2 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
QUESTION 1: SAFETY AND MATERIALS (GENERIC)
1.1 The purpose of the OHS Act is to ensure the health of the workers or their right
to a working environment free of hazards. (1)
1.2 Unsafe acts (1) and unsafe conditions (1). (2)
1.3 Any ONE reason for inspecting a scaffold:
• To ensure it is stable in all directions
• To ensure it is able to carry the mass of the load
• To ensure it is free of any defects (1 x 1) (1)
1.4 1.4.1 A – Guardrail
B – Kickboard OR toe-board
C – Base (3 x 1) (3)
1.4.2 Independent scaffolding (1)
1.4.3 1 m OR 1 000 mm (1)
1.5 1.5.1 Any ONE way to transport waste material from higher levels:
• Chute
• Conveyor belt
• Lift OR hoist (1 x 1) (1)
1.5.2 Safety net OR a catch platform (1)
1.6 1.6.1 False (1)
1.6.2 True (1)
1.6.3 False (1)
1.6.4 False (1)
1.7 Water-based paint (1) and oil-based paint (1) (2 x 1) (2)
1.8 It protects the metal against rust/corrosion. (1)
1.9 Any TWO advantages of curing (concrete):
• Allow adhesive bonding
• Prevent the concrete from drying out too quickly
• Assures the effective hardening of the concrete (2 x 1) (2)
[20]
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 3
QUESTION 2: GRAPHICS, JOINING AND EQUIPMENT (GENERIC)
2.1 • Window numbers
• Door swings
• Names of rooms
• Stair directions
• Sliding doors
• Floor covering (6 x 1) (6)
2.2 FIGURE 2.2 on ANSWER SHEET A shows the incomplete elevation of a
building.
Complete the elevation by drawing in the following parts on scale 1 : 50.
2.2.1 A window with a length of 1 800 mm and a height of 900 mm.
The window is built in 700 mm from the right-hand side and one third of the
right side of the window can open. (7)
2.2.2 A door according to standard measurements, 900 mm from the left-hand
side of the building. The door opens to the left. There is one step to the
ground level. (5)
2.2.3 The barge board against the gable end. (2)
2.3 2.3.1 Unfinished wood (1)
2.3.2 Two-way switch (1)
2.4 2.4.1 Water meter
(2)
2.4.2 Plaster
(2)
2.4.3 Invert level
(2)
2.5 When driven into place (1) it cannot be turned (1). (2)
2.6 R-RBL – Anchor name
M06 – Thread diameter
18 – Thickness (3 x 1) (3)
Copyright reserved Please turn over
4 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
2.7 To set the telescope of the instrument level. (1)
2.8 A – Vertical hair
B – Horizontal hair
C – Stage hairs (3 x 1) (3)
2.9 Any TWO uses:
• Determine differences between levels and vertical heights
• Determine slopes
• Setting out buildings
• Transfer of levels and heights (2 x 1) (2)
2.8 It can affect the measuring function of the tool. (1)
[40]
TOTAL SECTION A: 60
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 5
QUESTION 3: CASEMENT, CUPBOARDS, WALL-PANELLING AND
QUANTITIES (SPECIFIC)
3.1 3.1.1 Mullion ✓ (1)
3.1.2 Fanlight ✓ (1)
3.1.3 Drip groove ✓ (1)
3.1.4 Transom ✓ (1)
3.1.5 Tongue and groove ✓ (1)
3.2 3.2.1 A – Wood / Timber ✓ (1)
B – Glass / Perspex ✓ (1)
3.2.2 To hold glass or window pane in its place. (1)
3.3 3.3.1 D – Shelves ✓ (1)
E – Drawer ✓ (1)
3.3.2 Free-standing cupboard: Can be moved around to change the
appearance of a room. ✓ (1)
Built-in-cupboard: Fastened against the wall. ✓ (1)
3.3.3 520 mm – 570 mm ✓ (1)
3.3.4 They provide additional storage space in the top unit. (1)
3.3.5 Any TWO below: (Melamine instead of Chipboard)
• Waterproof ✓
• Easy to clean ✓
• More durable
• Has a smooth finish
• Enhance the appearance (2 x 1) (2)
3.4 See ANSWER SHEET B. (5)
3.5 See ANSWER SHEET C. (9)
[30]
Copyright reserved Please turn over
6 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
QUESTION 4: ROOFS, CEILINGS, TOOLS AND EQUIPMENT AND MATERIALS
(SPECIFIC)
4.1 4.1.1 C ✓ (1)
4.1.2 E ✓ (1)
4.1.3 D ✓ (1)
4.1.4 B ✓ (1)
4.1.5 F ✓ (1)
4.2 4.2.1 B – Purlin ✓
D – Valley ✓ (2 x 1) (2)
4.2.2 It is a roof with two slanting ends, sometimes across a short, flat gable. ✓ (1)
