Downloaded from hlayiso.com
NATIONAL
SENIOR CERTIFICATE
GRADE 12
SEPTEMBER 2017
MECHANICAL TECHNOLOGY
MARKING GUIDELINE
MARKS: 200
This marking guideline consists of 9 pages.
Skip to contentAll 2017 papers


%20GR12%20MEMO%20SEPT2023_English_hlayiso.com_--dfc975c1-e179-4741-8d4f-e3b20c744c7e/v1-c61c66086bf36fcf31e0/card.webp)


View all
%20Eng--5d2e2bd0-b02f-4218-849f-e7933bc6c4d1/v1-2dba8a1dc6758c98b205/card.webp)
%20Afr--1e7205e4-aef1-4cc4-afdf-aac93562ae67/v1-094abcfa5c3eff1cb995/card.webp)
%20MG%20Afr--552ebeca-d294-4c37-b3fb-cded79fa438f/v1-b698b76db92c8affef7e/card.webp)
%20Eng--10859467-be3e-41fb-aee0-b797c385437d/v1-986e8982bfb6b966a34d/card.webp)

Mechanical Technology Grade 12 Eastern Cape Mock 2017 Memo
Grade 12 Mechanical Technology memorandum from the Eastern Cape Mock Exam 2017 (English), 9 pages. Read online or download the free PDF.
Mechanical Technology · Grade 12 · Eastern Cape Mock Exam · 2017. Memorandum, 9 pages. Read online or download the PDF.
- Subject
- Mechanical Technology
- Grade
- Grade 12
- Document type
- Memorandum
- Year
- 2017
- Exam period
- Eastern Cape Mock Exam
- Curriculum
- CAPS
- Pages
- 9
- File size
- 381.6 KB
Free to read online, no sign-up needed
Loading document…
Loading document…
1 of 9
This exam
Eastern Cape Mock Exam 2017
Document textSearch extracted text and jump to a page.
Downloaded from hlayiso.com
2 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2017)
QUESTION 1: MULTIPLE-CHOICE QUESTIONS
1.1 A (1)
1.2 C (1)
1.3 B (1)
1.4 C (1)
1.5 D (1)
1.6 C (1)
1.7 A (1)
1.8 C (1)
1.9 B (1)
1.10 C (1)
1.11 A (1)
1.12 B (1)
1.13 D (1)
1.14 D (1)
1.15 A (1)
1.16 B (1)
1.17 C (1)
1.18 A (1)
1.19 D (1)
1.20 B (1)
[20]
QUESTION 2: SAFETY
2.1 Oil and grease are flammable and may cause a fire. (2)
2.2 Store full cylinders and empty ones separately.
Keep cylinders in a cool place.
Protect them from sunlight and other sources of heat.
Always store and use acetylene cylinders in an upright position.
Store oxygen and acetylene cylinders separately
Never stack cylinders on top of one another.
Do not bang or work on cylinders.
Never allow cylinders to fall.
Do not allow oil or grease to come into contact with oxygen fittings.
Keep the caps on an oxygen cylinder for protection. (Any 3) (3)
2.3 An operator should be instructed to use a machine safely.
A workplace must be effectively partitioned off.
An operator must use protective equipment.
Effective ventilation must be provided and maintained.
Masks or hoods maintaining a supply of safe air for breathing must be
provided and used by the operators.
The insulation of electrical leads must be satisfactory.
The holder which contains the wire must be completely insulated. (Any 2) (2)
2.4 2.4.1 Make sure the centre or drill chuck is well secured before switching
on the machine.
Make sure the tail stock is well secured and locked when cutting
between centres. (Any 1) (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) MECHANICAL TECHNOLOGY 3
2.4.2 Make sure the guard is well secured before switching on the
machine.
Machine guard must be in a good condition. (Any 1) (1)
2.4.3 Keep hands away from rotating chuck.
Don't leave the chuck key in the chuck.
Make sure the chuck is well secured before switching on the
machine.
Turn the chuck by hand to be certain that there is no danger of the
work piece striking any part of the lathe. (Any 1) (1)
[10]
QUESTION 3: TOOLS AND EQUIPMENT
3.1 Brinell hardness tester
Rockwell hardness tester
Vickers tester (Any 2) (2)
3.2 Check for worn cylinders
Check for worn piston rings
Check for worn pistons
Check for inlet valve leakage
Check for exhaust valve leakage (Any 3) (3)
3.3 A tensile tester measures the resistance of a material to a static or slowly
applied tensile axial force. (2)
3.4 Rich mixture setting
Incorrect idle speed
Faulty choke creating a rich mixture (jammed in the closed position)
(Any 2) (2)
3.5 Check if the measuring lead are inserted in the correct socket for the
measurement.
Turn the function switch to the desired function.
If you do not know what size of reading to expect, then switch to the
highest range first.
Connect the meter measuring lead probes to the correct points in the
circuit to be tested. (Any 3) (3)
[12]
