Downloaded from hlayiso.com
Civil Technology: Civil Services 2 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 1: OHSA, SAFETY, MATERIALS, TOOLS, EQUIPMENT AND JOINING
(GENERIC)
1.1 1.1.1 G (1)
1.1.2 E (1)
1.1.3 A (1)
1.1.4 C (1)
1.1.5 D (1)
1.2 • When heavy materials/loads are not lifted/lowered/handled correctly.
• Wrong posture when lifting materials.
• Not using safety apparel.
ANY ONE OF THE ABOVE (1)
1.3
1 : 4 OR 76° (2)
1.4 • A qualified person must operate the device.
• The device must never be overloaded.
• The gates and wire components of the lift of the hoisting device must be
at least 1 980 mm high.
• The gates must be shut when the device is being used.
• Emergency brake mechanisms must be installed.
• Safety measures must be displayed inside the cage.
• Inspections and maintenance work should be carried out regularly
(at least six-monthly) by qualified persons.
• Overhead protection must be provided to protect workers from falling
objects.
• When material or equipment is being hoisted, it must be stacked firmly
and correctly, and secured properly.
• The hoist must be inspected weekly by a qualified person.
ANY TWO OF THE ABOVE (2)
1.5.1 A = Laser level
B = Dumpy level (2)
Copyright reserved
Downloaded from hlayiso.com
Civil Technology: Civil Services 3 DBE/2019
SC/NSC – Marking Guidelines
1.5.2 Laser level (A) Dumpy level (B)
To determine levels when: The dumpy level is used
• installing ceilings and floor tiles. when:
• installing chair rails for example in • determining differences
a dining room. between levels and
• installing receptacles for power vertical heights, especially
inside a building during over longer distances
construction. • determining levels and
• hanging pictures. slopes.
• excavating for new buildings. • setting out buildings
• aligning and levelling floors. • transferring levels and
• when installing doors and windows. heights.
• aligning shelves and cabinets. • determining/measuring the
• levelling post and beams on decks, distances between two
fences and porches. points.
• setting out buildings on a site.
• aligning fences, post and decks.
• determining gradient/slope for
drainage and irrigation.
• establishing contours for farming or
drainage.
• To determine levels and slopes
when installing sewer pipes.
ANY ONE IN EACH COLUMN ABOVE (2)
1.6 1.6.1 Rawl bolt (1)
1.6.2 A – Drill a hole of the required diameter and depth.
B – Remove debris and thoroughly clean the hole with a brush or
by blowing into it.
C – Remove the bolt and washer, insert the sleeve/shield into the
hole and align the fixture (for example base plate, etc…) with
the hole.
D – Insert the bolt with washer through the fixture and tighten to the
recommended torque. (4)
1.6.3 Rawl bolts:
• are stronger fasteners than a screw with a plastic plug.
• are designed to resist pull-out failure.
• have excellent mechanical properties such as tensile and yield
stress.
• have excellent carrying capacity.
• have excellent tolerance to variance in the hole size.
ANY ONE OF THE ABOVE (1)
[20]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 4 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 2: GRAPHICS AS MEANS OF COMMUNICATION (GENERIC)
ANSWER SHEET 2
NO. QUESTIONS ANSWERS MARKS
1 Identify the elevation shown in
Eastern/East elevation/East 1
FIGURE A.
1
2 Name the scale of FIGURE B. 1 : 100
1
3 Identify number 1. Barge board
1
4 Identify number 2. Roof overhang/Eave/Open eave
5 Recommend a suitable finish for Plaster/Paint/Face brick/Tiles/
number 3. 1
Cladding
6 What is indicated by number 4? Door/Entrance door/Door opening 1
7 Identify the drawing symbol indicated
Finished floor level/FFL
by number 5. 1
8 Identify the drawing symbol indicated
Natural ground level/NGL 1
by number 6.
9 What is indicated by number 7? Step 1
10 Give the date on which the building
1
plan was printed. 2019/06/16
1
11 Who checked the building plan? P Blade
12 Name the electrical drawing symbol Two-way switch
in the column for the notes in
1
FIGURE 2 that must be placed at a
staircase.
