 43 ' + 'ORDER BY Age DESC'; // Provided code - DO NOT DELETE OR ALTER // dbCONN.runSQL(sSQL1); if length(sSQL1) <> 0 then SetGridColumnWidths(dbgSQL); end; ////////// Vraag 2.1.2 - 4 punte ////////// procedure TfrmQuestion2.btnQuestion2_1_2Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sSQL2: String; sLine : String; begin /// Enter your code below /// sLine := InputBox('Destination','Enter the destination',''); sSQL2 := 'SELECT * ' + 'FROM tblFlights ' + 'WHERE Destination LIKE ' + QuotedStr('%' + sLine + '%'); // Provided code - DO NOT DELETE OR ALTER // dbCONN.runSQL(sSQL2); if length(sSQL2) <> 0 then SetGridColumnWidths(dbgSQL); end; ////////// Question 2.1.3 - 3 Marks ////////// procedure TfrmQuestion2.btnQuestion2_1_3Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sSQL3 : String; begin /// Enter your code below /// sSQL3 := 'SELECT count(*) AS [Flights in September] ' + 'FROM tblFlights ' + Kopiereg voorbehou Blaai om asseblief
12 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) 'WHERE Month(DepartureDate) = 9'; // Provided code - DO NOT DELETE OR ALTER // dbCONN.runSQL(sSQL3); if length(sSQL3) <> 0 then SetGridColumnWidths(dbgSQL); end; ////////// Vraag 2.1.4 - 12 punte ////////// procedure TfrmQuestion2.btnQuestion2_1_4Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sSQL4: String; begin /// Enter your code below /// sSQL4 := 'SELECT Destination, ' + 'Format(sum(PilotCostPerFlight), "Currency") AS [Pilot Cost], ' + 'Format(sum(FlightCost), "Currency") AS [Flight Cost], ' + 'Format(sum(PilotCostPerFlight) + sum(FlightCost), "Currency") AS [Total Cost] ' + 'FROM tblPilots, tblFlights ' + 'WHERE tblPilots.PilotID = tblFlights.PilotID ' + 'GROUP BY Destination'; // Provided code - DO NOT DELETE OR ALTER // dbCONN.runSQL(sSQL4); if length(sSQL4) <> 0 then SetGridColumnWidths(dbgSQL); end; ////////// Vraag 2.1.5 - 3 punte ////////// procedure TfrmQuestion2.btnQuestion2_1_5Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sSQL5: String; begin /// Enter your code below /// sSQL5 := 'UPDATE tblPilots ' + 'SET PilotCostPerFlight = PilotCostPerFlight * 1.07 ' + 'WHERE LicenseType = "CPL"'; // Provided code - DO NOT DELETE OR ALTER // dbCONN.executeSQL(sSQL5,dbgPilots,dbgFlights,dbgSQL); if length(sSQL5) <> 0 then SetGridColumnWidths(dbgSQL); end; Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 13 ////////// Vraag 2.2.1 - 3 punte ////////// procedure TfrmQuestion2.btnQuestion2_2_1Click(Sender: TObject); begin // Provided code - DO NOT DELETE OR ALTER // redQ2_Output.Clear; with tblPilot do begin Open; redQ2_Output.Lines.Add('Pilots before regulation change: ' + IntToStr(RecordCount)); First; while not (eof) do begin /// Enter your code below /// if FieldByName('Age').AsInteger < 21 then Delete else Next; end; redQ2_Output.Lines.Add('Pilots after regulation change: ' + IntToStr(RecordCount)); end; end; ////////// Vraag 2.2.2 - 6 punte ////////// procedure TfrmQuestion2.btnQuestion2_2_2Click(Sender: TObject); // Provided code - DO NOT DELETE OR ALTER // var sDestination : string; iCPL, iPPL, iMPL, iCoPilot : Integer; begin // Provided code - DO NOT DELETE OR ALTER // redQ2_Output.Clear; iCPL := 0; iPPL := 0; iMPL := 0; iCoPilot := 0; with tblFlight do begin Open; sDestination := cmbQ2_2_2_Destination.Text; redQ2_Output.SelAttributes.Style := [fsBold]; redQ2_Output.Lines.Add(sDestination); redQ2_Output.Lines.Add('--------------------------'); First; Kopiereg voorbehou Blaai om asseblief
