2 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
SECTION A: SHORT QUESTIONS
QUESTION 1
1.1 1.1.1 Audit trail (1)
1.1.2 Destructor (1)
1.1.3 Smartwatch (1)
1.1.4 Robotics (1)
1.1.5 Compiler (1)
1.1.6 BitTorrent (1)
1.1.7 Internet of Things (1)
1.1.8 Transaction Processing System/TPS (1)
1.1.9 Green Computing (1)
1.1.10 Webinars (1)
1.2 1.2.1 B a sequence of logical steps that will solve a problem (1)
1.2.2 D 9 (1)
1.2.3 B A dynamic link library file (1)
1.2.4 D Denial-of-service attack (1)
1.2.5 B Encapsulation (1)
TOTAL SECTION A: 15
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 3
SECTION B: SYSTEM TECHNOLOGIES
QUESTION 2
2.1 2.1.1 (a) Cache is a small amount of high speed memory where data
and instructions likely to be used next by the CPU is stored,
eliminating the need to fetch it from the slower RAM.
Concepts:
High speed memory
Saving time in fetching instructions (2)
(b) Cache is embedded on the processor / It is built on the
processor and is not removable.
Concept:
not removable / embedded (1)
(c) Any TWO
Faster at boot up time / faster access time
No moving parts and is less easily damaged/longer life span
/lasts longer/more reliable
Uses less power
Generates less heat
Smaller dimensions (2)
2.1.2 (a) Any TWO
Provides a user interface
I/O management
Process management
File management
Security
Manages system memory
Optimises efficiency/speed (2)
(b) (i) Android is designed for mobile devices such as
smartphones and tablets. (1)
(ii) Linux Ubuntu is designed to be used in a network or
server or desktop environment (not by mobile devices). (1)
2.2 2.2.1 Any ONE (1)
Manage/Maintain/Control computer resources
Adds more functionality for specific management tasks
Performs routine maintenance and administration tasks in a
computer (1)
Copyright reserved Please turn over
4 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
2.2.2 Any ONE
Internet filters
Spam blockers
Pop-up blockers
Anti-spam programs
Phishing filters
Any other filtering tool (1)
2.3 2.3.1 Fast and reliable Internet connection (1)
2.3.2 Cloud application – is software where most of the processing of the
software is done in the cloud by one or more servers on the
Internet.
Local application – is the software/program that is stored and runs
on a computing device. (2)
2.3.3 Any THREE
Scalability
Ubiquity (Anywhere/Anytime)
Enables collaboration
Outsources maintenance and upgrades of hardware
Outsources software and installation and upgrades (3)
2.3.4 Cloud-based apps – software that runs on remote servers on
the internet
Downloadable, local installed apps – software that you rent is
downloaded and runs on your local computer
Integrated products – combine cloud-based software and
locally installed software (6)
TOTAL SECTION B: 23
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 5
SECTION C: COMMUNICATION AND NETWORK TECHNOLOGIES
QUESTION 3
3.1 Any TWO
High level of expertise is needed to set it up
Need a high level of security
Malware can spread very easily
If network develops a problem, no one can work
A central problem with server could lead to loss of connection to network/
non-availability of resources if the server is down/offline
Cost of hardware (2)
3.2 3.2.1
PC PC
Switch
PC
PC
Switch/Central connection point
Computers/nodes
Separate connection to the switch (3)
3.2.2 Any TWO:
Easy to troubleshoot
Easy to set-up
Easy to add new devices
Faster transmission of data to correct computer through a
switch
Can remove any computer that does not work without affecting
the network (2)
3.3 3.3.1 Any ONE
Cheap to install
Easy to install
Flexibility of cables
High bandwidth over short distances (1)
3.3.2 Any TWO
Electro Magnetic Interference (EMI)
Crosstalk
Eavesdropping (2)
Copyright reserved Please turn over
6 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
3.3.3 Any ONE
Amplifier can be used to boost the signal quality
Multiple Access Points added to increase the accessibility radius (1)
3.4 3.4.1 HTTPS (1)
3.4.2 3.4.1 Any ONE
Making video/audio/video calls over the Internet/network
Provides a two-way multimedia communication over the
Internet (1)
3.5 3.5.1 Video on Demand (1)
3.5.2 Hotspot (1)
3.5.3 To provide Internet access / to provide internet connection (1)
3.5.4 Wi-Fi / Wireless connectivity (1)
3.6 3.6.1 Digital certificate – is an electronic document/ certificate issued by a
third party to verify/authenticate the identity of a person or an
organisation may be trusted for communication of sensitive
information. (2)