QUESTION 4: MATERIALS
4.1 Low carbon steel 0,10 – 0,25%
Medium carbon steel 0,25 – 0,55%
High carbon steel 0,55 – 1,00% (9)
4.2 The internal structural changes take place and it takes up an entirely new form
at a temperature of about 800 °C. (2)
4.3 730° – 780 °C (2)
[13]
Copyright reserved Please turn over
Downloaded from hlayiso.com
4 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2017)
QUESTION 5: TERMINOLOGY
5.1 Arbor cutters (1)
e.g. plain, side, staggered-tooth, metal slitting saw and form cutters
(Any 2 examples)(2)
Shank cutters (1)
e.g. end mills, T-slot, Woodruff key seat and fly cutter
(Any 2 examples)(2) (6)
5.2 High abrasive resistance
Red hardness i.e. the hardness of the cutting edge must not be affected by
heat generated.
Edge toughness (Any 2) (2)
5.3 Turn the part to be threaded to the major diameter of the thread
Set compound slide 300 to the right and set tool up accurately in the tool
post.
Check index plate of the quick-change gearbox and move the levers for
the necessary pitch of the thread.
Start lathe and set cutting tool to touch work piece. Set dial to zero on
cross feed and compound slide.
Move the cutting tool a short distance off to clear the end of the work piece
and feed compound slide 0,05 mm inward.
With lathe turning, engage half-nuts in the correct line on the chasing dial,
putting the first cut in progress.
Withdraw the cutting tool quickly and disengage the half-nut lever return
the carriage to the starting point of thread and check with thread gauge to
see if thread pitch is correct.
Repeat with successive cut until thread is complete. (Max. 7 x 1) (7)
5.4 5.4.1 Form cutters
Profile cutters (Any 1) (1)
5.4.2 40 7
Number of turns = 33 = 133
1 Full turn and 7 holes in a 33 hole-circle (3)
5.5 A Side and face milling cutters
B Spindle nose
C Vice fixed jaw
D Parallels
E Work piece
F Shoulder width
G Collars and spacers
H Vice movable jaw (8)
5.6 A Major/Crest diameter
B Pitch diameter
C Minor or Root diameter (3)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) MECHANICAL TECHNOLOGY 5
QUESTION 6: JOINING METHODS
6.1 A Regulator
B Flow meter
C Continuous wire reel
D Wire feed roller unit
E Gun conduit
F Welding gun
G Weld pool
H Work piece
I Earth clamp (9)
6.2 A Parent metal
B Molten pool
C Continuous electrode wire
D Nozzle
E Gas shroud (5)
6.3 X-ray testing
Liquid dye penetrant
Ultrasonic testing (3)
6.4 Make a hacksaw cut at both edges through the centre of the weld.
Use a sledge hammer to break the specimen by striking it in the zone
where you made the saw cuts.
The weld metal exposed in the break should be completely free from slag
inclusions and contain no gas pockets greater than 1,6 mm. (4)
6.5 To protect the weld area from oxygen and water vapour. (2)
6.6 Solid metals entrapped in the weld metal or between the weld metal and
the base metal.
Weld temperature is too low.
Included angle is too small.
Repeating a weld without removing the previous slag.
High viscosity of the molten metal. (Max. 2) (2)
[25]
QUESTION 7: FORCES
7.1 7.1.1 A force is a push or a pull movement. (1)
7.1.2 It is a system in balance. (1)
7.1.3 It is a conversion of multiple forces into one. (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
6 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2017)
7.2 7.2.1 F
Stress =
A
F
A = Stress
𝜋𝐷 2 F
= Stress
4
F×4
D2 = π × 𝑠tress
4 × 40 × 103
D = √ 𝜋 × 20 × 106
D = √2,546
D = 0,05045 m
D = 50,45 mm Diameter of bar (6)
7.2.2 Stress
E = Strain
20 × 106
Strain = 90 × 109
= 2,222 × 10−4 (2)
7.2.3 Change in lenght
Strain = Original lenght
Change in length = Strain × Original length
= 0,177 mm (3)
7.3 X-component = 280 N + 300 Cos 30° - 400 Cos 30°
= 193,39 N
Y-component = 300 Sin 30° + 400 Sin 30° - 170
= 150 + 200 + 170
= 180 N
𝑅 = 𝑋2 + 𝑌2
2
= 193,392 + 1802
= √69799,69
R = 264,19 N - resultant
Calculation of the direction:
180
Tan Ɵ = 193,39
= 0,931
= 42,95° (10)
7.4 Reaction at A:
B × 6,2 = (496 × 3,1) + (350 × 7,9)
= 1537,6 + 2765
B = 693,96 N
Reaction at B:
(A × 6,2) + (350 × 1,7) = (800 × 6,2) + (496 × 3,1)
(A × 6,2) = 4960 + 1537,6 – 595
A = 952,03 N
A + B = 693,96 + 952,03 = 1645,99
Downwards = 800 + 496 + 350 = 1646
The beam is in equilibrium (6)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) MECHANICAL TECHNOLOGY 7