14 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) while not (eof) do begin /// Enter your code below /// if FieldByName('Destination').AsString = sDestination then begin if FieldByName('LicenseRequired').AsString = 'CPL' then inc(iCPL) else if FieldByName('LicenseRequired').AsString = 'PPL' then inc(iPPL) else if FieldByName('LicenseRequired').AsString = 'MPL' then inc(iMPL); if (FieldByName('CoPilotRequired').AsBoolean = True) then inc(iCoPilot); end; Next; end; redQ2_Output.Lines.Add('CPL: ' + IntToStr(iCPL) + #13 + 'PPL: ' + IntToStr(iPPL) + #13 + 'MPL: ' + IntToStr(iMPL) + #13 + 'Co-Pilots required: ' + IntToStr(iCoPilot)); end; end; Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 15 VRAAG 3 ////////// 35 punte ////////// ////////// Vraag 3.1.1 – 5 punte ////////// constructor TAircraft.Create(sName, sManufacturer : String; rSpeed, rHeight, rRange, rWeight : Real; rWingspan : Real; iFirepower : Integer; sImageName, sCountry : String; sDescription : WideString); begin fName := sName; fManufacturer := sManufacturer; fSpeed := rSpeed; fHeight := rHeight; fRange := rRange; fWeight := rWeight; fWingspan := rWingspan; fFirepower := iFirepower; fImageName := sImageName; fCountry := sCountry; fDescription := sDescription; end; ////////// Vraag 3.1.2 – 5 punte ////////// procedure TAircraft.setValues; begin fSpeed := fSpeed * 1.852; //Knots converted to KM/h fHeight := fHeight * 0.3048; //Feet converted to Meters fRange := fRange * 1.60934; //Miles converted to KM fWeight := fWeight * 0.45359; //Pounds converted to KG fWingspan := fWingspan * 0.3048 //Feet converted to Meters end; ////////// Question 3.2.1 - 20 marks ////////// procedure TfrmQuestion3.cmbQ3_SelectAircraftChange(Sender: TObject); var sName, sManufacturer, sImageName, sCountry : String; rSpeed, rHeight, rRange, rWeight : Real; rWingspan : Real; iFirepower : Integer; sDescription : Widestring; MyFile : Textfile; sOneLine : String; sSearch : String; iPos : Integer; bFound : Boolean; Kopiereg voorbehou Blaai om asseblief
16 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) begin sSearch := cmbQ3_SelectAircraft.Text; AssignFile(MyFile, 'Aircraft_List.csv'); try Reset(MyFile); except ShowMessage('File not found'); Exit; end; bFound := False; Readln(MyFile, sOneLine); //Skip the heading line in the textfile while (not eof(MyFile)) AND (bFound = False) do begin Readln(MyFile, sOneLine); if pos(UpperCase(sSearch),UpperCase(sOneline)) <> 0 then begin //Aircraft Name iPos := pos(',',sOneLine); sName := copy(sOneLine,1,iPos-1); delete(sOneLine,1,iPos); //Manufacturer Name iPos := pos(',',sOneLine); sManufacturer := copy(sOneLine,1,iPos-1); delete(sOneLine,1,iPos); //Speed iPos := pos(',',sOneLine); rSpeed := StrToFloat(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Range iPos := pos(',',sOneLine); rRange := StrToFloat(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Weight iPos := pos(',',sOneLine); rWeight := StrToFloat(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Height iPos := pos(',',sOneLine); rHeight := StrToFloat(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Wingspan iPos := pos(',',sOneLine); rWingspan := StrToFloat(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Firepower iPos := pos(',',sOneLine); iFirepower := StrToInt(copy(sOneLine,1,iPos-1)); delete(sOneLine,1,iPos); //Image Name iPos := pos(',',sOneLine); sImageName := copy(sOneLine,1,iPos-1); Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 17 delete(sOneLine,1,iPos); //Country iPos := pos(',',sOneLine); sCountry := copy(sOneLine,1,iPos-1); delete(sOneLine,1,iPos); //Description sDescription := sOneLine; objAircraft := TAircraft.Create(sName,sManufacturer,rSpeed,rHeight,rRange, rWeight,rWingspan,iFirepower,sImageName,sCountry,sDescription); bFound := True; end; end; if bFound then begin objAircraft.SetValues; lblQ3_AircraftName.Caption := objAircraft.getName; lblQ3_Manufacturer.Caption := objAircraft.getManufacturer; imgQ3_CountryFlag.Picture.LoadFromFile('Images\Flags\' + objAircraft.getCountry); imgQ3_AircraftImage.Picture.LoadFromFile('Images\Aircraft\' + objAircraft.getImageName); lblQ3_AircraftDescription.Caption := objAircraft.getDescription; lblQ3_MaxSpeed.Caption := FloatToStrF(objAircraft.getSpeed,ffFixed,10,0); lblQ3_MaxHeight.Caption := FloatToStrF(objAircraft.getHeight,ffFixed,10,0); lblQ3_Range.Caption := FloatToStrF(objAircraft.getRange,ffFixed,10,0); lblQ3_MaxTakeoffWeight.Caption := FloatToStrF(objAircraft.getWeight,ffFixed,10,0); lblQ3_Wingspan.Caption := FloatToStrF(objAircraft.getWingspan,ffFixed,10,2); lblQ3_Firepower.Caption := IntToStr(objAircraft.getFirepower); end; end; Kopiereg voorbehou Blaai om asseblief
18 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) VRAAG 4 ////////// 40 punte ////////// ////////// Vraag 4.1 – 6 punte ////////// procedure TfrmQuestion4.cmbQ4_1_DestinationChange(Sender: TObject); var iRow, iCol : Integer; begin case cmbQ4_1_Destination.ItemIndex of //Case or If Statement 0 : ar2Booking := ar2Bloemfontein; 1 : ar2Booking := ar2CapeTown; 2 : ar2Booking := ar2Durban; 3 : ar2Booking := ar2EastLondon; 4 : ar2Booking := ar2Johannesburg; end; // //Alternate Solution // case cmbQ4_Destination.ItemIndex of //Case or If Statement // 0 : for iRow := 0 to 14 do // for iCol := 0 to 4 do // ar2Booking[iRow,iCol] := ar2Bloemfontein[iRow,iCol]; // 1 : for iRow := 0 to 14 do // for iCol := 0 to 4 do // ar2Booking[iRow,iCol] := ar2CapeTown[iRow,iCol]; // 2 : for iRow := 0 to 14 do // for iCol := 0 to 4 do // ar2Booking[iRow,iCol] := ar2Durban[iRow,iCol]; // 3 : for iRow := 0 to 14 do // for iCol := 0 to 4 do // ar2Booking[iRow,iCol] := ar2EastLondon[iRow,iCol]; // 4 : for iRow := 0 to 14 do // for iCol := 0 to 4 do // ar2Booking[iRow,iCol] := ar2Johannesburg[iRow,iCol]; // end; //Provide Code - DO NOT DELETE PaintColour; end; ////////// Question 4.2 - 17 marks ////////// procedure TfrmQuestion4.pnlQ4_2_BookClick(Sender: TObject); var sDestination, sDate, sNameSur, sTime : String; sClass, sLine : String; rPrice : Real; iRow, iCol : Integer; cCol : Char; begin Kopiereg voorbehou Blaai om asseblief