DO NOT MARK
THESE QUESTIONS
13 Name the electrical feature in the
column for the notes in FIGURE 2
Wall light 1
that must be placed at the entrance
door of the house.
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 5 DBE/2019
SC/NSC – Marking Guidelines
14 Identify the type of roof that is
used on the building in Gable roof 1
FIGURE A.
15 Explain the purpose of number 1. To cover ends of purlins/battens/fixed to
the purlins/battens for a neat appearance. 1
To finish of the gable end of the roof.
16 Who is the owner of this house? Mr H Smith 1
17 In which street is the proposed
Jupiter street 1
dwelling situated?
18 Identify number 8. Rainwater down pipe/Downpipe 1
19 To wash your face/Body
What is the sanitary fitting Brush your teeth 1
indicated by number 9 used for? Wash your hands
Washing/Rinsing
20 Recommend an alternative
sanitary fitting to replace
Bath 1
number 10 that will serve a similar
purpose.
21 Explain the purpose of number 11 Landing to serve as resting place or
1
as indicated on the staircase. change of direction of staircase.
22 Emergency light/External light
What is indicated by number 13? 1
Thickness of wall/110 mm
23 What is indicated by number 15? North- symbol/direction/point 1
24 Deduce the height of window 1
1,8 m or 1 800 mm 1
from the window schedule.
25 Deduce the width of window 2
2,4 m or 2 400 mm 1
from the window schedule.
26 Name the elevations of the
building on which the staircase is Western/West elevation/West 2
situated. Southern/South elevation/South
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 6 DBE/2019
SC/NSC – Marking Guidelines
27 12 – One way light switch single pole/
Differentiate between the
electrical symbols indicated by lever 2
numbers 12 and 14. 14 – One way light switch double pole/
lever
28 Recommend a suitable floor Tiles/Novilon/Carpets/Laminated
1
covering for the lounge. flooring/Wooden flooring.
29 Calculate the area of the lounge 6 m x 3 m = 18 m²
in m². Show ALL calculations.
OR 3
6 000 mm x 3 000 mm = 18 m²
30 Calculate the perimeter of the (220 + 3 000 + 110 + 3 000 + 220) x 2
building. Show ALL calculations.
= 6 550 x 2
=13 100 mm
(220 + 6 000 + 220) x 2
= 6 440 x 2 7
= 12 880 mm
13 100 + 12 880
= 25 980 mm OR
= 25,98 m
TOTAL: 40
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 7 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 3: CONSTRUCTION ASSOCIATED WITH CIVIL SERVICES, OHSA,
SAFETY AND QUANTITIES (SPECIFIC)
3.1 3.1.1 • The sewage runs into the system at A and exits the system
at D.
OR
• Sewage flows from A to D. (2)
3.1.2 Branch/Open channel (1)
3.1.3 Benching must be installed at a slope for the following reasons:
• To ensure that sewage spills slide back into the channel.
• So that rats or other vermin cannot settle there.
ANY ONE OF THE ABOVE (1)
3.1.4 Engineering brick/Face brick/Common brick/Plaster brick (1)
3.2
√
√
A A
Section correctly drawn
ASSESSMENT CRITERIA MARK
Five brick courses in stretcher bond 5
Half brick on alternate plan courses on
3
left side
Section correctly drawn 1
Hatching lines (Accept any type of 1
hatching for brick work)
TOTAL: 10 (10)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 8 DBE/2019
SC/NSC – Marking Guidelines
3.3 3.3.1 Moderately firm ground (1)
3.3.2 A - Poling boards/planks
B - Strut (2)
3.4 Respirator/Breathing apparatus (1)
3.5 Regulations when working in high places:
• Appoint a competent person, responsible for the preparation of a fall
plan.
• Ensure that a fall protection plan is implemented, amended where and
when necessary, and maintained as required.
• Ensure that steps are taken in order to continue adherence to the fall
protection plan. (3)
3.6 A B C D
Total length of partition wall
1/ 1 200 mm - 2 /220
= 760 mm (2)
Area of partition wall
1/ 0,76
1,2 0,91 m2 (3)
Number of bricks needed for
partition wall excluding 5% for
breakage
1/
0,91
50 45,5 46 bricks are needed (3)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 9 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 4: HOT- AND COLD-WATER SUPPLY, TOOLS, EQUIPMENT AND
MATERIALS (SPECIFIC)
4.1 4.1.1 Solar geyser (1)
4.1.2 Sunlight (1)
4.1.3 Disadvantages of using a heat pump are:
• It runs on electricity.
