Downloaded from hlayiso.com NATIONAL SENIOR CERTIFICATE GRADE 12 MECHANICAL TECHNOLOGY: AUTOMOTIVE NOVEMBER 2023 MARKING GUIDELINES MARKS: 200 These marking guidelines consist of 23 pages. Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 2 DBE/November 2023 NSC – Marking Guidelines QUESTION 1: MULTIPLE-CHOICE (GENERIC) 1.1 B (1) 1.2 A (1) 1.3 C (1) 1.4 C (1) 1.5 A (1) 1.6 B (1) [6] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 3 DBE/November 2023 NSC – Marking Guidelines QUESTION 2: SAFETY (GENERIC) 2.1 Examination checks:  Severe bleeding   Internal bleeding   Head injuries   Neck injuries   Fractures   Vital signs   Physical abnormalities  (Any 2 x 1) (2) 2.2 Safety devices on the power-driven guillotine:  Finger protectors / Fixed guards / Blade guard   Rear view mirrors   Rear light curtains   Automatic sweep-away   Revolving warning lights   Two-hand / dual control device   Additional emergency buttons   Self-adjusting guards   Covered footswitch  (Any 2 x 1) (2) 2.3 Grinding wheel:  The wheel should be rated above the speed of the motor.   Check for cracks on the grinding wheel.   Check for chips on the grinding wheel.   Check that the arbor hole is the correct size.   Must not be contaminated by oil/fluids or grease.   Correct size of the wheel.   Correct type of wheel for the material.  (Any 2 x 1) (2) 2.4 Gas welding equipment – safety devices:  Valve guard   Flash back arrestor   Pressure regulator   C-clamps on hoses/Parallel hose clips   Acetylene spindle key must always be in place.   Cylinder valves.  (Any 2 x 1) (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 4 DBE/November 2023 NSC – Marking Guidelines 2.5 Advantages of process layout of machines are:  High machine utilisation.   Better supervision.   Less interruption in the flow of work.   Lower equipment costs.   Better control of total manufacturing costs.   Greater flexibility.  (Any 2 x 1) (2) [10] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 5 DBE/November 2023 NSC – Marking Guidelines QUESTION 3: MATERIALS (GENERIC) 3.1 Colour code of metal:  To identify the type of metal.   To identify carbon content especially after the metal was stored.   To identify the profile/size of the metal.  (Any 1 x 1) (1) 3.2 Tests to determine properties of steel: 3.2.1 Sound test:  Hardness   Softness  (Any 1 x 1) (1) 3.2.2 Bending test:  Ductility   Bend strength   Fracture strength   Resistance to fracture  Brittleness   Elasticity   Plasticity   Flexibility  (Any 1 x 1) (1) 3.2.3 Machining test:  Hardness   Strength  (Any 1 x 1) (1) 3.3 Reasons metal soaked during heat treatment:  To ensure uniform heat distribution  throughout the metal.   To achieve a uniform grain structure  after cooling the metal.  (Any 1 x 2) (2) 3.4 Case hardening:  Carburising   Nitriding   Cyaniding  (Any 2 x 1) (2) 3.5 Annealing process: Heating the steel slightly above AC3, (upper critical temperature)  soaking it for a required time/period  and then slow cooling  back to room temperature. (3) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 6 DBE/November 2023 NSC – Marking Guidelines 3.6 Rapid quenching mediums:  Brine/Salt water   Water   Nitrogen   Oil  (Any 2 x 1) (2) 3.7 Heat treatment process: Tempering  (1) [14] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 7 DBE/November 2023 NSC – Marking Guidelines QUESTION 4: MULTIPLE-CHOICE (SPECIFIC) 4.1 B (1) 4.2 B (1) 4.3 C (1) 4.4 B (1) 4.5 C (1) 4.6 B (1) 4.7 B (1) 4.8 A or D  (1) 4.9 C (1) 4.10 C (1) 4.11 B (1) 4.12 D (1) 4.13 A (1) 4.14 A (1) [14] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 8 DBE/November 2023 NSC – Marking Guidelines QUESTION 5: TOOLS AND EQUIPMENT (SPECIFIC) 5.1 Compression tester: 5.1.1 Function of the compression tester:  It measures the pressure created  when the piston is at top dead centre on the compression stroke.   