4.2.3 Prevent dirt / dust / insects / rain from entering into the roof space. ✓✓ (2)
4.2.4 Allow rain water to be directed into the gutter. ✓ (1)
4.2.5 HIPPED ROOF GABLE ROOF
MATERIAL - More timber is used - Less timber is used
because of complex because of simple
design design
- More roof covering is - Less roof covering
used is used
- More cutting and - Less cutting and
waste waste
Any ONE (1) Any ONE (1)
CONSTRUCTION - Construction is - Design is simple
complex - Roof is not strong
- Roof is stronger because less
- Roof takes longer to timber is used
construct - Roof is constructed
- Slopes down in all fast
sides - Slopes down in two
sides
Any ONE (1) Any ONE (1) (4)
4.3 Any TWO purposes of roof underlay:
• Allows rain that is blown in under the tiles to flow to the gutter ✓
• Acts as a thermal barrier by providing insulation ✓
• Provides effective barrier against wind driven rain and dust
• Reduces the risk of wind lifting the tiles (2 x 1) (2)
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 7
4.4 Step 1 – Sand the wood with different grades of sand paper. ✓
Step 2 – Sand until the wood is smooth and free from scratches. ✓
Step 3 – Remove dust ✓ (3 x 1) (3)
4.5 Any TWO:
• Good roof covering should resist weather conditions such as wind and
rain ✓
• Looks durable and enhance the appearance of the building ✓
• Be fire resistance
• Provides insulation against heat and cold (2 x 1) (2)
4.6 • Timber framework ✓
• Panel ✓
• Cover strips ✓ (3 x 1) (3)
4.7 Hurricane clips:
Any ONE:
• To fix purlins to rafters ✓
• To fix trusses to wall plate
• Used at eaves overhangs
• Where members of trusses meet at 90⁰
• To fix opposite faces of members (1 x 1) (1)
Storm clips:
Any ONE:
• To secure roof tiles to the brandering ✓
• To fasten ridge tiles to each other
• To prevent tiles from being lifted by strong winds
• To fasten ceiling tiles (1 x 1) (1)
4.8 4.8.1 Portable electric plane ✓ (1)
4.8.2 Any TWO:
• Safety goggles ✓
• Dust mask ✓
• Respiratory mask (2 x 1) (2)
4.8.3 Any TWO:
• Store in a safe dry place ✓
• Wooden or plastic box away from moisture ✓
• Place on its side to prevent damage from the blade
• Retract the blade (2 x 1) (2)
4.8.4 Any TWO:
• Check timber for loose knots ✓
• Check for sand ✓
• Check nails (2 x 1) (2)
Copyright reserved Please turn over
8 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
4.9 4.9.1 Any THREE below or any similar answer:
• Avoid making adjustments while the blade is turning ✓
• Keep your fingers away from the rotating blade ✓
• Ensure that all clamps and locking devices are locked ✓
• Check the wood for loose knots/nails/screws
• Ensure that the blade is properly fastened (3 x 1) (3)
4.9.2 Any TWO:
• Check the wood for any metal objects before cutting
commences ✓
• Make sure that the teeth of the blade are sharp ✓
• Ensure that the blade is properly fastened
• Do not force the material on the blade (2 x 1) (2)
4.10 Letter – Grading method ✓ (1)
Number – Strength ✓ (1)
[40]
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 9
QUESTION 5: CENTERING, FORMWORK, SHORING AND GRAPHICS AS
MEANS OF COMMUNICATION (SPECIFIC)
5.1 A – Concrete / Concrete beam ✓ (1)
B – Brace / Strut ✓ (1)
C – Prop / Adjustable prop ✓ (1)
D – Sole plate ✓ (1)
5.2 Any TWO:
• Block board ✓
• Shutter board ✓
• Laminated board
• Plywood
• Hardboard / Masonite (2 x 1) (2)
5.3 5.3.1 Tie – To make formwork sides sturdy. ✓ (1)
5.3.2 Fish plate – To strengthen the fixing between the prop and the
bearer / head tree. ✓ (1)
5.4 Any ONE:
• It has to support the weight of fresh concrete ✓
• It supports more weight. (1 x 1) (1)
5.5 5.5.1 Any ONE:
Double flying shore:
• Provides temporary support where one or both walls show signs
of failure. ✓
• It gives temporary support to two parallel defective walls that are
located between 9 to 15 metres apart. (1 x 1) (1)
5.5.2 Any ONE:
Dead shore:
• Support existing walls when new or large openings are to be cut
into the existing wall.
