Downloaded from hlayiso.com GRAAD 12 NATIONAL SENIOR CERTIFICATE GRADE 12 CIVIL TECHNOLOGY: CONSTRUCTION NOVEMBER 2018 MARKING GUIDELINES MARKS: 200 These marking guidelines consist of 18 pages. Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 2 hlayiso.com DBE/ November 2018 NSC – Marking Guidelines QUESTION 1: OHSA, MATERIALS, TOOLS, EQUIPMENT AND JOINING (GENERIC) 1.1 1.1.1 F (1) 1.1.2 A (1) 1.1.3 G (1) 1.1.4 E (1) 1.1.5 B (1) 1.2 • Do not throw any tools or materials from a scaffold.  • Never jump on to and off a scaffold.  • Never overload a scaffold. • Remove or cover sharp edges or corners. • Always attach free-standing scaffoldings to a building. • Use a ladder to get on and off a scaffold. • Keep free of waste or any other obstruction. • Never jump on a scaffold while working on it. • Responsible/qualified person must ensure that scaffolding is safe, rigid, stable and firm or has no defects. • Scaffold must be supplied with guard rails/toe boards. • Scaffolds must be levelled on uneven ground. • Do not work on a scaffold in bad weather. • Wear a safety harness when working on scaffolding. • Do not throw tools on/off a scaffold. ANY TWO OF THE ABOVE (2) 1.3 • It prevents workers from falling off the scaffold.  • It is used as a handrail.  • It is used to strap on safety harnesses. • To protect the worker working on the scaffold. ANY TWO OF THE ABOVE (2) 1.4 • The primary purpose of painting is to protect metals, wood and other material against corrosion and decay.  • Provides a decorative/aesthetic appearance/finishing.  • Protects surfaces from moisture penetration. • Protects surfaces from rust/uv rays. ANY TWO OF THE ABOVE (2) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 3 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 1.5 The curing of concrete: • Increases the strength of concrete.  • Decreases the permeability of hardened concrete. • Improves durability of concrete by reducing cracks. • Makes concrete more watertight. • Minimises shrinkage cracks in concrete. • Provides volume stability. • Cured concrete can carry more weight without breaking/crumbling than uncured concrete. • Prevents rapid drying of concrete. • Curing ensures that the hydration process continues. ANY ONE OF THE ABOVE (1) 1.6 1.6.1 Multi detector  (1) 1.6.2 Tool A is used: • to detect materials found in/behind walls, ceilings and underneath floors, including ferrous and non-ferrous metals, electrical wiring, wood and metal studs.  • to locate steel bars and copper pipes.  • in carpentry, plumbing, and construction. • to measure the distance to/from covered objects. ANY TWO OF THE ABOVE (2) 1.6.3 The batteries must be removed from the tool: • to prevent the battery from running flat/battery can die.  • to prevent acid leaks from batteries damaging the tool. ANY ONE OF THE ABOVE (1) 1.7 1.7.1 A – Bolt and nut/Bolt  B – Rawl bolt  (2) 1.7.2 Bolt and nut • Bolts and nuts are used to secure pipe supports to metal parts.  • To join components together. Rawl bolt • A Rawl bolt is used to fix a truss hanger to a wall.  • To fix brackets/structures/panels to a wall/concrete. • For construction, renovation and industrial work ANY TWO OF THE ABOVE (2) [20] Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 4 hlayiso.com DBE/November 2018 NSC – Marking Guidelines QUESTION 2: GRAPHICS AS METHOD OF COMMUNICATION (GENERIC) ANSWER SHEET 2 NO. QUESTIONS ANSWERS MARKS 1 Identify FIGURE A. South Elevation/Elevation  1 2 Identify FIGURE B. Ground floor plan/floorplan  1 First floor level/Second floor 3 Identify number 4. level/Suspended floor/Floor level/ 1 dash line/ FFL/Expansion joint  4 Identify number 5. Window Sill  1 Hand wash basin/Wash 5 Identify number 9. 1 basin/Washing basin/HWB/basin  6 Identify number 10. Water closet/WC/Toilet pan  1 7 Identify number 11. Bath/B  1 8 On what date was the plan printed? 