NATIONAL
SENIOR CERTIFICATE
GRADE 12
SEPTEMBER 2022
CIVIL TECHNOLOGY: CIVIL SERVICES
MARKING GUIDELINE
MARKS: 200
This marking guideline consists of 14 pages, including 2 answer sheets.
Skip to contentAll 2022 papers





View all
%20Afr--05a95faf-5891-4d88-9e5e-7d13c1d21648/v1-f5ca67113376f7457b83/card.webp)

%20Afr--eefaae29-fe93-4b75-8223-87bf4f3fc14c/v1-3553acfa446acbaa2a45/card.webp)
%20Afr--307147a5-3280-4a11-a82e-cf3e33388eb0/v1-e53e38093df191bfe243/card.webp)
%20Eng_hlayiso.com_--e6743728-8140-42ae-838d-282654a975a5/v1-dce3e047e0d7ad60a32b/card.webp)
Civil Technology Grade 12 Eastern Cape Mock 2022 Memo (Eng)
Grade 12 Civil Technology memorandum from the Eastern Cape Mock Exam 2022 (English), 14 pages. Read online or download the free PDF.
Civil Technology · Grade 12 · Eastern Cape Mock Exam · 2022 · English. Memorandum, 14 pages. Read online or download the PDF.
- Subject
- Civil Technology
- Grade
- Grade 12
- Language
- English
- Document type
- Memorandum
- Year
- 2022
- Exam period
- Eastern Cape Mock Exam
- Curriculum
- CAPS
- Pages
- 14
- File size
- 523.6 KB
Free to read online, no sign-up needed
Loading document…
Loading document…
1 of 14
This exam
Document textSearch extracted text and jump to a page.
2 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
INSTRUCTIONS FOR THE MARKERS
1. Markers should:
• Familiarise themselves with the question and answer before evaluating the
responses of candidates.
• Always interpret the responses of the candidates within the context of the
question.
• Consider any relevant and acceptable answer during pre-marking but should
strictly adhere to the answers after finalisation of the marking guideline.
• There are two approaches to answering questions, these are (1) to describe and
(2) to explain.
• If a candidate is required to explain e.g., a process in 4 steps, only the first 4
responses should be considered.
• If, however a candidate is required to e.g., explain or describe how to transfer
heights from one point to another using a transparent pipe level we need to
consider that candidates may write a long description not necessarily well
organised as an intellectual response may do. In this case the marker needs to
evaluate the complete statement to judge if the candidate explained the required
outcome satisfactorily and allocate marks on merit. The marker should apply
his/her professional judgement with these types of questions.
• Mark what the candidate wrote and do not award marks for answers that the
marker thinks the candidate meant with what was written.
• Indicate the tick or cross right at the position where the mark needs to be
awarded or where the candidate made the error.
• Accept the letter corresponding with the correct answer as well as the answer
written in full in multiple-choice questions.
• Accept incorrect spelling in one-word answers unless the spelling changes the
meaning of the answer.
2. For calculations:
• A mark is only awarded if the correct unit is written next to the answer.
• If TWO marks are awarded ONE mark is awarded for the answer and ONE mark
for the correct unit.
• Where the candidate made a principle error e.g. added instead of multiplying, no
marks will be awarded for the steps. If the answer is correct according to what
the candidate did, the mark for the answer can be awarded for the application of
skills.
• Where an incorrect answer could be carried over to the next step, the first
answer will be deemed incorrect. However, should the incorrect answer be
carried over correctly, the marker has to recalculate the values, using the
incorrect answer from the first calculation. If correctly used, the candidate should
receive the full marks for subsequent calculations.
• Markers should consider when and where a candidate has rounded off in a
calculation, as well as the subsequent effect it has on the final answer obtained.
The calculation should therefore be awarded marks on merit.
• Alternative methods of calculations must be considered, provided that the
correct answer is obtained.
