Downloaded from hlayiso.com
Civil Technology: Civil Services 2 DBE/November 2019
NSC – Marking Guidelines
QUESTION 1: OHSA, SAFETY, MATERIALS, TOOLS, EQUIPMENT AND JOINING
(GENERIC)
1.1 1.1.1 B (1)
1.1.2 I (1)
1.1.3 A (1)
1.1.4 G/H (1)
1.1.5 C (1)
1.1.6 F (1)
1.1.7 J (1)
1.1.8 E (1)
1.2 Electroplating:
• protects metals against corrosion.
• improves the engineering- and mechanical properties of metal.
• may be used to increase the thickness of undersized parts.
• is decorative.
• will extend the life span.
ANY TWO OF THE ABOVE (2)
1.3 Curing (1)
1.4 The moisture:
• delays/prevents the rapid drying of fresh concrete.
• prevents concrete from cracking.
• ensures that fresh concrete hardens properly.
• allows adhesive bonding.
• increases strength of fresh concrete.
ANY ONE OF THE ABOVE (1)
1.5 •When material is transported in bulk, it must be secured firmly.
•When material is transported to higher levels, make sure that workers
maintain a safe distance from the material being moved overhead.
• When heavy material is transported with a lift/hoist/machine, a
qualified person must take charge of operations.
• Wear appropriate personal protective equipment(PPE).
• Material must be transported in a safe way.
• Transport should not be overloaded with material.
ANY TWO OF THE ABOVE (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 3 DBE/November 2019
NSC – Marking Guidelines
1.6 Scaffold planks should:
• be made of a solid wood at least 228 mm wide and 38 mm thick.
• be able to support the load.
• be free from defects.
• not be painted as it will hide defects/be slippery.
• be supported at distances not exceeding 1,25 m.
• not project less than 70 mm and not more than 230 mm beyond the
ends of the last prop.
• be firmly secured to prevent its displacement.
• be placed in such a way to prevent materials and tools from falling
through.
ANY ONE OF THE ABOVE (1)
1.7 1.7.1 Dumpy level (1)
1.7.2 If the dumpy level is not set up level:
• it will give inaccurate readings.
• wrong levels will be transferred.
• true levels will not be transferred.
ANY ONE OF THE ABOVE (1)
1.8 1.8.1 A – Plastic plug/Plug/Rawl plug/Fisher plug/Fibre plug (1)
1.8.2 A screw (1)
1.8.3 Plastic plugs are used to secure:
• cupboards against a wall.
• mirrors against a wall.
• portraits and similar objects against a wall.
• objects, limited to certain weight, against walls.
ANY ONE OF THE ABOVE (1)
[20]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 4 DBE/November 2019
NSC – Marking Guidelines
QUESTION 2: GRAPHICS AS MEANS OF COMMUNICATION (GENERICS)
ANSWER SHEET 2
NO. QUESTIONS ANSWERS MARKS
1 Identify the elevation in FIGURE A. West Elevation 1
Identify the type of roof that is used
2 Hipped roof 1
on the building in FIGURE A.
Ridge Capping/Ridge plate/Ridge
3 Identify number 1. 1
tile/Hip cap
Balcony/Floor slab of
4 Identify number 4. 1
balcony/Cantilever/Concrete slab
External door/Entrance
5 Identify number 5. 1
door/Door/Outside door
6 Identify number 7. Gutter 1
Rainwater down pipe/RWDP/Down
7 Identify number 8. 1
pipe
8 Identify number 12. Wash trough/Wash tub 1
9 Identify number 13. Built-in cupboard/BIC 1
10 Identify number 15. Landing 1
Identify the company that printed
11 Dlamini printers 1
the building plan.
Name a suitable material that can
Fibre cement/Galvanised sheeting/
12 be used for the manufacturing of 1
Timber/Plastic/PVC/Polyvinylchloride
number 2.
Name the drawing symbol in the
Electricity meter/Electrical meter/Watt
13 column for the notes in FIGURE 2 1
meter/Prepaid meter
that must be installed in the kitchen.
Name the drawing symbol in the
column for the notes in FIGURE 2
14 Face brick 1
that indicates the type of bricks for
the building.
Name a material that should NOT Steel/Mild steel/Iron/Ferrous
15 be used to manufacture the frame 1
of number 9 for coastal areas. metals
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 5 DBE/November 2019
NSC – Marking Guidelines
Name a material that can be used Stainless steel/Plastic/Ceramic/
16 to manufacture the sanitary fitting Granite/Acrylic/Fibre 1
indicated by number 11. Glass/Concrete
17 Who checked the building plan? P Carter 1
How many types of windows are
18 2 1
used in FIGURE B?