2018/10/02  1 9 Who drew the building plan? JP Maloi  1 Name the feature in the column for the 10 notes in FIGURE 2 that must be Ramp  1 installed in front of the sliding door. Name the feature in the column for the 11 notes in FIGURE 2 that must give 1 Staircase/Stairs/Stairway access to the first floor. Identify the type of roof that is used for 12 Gable roof  1 the building in FIGURE A. To cover the opening/close the gap between the two slopes of the roof.  13 Explain the purpose of number 1. Prevent water and other elements 1 from entering the roof. ANY ONE OF THE ABOVE Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 5 hlayiso.com DBE/November 2018 NSC – Marking Guidelines • To prevent water from falling onto the ground  • To collect rainwater • To channel the rainwater into the downpipe 14 Explain the purpose of number 2. • To protect the wall from water 1 • To hide the rafters/finish off the roof ANY ONE OF THE ABOVE Explain the abbreviation FFL at 15 Finished floor level  1 number 6. To channel the water from the gutter 16 Explain the purpose of number 7. 1 to the ground.  Explain the meaning of the arrow on It indicates the direction of the slope 17 the feature that must be installed in 1 of the ramp/it indicates the slope.  front of the sliding door. It indicates the slope or the gradient Explain what is meant by 1:10 of the ramp/for every 10 metres 18 1 indicated on the symbol in the notes. horizontally rises 1 metre vertically. 19 Which room will feature 15 serve? The bathroom.  1 • Indicates what direction the window is opening/window opening.  • Indicates the location of the Explain the short dash lines on the hinges. 20 1 windows. • Indicates the location of the casement stay. ANY ONE OF THE ABOVE Deduce the height of window 2 from 21 1,2 m or 1 200 mm (Ignore units) 1 the window schedule. Deduce the width of window 3 from 22 2 m or 2 000 mm (Ignore units) 1 the window schedule. On what elevation of the building is 23 Western elevation/Western side  1 the bathroom window situated? Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 6 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 3 – window/window frame/reveal frame stile/casement stile  Differentiate between component 24 2 number 3 and component number 8. 8 – sliding door /door frame/ door/reveal /sliding door stile  The light in the lounge is a fluorescent light/1 x 40W/2x40/3x40 Differentiate between the light in the 25 fluorescent light  and the light in 2 lounge and the light in the bathroom. the bathroom is a normal ceiling light  Tile/ Vinyl flooring (Novilon)/ Coloured screed/Polished or stained Recommend a suitable floor covering concrete flooring/Water proof 26 1 for the bathroom. laminated floor/carpet.  ANY ACCEPTABLE ANSWER Recommend an appropriate scale to 27 which FIGURE A should be drawn, 1:50/100/200  1 according to SANS. Recommend an alternative sanitary 28 fitment to replace number 11 that will Shower  1 serve a similar purpose. Calculate the internal area of the office 4 m  x 3 m  = 12 m²  OR 12 29 3 in m² Show ALL calculations. 4 000 X 3 000 = 12 000 000mm2 Positive marking (220 + 3 000 + 110 + 2 800 + 220)  x 2  = 6 350 x 2 =12 700 mm  Calculate the perimeter of the building. (220 + 4 000 + 110 + 2 000 + 220)  x 2  30 = 6 550 x 2 7 Show ALL calculations. = 13 100 mm  12 700 + 13 100 mm = 25 800 mm  OR = 25,8 m TOTAL 40 Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 7 hlayiso.com DBE/November 2018 NSC – Marking Guidelines QUESTION 3: ROOFS, STAIRCASES AND JOINING (SPECIFIC) 3.1 5°/10/30°  (1) 3.2 1 400 mm  (1) 3.3  (Square) (Rectangular) Batten  Purlin ANY ONE OF THE ABOVE (2) 3.4 50 mm x 76 mm/ 76 mm x 50 mm  OR 76 mm x 76 mm (1) 3.5 Clay roof tiles Fibre cement tiles (2) 650 mm/closer together  760 mm/ further apart  3.6 A - Ridge capping/Ridge plate/Roof capping  B - Roof covering/Corrugated iron roof/IBR iron roof/roof sheeting  C - Gang nail/Nail plate/Connector plate/Joining piece  D - King post  (4) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 8 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 3.7       2 800 mm   ASSESSMENT CRITERIA MARK CANDIDATE'S MARK Walls 2 Wall plates (Wrong position – 1 mark) 2 Rafters 2 Collar beam/Collar tie 1 Ridge beam correctly drawn 1 TOTAL: 8 (8) 3.8 3.8.1 Riser  (1) 3.8.2 Balusters  (1) 3.8.3 Going/Tread  (1) 3.8.4 Landing  (1) 3.8.5 Run  (1) 3.9   AND OR (2) ANY TWO OF THE ABOVE OR ANY OTHER SHAPE RESEMBLING A SQUARE OR ROUND SHAPE/ 2 AND 3 DIMENSIONAL DRAWINGS ACCEPTABLE Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 9 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 3.10 • Screwed on to the face of the wall.  • By means of a bracket. • Fixed to face of wall using Rawl bolts or sleeved anchors by means of a bracket. ANY ONE OF THE ABOVE (1) 3.11 • Timber that is bolted to the top of the wall. • Nailed or screwed to the wall.  • A galvanised strap/hoop iron nailed or built into the wall. • Tie with roof wire built into wall. ANY TWO OF THE ABOVE (2) 3.12 • Supports the steel and withstands the loads.  • The pin serves as a pivoting point to adjust the angle or to lower the steel section. • The pin can be removed to separate the steel section from the base. • To keep the steel section attached to the base plate/concrete base. ANY ONE OF THE ABOVE (1) [30] Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 10 hlayiso.com DBE/November 2018 NSC – Marking Guidelines QUESTION 4: EXCAVATIONS, FORMWORK, TOOLS AND EQUIPMENT AND MATERIALS (SPECIFIC) 4.1 4.1.1 C  4.1.2 D  4.1.3 F  4.1.4 E  4.1.5 A  (5) 4.2.1 • Keep excavated soil away from edge at least 600 mm.  • Identify any equipment that will affect trench stability.  • Trenches should be inspected at the start of each shift.  • Trenches should be inspected after a rain storm. • No worker will be allowed to work or move in trenches deeper then 1,5 metres if the sides are not protected by formwork or braced. • Test for atmospheric hazards (low oxygen, hazardous fumes and toxic gases) when trenches are more than 1,3 metres deep. • No load vehicle or plant equipment should be used, placed driven or used on or near the edge of any excavation where it is likely to cause a collapse and endanger workers lives. • A warning system for mobile equipment should be provided. • Always protect workers from loose rock or soil that could fall or roll from an excavation by installing protective barricades at appropriate intervals. • Prohibit workers from working on faces of slopes or benched excavations at levels above other workers, unless workers at a lower level is protected against hazards of falling or sliding material or equipment. • Members/parts of the support system (formwork or shuttering) should be securely connected to prevent sliding, falling material. • Avoid overloading members of support systems. • Formwork/shuttering should be removed in a manner that will protect workers from cave-ins. • Before temporary removal of individual formwork members/parts, additional precautions should be in place, installing other structural members. • Backfilling should always progress with the removal of the support system (formwork from the excavation). • The area should be cordoned off and warning signs must be posted and must be clearly visible. • Cover the entire work area after hours, especially if children might gain entry to the site. • A suitable barrier(fence) must be provided where any excavation is more than 2 metres deep. • Excavation sites should be well lit at night. • Red warning lights should be placed strategically to warn the public. • Workers should not work under suspended or raised loads of materials. • Always start dismantling the formwork from the bottom of the formwork. • Never work alone in deep excavations. ANY THREE OF THE ABOVE (3) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 11 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 4.2.2 • The site must be levelled.  • The site must be cleared properly, and all loose soil must be removed. • A baseline must be established.  (3) 4.3   Poling boards  Folding wedges  Struts  Walling boards   Wedge pair also accepted Shuttering correctly drawn  ASSESSMENT CRITERIA MARK CANDIDATE'S MARK Folding wedges 1 Walling boards 1 Poling boards 2 Struts 1 Shuttering correctly drawn 1 Any TWO labels 2 TOTAL: 8 (8) 4.4 Good formwork should be: • made accurately to the dimensions.  • stable enough to bear the load of wet concrete. • bear the mass of workers on it. • able to withstand the vibrating and tamping of concrete. • strong enough to provide enough support, without too much deflection, until the concrete has set and cured. • easy to repair on site. • secured with wire nails so that it can be easily dismantled. • secured with bolts and nuts ranging from 13 mm to 19 mm in diameter. • should be sealed properly. • should be free of dirt such as saw dust. • quick and simple to erect to ensure the correct cover depth for the reinforcing. • removed only when concrete has cured. • close-fittings along seams and joints. • made of recyclable components. • fitted with plywood laggings for a smooth finish. • ensure the correct cover depth for the reinforcing in order to prevent structural failure. • sealed properly so that the concrete does not leak and form a honeycomb effect. ANY ONE OF THE ABOVE (1) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 12 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 4.5 4.5.1 Beam formwork/Formwork for beams (1) 4.5.2 A - Tie 50 mm x 25 mm at 600 mm centres  B - Cleat 76 mm x 50 mm  C - Fixing plate/Kicker plate 76 mm x 50 mm  D - Brace/Strut 76 mm x 25 mm  (4) 4.5.3 • The shape of folding wedges simplifies the erecting and dismantling of formwork.  • Folding wedges can easily be removed by knocking one away from the other. • Folding wedges help to keep formwork components sturdy/secured/stable. • Folding wedges play an important role in the levelling of formwork for beams, floor slabs and columns. • Folding wedges facilitate the raising or lowering of the formwork to the required height. • Folding wedges are used as pins to strengthen adjoining concrete formwork (1) ANY ONE OF THE ABOVE 4.6 • Sturdy/Rigid enough to bear the mass of wet concrete without collapsing. • Stronger than wood and timber board products.  • Easily removed when the concrete has set. • Not as adaptable as timber shuttering. • More expensive than timber. • Will last longer than timber. • Can be used repeatedly. • Tight along the seams and joints so that concrete does not leak. • It’s prone to rust. (2) ANY TWO OF THE ABOVE 4.7 4.7.1 • Operate with care and wear appropriate personal protective equipment.  • Check the controls for proper response before use. • Check the condition of the machine at the start and end of each shift. • Never use a faulty machine. • Never lay the machine on its side. • Do not allow the vibrating pipe to make contact with any part of the body or formwork. • Switch of the machine when it is left unattended. • Long use of the machine exposes the operator to vibrations. Stop if you feel numbness. • Switch off the machine and wait for all moving parts to stop before adjusting, repairing, inspecting or cleaning it. • Must be operated by a qualified person. (2) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 13 hlayiso.com DBE/November 2018 NSC – Marking Guidelines ANY TWO OF THE ABOVE 4.7.2 • Maintain like all machinery. Lubricate and adjust according to the manufacturer’s instruction.  • Clean after use and store in a safe dry place.  • Service the concrete vibrator regularly. • Repair or replace damaged electric cords. (2) ANY TWO OF THE ABOVE 4.8 • Service the tamping rammer/plate compactor regularly.  • Remove loose dirt and soil after use.  • Maintain like all machinery, lubricate and adjust according to the manufacturers instruction. • Clean after use. • Store in a safe dry place. • Ensure that all parts are firmly attached to the machine. • Repair or replace damaged electric cords. (2) ANY TWO OF THE ABOVE 4.9 Ready-mix concrete: • is very expensive.  • delivery and pouring delays may affect the quality of the concrete.  • site batching in residential areas raises concerns about noise levels • must be poured within a specified time. • trucks may damage or soil house frontages and sidewalks. • contaminations of storm-water drains. ANY TWO OF THE ABOVE (2) 4.10 The purpose of the slump test: • is to test the density of the concrete before it is placed by determining the percentage of water it contains.  • Is to determine the workability and consistency of the batches that are mixed.  • To determine the slump of the mixture. ANY TWO OF THE ABOVE (2) 4.11 • Water – hosepipe or continuous spraying  • Water- retaining substances, such as damp sand, damp sacking, straw, hessian and canvas.  • Plastic membranes and plastic sheeting • Chemical curing products ANY TWO OF THE ABOVE (2) [40] Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 14 hlayiso.com DBE/November 2018 NSC – Marking Guidelines QUESTION 5: PLASTER AND SCREED, BRICKWORK AND GRAPHICS AS MEANS OF COMMUNICATION (SPECIFIC) 5.1 5.1.1 A - Wet the wall thoroughly  B - Apply plaster  C - Scrape the plaster to obtain a flat surface/levelling  D - Float to smooth the surface  (4) 5.1.2 Straight edge  (1) 5.2          LEFT VIEW INCORRECTLY DRAWN -1 CRITERIA ASSESSMENT MARK CANDIDATE'S MARK Full bricks and ½ brick every alternate course 4 on front view Left view full brick every course 1 Left view ¼ brick every course 1 TOTAL: 6 (6) 