It is used to determine the condition of the piston rings after a wet compression test.  (Any 1 x 2) (2) 5.1.2 Reasons for low compression:  Worn cylinders   Worn piston rings   Worn piston   Leaking inlet valve   Leaking exhaust valve   Leaking cylinder head gasket   Cracked cylinder head   Cracked piston / Damaged piston.   Piston ring groove worn out and not holding pressure.   Insufficient volumetric efficiency.   Cracked cylinder sleeve.  (Any 1 x 1) (1) 5.1.3 Card-type compression tester:  The compression tester automatically records  the readings on the card in the tester.   To eliminate the human error  that can be made when taking the readings,  in terms of estimations. (Any 1 x 2) (2) 5.2 Cylinder leakage tester: 5.2.1 Function:  To check where the combustion chamber/cylinder leaks gases  during compression stroke.   To determine the percentage  pressure loss  from the combustion chamber. (Any 1 x 2) (2) 5.2.2 Gauge A: Percentage leakage (%) / Pressure leakage gauge  (1) 5.2.3 Control valve:  Used to calibrate the cylinder leakage tester.   Regulates the air pressure entering the cylinder leakage tester.  (Any 1 x 1) (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 9 DBE/November 2023 NSC – Marking Guidelines 5.3 Exhaust gas analysis unit of measure: 5.3.1 Carbon dioxide (CO2): Percentage (%)  (1) 5.3.2 Hydrocarbon (HC): Parts per million (ppm)  (1) 5.4 Reason for removing pick-up hose:  For auto-zero on the analyser to start at zero. / Calibration of tester to zero.   For exhaust gases to get out of the hose.  (2) 5.5 OBD-II plug location:  At the glove compartment (cubby hole).   Under the dashboard by the driver.   Behind a trim panel.   Between the front seats.   By the ashtray.   The floor panel.   In the fuse box.  (Any 2 x 1) (2) 5.6 Information typed into the diagnostic scanner:  The vehicle identification number (VIN).   The make of the vehicle.   The model of the vehicle.   The engine type.  (Any 3 x 1) (3) 5.7 Wheel balancing: Static  (1) 5.8 Label the bubble gauge: Gauge 1 - Zero scale/level  Gauge 2 - Castor  Gauge 3 - King pin inclination  Gauge 4 - Camber  (4) [23] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 10 DBE/November 2023 NSC – Marking Guidelines QUESTION 6: ENGINES (SPECIFIC) 6.1 Crankshaft of a four-cylinder engine: 6.1.1 Label the crank shaft: A – Crank nose/vibration damper mounting  B – Main journals  C – Big-end journals / Crankpin journals  D – Counterweight/Crank web  (4) 6.1.2 Correcting crank shaft imbalance:  By removing metal/weight from the crank webs.   By adding metal/weight to the crank webs.  (2) 6.2 Vibration dampers: 6.2.1 Label: A – Friction disc  B – Crankshaft  C – Secondary flywheel  D – Rubber cushion  (4) 6.2.2 Location: Fitted to the front end/nose of the crankshaft.  (1) 6.2.3 Function:  To smooth out / absorb/ minimize the engine vibrations.   To counteract the torsion of the crankshaft.  (Any 1 x 1) (1) 6.3 Engine configurations:  Inline / Straight   V-engine   W-engine / Double V-engine   Horizontally opposed engine / Flat engine / Boxer engine   Radial engine   X-Engine   U-engine   Delta engine   K-engine   Opposed-piston engine  (Any 2 x 1) (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 11 DBE/November 2023 NSC – Marking Guidelines 6.4 Power strokes per revolution: 6.4.1 Four-cylinder: 2 (1) 6.4.2 Six-cylinder: 3 (1) 6.5 Turbo-chargers: 6.5.1 Type: Variable geometry turbo-charger  (1) 6.5.2 Reason turbocharger boosts:  It increases  volumetric efficiency  of the cylinders.  