3.6.2 Certificate Authority/CA (1)
3.6.3 Any ONE
Investigate and verify that the business or organisation is what it
claims to be
Its website exists at the IP address specified
Its public key has not expired (1)
3.6.4 Any FOUR
Owner’s public key
Owner’s name
Expiration date of the public key
Name of issuer (the Certificate Authority that issued the digital
certificate)
Serial number of the digital certificate
Digital signature of the issuer (4)
TOTAL SECTION C: 25
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 7
SECTION D: DATA AND INFORMATION MANAGEMENT
QUESTION 4
4.1 4.1.1 Any ONE
Yes/No
Boolean (1)
4.1.2
1
tblEmployees
tblDepartment Key Fieldname
PK 1
EmpID
Key Fieldname
PK DepartmentID EmpName
DeptName EmpSurname
Gender
Permanent
Salary
∞ FK DepartmentID
Concepts:
(a) PK in tblDepartment and PK in tblEmployees (2)
(b) FK, DepartmentID and tblEmployees (3)
(c) 1 and ∞ (2)
4.2 4.2.1 Insert anomaly - the database design prevents a user from
capturing data when they want or need to.
Delete anomaly – deleting one piece of data results in the
simultaneous removal of other, unrelated data.
Update anomaly – when an item of data changes, it has to be
altered/changed in multiple records in the table. (3)
4.3 4.3.1 Physical integrity – overcoming practical issues such as power failure,
mechanical failure, natural disasters and dealing with the physical
storage and retrieval of data.
Logical integrity – correctness of data or data making sense in a
particular context. (2)
4.3.2 UPS and RAID (2)
Copyright reserved Please turn over
8 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
4.4 4.4.1 Physical independence and Logical independence (2)
4.4.2 The actual data management is left to the DBMS software
Multiple applications can interface to the same data because the
physical structure of the database is not a factor.
The use application cannot change the structure or format of the
data (3)
4.5 Rollback – happens when the DBMS gets the instruction to reverse a
transaction or series of transactions and restores the data back to its previous
state.
Record lock – happens when a record is open, either for editing or for
inserting, the record is flagged as in use and no other user can make changes
to that specific record. (2)
TOTAL SECTION D: 22
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 9
SECTION E: SOLUTION DEVELOPMENT
QUESTION 5
5.1 Any TWO
The button at the top should be placed at the bottom
The edits should be empty
The order is incorrect – put Name first
Could use SpinEdits for age instead of an Edit (2)
5.2 5.2.1 Type of error ERROR Error Message
(a) Syntax No semicolon entered at Missing semicolon
the end of an instruction
(b) Logical The stock amount is No error message
calculated incorrectly. The
formula is:
StockAmount = quantity -
ItemPrice
(c) Runtime A variable is created as an Data-type
integer data type to store mismatch
the number of items. When
the program runs, the user
enters the word instead of
a number in a component (3)
5.2.2 Debugging is a technique/process of finding/locating and
resolving defects/problems/errors/bugs. (2)
5.3 5.3.1 Creates a link between an external/physical/permanent/textfile
and variable textfile/logical file in the program (2)
5.3.2 Reset opens a variable textfile and moves the file pointer/cursor
to the start/beginning of the file, ready to start reading. (2)
5.4 5.4.1 Array – a data structure that contains a group of variables
containing values of the same data type
Index – an ordinal value indicating the position of the element in the
array (2)
5.4.2 Subscript (1)
Copyright reserved Please turn over
10 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
5.5 5.5.1 Space is created in memory to keep the attributes of a specific
object
OR
A constructor is used to create an instance of the object class/a
space is reserved in memory which is allocated to the properties of
an object class. (2)
Constructor (1)
5.5.2 Auxiliary method – methods (procedures or functions) in the class
that can assist with calculations and formatting.
OR
Methods which perform specific tasks without modifying the state of
the object (i.e. the content of any of the instance fields).
Example: toOutputString (2)
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 11
5.6
Line iCount iCount > 5? iNumber Output
redOut
1 1 No
2 1
3 1
1 2 No
2 4
3 4
1 3 No
2 9
3 9
1 4 No
2 16
3 16
1 5 No
2 25
3 25
1 6 Yes
(21÷3) = (7)
TOTAL SECTION D: 26
Copyright reserved Please turn over