• Wall on the lower level is defective and underpinning is needed
during restoration of the wall.
• Support structure / transfer the weight of the structure to firm
ground during structural renovations. (1 x 1) (1)
Copyright reserved Please turn over
10 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
5.6 5.6.1 Any ONE:
• Spread the weight transferred by the props over a wider area ✓
• Prevent the props from sinking into the ground
• Provide a level area where props rest on (1 x 1) (1)
5.6.2 To strengthen or brace the floor and ceiling. ✓ (1)
5.6.3 Secure the joint between prop and the needle. ✓ (1)
5.7 45° ✓ (1)
5.8 5.8.1 A – Ribs ✓
B – Bearer ✓
C – Folding wedges ✓
D – Prop ✓ (4 x 1) (4)
5.8.2 The top part of the ribs is formed to look exactly like the soffit of the
arch. ✓ (1)
5.8.3 Any TWO:
• Support the centre/ construction above ✓
• Raise or lower the centre to the required height ✓
• Facilitate the removal of the centre after completion of the arch
(2 x 1) (2)
5.8.4 To support the centre/ construction above. ✓ (1)
5.9 See ANSWER SHEET D. (7)
[30]
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 11
QUESTION 6: SUSPENDED TIMBER FLOORS, STAIRCASES, IRONMONGERY,
DOORS AND JOINING (SPECIFIC)
6.1 6.1.1 B✓ (1)
6.1.2 D✓ (1)
6.1.3 C✓ (1)
6.1.4 A✓ (1)
6.1.5 C✓ (1)
6.2 6.2.1 A – Wall plate ✓ (1)
B – Floor joist ✓ (1)
C – Brick pier ✓ (1)
D – Bearer ✓ (1)
6.2.2 Concrete base must be wider than the brick pier in order to distribute
the load (1) imposed on it to the ground (1). (2 x 1) (2)
6.3 • Span of the floor. (1)
• Centre –centre spacing between the floor joist. (1)
• Grade of timber. (1) (3 x 1) (3)
6.4 To allow movement. (1)
6.5
✓
✓
✓
✓
Floor joist built into the wall Floor joist bolted to the wall with truss hangers (4)
6.6 Mortise lock – Mortised into one of the door stiles. (1)
Night latch – Mounted onto the internal surface of the door. (1) (2 x 1) (2)
Copyright reserved Please turn over
12 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
6.7
Raised panel
✓
✓
✓ Lock rail
Clearance / opening for ✓
shrinkage and expansion
✓
Correctness
of drawing
Stile
ASSESSMENT CRITERIA MARK
Raised panels 2
Lock rail 1
Clearance/opening for shrinkage
and expansion 2
Correctness of drawing 1
TOTAL: 6 (6)
6.8 6.8.1 Framed ledged and braced batten door. ✓ (1)
6.8.2 Prevent rain from penetrating the grooves of the bottom rail. ✓ (1)
6.8.3 Stub mortise and tenon joint. ✓ (1)
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 13
6.9
✓ 110 mm Wall
✓ ✓ Treads on both sides of
✓
✓ the landing
OF OF
✓ ✓
√ Landing
Posts
ASSESSMENT CRITERIA MARK
110 mm Wall 1
Three treads on both sides of the landing 2
Landing 1
Handrail 1
TWO newel posts 2
Arrow – indicating the rise of the staircase 1
TOTAL: 8 (8)
6.10 Any ONE:
• Landing allows the user to pause when ascending and descending stairs
/ serves as resting place ✓
• Ideal when staircases change the direction (1 x 1) (1)
6.11 Not less than 2 100 mm. (1)
[40]
TOTAL: 200
Copyright reserved Please turn over
14 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
CIVIL TECHNOLOGY
ANSWER SHEET A GENERIC
NAME:
2.2 FIGURE 2.2 on ANSWER SHEET A shows the incomplete elevation of a
building.