• It is costly.
• Does not work well in all climates.
• Supplementary heat is needed for lower temperatures.
ANY TWO OF THE ABOVE (2)
4.2 4.2.1 Preventing poor hot water pressure:
• Replace geyser if it is faulty with new/modern one with a
higher pressure rating.
• Replace blocked pipes.
• Replace the valves if it is faulty.
• Clean pipes
ANY ONE OF THE ABOVE (1)
4.2.2 Preventing ware not being hot enough:
• Adjust the thermostat to a higher temperature.
• Replace the thermostat and element if it is faulty.
• Replace the geyser if it is faulty.
ANY ONE OF THE ABOVE (1)
4.2.3 Prevent dripping geyser overflow:
• Replace the pressure control/relief valve.
• Clean the filter of the relief valve.
• Replace the o-ring in the relief valve.
• Replace the spring in the relief valve.
ANY ONE OF THE ABOVE (1)
4.3 4.3.1
P
(2)
4.3.2
PV
(2)
4.3.3
(2)
4.4 4.4.1 Full-way valve/Gate valve (1)
4.4.2 A - Hand wheel
B - Gland nut (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 10 DBE/2019
SC/NSC – Marking Guidelines
4.4.3 This valve can be used at:
• geysers.
• water meters.
• a place in a system where water supply needs to be shut off.
• a water supply system in a building.
• Inside/outside a building.
ANY ONE OF THE ABOVE (1)
4.5 Devices that can reduce water consumption are:
• water-saving aerator device on tap.
• sensor/electronic taps.
• metered taps.
• demand pillar taps.
• water saving shower heads.
• flushing devices with two buttons, to save water.
ANY TWO OF THE ABOVE (2)
4.6 How to repair a galvanised pipe by using a Johnson pipe coupling:
• Shut off the water supply.
• Use a pipe cutter/hacksaw and cut the damaged section from the supply
line.
• Put the Johnson pipe coupling over the one side of the pipe, ensuring
that the tapered rubber seal is in place and secure it to the centre-
coupling piece.
• Add a new length of pipe.
• Put the Johnson pipe coupling over the other side of the pipe and fasten
it on both sides.
• Test for leaks.
ANY FIVE OF THE ABOVE (5)
4.7 4.7.1 E (1)
4.7.2 B (1)
4.7.3 A (1)
4.7.4 F (1)
4.7.5 C (1)
4.8 Problems that can be caused by dezincification are:
• In the presence of oxygen and water, zinc gradually dissolves from the
surface of an alloy; the material that will remain is a weak, spongy copper
layer.
• It can progress through the part and cause leaks.
• It can cause blockages if it forms a deposit.
ANY TWO OF THE ABOVE (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 11 DBE/2019
SC/NSC – Marking Guidelines
4.9 Methods to prevent galvanic corrosion in metals are:
• electrically insulating the two metals.
• making sure that there is no contact with an electrolyte.
• applying an antioxidant paste to copper and aluminium surfaces.
• choosing metals that have similar electrode potentials.
• connecting a direct current (DC) supply to oppose the corrosive galvanic
current.
ANY TWO OF THE ABOVE (2)
4.10 4.10.1 Pipe thread cutting machine (1)
4.10.2 • To thread pipes
• To cut pipes
• To ream pipes
• To thread and cut bolts and nuts
ANY ONE OF THE ABOVE (1)
4.10.3 Factors to be considered when taking care:
• Maintain tool with care.
• Keep cutting tools sharp and clean.
• Check for misalignment or binding of moving parts, breakage
of parts and any other conditions that may affect the operation
of the tool.
• Use only accessories that are recommended by the
manufacturer.
• Grease surface of pipe before cutting.
• Start the cutting of threads slowly at first and then move to a
steady pace.
• Secure the machine to a bench or stand.
• Keep the covers in place.
• Support long heavy pipes.
• Do not wear gloves or loose clothing's that can get caught in
moving parts.
• Do not use the machine if the foot switch is broken.