(EC/SEPTEMBER 2023) INLIGTINGSTEGNOLOGIE V1 19 redQ4_Output.Clear; iRow := sedQ4_RowNumber.Value; case cmbQ4_ColNumber.ItemIndex of 0 : begin iCol := 0; cCol := 'A'; end; 1 : begin iCol := 1; cCol := 'B'; end; 2 : begin iCol := 3; cCol := 'C'; end; 3 : begin iCol := 4; cCol := 'D'; end; end; if ar2Booking[iRow-1,iCol] = 'B' then MessageDLG('Seat has already been booked',MTInformation,[MBOK],0) else begin ar2Booking[iRow-1,iCol] := 'B'; sDestination := cmbQ4_1_Destination.Text; sDate := DateToStr(dtpQ4_Date.Date); sTime := cmbQ4_Time.Text; sNameSur := edtQ4_NameSur.Text; sClass := 'Economy Class'; rPrice := arrPrice[cmbQ4_1_Destination.ItemIndex]; case iRow of 1,2 : begin rPrice := rPrice * 1.95; sClass := 'Business Class'; end; end; sLine := 'Name and Surname: ' + #13#9 + sNameSur + #13 + 'Destination: ' + #13#9 + sDestination + #13 + 'Date and Time: ' + #13#9 + sDate + #13 + #9 + sTime + ' flight' + #13 + 'Cabin: ' + #13#9 + sClass + #13 + 'Seat Number: ' + #13#9 + cCol + IntToStr(iRow + 1) + #13 + 'Price: ' + #13#9 + FloatToStrF(rPrice,ffCurrency,10,2); redQ4_Output.SelAttributes.Style := [fsBold]; redQ4_Output.Lines.Add('Booking Information' + #13); redQ4_Output.Lines.Add(sLine); end; PaintColour; end; Kopiereg voorbehou Blaai om asseblief
20 INLIGTINGSTEGNOLOGIE V1 (EC/SEPTEMBER 2023) ////////// Vraag 4.3 – 17 punte ////////// procedure TfrmQuestion4.pnlQ4_3_StatsClick(Sender: TObject); var sLine : String; iRow, iCol : Integer; iBusClass, iEcoClass : Integer; rBusPrice, rEcoPrice : Real; begin redQ4_Output.Clear; redQ4_Output.Paragraph.TabCount := 1; redQ4_Output.Paragraph.Tab[0] := 10; iBusClass := 0; iEcoClass := 0; rBusPrice := 0; rEcoPrice := 0; for iRow := 0 to 1 do for iCol := 0 to 4 do begin if ar2Booking[iRow,iCol] = 'B' then inc(iBusClass); end; for iRow := 2 to 14 do for iCol := 0 to 4 do begin if ar2Booking[iRow,iCol] = 'B' then inc(iEcoClass); end; rBusPrice := iBusClass * (arrPrice[cmbQ4_1_Destination.ItemIndex] * 1.95); rEcoPrice := iEcoClass * (arrPrice[cmbQ4_1_Destination.ItemIndex]); redQ4_Output.SelAttributes.Style := [fsBold]; sLine := 'Passengers' + #13 + #9 + 'Business Class: ' + IntToStr(iBusClass) + #13 + #9 + 'Economy Class: ' + IntToStr(iEcoClass) + #13 + #9 + 'Total: ' + IntToStr(iBusClass + iEcoClass) + #13#13 + 'Cost' + #13 + #9 + 'Business Class: ' + FloatToStrF(rBusPrice,ffCurrency,10,2) + #13 + #9 + 'Economy Class: ' + FloatToStrF(rEcoPrice,ffCurrency,10,2) + #13 + #9 + 'Total Cost: ' + FloatToStrF(rBusPrice + rEcoPrice,ffCurrency,10,2); redQ4_Output.Lines.Add('Statistics of Flight' + #13); redQ4_Output.Lines.Add(sLine); end; TOTAAL: 150 Kopiereg voorbehou Blaai om asseblief