Complete the elevation by drawing in the following parts on scale 1 : 50.
2.2.1 A window with a length of 1 800 mm and a height of 900 mm.
The window is built in 700 mm from the right-hand side and one third of
the right side of the window can open. (7)
2.2.2 A door according to standard measurements, 900 mm from the left side
of the building. The door opens to the left. There is one step to the
ground level. (5)
2.2.3 The barge board against the gable end. (2)
Window 7
Door 5
Barge board 2
TOTAL: 14
FIGURE 2.2
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 15
ANSWER CIVIL TECHNOLOGY
SHEET B SPECIFIC
NAME:
Use ANSWER SHEET B and draw in good proportion a neat sketch of a vertical
section through the wall panelling that ends half way between the floor and ceiling.
Show any TWO labels.
3.4
ASSESSMENT MARK
CRITERIA
✓ Capping 1
Rough ground 1
Tongue and groove board 1
✓ ✓ Any TWO labels 2
TOTAL: 5
Copyright reserved Please turn over
16 CIVIL TECHNOLOGY: WOODWORKING (EC/SEPTEMBER 2023)
CIVIL TECHNOLOGY
ANSWER SHEET C SPECIFIC
NAME:
Dimension paper
3.5 3.5.1 A B C D
Length of the fascia board:
√ √ √
= 9 000 mm + 300 mm + 9 000 mm + 300 mm
= 18.6 m √
OR
√ √ √ √
(9 000 mm + 300 mm) x 2 = 18.6 m
OR
√ √ √
(150 mm + 9 000 mm + 150 mm) x 2
= 18 600 mm
= 18,6 m √ (4)
3.5.2 Length of ONE corrugated roof sheet:
= Length of rafter + overhang for gutter
= 2 900 mm + 50 mm √
= 2 950 mm √ (2)
3.5.3
Number of ridge capping:
= Width of roof
Length of one ridge capping
= 9300 mm √
2350 mm
= 3.9 √
= 4 ridge capping of 2 350 mm is
required √ (3)
Copyright reserved Please turn over
(EC/SEPTEMBER 2023) CIVIL TECHNOLOGY: WOODWORKING 17
CIVIL TECHNOLOGY
ANSWER SHEET D SPECIFIC
NAME:
5.9
✓
✓
✓ ✓
Slope of roof 45°
✓ ✓
✓
Span / 3 000 mm
LEARNER’S
ASSESSMENT CRITERIA MARK
MARK
Span 1
Wall plates 2
Rafters 2
Ridge beam 1
Slope of the roof 45° 1
TOTAL: 7 (7)
Copyright reserved Please turn over
Study this subject
Recommended for this subject

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2023 QP (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2022 Memo (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2022 Memo (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2021 Memo (Eng)

Memorandum
Civil Technology Grade 12 Eastern Cape Mock 2017 Memo (Eng)

Question paper
Civil Technology Grade 12 Eastern Cape Mock 2022 QP (Eng)
More from Grade 12 Civil Technology
%20Afr--05a95faf-5891-4d88-9e5e-7d13c1d21648/v1-f5ca67113376f7457b83/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2025 QP (Afr)

Question paper
Civil Technology Grade 12 Eastern Cape Prelim 2024 QP (Eng)
%20Afr--eefaae29-fe93-4b75-8223-87bf4f3fc14c/v1-3553acfa446acbaa2a45/card.webp)
Question paper
Civil Technology Grade 12 November 2024 NSC QP (Afr)
%20Afr--307147a5-3280-4a11-a82e-cf3e33388eb0/v1-e53e38093df191bfe243/card.webp)
Question paper
Civil Technology Grade 12 November 2024 NSC QP (Afr)
%20Eng_hlayiso.com_--e6743728-8140-42ae-838d-282654a975a5/v1-dce3e047e0d7ad60a32b/card.webp)
Question paper
Civil Technology Grade 12 NSC November 2023 QP (Eng)
%20Afr_hlayiso.com_--b820ac91-947c-4aed-821f-256aa13aabe1/v1-3be01795eace6f81b174/card.webp)
Question paper