5.3 5.3.1 A- Herring bone paving pattern  B- Basket-weave paving pattern  (2) 5.3.2 • Dry-laid or sand-set  • Bitumen-set • Mortar-set ANY ONE OF THE ABOVE (1) 5.3.3 • River/Plaster sand is used to grout between paving bricks. • Sand mixed with cement is used to grout between paving bricks  ANY ONE OF THE ABOVE (1) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 15 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 5.4 ROOF COVERING  PURLIN 76 X 50     RAFTER 114 X 38  BEAM FILLING  TIE BEAM 114 X 38  WALL PLATE 114 X 38  WALL   FASCIA BOARD 230 X 30 SCALE: 1:10  NOT DRAWN TO SCALE APPLICATION OF SCALE   USE A MASK TO MARK THIS QUESTION ACCEPT ANY ANGLE BETWEEN 30° AND 45°. ASSESSMENT CRITERIA MARK CANDIDATE'S MARK Wall: 220 mm wide face brick 1 Beam filling 1 Wall plate 114 mm x 38 mm 1 Tie beam 114 mm x 38 mm 1 Rafter 114 mm x 38 mm 1 Purlins 76 mm x 50 mm 2 Corrugated iron roof covering 1 Fascia board 230 mm x 38 mm 1 Any TWO labels 2 Print the scale below the drawing 1 Application of scale One or two incorrect =3 Three or four incorrect =2 3 More than five incorrect =1 No measurement correct =0 TOTAL 15 (15) [30] Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 16 hlayiso.com DBE/November 2018 NSC – Marking Guidelines QUESTION 6: REINFORCEMENT IN CONCRETE, FOUNDATIONS, CONCRETE FLOOR AND QUANTITIES (SPECIFIC) 6.1 6.1.1 B (1) 6.1.2 D (1) 6.1.3 D (1) 6.1.4 B (1) 6.1.5 A (1) 6.2 Minimum concrete cover     Stirrups  Main bars     Proportion  ASSESSMENT CRITERIA MARK CANDIDATE'S MARK Column 2 8 Main bars 2 Binders/Stirrups 2 Min concrete cover 1 Any TWO Labels 2 Proportion 1 TOTAL 10 (10) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 17 hlayiso.com DBE/November 2018 NSC – Marking Guidelines 6.3 Pile foundations: • can be used in poor/unstable/soft/loose soil.  • can be used anywhere even in water.  • the larger base ensures stability.  • is relatively quick to install if the equipment is available. • where pre-fabricated piles are used, much time is saved. • resists tensile stress well. • is quick and less expensive to produce. • can be manufactured and transported elsewhere. • can be installed in poor weather conditions. • the length can easily be adjusted. • offers good resistance against moving soil. ANY THREE OF THE ABOVE (3) 6.4 • Metal pipes that contain a dry concrete mix (gravel plug) are driven into a drilled hole in the ground.  • The pipe is held firmly in position while a drop hammer is used to drive the pre-filled dry concrete mix (gravel plug) out of the pipe to form an extended base (toe) at the bottom of the hole.  • Concrete is now poured into the pipe and compacted, using an internal drop hammer, until the pipe is filled to the top.  • The steel pipe is slowly extracted as the concrete is poured into the pipe. ANY THREE OF THE ABOVE (3) 6.5 6.5.1 Hollow-core concrete block/Concrete block/Block  (1) 6.5.2 • Used for the placement of the conduit pipes.  • Serves as insulation. • Reduce the weight. ANY ONE OF THE ABOVE (1) 6.5.3 Reinforced ribs/Ribs/Pre-stressed concrete ribs  (1) 6.5.4 • Ribs (pre-stressed reinforced ribs)  • Hollow-core blocks (polystyrene blocks can also be used)  • Steel mat/Mesh/Steel/Reinforcement  • In-situ cast concrete/Concrete • Spacers ANY THREE OF THE ABOVE (3) Copyright reserved Please turn over
Downloaded from Civil Technology: Construction 18 hlayiso.com DBE/ November 2018 NSC – Marking Guidelines 6.5.5 After the installation of a rib-and-block floor: • Ensure that the correct curing procedure is followed for 7 days to ensure a well-set slab.  • allow 28 days for setting of the concrete slab. • temporary props can be removed after the concrete slab has reached a crushing strength of 17 MPa. ANY ONE OF THE ABOVE (1) 6.5.6 • Because the units are precast, mechanical handling is required on site.  • The placing of the blocks between the ribs requires manual labour.  (2) 6.6 ANSWER SHEET 6.6 A B C D Skirting: Inside length of building = 8 000 mm – 440 mm  OR – 2(220) = 7 560 mm  (2) Skirting: Inside width of the building = 5 000 mm – 440 mm  OR – 2(220) = 4 560 mm  (2) Total length = 7 560 + 4 560 x 2 =12,12 x 2 = 24,24  meter skirting needed – 0,900 m for the door. = 23,34 m  (2) 1/ Screed: Inside area of building 7,56  4,56  0,025  0,86 m³  = 0,86 m³ screed is needed (4) (10) [40] TOTAL: 200 Copyright reserved