12 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
SECTION F: INTEGRATED SCENARIO
QUESTION 6
6.1 6.1.1 orico.co.za (1)
6.1.2 Classen Jim and Breeze Kelly (1)
6.1.3 Spoofing (1)
6.2 6.2.1 Secure Sockets Layer is an encryption protocol for managing the
transmission of sensitive data over the Internet (2)
6.2.2 Any TWO
DRM (Digital Rights Management)
ATM
Internet browsers
Skype calls
Online storage devices (2)
6.3 Any TWO
Network engineer
Network architect
Network administrator
Network analyst (2)
6.4 6.4.1 Biometrics refers to the use of personal characteristics to
authenticate the identity of a person. (1)
6.4.2 Any ONE suitable example
Retina/Eye
Fingerprint
Voice recognition
Facial recognition
Palm readers (1)
6.4.3 Any TWO
Cards can be cloned
Cards can be stolen/lost
Inconvenience of carrying cards around
Cots of manufacturing cards
Cards do not validate the identity of the user
RFID cards can be read from a distance that can trigger the
unlocking of the room even when not required (2)
Copyright reserved Please turn over
(EC/SEPTEMBER 2019) INFORMATION TECHNOLOGY P2 13
6.5 6.5.1 Computer drone – is an unmanned aerial vehicle or is an aircraft
without a human pilot aboard. (1)
6.5.2 It is used to gather information especially where the environment
may be dangerous for humans. (1)
6.5.3 Any THREE
Aerial Military purposes Telecommunications
surveying
Journalism Mapping /Urban Mining
planning
Law Agriculture Waste management
enforcement
Search and Healthcare Weather forecasting
rescue
Scientific Emergency
research response
Conservation Disaster
and management
surveying (3)
6.6 6.6.1 Distributed database refers to parts of the database that are
spread over multiple servers in different locations. (2)
6.6.2 Any TWO
Eliminate congestion on a single server
Can handle a large number of simultaneous users
The branches of a company can be spread over a large
geographical area
If one server is down, other databases can be used
Lower cost of communication as less data is being
communicated. (2)
6.7 6.7.1 Wiki – a web application that allows people to add to and modify
the content of an online knowledge resource. (1)
6.7.2 Any TWO
Free access or low cost access to information
Collaboration
Publish and share documents
Flexible tool which can be used for a wide range of
applications
Knowledge centre (2)
6.7.3 Any TWO
Poor quality
Poor standard
Information not properly researched and approved (2)
Copyright reserved Please turn over
14 INFORMATION TECHNOLOGY P2 (EC/SEPTEMBER 2019)
6.8 Click farms refer to businesses that use groups of low paid workers
whose work is to repetitively click on links to fake high web traffic. (2)
6.9 6.9.1 Any TWO
Limit time on the web
Turn off notifications when doing important work
Remove yourself from FOMO
Refrain from insulting other people/bullying
Be aware that all posts are public
Do not befriend strangers
Do not share personal information e.g. ID number, bank account
numbers, address etc.
Be aware that the Internet never forgets information/cannot
delete information from the Internet. (2)
6.9.2 Piggybacking (1)
6.10 Telecommuting – working in decentralised locations e.g. from
home, but using modern communication to check in at a
physical office. (2)
6.11 Virtual office refers to a fixed physical address, containing
minimal office setup which is used as a shared space by people
who work from a mobile office. (2)
6.12 Fix errors or bugs in our existing programs
Close/seal security loopholes that hackers and malware might
try to exploit
Add new features and improvements to existing software (3)
TOTAL SECTION F: 39
GRAND TOTAL: 150
Copyright reserved Please turn over
Study this subject
Recommended for this subject

Question paper
Information Technology Grade 12 P2 Eastern Cape Mock 2019 QP

Memorandum
Information Technology Grade 12 P1 2019 Memo (Eng)

Memorandum
Information Technology Grade 12 P2 NSC November 2019 Memo

Memorandum
Information Technology Grade 12 P2 NSC November 2019 Memo

Memorandum
Information Technology Grade 12 P2 2021 Memo (Eng)

Memorandum
Information Technology Grade 12 P2 2017 Memo (Afr)
More from Grade 12 Information Technology

Question paper
Information Technology Grade 12 P2 Eastern Cape Mock 2025 QP

Question paper
Information Technology Grade 12 P2 2024 QP (Afr)

Question paper
Information Technology Grade 12 P2 2024 QP (Eng)

Question paper
Information Technology Grade 12 P1 November 2024 NSC QP

Question paper
Information Technology Grade 12 P2 November 2024 NSC QP

Memorandum