It increases  the pressure of the air  entering the cylinder. (Any 1 x 2) (2) 6.5.3 Influence on the lifespan:  The oil supply is clean.   Use of the correct grading/type of oil.   The exhaust gas does not become overheated.   Adopting the proper switch-off procedure.   Sufficient oil pressure.  (Any 2 x 1) (2) 6.6 Disadvantages of a turbo-charger:  It requires pressure lubrication for high-speed bearings.   It requires pressure lubrication to act as a coolant.   It suffers from lag.   It tends to heat the air, reducing its density.   It needs to be controlled from over-revving by the waste gate.   Some require a special shut-down procedure before the engine can be switched off.  (Any 3 x 1) (3) 6.7 Disadvantage of superchargers: 6.7.1 Roots supercharger:  The least efficient supercharger.   They add more weight to the vehicle.   Usually large/bonnet(hood) must be modified.   They move air in bursts.  (Any 1 x 1) (1) 6.7.2 Twin-screw supercharger:  They are expensive.   They require more precision manufacturing.  (Any 1 x 1) (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 12 DBE/November 2023 NSC – Marking Guidelines 6.8 Reasons for a supercharger with a turbocharger on its engine:  To overcome lag at low rpm.   To increase power at all rpm.   Outstanding fuel economy.   To increase torque at all rpm.   Reduces the parasitic effect/power sapping on the engine.  (Any 2 x 1) (2) [28] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 13 DBE/November 2023 NSC – Marking Guidelines QUESTION 7: FORCES (SPECIFIC) 7.1 Indicated power: Brake power  Calculated using the volume and  Calculated using the torque the indicated mean effective developed.  pressure.   Indicated power is the theoretical  Brake power is the actual power power.  output of an engine.   Indicated power is calculated  Calculated considering without considering any mechanical or other losses of the mechanical or other losses of the engine.  engine.  (Any 1 x 2) (2) 7.2 Calculations: 7.2.1 Swept volume: π  D2 Swept volume  L 4 π  7,5 2   8  4  353,43 cm 3  (3) 7.2.2 Original clearance volume: SV CV = (CR - 1) 353,43  = (10 - 1)  = 39,27 cm3 (3) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 14 DBE/November 2023 NSC – Marking Guidelines 7.2.3 Stroke length: SV = CV(CR - 1) = 39,27(11 - 1)  = 392,7cm3  π  D2   7,52 Swept volume  L Area  4 4 SV  44,18 cm2  L  Area 392,70   44,18  8,89 cm  10  88,89 mm (6) 7.3 Methods to lower the compression:  Fit thicker gasket between cylinder block and cylinder head.   Fit a shim between cylinder block and cylinder head.   Fit piston with suitable lower crowns.   Fit crankshaft with shorter stroke (with suitable connecting rods).   Decrease bore diameter.  (Any 2 x 1) (2) 7.4 Prony brake test: 7.4.1 Torque: Torque = Force  radius  400 Torque = (30  10)   (g = 10 m/s2)  1000 = 120 Nm  OR  400  Torque = (30  9,81)  (g = 9, 81 m/s2)  1000 = 117,72 Nm  (4) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 15 DBE/November 2023 NSC – Marking Guidelines 7.4.2 Brake power: BP  2 NT   2000  (g = 10 m/s2) 2    120   60   25,13 kW  OR BP  2 NT   2000  2    117,72  (g = 9, 81 m/s2)  60   24,66 kW  (3) 7.4.3 Indicated power: IP  PLANn Where P  950  10 3 Pa 85 L 1000  0,085 m   π  0,09 2   A      4   6,36  10 3 m 2  2000 N  60  2  16,67 pow er strokes per second  n4 IP (950  10 3 )  0,085 (6,36  10 -3 )  16,67   4   34,24 kW  (7) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 16 DBE/November 2023 