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 3
3. When marking drawings:
• The member for which the mark should be awarded should be drawn correctly in
the correct position to receive a mark.
• A member incorrectly drawn but wrongfully repeated in another position will be
awarded the mark for the repeated incorrect member provided that the marking
guideline provide for TWO or more marks for that member (positive marking).
• Marks can only be awarded for a label if the label is correctly indicating the
correct member.
• Scale drawings should always be marked using an appropriate mask.
When a candidate drew the wrong drawing e.g.:
• A horizontal section instead of a vertical section, no marks will be allocated to
the drawing as the candidate did not respond to the expected outcome.
• An orthographic view instead of sectional view, no marks will be allocated to the
drawing as the candidate did not respond to the expected outcome.
• An orthographic view instead of an isometric view, no marks will be allocated to
the drawing as the candidate did not respond to the expected outcome.
• If the incorrect drawing was drawn, the candidate can be awarded for only what
was asked but mark/s for the correctness of the drawing will not be awarded
e.g., if a King Post roof truss was asked in the question, and candidate drew SA-
Howe Truss.
Copyright reserved Please turn over
4 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
QUESTION 1: OHSA, SAFETY MATERIALS, TOOLS, EQUIPMENT AND
JOINING (GENERIC)
1.1 It is an unplanned/uncontrolled (1) event that occurs because of an unsafe
act/unsafe conditions. (1) (2)
1.2 Steel alloy pipe (1)
1.3 1.3.1 Two (1)
1.3.2 38 mm (1)
1.3.3 900 mm (1)
1.4 Any TWO:
• To ensure that the scaffolding is stable in all directions
• Must be able to carry the mass of the load
• Free of any defects
• Similar answer (Any 2 x 1) (2)
1.5 1,8 meters (1)
1.6 3 meters (1)
1.7 1.7.1 Any ONE:
• Higher person can slip and fall on the lower person
• Can damage the ladder
• Makes it more unstable
• Similar answer (1)
(Any 1 x 1)
1.7.2 Red or orange flag (1)
1.7.3 Any ONE:
• Aluminium
• Wood
• Metal
• Similar answer (1)
(Any 1 x 1)
1.7.4 Any ONE:
• Defects must be visible (clean)
• Will prevent slipping accidents (oil / grease)
• Similar answer (1)
(Any 1 x 1)
1.8 Any TWO:
• Can be applied with a brush, roller or spray-gun
• Enhances appearance of surfaces
• Easy to apply
• Makes cleaning and maintenance easier
• Dry quickly
• Marks/smudges are easily cleaned with water
• Gives elastic/flexible finish resistant to cracking (Any 2 x 1) (2)
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 5
1.9 Any TWO:
• Increases the strength of concrete
• Decreases the permeability of concrete
• Improves the durability of concrete
• Reduces cracks
• Makes concrete more watertight
• Reduce crimping cracks in the concrete
• Provides volume stability
• Concrete can carry more weight without being damaged (Any 2 x 1) (2)
1.10 Any TWO:
• Painting
• Electroplating
• Powder coating
• Galvanising (Any 2 x 1) (2)
[20]
QUESTION 2: GRAPHICS, JOINING AND EQUIPMENT (GENERIC)
2.1 FIGURE 2.1 on ANSWER SHEET A shows the outer lines of a structure that
must be built on a site. Draw the site plan on scale 1 : 200 on ANSWER
SHEET A so that the structure is in the middle of the site.
The site plan must comply with the following requirements:
2.1.1 Plot size is 30 m wide from east to west and 40 m long from south to
north (2)
2.1.2 Pavement of 2 m and the street of 6 m on the south side (3)
2.1.3 Building boundaries are 2 m on the east, north and west sides and
4 m on the south side (4)
2.1.4 3 m wide entrance to the site (2)
2.1.5 Datum level in the north-west corner of the site (2)
Also draw in the sewer lay-out on the structure and show the following:
2.1.6 Water closet and symbol at the abbreviation (1)
2.1.7 Sewer pipes (2)
2.1.8 Rodding eye with the abbreviation (2)
2.1.9 Inspection eye with the abbreviation (2)
2.1.10 Manhole with the abbreviation (2)
Indicate the following measurements:
2.1.11 Length and width of the site (4)
2.1.12 South and west building boundaries (2)
Use the points table on ANSWER SHEET A as reference.
Copyright reserved Please turn over
6 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
2.2 When square shoulder is driven in it resists rotation. (1)
2.3 A – Nut (1)
B – Thread (1)
C – Run-out (1)
D – Shank (1) (4 x 1) (4)
2.4 Prevents backing off. (1)
2.5 Can be tightened with fingers. (1)
2.6 2.6.1 1,61 m (1)
2.6.2 1,64 – 1,584 x 100 = 5,6 m (4)
[40]
TOTAL SECTION A: 60
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 7
QUESTION 3: SAFETY, MATERIAL AND CONSTRUCTION (SPECIFIC)
3.1 3.1.1 False (1)
3.1.2 True (1)
3.1.3 True (1)
3.1.4 False (1)
3.2 Prevent (1) falling objects from (2) injuring workers. (2)
3.3 Any TWO responsibilities:
• (1) A competent person must (2) prepare a fall protection plan.
• The (1) fall protection plan must be implemented and (2) maintained.
• (1) Ensure steps for the (2) adherence of the fall protection plan. (2 x 2) (4)
3.4 Zink is a (1) weak atomic bond (2) relative to other metals which during
(3) dezincification (when zinc is removed from an alloy) (4) A weak deposit of
porous/nobler/copper-rich metal will remain. (4)
3.5 3.5.1 Electrode (1)
3.5.2 Boundary (1)
3.5.3 Electrolyte (1)
3.5.4 Passive (1)
3.6 3.6.1 Manhole (1)
3.6.2 A – Benching
B – Branch channel (2)
3.6.3 (1) So that the sewage spills slide back into the channel pipe.
(2) So that vermin cannot settle there. (2)
3.7 20
40 = 0,5 m (3)
3.8 3.8.1 Loose / waterlogged / saturated ground (1)
3.8.2 A – Wedge
B – Walling
C – Strut (3)
[30]
Copyright reserved Please turn over
8 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
QUESTION 4: COLD WATER SUPPLY, HOT WATER SUPPLY AND TOOLS
(SPECIFIC)
4.1 4.1.1 A – Water main
B – Meter box
C – Stopcock
D – Water meter (4 x 1) (4)
4.1.2 450 mm (1)
4.1.3 Municipality (1)
4.2 4.2.1 Full-way valve (1)
4.2.2 A – Lever
B – Stem
C – Ball (3)
4.2.3 At water inlets where water needs to be shut off quickly. (1)
4.3 4.3.1 ø 110 mm (1)
4.3.2 Bend 90° with inspection eye. (1)
4.3.2 Cleaning / inspection of the system. (1)
4.4 (1) To prevent water from (2) leaking through the connection. (2)
4.5 Saves water. (1)
4.6 Operation: (1) When the hot water tap is opened, (2) first cold water is running
out. The red water diverter is a (3) valve which diverts the (4) cold water to a
water tank, garden, etc.
Any TWO advantages:
• Now wiring
• Do not use electricity
• No energy wastage
• No heat loss
• Saves water (6)
4.7 4.7.1 Hot water pipe (1)
4.7.2 Balancing device (Hot water control) (1)
4.7.3 Thermostatic controller (1)
4.7.4 Pressure control valve (1)
4.7.5 Valve (1)
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 9
4.8 4.8.1 B
4.8.2 B
4.8.3 B
4.8.4 A
4.8.5 A (5 x 1) (5)
4.9 4.9.1 False (1)
4.9.2 False (1)
4.9.3 True (1)
4.10 Any FOUR caring measures for the compressed-air test apparatus.
• Check equipment regularly.
• Clean the stopper after use.
• Place the manometer in its holder after use.
• Do not bump the instrument.
• All the air must escape from the manometer pipe.
• Ensure that the inside surface of the pipe is clean. (4 x 1) (4)
[40]
Copyright reserved Please turn over
10 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
QUESTION 5: DRAINAGE AND QUANTITIES (SPECIFIC)
5.1 5.1.1 Vent valve / Air admittance valve (1)
5.1.2 (1) Valve opens and (2) reduces the vacuum and allows (3) air into the
system so that (4) the water can flow away freely / without releasing
gases into the building. (4)
5.2 5.2.1 Gully (1)
5.2.2 Outlet of waste water from the kitchen (sink) / from the bathroom (bath,
shower and hand basin) to drainage pipes. (1)
5.2.3 Any TWO disadvantages of the fixture.
Greasy / leaves / litter residue can collects on the grating.
• Blockages can cause an overflows.
• Blockages can cause foul odours. (2 x 1) (2)
5.2.4 (1) Serves as a water lock which (2) prevent bad odours/gases emerge. (2)
5.3 5.3.1 Septic tank (1)
5.3.2 (1) Decomposes and liquefied by (2) anaerobic bacteria and other