QUESTION 8: MAINTENANCE
8.1 It prevents the shavings or metal chips from sticking and fusing to the
cutting tool.
It will carry the heat generated by the turning process.
It flushes away shavings/metal chips.
It improves the quality of the finish of the turned surface. (Max. 3) (3)
8.2 Formation of gum, acids and lacquer may be left by the oil to coat the
surfaces.
Oil loses its viscosity after a while due to excessive heat transfer which
results in friction of lubricating efficiency.
Metal particles deposit in the oil due to metal and metal contact. (Max. 3) (3)
8.3 8.3.1 It is the lowest temperature at which the oil gives off vapours which
can ignite (2)
8.3.2 It is the lowest point at which a liquid remains ‘pourable’ (meaning it
still behaves like a fluid) (2)
8.4 It must be water resistant, it must not mix
Rust/Corrosion resistant
Good for load pressure
High melting point
Low freezing point (Any 3) (3)
8.5 To provide friction between the clutch and pressure plate
To connect the flywheel to the gearbox shaft (2)
[15]
QUESTION 9: SYSTEMS AND CONTROL
9.1 9.1.1 First calculate the volume of cylinder B.
𝑉𝐵 = 𝐴𝑟𝑒𝑎𝐵 × 𝑆𝑡𝑟𝑜𝑘𝑒 𝑙𝑒𝑛𝑔𝑡ℎ𝐵
2
𝜋 × 𝐷𝐵
= × 𝐿𝐵
4
𝜋 × (0,18)2
= × 0,012
4
= 0,305 × 10−3 𝑚3
But 𝑉𝐴 = 𝑉𝐵
𝐴𝐴 𝑋 𝐿𝐴 = 𝑉𝐵
𝐴𝐴 × 0,06 = 0,305 × 10−3
𝑜,305 × 10−3
𝐴𝐴 =
0,06
= 5,08 × 10−3 𝑚2
2
𝜋𝐷𝐴
𝐴𝐴 = 4
4 × 5,08 × 10−3
𝐷𝐴2 =
𝜋
𝐷𝐴 = √6,47 × 10−3
𝐷𝐴 = 0,80 m
= 800 mm (9)
Copyright reserved Please turn over
Downloaded from hlayiso.com
8 MECHANICAL TECHNOLOGY (EC/SEPTEMBER 2017)
9.1.2 FA
Pressure at A =
AA
550
𝑃𝐴 = 5,08 × 10−3
= 108,268 × 103 Pa
= 108,27 kPa (2)
9.1.3 Note: Pressure at A is equal to pressure at B
𝑃𝐴 = 𝑃𝐵
𝐹
𝑃𝐵 = 𝐴𝐵
𝐵
𝐹𝐵 = 108,268 × 103 × 𝐴𝐵
= 108,268 × 103 × 25,45 × 10−3
= 2755,42 N
𝐹𝐵 = 2,76 kN (4)
9.2 9.2.1 Compressive stress (1)
9.2.2 𝝅( 𝑫𝟐 −𝒅𝟐 )
A = 𝟒
𝝅(𝟎,𝟎𝟒𝟐 )− (𝟎,𝟎𝟑𝟐 )
=
𝟒
−𝟑 𝟐
= 0,55 × 𝟏𝟎 𝒎
𝑭𝒐𝒓𝒄𝒆
Stress = 𝑨𝒓𝒆𝒂
𝟐𝟑× 𝟏𝟎𝟑
=
𝟎,𝟓𝟓 × 𝟏𝟎𝟑
= 41818181,8 Pa
= 41,82 MPa (5)
9.3 9.3.1 Rotation of motor
80 × 40 × 90
𝑁𝐸 = 30 × 20
288000
= 600
= 480 r/min (2)
9.3.2 No slip occurs
It is much stronger
More accurate
Last longer (Any 2) (2)
[25]
Copyright reserved Please turn over
Downloaded from hlayiso.com
(EC/SEPTEMBER 2017) MECHANICAL TECHNOLOGY 9
QUESTION 10: TURBINES
10.1 The supercharger fills the cylinder with an increased pressure that is higher
than atmospheric pressure.
The compression pressure in the cylinder is increased.
The volumetric efficiency of the engine is increased. (Any 2) (2)
10.2 Used in racing cars
Four-stroke compression ignition engines in heavy vehicles
Earth moving equipment
Aircraft engine to overcome loss of power owing to height above sea
level (Any 2) (2)
10.3 A turbine is driven by the exhaust gas from a pump, most often an internal
combustion engine, to spin an impeller whose function is to force air into
the pump’s intake or air supply.
The shaped fins on the impeller move the air around to the outer edge of
the impeller into the housing.
In doing so, the moving fins leave a low pressure behind it.
Air, under atmospheric pressure, rushes in to fill the low pressure at the
centre of the impeller.
By spinning at a relatively high speed, the compressor turbine draws in a
large volume of air and forces it into the engine.
As the turbocharger’s output – flow volume exceeds the engine’s
volumetric flow, air pressure in the intake system begins to build.
The speed at which the assembly spins is proportional to the pressure of
the compressed air and total mass of air flow being moved.
Since a turbo will spin faster than is needed, the speed must be controlled
and thus it is also the property used to set the desired compression
pressure. (8)
10.4 Kinetic energy is the steam which is converted to mechanical energy to
cause rotation. (mechanical energy)
Steam at very high temperature and pressure is directed to the turbine.
Nozzles are used to direct the pressure onto the blades.
The blades are attached to the turbine and shaft causing it rotate.
This is mechanical energy created by the impulse and the reaction effort of
the steam jet. (5)
10.5 Water turbines
Gas turbines
Wind turbines (3)
[20]
TOTAL: 200
Copyright reserved Please turn over
Study this subject
Recommended for this subject