NSC – Marking Guidelines 7.4.4 Mechanical efficiency: BP ME   100 IP 25,13    100 (g = 10 m/s2) 34,24  73,39 %  OR BP ME   100 IP 24,66 (g = 9, 81 m/s2)    100 34,24  72,02 %  (2) [32] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 17 DBE/November 2023 NSC – Marking Guidelines QUESTION 8: MAINTENANCE (SPECIFIC) 8.1 Exhaust gas analysis: 8.1.1 Readings caused by a leak:  Incorrect  readings   No  readings at all  (Any 1 x 2) (2) 8.1.2 Ideal exhaust gas readings:  Low carbon monoxide   High carbon dioxide   Low Hydrocarbon  (Any 2 x 1) (2) 8.2 Compression tester:  Ensure that the tester can handle the pressure you want to test.   Ensure the rubber pipes are not perished.   Ensure the relief valve is working on the tester. / Zero the tester.   Ensure you use the correct adapter for the plug hole.  (Any 2 x 1) (2) 8.3 Cylinder leakage test: Fault Possible cause  Hissing noise at air intake.   Leaking inlet valve.   Hissing noise at exhaust.   Leaking exhaust valve.   Hissing noise at oil filler  Piston rings are worn.  cap/dipstick.   Bubbles in the radiator.   Blown cylinder head gasket/Cracked cylinder head.   Hissing sound from adjacent  Blown cylinder head gasket spark plug hole  between cylinders / crack between cylinders.  (Any 3 x 2) (6) 8.4 Oil pressure test:  Oil pressure when engine is idling.   Oil pressure when engine is cold.   Oil pressure when engine is hot.   Oil pressure on high revolutions.  (Any 3 x 1) (3) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 18 DBE/November 2023 NSC – Marking Guidelines 8.5 Fuel pressure:  Faulty fuel pump   Blocked fuel filter   Cracked fuel line   Clogged pump strainer   Low voltage to the fuel pump   Faulty fuel pressure regulator   Empty fuel tank   Faulty fuel pump relay   Leaking fuel injectors   Blocked fuel line  (Any 4 x 1) (4) 8.6 Radiator cap pressure test: Step 1: Obtain the release pressure on the cap or from manufacturer’s specifications.  Step 2: Fit the radiator cap with the correct adaptor on the cooling system pressure tester.  Step 3: Now pump the tester while watching the release pressure on the gauge.  Step 4: Check that the cap holds the specified pressure.  (4) [23] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 19 DBE/November 2023 NSC – Marking Guidelines QUESTION 9: SYSTEMS AND CONTROL (AUTOMATIC GEARBOX) (SPECIFIC) 9.1 Reasons for automatic gearbox preferred over manual gearbox:  There is no clutch pedal. (relieve the driver of clutch operation).   There is no need to change gears. (relieve the driver of gearshift operation).   Allows the driver to concentrate on driving.   Smoother and easier driving of the vehicle.   It reduces driving fatigue.   It ensures great reduction of wheel spin.   The vehicle can be stopped suddenly without the engine stalling.   The system dampens all engine torsional vibrations.  (Any 4 x 1) (4) 9.2 Towing vehicle with automatic gearbox:  The drive wheels must be lifted off the ground.   The vehicle  should be lifted on a flatbed tow truck.   The drive shaft/propeller  shaft should be removed. (Any 1 x 2) (2) 9.3 Torque converter: 9.3.1 Functions:  It transfers the torque and power from the engine to the gearbox.   It drives the front pump of the gearbox.   It isolates the engine from the gearbox when the vehicle is stationary.   It multiplies the torque of the engine.   Reduction of engine vibrations transmitted to the gearbox.   