biological life such as maggots / worms / micro-organisms. (2)
5.3.3 Gas escape (1)
5.3.4 (1) Not disturbing (2) surface water layer. (2)
5.3.5 French drain (1)
5.4 5.4.1 Sink
(2)
5.4.2 Bidet
(2)
5.5 5.5.1 Underground sewerage pipes (1)
5.5.2 Bigger solids (1)
5.6 5.6.1 Polycop (1)
5.6.2 1 3240 mm (13,24 m) (1)
5.6.3 Polycop (1)
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 11
5.6.4 8 800 mm (1,5 + 5,48 + 1,82 = 8,8 m) (1)
5.6.5 Copper (1)
5.6.6 1 (1)
5.6.7 Copper (1)
5.6.8 1 (1)
5.6.9 Copper (1)
5.6.10 1 (1)
5.6.11 Copper (1)
5.6.12 1 (1)
5.7 = πr²h
= 22 x 1,05 x 1,05 x 2,4
7
= 8,316 m³ (4)
[40]
Copyright reserved Please turn over
12 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
QUESTION 6: GRAPHIC COMMUNICATION, ROOF WORK, STORMWATER AND
JOINING (SPECIFIC)
6.1 FIGURE 6.1 on ANSWER SHEET C shows the top and front elevation of a cone.
Draw the development of the cone according to the radial-line method on
ANSWER SHEET C. Add an allowance for the seam.
Show all construction lines. (14)
6.2 6.2.1 D
6.2.2 F
6.2.3 G
6.2.4 A
6.2.5 C (5)
6.3 Any similar answer:
• (1) Waterproofing of (2) roofs.
• (1) Junctions of walls (2) that protrude above the roof.
• (1) At joints where pipes (2) project through the roof cladding. (2)
6.4 Route stormwater to rivers / dams. (1)
6.5 Any THREE consequences:
• Discomfort of public
• Loss of life
• Damage to properties
• Pollution of the environment
• Negative environment impact (3 x 1) (3)
6.6 Keep solids out of the stormwater pipe. (1)
6.7 6.7.1 True (1)
6.7.2 False (1)
6.8 6.8.1 Rubber ring seal / Compression joint (1)
6.8.2 Compression screw (1)
[30]
TOTAL: 200
Copyright reserved Please turn over
(EC/SEPTEMBER 2022) CIVIL TECHNOLOGY: CIVIL SERVICES 13
CIVIL TECHNOLOGY NAME:
ANSWER SHEET A GENERIC
2.1 FIGURE 2.1 on ANSWER SHEET A shows the outer lines of a structure that
must be built on a site. Draw the site plan on scale 1 : 200 on ANSWER
SHEET A so that the structure is in the middle of the site.
(28)
30 m
RE
SK
40 m
SO
m
IO
2m
IE
Plot size 2
Pavement + street 3
Building boundaries 4
Entrance 2
Datum level 2
Water closet 1
MH
MG Sewer connection 2
m Inspection eye + abbr. 2
Rodding eye +abbr. 2
Manhole + abbr. 2
4 4mm Measurements 6
TOTAL: 28
Copyright reserved Please turn over
14 CIVIL TECHNOLOGY: CIVIL SERVICES (EC/SEPTEMBER 2022)
CIVIL TECHNOLOGY NAME:
ANSWER SHEET B CIVIL SERVICES
6.1 FIGURE 6.1 on ANSWER SHEET B shows the top and front elevation of a
cone.
Draw the development of the cone according to the radial-line method on
ANSWER SHEET B. Add an allowance for the seam. Show all construction
lines. (14)
M
4
G
m 0
12
1
1
C
1
9
V
O
2O
R
3A
A
N
8
S
6 I
G
6
2
7
3
Dividing lines 0–6 on top view 4
Halve circle B–C 2
Seam lines A–B and A–C 2
4 5 Construction lines A0–A 12 6
TOTAL: 14
0 1
0
1 4
B
5 O
A
Copyright reserved A Please turn over
N
S
Study this subject
Recommended for this subject

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2022 Memo (Eng)

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2022 QP (Eng)

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2022 QP (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2021 Memo (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2017 Memo (Eng)

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2023 QP (Eng)
More from Grade 12 Civil Technology

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2025 QP (Eng)
%20Afr--05a95faf-5891-4d88-9e5e-7d13c1d21648/v1-f5ca67113376f7457b83/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2025 QP (Afr)

Question paper
Civil Technology Grade 12 Eastern Cape Prelim 2024 QP (Eng)
%20Afr--eefaae29-fe93-4b75-8223-87bf4f3fc14c/v1-3553acfa446acbaa2a45/card.webp)
Question paper
Civil Technology Grade 12 November 2024 NSC QP (Afr)
%20Afr--307147a5-3280-4a11-a82e-cf3e33388eb0/v1-e53e38093df191bfe243/card.webp)
Question paper
Civil Technology Grade 12 November 2024 NSC QP (Afr)
%20Eng_hlayiso.com_--e6743728-8140-42ae-838d-282654a975a5/v1-dce3e047e0d7ad60a32b/card.webp)
Question paper