• Tighten the chuck wheel and engage the rear centring device
before turning on the machine.
• Lock the foot switch when the machine is not in use to prevent
accidental starting.
• Use the clamp or any other practical way to secure and
support the work piece.
ANY TWO OF THE ABOVE (2)
4.11 Water pressure testing pump is used to test the pressure of water
systems. (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 12 DBE/2019
SC/NSC – Marking Guidelines
4.12 Factors to be considered when taking care of this water pressure testing
pump:
• Keep the tank and pump system clean.
• The suction pipe is provided with a filter to prevent dirt from entering the
system. Remove and clean the filter with water when it
becomes clogged.
• Grease the piston regularly with water repellent grease.
• Be careful not to damage the piston.
• After use, turn off the test pump, disconnect it from the system and store
it safely.
• Use only liquids specified for the test.
• No acids or other corrosive liquids may be used.
• Use only clean water; oil can be used as an alternative.
• Check the pump for damaged or defective parts before use.
• The pump should not be used if pressure hoses or any other parts are
faulty or damaged.
ANY TWO OF THE ABOVE (2)
[40]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 13 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 5: GRAPHICS AS MEANS OF COMMUNICATION, ROOF WORK AND
STORM WATER (SPECIFIC)
5.1 5.1.1 Stop end (1)
5.1.2 Flashing (1)
5.1.3 Hacksaw (1)
5.1.4 Union clip (1)
5.1.5 Fascia board (1)
5.2 5.2.1 Square gutter/Gutter (1)
5.2.2 Offset (1)
5.2.3 Holder bat – is used to keep the downpipe anchored to the wall. (1)
5.3 5.3.1 Grid (1)
5.3.2 Other methods of channelling water to catchment areas are:
• Gutters on roofs collect rainwater and feed it to down pipes.
• Manholes connected to storm-water drains will carry the water
away from inhabited areas to be safely discharged into rivers
or dams.
• Furrows can channel water to catchment areas.
ANY TWO OF THE ABOVE (2)
5.3.3 Poorly constructed or managed storm water systems can result in:
• discomfort of occupants or the public.
• loss of life.
• damage to properties.
• pollution of the environment.
• negative environmental impact.
ANY ONE OF THE ABOVE (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 14 DBE/2019
SC/NSC – Marking Guidelines
5.4
7
2 4
5
6
1 1 5
4
4
5 5
2
5
7
5 Candidates can use any one of the two
methods:
1. Calculate the circumference
and divide by 12
OR
2. Measure distance between any
two parts on top view (circle)
3
DRAWING NOT TO SCALE: USE A MASK
TO MARK THIS QUESTION
ASSESSMENT CRITERIA Code M
Construction lines to top of cone 1 2
Construction lines of outer circle 2 2
Divide outer circle in 12 parts 3 1
Construction lines from top of cone to outer circle 4 3
Cone measurement (marked/transferred) from front
view to determine top part of development (ONE 5 6
mark for every FOUR coordinates = 3)
Outside lines of development 6 2
3 mm seam on both sides 7 2
TOTAL: 18
(18)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 15 DBE/2019
SC/NSC – Marking Guidelines
QUESTION 6: DRAINAGE SYSTEMS AND SANITARY FITTINGS (SPECIFIC)
6.1 6.1.1 B (1)
6.1.2 A (1)
6.1.3 C (1)
6.1.4 A (1)
6.1.5 C (1)
6.2 6.2.1 Trap A – has the shape of a S.
Trap B – has the shape of a P. (2)
6.2.2 It forms a water seal to prevent gasses and bad smells from the
sewerage system to enter the atmosphere. (1)
6.3 6.3.1 Cistern/Water container (1)
6.3.2 Rubber cone is malleable/elastic.
Can make a watertight seal between the pipe and the water closet.
ANY ONE OF THE ABOVE (1)
6.3.3 Access junction – if there is no access junction there will be no
access to the pipe to clean blockages.
OR
Inspection eye – if there is no inspection eye there will be no
access to the pipe to clean blockages.
OR
Soiled water will flow out.