What does the abbreviation NGL at
19 Natural ground level 1
number 6 stand for?
Give the reference code for this
20 QP 2-2019 1
plan.
Which room will electrical symbol
21 Lounge 1
16 serve?
Prevent people from falling off/through.
22 Describe the purpose of number 3. 2
Electrical wiring/Wiring/Electrical
Explain what the curved lines
cable/Wiring from light switch to
23 between the electrical installations 2
light/Shows which switch operates
in FIGURE B indicate.
which electrical fitting.
Explain why the light switch is To prevent steam/moisture entering
24 mounted on the outside of the the switch/To prevent electrical shock 1
bathroom. due to moisture/For safety purposes
Identify in FIGURE 2 which
25 North elevation 1
elevation does NOT have windows.
Identify the thickness of the internal
26 110 mm 1
wall in FIGURE 2.
13 – Built-in cupboard: to store
items.
Differentiate between symbols 13
27 15 – Landing: to rest/safety 2
and 15 in terms of their purpose.
feature/change of direction of
stairs
Ground floorplan:
• does not indicate the roofline
• does not indicate the balcony
• indicate an entrance door to the
Justify why FIGURE B is a ground house
28 • indicate a step at the entrance 1
floor plan.
door
• the position of the windows and
door correlate with the positions
of the window and door on the
west elevation
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 6 DBE/November 2019
NSC – Marking Guidelines
Predict what will happen if number 10 Water/Damp will penetrate into the
29 1
is NOT installed. wall.
Redraw the staircase in FIGURE B in OR
30 the adjacent column and indicate the 2
direction of the flight with arrows.
220 + 2 600 + 110 +
3 400 + 220
= 6 550 mm or 6,55 m
IF INCORRECT METHOD IS USED
TO CALCULATE THE ANSWER
USE THE FOLLOWING SLIDING
SCALE:
Calculate the total length of the wall
31 on the eastern side of the building. • 4 MARKS WILL BE 6
Show ALL calculations. AWARDED IF ALL FIVE
VALUES ARE CORRECT
• 3 MARKS FOR FOUR
VALUES CORRECT
• 2 MARKS FOR THREE
VALUES CORRECT
• 1 MARK FOR 2 VALUES
CORRECT
TOTAL: 40
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 7 DBE/November 2019
NSC – Marking Guidelines
QUESTION 3: CONSTRUCTION ASSOCIATED WITH CIVIL SERVICES, OHSA,
AND QUANTITIES (SPECIFIC)
3.1.1 Step irons/Ladder/Concrete/Cast iron lid (ANY ONE) (1)
3.1.2 Step irons/Ladder/Concrete/Cast iron lid (ANY ONE) (1)
3.2 3.2.1 Wedge (1)
3.2.2 300 mm (1)
3.3 3.3.1 4 (1)
3.3.2 3 (1)
3.3.3 L x b x h OR Area of base x height OR Side x side x side OR S3
= 2,7 x 2,7 x 2,7
= 19,68 m³ (4)
= 19,68 m³ x 1 000 ℓ
= 19 680 ℓ OR 19 683 ℓ (2)
3.4 3.4.1 D- Clip (1)
3.4.2 Rope grab (1)
3.4.3 Breathing apparatus (1)
3.4.4 Transparent pipe level (1)
3.4.5 Manhole (1)
3.5 A – Spirit level
B – Long straight edge/Straight edge
C – Steel peg/Peg (3)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 8 DBE/November 2019
NSC – Marking Guidelines
3.6
1st COURSE
2nd COURSE
Correctness
ASSESSMENT CRITERIA MARK
Bricks at corner drawn correctly 2
2 x ¾ bricks 4
Full bricks on each side of ¾ bricks 2
Full brick at T-junction 1
Correctness of drawing 1
TOTAL: 10 (10)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 9 DBE/November 2019
NSC – Marking Guidelines
QUESTION 4: HOT- AND COLD-WATER SUPPLY, TOOLS, EQUIPMENT AND
MATERIALS (SPECIFIC)
4.1 4.1.1 Solar geyser system/Solar panel with geyser (1)
4.1.2 Water will get cold. (1)
4.1.3 To ensure maximum operation/efficiency.
So that dirt cannot accumulate on the glass panel.