Memorandum
Mechanical Technology Grade 12 NSC November 2017 Memo (Eng)

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2023 Memo

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2023 Memo
%20GR12%20MEMO%20SEPT2023_English_hlayiso.com_--dfc975c1-e179-4741-8d4f-e3b20c744c7e/v1-c61c66086bf36fcf31e0/card.webp)
Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2023 Memo

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2023 Memo

Memorandum
Mechanical Technology Grade 12 Eastern Cape Mock 2020 Memo
More from Grade 12 Mechanical Technology

Annual teaching plan
Gr 12 Weld Met ATP 2023 24
%20Eng--5d2e2bd0-b02f-4218-849f-e7933bc6c4d1/v1-2dba8a1dc6758c98b205/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Eng)
%20Afr--1e7205e4-aef1-4cc4-afdf-aac93562ae67/v1-094abcfa5c3eff1cb995/card.webp)
Question paper
Mechanical Technology Grade 12 November 2024 NSC QP (Afr)
%20MG%20Afr--552ebeca-d294-4c37-b3fb-cded79fa438f/v1-b698b76db92c8affef7e/card.webp)
Memorandum
Mechanical Technology Grade 12 NSC June 2024 Memo (Afr)
%20Eng--10859467-be3e-41fb-aee0-b797c385437d/v1-986e8982bfb6b966a34d/card.webp)
Question paper
Mechanical Technology Grade 12 NSC June 2024 QP (Eng)

Question paper