Gasses would escape. (2)
6.3.4 Drain-cleaning rods/Plunger/Coil spring
ANY ONE OF THE ABOVE (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 16 DBE/2019
SC/NSC – Marking Guidelines
6.3.5 CASING
SILENCING TUBE
BALL
LEVER ARM
Line diagrams will also be accepted
ASSESSMENT CRITERIA MARK
Shape of the ball 1
Lever arm 1
Casing with silencing tube 1
Any TWO labels 2
TOTAL: 5
(5)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 17 DBE/2019
SC/NSC – Marking Guidelines
6.4
RE
IE IE IE
RE
VP
IE
WB
WC
B
S G
IE
MH
ASSESSMENT CRITERIA MARK
2 x rodding eyes correctly positioned 2
5 x inspection eyes correctly
5
positioned
1 x ventilation pipe correctly positioned 1
Sewerage pipes drawn correctly (main
2
and branch pipes)
TOTAL 10
(10)
6.5 6.5.1 French drain (1)
6.5.2 The grey water will kill the bacteria in the septic tank. (1)
6.6 • Vacuum tanks are installed anywhere where there is no municipal
sewerage systems.
• Farms
• Rural areas
• New developments
ANY ONE OF THE ABOVE (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 18 DBE/2019
SC/NSC – Marking Guidelines
6.7 Inspection chamber (1)
6.8 Copper pipes can be joined by means of:
• capillary/soldered joints.
• brass compression joints. (2)
6.9
(2)
6.10 6.10.1 A – Tension force
B – Shear force (2)
6.10.2 The position of the soldering iron is important because:
• proper contact of the soldering iron to the metal will ensure that
the metal heats up to the melting point of the solder.
• heat is transferred from the tip of the soldering iron to the
metal.
• it melts the solder and keeps it in liquid form during the
soldering process.
ANY TWO OF THE ABOVE (2)
[40]
TOTAL: 200
Copyright reserved
Study this subject
Recommended for this subject
%20Memo%20Afr_hlayiso.com_--2a9b9e1b-37dc-48dc-9aa7-67dd5fa19a10/v1-8a03885eb99c8043e8b1/card.webp)
Memorandum
Civil Technology Grade 12 NSC June 2019 Memo (Afrikaans)
%20Eng_hlayiso.com_--3f3d8211-a2ae-4ecd-89a4-623bb435b86a/v1-648207bcb15a032d7837/card.webp)
Question paper
Civil Technology Grade 12 NSC June 2019 Question Paper (Eng)
%20Afr_hlayiso.com_--87c657e9-94a5-422f-ade2-b3b897806384/v1-9312fb31c11787e210aa/card.webp)
Question paper
Civil Technology Grade 12 NSC June 2019 Question Paper (Afr)
%20Afr_hlayiso.com_--bdea7087-4612-4372-bd72-70147466f760/v1-e8611611e9b476da11a3/card.webp)
Question paper
Civil Technology Grade 12 NSC June 2019 Question Paper (Afr)
%20Memo%20Afr_hlayiso.com_--13c03cd5-cfa4-42cf-9a7c-5d7b0e1069f0/v1-b52b9528a267b4d4a925/card.webp)
Memorandum
Civil Technology Grade 12 NSC November 2019 Memo (Afrikaans)
%20Memo%20Eng_hlayiso.com_--53bd979c-a0bb-411f-960b-1f8755cd4874/v1-6e2a9c2564a39a8c61d5/card.webp)
Memorandum
Civil Technology Grade 12 NSC November 2019 Memo (English)
More from Grade 12 Civil Technology

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2025 QP (Eng)
%20(English%20and%20Afrikaans)%20June%202025%20Question%20Paper--c8edd459-5237-48e0-8588-69d7ecd7f8e5/v1-be996aaed91bf782e098/card.webp)
Question paper
Civil Technology Grade 12 Gauteng June 2025 QP (Afr)
%20Afr--591d6ffd-20b1-4748-a1ba-b055be0a14c3/v1-4d98a131fd37e013458a/card.webp)
Question paper
Civil Technology Grade 12 NSC June 2025 Question Paper (Afr)
%20Afr--05a95faf-5891-4d88-9e5e-7d13c1d21648/v1-f5ca67113376f7457b83/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2025 QP (Afr)

Question paper
Civil Technology Grade 12 Eastern Cape Prelim 2024 QP (Afr)

Question paper