ANY ONE OF THE ABOVE (1)
4.2 An airlock is a pocket of air that is trapped inside a pipe and it prevents
constant water flow. (3)
4.3 Causes of water hammer are:
• Sudden drop in secondary supply pipes
• Loose jumpers in taps
• Pipes in walls are not properly caulked
• Pipes are not properly secured in roof spaces above the ceiling
• Draw-off pipe is bigger than the supply pipe
• Bad/Poor installation
ANY TWO OF THE ABOVE (2)
4.4 4.4.1 Balancing device (hot water control) (1)
4.4.2 Shower (movable)/Movable shower (1)
4.5 4.5.1 C
H
Correctness of symbol = 2 marks (2)
4.5.2
Correctness of symbol = 2 marks (2)
4.6 4.6.1 S-Trap (1)
4.6.2 40/50 mm (1)
4.7 4.7.1 A – T Junction (Plain)
B – 90º bend with inspection eye (2)
4.7.2 A – Where three soil pipes with the same
diameter meets/Where the branch pipe connects to the main
sewerage pipe.
B – Above ground where soil pipes have to change direction at a
90º angle/Outside the external wall where the water closet is
. installed. (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 10 DBE/November 2019
NSC – Marking Guidelines
4.8 4.8.1 Pipe-thread cutting machine (1)
4.8.2 Water pressure testing pump (1)
4.8.3 Drain-cleaning machine/Jetting machine (1)
4.9 Functions of the centrifugal pump:
• To pump water out of excavations or trenches.
• To move liquids through pipes or pipelines.
• To move slurries or liquid containing suspended matter.
• To convert rotational motion/kinetic energy to hydrodynamic energy.
• To increase the pressure of water in pipes.
ANY TWO OF THE ABOVE (2)
4.10 It is not recommended that copper pipes are joined to galvanised pipes
because:
• Negative effects on the pipeline can be caused due to the chemical
reactions between the metals and acidic water.
• Pit marks are caused by the chemical reaction between the two
metals.
• An electrochemical reaction can take place between two dissimilar
metals causing corrosion/dezincification.
ANY TWO OF THE ABOVE (2)
4.11 4.11.1 Pillar tap (1)
4.11.2 A pillar tap can be used at:
• Sinks/Kitchen
• Baths/Bathroom/En-suite
• Basins/Bathroom/En-suite
ANY TWO OF THE ABOVE (2)
4.12 4.12.1 Water meter (1)
4.12.2 Full way valve/Stop cock
To shut off the water supply (2)
4.12.3 Bibcock/Bib tap/Garden tap (1)
4.12.4 No reaction will take place/No (1)
4.12.5 Dezincification (1)
4.13 Water saving devices:
• Sensor taps
• Demand pillar taps
• Metered taps
ANY TWO OF THE ABOVE (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 11 DBE/November 2019
NSC – Marking Guidelines
4.14 Pressure control valve reduces/control the incoming water pressure to a
building. (1)
Temperature and pressure safety valve will reduce/relieve pressure in a hot
water system in case of excessive pressure building up in the geyser. (1)
[40]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 12 DBE/November 2019
NSC – Marking Guidelines
QUESTION 5: GRAPHICS AS MEANS OF COMMUNICATION, ROOF WORK AND
STORM WATER (SPECIFIC)
5.1 5.1.1
ORTHOGRAPHIC VIEWS WILL
Correctness – 4 marks ALSO BE ACCEPTED - ONLY 2
MARKS (4)
5.1.2 Fascia board/Rafter (1)
5.2 5.2.1 Surface channel (1)
5.2.2 Rainwater shoe/Concrete shoe (1)
5.2.3 Road kerb/Kerb (1)
5.2.4 Flashing (1)
5.3 Municipality/Local Government/Local Authorities. (1)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 13 DBE/November 2019
NSC – Marking Guidelines
5.4
4
6
4
5
5
5 4
3 3
5
1 1 5 4
2
6
4
DRAWING IS NOT
A ACCORDING TO SCALE
2 USE A MASK TO MARK THIS
QUESTION
2 2
NO. ASSESSMENT MARK
CRITERIA
1 Projection lines to determine the apex 2
2 Determine true length 4
ANY ALTERNATIVE METHOD 3 Top and bottom arc of pyramid 2
TO OBTAIN TRUE LENGTH 4 Development of base of pyramid 5
WILL BE ACCEPTED 5 Development of top of pyramid 5
6 3 mm seams 2
TOTAL: 20 (20)
[30]
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 14 DBE/November 2019
NSC – Marking Guidelines
QUESTION 6: SEWERAGE, SANITARY FITTINGS AND JOINING (SPECIFIC)
6.1 6.1.1 D (1)
6.1.2 A (1)
6.1.3 D (1)
6.1.4 B (1)
6.1.5 C (1)
6.2 ASSESSMENT MARK
CRITERIA
Solder 1
Plates 1
Cover strip 1
TOTAL: 3 (3)
6.3 DRAINAGE ABOVE GROUND DRAINAGE BELOW GROUND
6.3.1 OR Water meter OR 6.3.2 OR Sewerage line OR
6.3.4 OR Washbasin OR 6.3.3 OR Inspection eye OR
IE
(4)
6.4 6.4.1 135° (1)
6.4.2 The purpose of the inspection eye is to gain access to the sewer
pipe to:
• inspect it.