Turn the engine during the idle strokes. (flywheel effect)  (Any 3 x 1) (3) 9.3.2 Component that prevents slip: Pressure plate/Clutch assembly  (1) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 20 DBE/November 2023 NSC – Marking Guidelines 9.4 Brake band in automatic gearbox: 9.4.1 Label: A – Band adjuster  B – Anchor  C – Lever  D – Brake band  (4) 9.4.2 Function of brake band: The brake band holds the drum/annulus in a stationary position.  (1) 9.4.3 Component controlling the brake band: Hydraulic piston  (1) 9.5 Double epicyclic gear train: 9.5.1 First (1st) gear / Gear reduction  (1) 9.5.2 Second (2nd) gear / Overdrive  (1) [18] Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 21 DBE/November 2023 NSC – Marking Guidelines QUESTION 10: SYSTEMS AND CONTROL (AXLES, STEERING GEOMETRY AND ELECTRONIC) (SPECIFIC) 10.1 Steering mechanism: The steering mechanism must enable the driver  to be in control of the path taken by the vehicle at all times.  (2) 10.2 Signs of wheel imbalance:  Excessive tyre wear   A poor ride/tracking   Vibrations on the steering wheel   Wheel bounce/hop   Wheel shimmy/wobble   Vibrations on the brake pedal   Excessive wear on the suspension  (Any 2 x 1) (2) 10.3 Static wheel balance:  Mount the wheel so that it is free to turn on a spindle through its center.   The spindle must be approximately horizontal and the wheel turning slowly.   If the wheel is out of balance, it will always come to rest with one point, the ‘heavy spot’, at the bottom.   To correct static imbalance, a small mass (weight) is applied to the wheel rim, diametrically opposite the ‘heavy spot’. The size and position of the weight to be fitted are found by trial and error.  (4) 10.4 Negative caster angle: A - Kingpin  B - Perpendicular line  C - Negative caster angle  D - Centre line of kingpin  (4) 10.5 Electric fuel pump:  Immediate supply of fuel when the ignition switch is turned on.   Low operation noise.   Less discharge pulsation of fuel.   Compact and light design.   It helps to prevent fuel leak.   It reduces vapour lock.   Delivers fuel at a higher rate / pressure.  (Any 2 x 1) (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 22 DBE/November 2023 NSC – Marking Guidelines 10.6 Fuel delivery system: 10.6.1 Pressure regulator:  It keeps the pressure in the rail at a specified value.   It regulates the pressure in the rail.  (Any 1 x 1) (1) 10.6.2 Fuel filter:  Prevents dirt from entering the fuel line.   Prevents damaging or clogging of the injectors.   Prevents damage to the pressure regulator.  (Any 1 x 1) (1) 10.7 Air induction system: 10.7.1 Label: A - MAF sensor  B - Air filter/Air filter housing  C - Throttle valve / Throttle body  D - Intake valve  (4) 10.7.2 Purpose: The air-induction system measures  and controls the air required for the combustion.  (2) 10.8 Purpose of lambda sensor: The sensor measures the oxygen content in the flow of the exhaust gas  and then sends a signal to the engine control unit.  (2) 10.9 Stator windings: (Sketch ) (Sketch ) Delta  Star- or Y-connected  (4) 10.10 Increase the output frequency:  Increase the turns of wire/windings on the stationary coil/stator.   Increase the strength of the magnetic fields.   Increase the rotational frequency at which the magnets rotate.  (Any 2 x 1) (2) Copyright reserved Please turn over
Downloaded from hlayiso.com Mechanical Technology: Automotive 23 DBE/November 2023 NSC – Marking Guidelines 10.11 Adaptive speed control:  To maintain a speed as set by the driver.   To adapt this speed and maintain a safe distance from the vehicle in front.   To provide a warning if there is a risk of a collision.   To provide a warning if the set speed is exceeded.   Reduces driver fatigue.   Improves fuel consumption.  (Any 2 x 1) (2) [32] TOTAL: 200 Copyright reserved