• clear blockages/allow for cleaning.
ANY ONE OF THE ABOVE (1)
6.5 Fittings in a drainage system should:
• be made of material that is suitable for the piping.
• remain watertight under normal working conditions.
• be able to withstand internal water pressure of 50 kPa and external
pressure of 30 kPa without leaking.
ANY TWO OF THE ABOVE (2)
6.6 • Ventilation pipes/Vent pipe
• Vent valves (2)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 15 DBE/November 2019
NSC – Marking Guidelines
6.7 Septic tanks:
• Must be cleaned when the sludge level rises above the outlet and
starts flowing out.
• Soil water is discharged into a French drain. (2)
Vacuum tanks:
• Must be emptied when it reaches its maximum capacity.
• Must be cleaned more regularly than a septic tank.
• Sewage is stored until it is pumped out by the local municipality.
ANY TWO OF THE ABOVE (2)
6.8
H OR C H C
OR
H C
M
OR
H C
H C
ASSESSMENT CRITERIA MARK
Cold water inlet 1
Hot water inlet 1
Cold water tap (NO mixer taps) 1
Hot water tap (NO mixer taps) 1
Flow direction on mixed pipe 1
TOTAL: 5 (5)
Copyright reserved Please turn over
Downloaded from hlayiso.com
Civil Technology: Civil Services 16 DBE/November 2019
NSC – Marking Guidelines
RE
6.9 RE
VP
GRANNY
FLAT
PART OF
HOUSE
1:40 /1:60
FIGURE 6.9
ABREVIATIONS ALSO ACCEPTED IN THE PLACE OF THE SYMBOL
A MAXIMUM OF 2 MARKS WILL BE AWARDED IF THE WRONG LINE
TYPES ARE USED FOR THE BRANCH PIPES.
ASSESSMENT MARK
CRITERIA
BRANCH PIPES 3
VENT PIPE 1
GULLEY’S 2
JUNCTION OF TWO
1
MAIN SEWER PIPES
RODDING EYES 2
INSPECTION EYES 3
GRADIENT 1
TOTAL: 13 (13)
[40]
TOTAL: 200
Copyright reserved
Study this subject
Recommended for this subject
%20Memo%20Afr_hlayiso.com_--13c03cd5-cfa4-42cf-9a7c-5d7b0e1069f0/v1-b52b9528a267b4d4a925/card.webp)
Memorandum
Civil Technology Grade 12 NSC November 2019 Memo (Afrikaans)
%20Eng_hlayiso.com_--b6e1822a-1416-45e5-97a8-13da0db177cd/v1-eeb0408976bd747bcb1f/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2019 QP (Eng)
%20Eng_hlayiso.com_--52c5e936-0c5c-4ea4-8929-a76fdaa48f02/v1-dee98d56b9368d5925f1/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2019 QP (Eng)
%20Afr_hlayiso.com_--560716c2-e3ed-412e-90e8-42d36162ee0d/v1-41dc402fc627c1a9afd9/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2019 QP (Afr)
%20Afr_hlayiso.com_--1a837a2b-2575-4096-939a-dd10f12a0bf9/v1-5a0c458a76489c046ea7/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2019 QP (Afr)
%20Memo%20Afr_hlayiso.com_--2a9b9e1b-37dc-48dc-9aa7-67dd5fa19a10/v1-8a03885eb99c8043e8b1/card.webp)
Memorandum
Civil Technology Grade 12 NSC June 2019 Memo (Afrikaans)
More from Grade 12 Civil Technology

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2025 QP (Eng)
%20(English%20and%20Afrikaans)%20June%202025%20Question%20Paper--c8edd459-5237-48e0-8588-69d7ecd7f8e5/v1-be996aaed91bf782e098/card.webp)
Question paper
Civil Technology Grade 12 Gauteng June 2025 QP (Afr)
%20Afr--591d6ffd-20b1-4748-a1ba-b055be0a14c3/v1-4d98a131fd37e013458a/card.webp)
Question paper
Civil Technology Grade 12 NSC June 2025 Question Paper (Afr)
%20Afr--05a95faf-5891-4d88-9e5e-7d13c1d21648/v1-f5ca67113376f7457b83/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2025 QP (Afr)

Question paper
Civil Technology Grade 12 Eastern Cape Prelim 2024 QP (Afr)

Question paper
